- Page 1 CODE 313176 MODEL B8FXGN9 DESCRIPTION FREESTANDING 80LT GAS TILTING BRATT PAN WITH STAINLESS STEEL TANK ON CLOSED CABINET 06-03-2023 09:08...
- Page 2 INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE RECTANGULAR BRATT PANS GAS TYPE “B8FXGN9 – B8MFXGN9” “B8FIGN9 – B8MFIGN9” “B12FXGN9 – B12MFXGN9” “B12FIGN9 – B12MFIGN9”...
-
Page 3: Table Of Contents
TABLE OF CONTENTS GENERAL REMINDERS AND NOTES ....................4 Introduction ............................4 Simbols and pictograms........................4 General reminders ..........................4 Construction ............................5 Laws, technical prescriptions and directives ..................6 Special requirements for the installation site ..................6 Technical data ............................. 7 Table-Categories;... - Page 4 LAYOUT CONNECTIONS B12 ......................24 FIG. GAS VALVE ..........................25 FIG. MAIN BURNER – PRIMARY AIR REGULATION ..............26 FIG. PILOT BURNER ........................27 FIG. GAS VALVE ..........................28 WIRING DIAGRAM ..........................29 FIG. CONTROLS ..........................30 FIG. CONTROLS ..........................31 6.10 FIG.
-
Page 5: General Reminders And Notes
GENERAL REMINDERS AND NOTES INTRODUCTION The heads of business units, where the unit will be installed, have an obligation, in accordance with the regulations, read carefully the contents of this manual and read the operators and maintainers involved for parts that they compete. This manual includes all the information necessary to ensure that our equipment can be used properly and safely. -
Page 6: Construction
− Unplug the appliance in case of failures or improper operation. − Apply exclusively to a service centre for repairs or maintenance. − Any important information about the appliance required for technical service is contained in the technical data plate (see figure “View of appliance”). −... -
Page 7: Laws, Technical Prescriptions And Directives
LAWS, TECHNICAL PRESCRIPTIONS AND DIRECTIVES When installing the appliance it is necessary to follow and comply with the following regulations: − current regulations on the matter; − any hygienic-sanitary regulations concerning cooking environments; − municipal and/or territorial building regulations and fire prevention prescriptions; −... -
Page 8: Technical Data
TECHNICAL DATA B8FXGN9 – B8MFXGN9 B12FXGN9 – B12MFXGN9 B8FIGN9 – B8MFIGN9 B12FIGN9 – B12MFIGN9 TECHNICAL DATA (DIMEMSIONS) Equipment dim.A 1200 Equipment dim.B Equipment dim.H Equipment dim.H2 1630 1630 TECHNICAL DATA (FUNCTIONALITY) Pan dimension A 1098 Pan dimension B Pan dimension H Pan area dm²... - Page 9 TABLE-CATEGORIES; GAS INLET PRESSURES APPLIANCE PN NOMINAL COUNTRY CATEGORY MAIN PRESSURE 20 mbar I2EK 20; 25 mbar II2EK3B/P 20/25, 28-30 mbar 20 mbar LU, PL I3B/P 28-30 mbar CY, MT, NO, NL I3B/P 37 mbar 28-30/37 mbar DK, SE, FI, BG, EE, LV, LT, CZ, SI, TR , II2H3B/P 20, 28-30 mbar HR, RO...
- Page 10 mbar mbar mbar mbar SECOND FAMILY GASES 17÷25 20÷30 17÷25 20÷30 G25.1 20÷30 G25.3 20÷30 G2.350 10÷16 THIRD FAMILY GASES G30/G31 28-30 25÷35 28-30/37 20÷35 / 25÷45 20 / 25 35 / 45 25÷45 42,5÷57,5 42,5 57,5 RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I – INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE Rev-01 BR9G090I.M”...
-
Page 11: Gas Data
GAS DATA B8FXGN9 – B8MFXGN9 B12FXGN9 – B12MFXGN9 B8FIGN9 – B8MFIGN9 B12FIGN9 – B12MFIGN9 Rated heating power Reduced power ON-OFF ON-OFF CONSUMPTION 20 mbar m³/h 2,12 3,17 25 mbar m³/h 2,12 3,17 20 mbar m³/h 2,46 3,69 G25.1 25 mbar m³/h... -
Page 12: Positioning, Installation And Maintenance
POSITIONING, INSTALLATION AND MAINTENANCE POSITIONING − Remove all the packaging and check that the appliance is in perfect conditions. In case of visible damage, do not connect the appliance and notify the sales point immediately. − Remove the PVC protection from the panels. −... -
Page 13: Connection To Waterworks
− Connect the terminal on the lower left-hand side marked with the international symbol a connector with a nominal cross section <10 mm2. All the appliances installed and the earth system of the building shall be connected like this. ATTENTION! Cut the tension before to make the connection and/or maintenance . -
Page 14: Checking The Operation Of The Gas System
2.2.4 CHECKING THE OPERATION OF THE GAS SYSTEM Check that the appliance has been prepared (category and type of gas) equivalent to the family of gas available on site. If not, it is necessary to convert the appliance to whatever is available. See the paragraph “CONVERSION TO OTHER TYPES OF GAS”. -
Page 15: Commissioning And Testing
The value measured by the pressure gauge should be in the range of allowable pressure shown in the tab. "TABLE-CATEGORIES; GAS INLET PRESSURE ". If the value does not match, request the intervention the gas board or the company which has installed the system At the end tighten the screw of the inlet pressure intake. -
Page 16: Periodic Maintenance
2.4.1 PERIODIC MAINTENANCE Periodic inspection will minimize machine downtime and increase operating efficiency. FOR THE OPERATOR / FOR THE TECHNICAL SERVICE GREASING SCREW WITHOUT END − Turn the tank completely − Connect a grease fitting to the connection on the lower front on the right side. −... -
Page 17: Possible Failures And Their Elimination
2.4.2 POSSIBLE FAILURES AND THEIR ELIMINATION Only technically qualified service centres can perform the operations described below! PROBLEM AND POSSIBLE CAUSE The pilot burner does not light up: − The ignition plug is not fixed correctly or it is badly connected. −... -
Page 18: Conversion To Other Types Of Gas
CONVERSION TO OTHER TYPES OF GAS THE TRANSFORMATION TO A DIFFERENT TYPE OF GAS MEANS: the replacement of the main burner nozzles; primary air adjustment; the replacement of the 'nozzle on pilot burners; control inlet pressures REPLACEMENT OF INJECTORS FOR MAIN BURNERS The device must be operated with nozzles provided for its nominal heat input (See.tab. -
Page 19: Use
WARNINGS AND HINTS FOR USER − This manual contains all the instructions required for a proper and safe use of our appliances. − Keep the manual in a safe place for future consultation! − This appliance is for catering use, hence they must be used only by trained kitchen staff. −... -
Page 20: Switch On, Start Of Cooking And Switch Off
4.2.1 SWITCH ON, START OF COOKING AND SWITCH OFF − Here is a list of the procedures for a safe and correct use of the appliance. − Open the gas valve located upstream of the appliance. Pilot burner lighting − Starting from position “⚫” press the gas-valve knob and turn leftwards to position “ “... -
Page 21: Emptying The Cooking Pan
EMPTYING THE COOKING PAN: − The device serves to facilitate the emptying of the tank. In this device is operated by handwheel placed on the right side in the front. By turning the hand wheel clockwise the tank rises, by turning the tank counter- clockwise lowers. -
Page 22: Cleaning And Care
CLEANING AND CARE CLEANING AND CARE OF THE APPLIANCE − Do not use aggressive substances or abrasive detergents when cleaning the stainless steel components. − Avoid using metal pads of the steel parts as they may cause rust. For the same reason, avoid contact with materials containing iron. -
Page 23: How To Proceed, If
The manufacturer shall not be held responsible nor has any warranty commitments for damage caused by non-compliance with prescriptions or by installation not in conformity with instructions. The same applies in case of improper use or different application by the operator. HOW TO PROCEED, IF …... -
Page 24: Figures And Details
FIGURES AND DETAILS LAYOUT CONNECTIONS B8 LEGEND: Gas connection (ISO 7-1) Gas connection (ISO 7-1) Water connection Water connection Electrical connection Equipotential clamp RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I – INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE Rev-01 BR9G090I.M”... - Page 25 LAYOUT CONNECTIONS B12 LEGEND: Gas connection (ISO 7-1) Gas connection (ISO 7-1) Water connection Water connection Electrical connection Equipotential clamp RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I – INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE Rev-01 BR9G090I.M” “BR1G120I – BR1G120I.M” “BR1G150I – BR1G150I.M” “BR1G160I – BR1G160I.M”...
- Page 26 FIG. GAS VALVE LEGEND: Control knob Inlet pressure intake Pilot output adjustment screw Excluder pressure regulator Inlet pressure intake IMPORTANT The adjustment screws visible on the cocks and/or valves must not be touched because they been set and sealed in the factory dis.30100014 RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M”...
- Page 27 FIG. MAIN BURNER – PRIMARY AIR REGULATION LEGEND: Burner Air regulation square Injector (tab."GAS DATA") Square lock screws See tab."GAS DATA" RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I – INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE Rev-01 BR9G090I.M”...
- Page 28 FIG. PILOT BURNER LEGEND: Pilot burner Injector (tab."GAS DATA") Thermocouple Bicone Ignition plug Tightness screw Thermo-pile Nut for thermocouple RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I – INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE Rev-01 BR9G090I.M” “BR1G120I – BR1G120I.M” “BR1G150I – BR1G150I.M” “BR1G160I – BR1G160I.M”...
- Page 29 FIG. GAS VALVE LEGEND: Pilot burner Electronically controlled gas valve Thermocouple Ignition plug Thermo-pile BT-S1 Operating thermostat Ignition device Heating microswitch RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I – INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE Rev-01 BR9G090I.M” “BR1G120I – BR1G120I.M” “BR1G150I – BR1G150I.M” “BR1G160I – BR1G160I.M”...
- Page 30 WIRING DIAGRAM LEGEND: Vessel return limit switch QM-G Electronically controlled gas valve Vessel tilting limit switch Tilting Single-phase gearmotor Condenser 16 nF Transformer for ignition Condenser 20 nF TA10 Transformer 120-208-400-440-460-480/230V Ignition candle Up/down selector Fuse 2,5 A-T Main ignition botton Fuse 2/4/6 A-AM Power cable Green warning light...
- Page 31 FIG. CONTROLS LEGEND: Control knob Peephole Ignition device Vat water feed tap Operating thermostat Tilting handwheel RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I – INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE Rev-01 BR9G090I.M” “BR1G120I – BR1G120I.M” “BR1G150I – BR1G150I.M” “BR1G160I – BR1G160I.M”...
- Page 32 FIG. CONTROLS LEGEND: Control knob Vat water feed tap Operating thermostat Up/down selector Peephole Tilting handwheel RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I – INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE Rev-01 BR9G090I.M” “BR1G120I – BR1G120I.M” “BR1G150I – BR1G150I.M” “BR1G160I – BR1G160I.M”...
- Page 33 6.10 FIG. DETAILS OF COMMANDS CONTROL KNOB “A” = Off “B” = Pilot burner C” = MAXIMUN OPERATING THERMOSTAT Position “0” = Off Position “1” = minimum Position “2” = MAXIMUN RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I – INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE Rev-01 BR9G090I.M”...
- Page 34 KNOB FOR WATER WAY FOR WATER INLET STOP WATER INLET MOTOR TILTING PAN Position “0” = Off Position “1” = pan tilting Position “2” = pan return CAUTION: Illuminated selector on indicates the presence of electric voltage !! RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I – INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE Rev-01 BR9G090I.M”...
- Page 35 RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I – INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE Rev-01 BR9G090I.M” “BR1G120I – BR1G120I.M” “BR1G150I – BR1G150I.M” “BR1G160I – BR1G160I.M” “BR1G200I – BR1G200I.M”...
