PILLBOX TIMER WITH
PULSEMETER
MODEL: PMP238
INSTRUCTION MANUAL

INTRODUCTION

Congratulations on your purchase of Oregon Scientific's
easy-to-use Pillbox timer with Pulsemeter (PMP238).
This product combines several unique features to assist
individuals when taking medication. Features include a
medication timer with alarm, a touch-sensitive pulsemeter,
a digital clock and electro-luminescent (EL) back light.
The PMP238's trouble-free qualities are enhanced through
the product's small size, it's lightweight, and pillbox
design.

FEATURES

1. Pillbox storage
2. User select 12 or 24-hour clock
3. Pulse monitor
4. Countdown timer
5. Timer alarm
6. 12 /24 hr. real-time clock
7. EL back light
8. Low-battery indicator
DESCRIPTION AND FUNCTION OF
PARTS [FIG. A]
A. LCD
- Multi-function display
B. [
ADV] Button
- Activates EL back light
- Increases values when setting the clock or timer
C. [PULSE] Button
- Sets the unit in pulse-display mode
- Returns unit to a previous mode from Pulse mode
D. [MODE] Button
- Alternates between clock and timer displays
- Initiates settings changes
E. Pulse Sensor
- Detects and displays a person's pulse rate
F. [ST/ SP] Button
- To start or stop the timer
G. Battery Compartment
- One (1) CR2032 3V lithium cell

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PMP238 and is the answer not in the manual?

Questions and answers

Summary of Contents for Oregon Scientific PMP238

  • Page 1 This product combines several unique features to assist individuals when taking medication. Features include a medication timer with alarm, a touch-sensitive pulsemeter, a digital clock and electro-luminescent (EL) back light. The PMP238’s trouble-free qualities are enhanced through the product’s small size, it’s lightweight, and pillbox design. FEATURES 1.
  • Page 2: Getting Started

    GETTING STARTED Battery is included. Please pull the protective insulation tape out with a firm pull to start your pmp238. BATTERY INSTALLATION 1. Using a coin, carefully twist open the back panel. 2. Insert one (1) CR2032 3V lithium cell or equivalent 3.
  • Page 3 is 12:00:00AM for time and 0:00:00 for the timer. The current time will require manual setting. A low-battery icon [ ] indicates that the batteries require changing. Note: If not disposed properly, batteries can be harmful. Protect the environment by taking exhausted batteries to authorized disposal stations.
  • Page 4 3. Press [ ADV] to make a selection between 12-hour and 24-hour format. 4. Press [MODE] the hour digits will flash. 5. Press [ ADV] to advance the numbers until the appropriate hour digit is displayed. Note: Holding down the button will increase the value rapidly.
  • Page 5 5. Press [ ADV] to advance the minute digits to the desired time. The timer is now set. Note: If no buttons are pressed for 60-seconds during the timer-setting function, the unit will automatically exit the timer-setting mode. To start the timer: Press [ST / SP].
  • Page 6 2. Position your right index finger so that the padded portion over the pulse sensor . Sensor 3. Maintain a steady position, holding too forcefully or too lightly may result in an incorrect reading. 4. After several seconds a pulse rate will display. Note: When your finger is positioned properly, the heart icon on the display will flash.
  • Page 7: Specifications

    Defective product returns should be directed to the place of retail purchase. If this is not posibble all direct returns must include a Return Authorization Number from Oregon Scientific, together with proof of purchase date, your name and address, shipped prepaid to Oregon Scientific Inc., 19861 SW 95th Place, Tualatin, Oregon 97062, USA.
