4 Con guration Options
The ULP Wired Mini can be set up by using a special configuration app made by Calypso
Instruments.
In order to use the app, you should download theconfigurator from our website at www.-
calypsoinstruments.com.
To configure your device, connect the ULP Wired Mini via a USB to UART converter cable.
Connect all the ULP cables except for the brown cable to the converter. Insert the USB into
the computer, open the configurator app, select the configuration wanted and follow the
instructions on the screen to finish the configuration. You will be prompted by the app to
connect the brown wire at a specific moment of the configuration.
For more information, please watch the following video.
https://bit.ly/3DuA7lM
*USB converter cables available on calypsoinstruments.com
2400 to 115200 (8n1) bauds
Baudrate:
Output rate:
0.1 to 10 Hertz
Output units:
m/sec., knots or km/h
ULP Wired Mini
User manual
6
03/08
