O P E R ATI NG MAN UAL
SOUP WELL
MODEL NUMBER
DHSS2
Thank you for buying a Victor Unit. We hope and expect that
you will get many years of satisfactory use from your purchase.
In order to achieve the best results from your equipment please
read, and follow, the installation, operating, cleaning and
maintenance instructions below. Failure to follow them may
affect the warranty.
1. UNPACKING AND ASSEMBLY
All protective coating used on stainless steel surfaces of the hot
cupboard must be removed. The exposed surfaces can then be
wiped clean with a damp cloth, using a mild detergent or soap
if necessary.
Do not use any abrasive material or form of bleach for cleaning
purposes. Please see cleaning section of these instructions.
2. INSTALLATION
Where the appliance is to be positioned in close proximity to a
wall, partition, kitchen furniture, decorative finishes, etc., it is
recommended that they be made of a non-combustible
material or clad in a suitable non-combustible heat insulating
material and that the closest attention be paid to fire
preventative regulations.
The appliance is fitted with a 13 Amp fused plug and only
requires connection to a suitable 13 Amp socket outlet. This
model is suitable for 230 - 240V A.C. supply only. Ensure that the
electricity supply is as stated on the model's data plate.
Important:
Wires in the mains lead are coloured in accordance with the
following code:
Green and Yellow (Earth) • Blue (Neutral)) • Brown (Live)
Warning: This appliance must be earthed, do not touch internal
wiring.
As the colours of the wires in the mains lead on this appliance
may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows:
(a) The wire which is coloured green and yellow must be
connected to the terminal in the plug, which is marked with
letter E or the symbol .
(b) The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or is coloured black.
(c) The wire which is coloured brown must be connected to the
terminal which is marked with the letter L or is coloured red.
INSTALLING UNIT INTO COUNTERTOP
(a) Cut 300mm Dia opening in countertop.
(b) Place the unit in the countertop opening.
(c) Assemble L-brackets to the underside of the unit.
(d) Tighten the L-bracket screws until top flange lies flat on
countertop.
Please note:
Use of excessive force when tightening mounting screws may
damage unit.
