- Page 1 ® CLICK & FLY for LINE 212 / SW 215E User’s Manual Important Information, Please Read Before Use! KLING FREITAG GmbH & Junkersstrasse 14 D-30179 Hannover PHONE 0 (049) 511- 969 97-0 FAX 0 (049) 511- 67 37 94 www.kling-freitag.de...
- Page 2 User’s Manual Click & Fly® for LINE 212 / SW 215E KLING & FREITAG GMBH ©2002 Page 2 of 26...
- Page 3 Important Information about this User's Manual User’s Manual Click & Fly ® for Line 212 / SW 215E Version 3.0, 30.09.2004 © by André Figula, Kling & Freitag GmbH, June 2004 - 2004; all rights reserved Click & Fly ® is a registered trademark of KLING & FREITAG GmbH All specifications in this manual are based on information available at the time of pub- lishing for the features and safety guidelines of the described products.
-
Page 4: Table Of Contents
4.3 Connecting SW 215E Systems and Line 212 Systems Instructions for Use with Line 212 Systems 5.1 Mounting the Click & Fly on the Line 212 5.2 Connecting several Line 212 Systems, vertical Array 5.3 Connecting several Line 212 Systems, horizontal Array Instructions for Use with SW 215E Systems 6.1 Mounting the Click &... -
Page 5: Safety Instructions
The Click & Fly System is only for professional use and is only to be used to mount Kling & Freitag speakers SW 215E, SW 215E – SP, Line 212 and Line 212 – SP. Fur- thermore, it may only be used as specified for uses at trade fairs, in theatres, studios, Warning and events, etc. -
Page 6: Click & Fly With Classification 'Click & Fly Rigging System
1.1 Click & Fly with Classification ‘CLICK & FLY RIGGING SYSTEM’ Older Click & Fly systems with the classification of ‘CLICK & FLY RIGGING SYSTEM’ may only be used with Line 212 systems without the supplementary measures de- scribed below. -
Page 7: Shipped Components And Part Definitions
User’s Manual Click & Fly® for LINE 212 / SW 215E 2. Shipped Components and Part Definitions The Click & Fly system consists of the main bar with a stabiliser bar and the welded-on Click Studs. Additionally, two double stud fittings and one 1/2" shackle are included. -
Page 8: General Instructions For Using The Click & Fly System
Line 212 or SW 215E system. To do this both flying points (Line 212) or flying tracks (SW 215E) at the bottom of the speaker must be used. In addition, it must be ensured that the speakers mounted below are also secured at two flying points. -
Page 9: Selection Of The Right System Connector
If you want to array several Line 212-6 systems (horn not rotated), we recommend using the 38.5° System Connector. Click & Fly System Connector 45°: If you want to array a Line 212-6 (horn not rotated) and a Line 212-9 (horn not rotated) we recommend using the 45° System Connector. Click & Fly System Click &... -
Page 10: Coverage Pattern Of The Line 212 Systems
User’s Manual Click & Fly® for LINE 212 / SW 215E 4.1.1 Coverage Pattern of the Line 212 Systems The following graphics demonstrate how to recognize how the built-in horn emits in a standing speaker: To determine the coverage pattern of the high frequency horn, shine a flashlight through the front covering at the level of the horn. -
Page 11: Connecting Several Sw 215E System
Click & Fly - SW 215E System Connector. 4.3 Connecting SW 215E Systems and Line 212 Systems If you want to array SW 215E Systems with Line 212 Sys- tems, then connect the speakers by using the Click & Fly - SW 215E System Connector. -
Page 12: Instructions For Use With Line 212 Systems
User’s Manual Click & Fly® for LINE 212 / SW 215E 5. Instructions for Use with Line 212 Systems 5.1 Mounting the Click & Fly on the Line 212 Adjust the locking slee- ves (A) of the Click Studs by turning the sleeves so... -
Page 13: Connecting Several Line 212 Systems, Vertical Array
User’s Manual Click & Fly® for LINE 212 / SW 215E 5.2 Connecting several Line 212 Systems, vertical Array Slide the System Connector into the square tube of the main bar until the fixating drill hole of the connector is aligned with the drill holes in the main bar. -
Page 14: Connecting Several Line 212 Systems, Horizontal Array
User’s Manual Click & Fly® for LINE 212 / SW 215E 5.3 Connecting several Line 212 Systems, horizontal Array Horizontal arrays of several speaker systems connected to one another can be set up best in the following manner: If available, leave the transport covers on the speakers. -
Page 15: Instructions For Use With Sw 215E Systems
User’s Manual Click & Fly® for LINE 212 / SW 215E 6. Instructions for Use with SW 215E Systems Pay attention to the safety instructions in chapter 1.1 : Click & Fly with Classifica- tion ‘CLICK & FLY RIGGING SYSTEM. -
Page 16: Connecting Several Sw 215E Systems
User’s Manual Click & Fly® for LINE 212 / SW 215E 6.2 Connecting several SW 215E Systems Slide the SW 215E System Connector into the square tube of the main bar until the fixating drill hole of the connector is aligned with the drill holes in the main bar. -
Page 17: Instructions For Combinations Of Line 212 And Sw 215E
User’s Manual Click & Fly® for LINE 212 / SW 215E 7. Instructions for Combinations of Line 212 and SW 215E Pay attention to the safety instructions in chapter 1.1 : Click & Fly with Classifica- tion ‘CLICK & FLY RIGGING SYSTEM. -
Page 18: Horizontal Arrays
If several subwoofer systems are required, con- nect several SW 215E speakers first, as described in chapter 6.2 . In order to mount the Line 212 System on the SW 215E, attach an additional SW 215E System Con- nector to the Click & Fly Main Bar. -
Page 19: Examples For Correctly Suspended Speaker Systems
User’s Manual Click & Fly® for LINE 212 / SW 215E 8. Examples for correctly suspended Speaker Systems The Click & Fly system must always be mounted with two wire ropes or chains, which are independent of one another! Furthermore, the systems, no matter if indi-... - Page 20 User’s Manual Click & Fly® for LINE 212 / SW 215E Right: − The uppermost drill holes of the main bars are used as suspension points. − Warning The speakers are connected to one another on the rear with double stud fittings and shackles.
- Page 21 User’s Manual Click & Fly® for LINE 212 / SW 215E Right: − In this configuration, 6 Click & Fly systems are used: 2x subwoofers top, 2x subwoofers bottom, and 2x line Warning 212 systems top. The Click & Fly sys- tems are connected to one another in pairs using system connectors.
-
Page 22: Maximum Admissible Configurations
9.1 Line 212 Clusters 9.1.1 Vertical Central cluster, consisting of 12 x Line 212-6 systems for long distances with e.g. 6 mounted K&F CA 1515 systems for shorter distances. A wire rope or chain must be attached to every second Click & Fly system for suspen- sion. -
Page 23: Sw 215E Clusters
User’s Manual Click & Fly® for LINE 212 / SW 215E 9.2 SW 215E Clusters 9.2.1 Vertical 3 x SW 215E may be flown next to one another. One suspension point must be hooked up to each of the outer main bars. -
Page 24: Combinations Of Line 212 And Sw 215E
9.3 Combinations of Line 212 and SW 215E 9.3.1 Vertical A maximum of two SW 215E and two Line 212 systems may be combined in vertical arrays! The speakers must be connected on the rear, and -- - as shown in the illustration -- - secured with safety ropes. -
Page 25: Basic Dimensions, Weights And Load Capacity
User’s Manual Click & Fly® for LINE 212 / SW 215E 10. Basic Dimensions, Weights and Load Capacity CLICK & FLY -- - Main Bar 352.0 mm Weight: 3.3 kg Safe Load: 135 kg Click & Fly - Line 212 System Connector Click &... -
Page 26: Care And Maintenance
User’s Manual Click & Fly® for LINE 212 / SW 215E 11. Care and Maintenance For the owner and user it is of the utmost importance to be aware that a rigging sys- tem is an extremely safety-sensitive accessory. For this reason it is absolutely imperative to carry out careful and well-documented maintenance procedures and checks.
