In Case Of Little Paper Jammed; In The Event Of A Major Jam; Techincal Data - Titanium 512XN Operating Manual

2. if introduced above the maximum capacity of 12 sheets at a time or
if the paper is not inserted correctly into the slot.
A jam could trigger the motor overload protection system resulting
in an inter- ruption of the shredder power supply. Never leave the
shredder turned on in a jamming condition.

In case of little paper jammed

1. Taking care not to put your fingers near the sheet opening,
grasp the excess paper and pull it out by placing the switch on
REV (reverse).
2. Make sure that all excess paper has been removed and turn the
switch back to the AUTO position.
3. In this way it will be possible to proceed again with the
fragmentation of the documents.

In the event of a major jam

1. Turn off the shredder or unplug it. Wait at least 30 minutes to
reset the overheat protection system.
2. Reconnect the plug. Open the top cover and set the switch to
AUTO. If there is paper in the mouthpiece, set the switch to REV
(reverse) and remove the excess paper paying attention to the
fingers. Reposition the switch to AUTO.
3. In this way it will be possible to proceed again with the
fragmentation of the documents.
6. Technical Data
paper shredder type:
Fragment size:
Destruction capacity:
Topping:
Weight:
Dimensions:
Input:
Shredded paper shredder
4.3x33.34mm
12sheets (80gr paper)
220mm
6.7kg
350x255x495mm
230V AC/50Hz
512XN
17
