Maintenance Instructions
FOR EVAPCO INDUCED DRAFT AND FORCED DRAFT CLOSED
CIRCUIT COOLERS AND EVAPORATIVE CONDENSERS
ATC-E/eco-ATC/
eco-ATWE
ATWB/eco-ATW
For EVAPCO Authorized Parts and Service, Contact Your Local EVAPCO
Representative or the Local Mr. GoodTower
EVAPCO, Inc. — World Headquarters & Research/Development Center
P
EVAPCO North America
EVAPCO, Inc.
World Headquarters
P.O. Box 1300
Westminster, MD 21158 USA
Phone: 410-756-2600
Fax: 410-756-6450
E-mail: marketing@evapco.com
EVAPCO East
5151 Allendale Lane
Taneytown, MD 21787 USA
Phone: 410-756-2600
Fax: 410-756-6450
E-mail: marketing@evapco.com
EVAPCO Midwest
1723 York Road
Greenup, IL 62428 USA
Phone: 217-923-3431
Fax: 217-923-3300
E-mail: evapcomw@evapcomw.com
EVAPCO West
1900 West Almond Avenue
Madera, CA 93637 USA
Phone: 559-673-2207
Fax: 559-673-2378
E-mail: contact@evapcowest.com
EVAPCO Iowa
925 Quality Drive
Lake View, IA 51450 USA
Phone: 712-657-3223
Fax: 712-657-3226
EVAPCO Iowa
Sales & Engineering
1234 Brady Boulevard
Owatonna, MN 55060 USA
Phone: 507-446-8005
Fax: 507-446-8239
E-mail: evapcomn@evapcomn.com
EVAPCO... S
PECIALISTS IN
P
RODUCTS AND
Operation and
PMC-E/PMWQ
EVAPCO, Inc. • P.O. Box 1300 • Westminster, MD 21158 USA
: 410-756-2600 • F
: 410-756-6450 • E-
HONE
AX
Refrigeration Valves &
Systems Corporation
A wholly owned subsidiary of EVAPCO, Inc.
1520 Crosswind Dr.
Bryan, TX 77808 USA
Phone: 979-778-0095
Fax: 979-778-0030
E-mail: rvs@rvscorp.com
McCormack Coil Company, Inc.
A wholly owned subsidiary of EVAPCO, Inc.
P.O. Box 1727
6333 S.W. Lakeview Boulevard
Lake Oswego, OR 97035 USA
Phone: 503-639-2137
Fax: 503-639-1800
E-mail: mail@mmccoil.com
EvapTech, Inc.
A wholly owned subsidiary of EVAPCO, Inc.
8331 Nieman Road
Lenexa, KS 66214 USA
Phone: 913-322-5165
Fax: 913-322-5166
E-mail: marketing@evaptech.com
Tower Components, Inc.
A wholly owned subsidiary of EVAPCO, Inc.
5960 US HWY 64E
Ramseur, NC 27316
Phone: 336-824-2102
Fax: 336-824-2190
E-mail: mail@towercomponentsinc.com
EVAPCO Newton
701 East Jourdan Street
Newton, IL 62448 USA
Phone: 618-783-3433
Fax: 618-783-3499
E-mail: evapcomw@evapcomw.com
H
T
EAT
RANSFER
S
.
ERVICES
ESWA
LSWE/LSC-E
®
Service Provider
: marketing@evapco.com
MAIL
EVAPCO Europe
EVAPCO Europe, N.V.
European Headquarters
Industrieterrein Oost 4010
3700 Tongeren, Belgium
Phone: (32) 12-395029
Fax: (32) 12-238527
E-mail: evapco.europe@evapco.be
EVAPCO Europe, S.r.l.
Via Ciro Menotti 10
I-20017 Passirana di Rho
Milan, Italy
Phone: (39) 02-939-9041
Fax: (39) 02-935-00840
E-mail: evapcoeurope@evapco.it
EVAPCO Europe, S.r.l.
Via Dosso 2
23020 Piateda Sondrio, Italy
EVAPCO Europe, GmbH
Bovert 22
D-40670 Meerbusch, Germany
Phone: (49) 2159-69560
Fax: (49) 2159-695611
E-mail: info@evapco.de
Flex coil a/s
A wholly owned subsidiary of EVAPCO, Inc.
Knøsgårdvej 115
DK-9440 Aabybro Denmark
Phone: (45) 9824 4999
Fax: (45) 9824 4990
E-mail: info@flexcoil.dk
EVAPCO S.A. (Pty.) Ltd.
A licensed manufacturer of EVAPCO, Inc.
18 Quality Road
Isando 1600
Republic of South Africa
Phone: (27) 11-392-6630
Fax: (27) 11-392-6615
E-mail: evapco@evapco.co.za
Evap Egypt Engineering Industries Co.
A licensed manufacturer of EVAPCO, Inc.
5 El Nasr Road
Nasr City, Cairo, Egypt
Phone: 2 02 24022866 /2 02 24044997
Fax: 2 02 24044667/2 02 24044668
E-mail: Primacool@link.net / Shady@primacool.net
Bulletin 116B
LRWB/LRC
WDW
EVAPCO Asia/Pacific
EVAPCO Asia/Pacific Headquarters
1159 Luoning Rd. Baoshan Industrial Zone
Shanghai, P. R. China, Postal Code: 200949
Phone: (86) 21-6687-7786
Fax: (86) 21-6687-7008
E-mail: marketing@evapcochina.com
Evapco (Shanghai) Refrigeration
Equipment Co., Ltd.
1159 Louning Rd., Baoshan Industrial Zone
Shanghai, P.R. China, Postal Code: 200949
Phone: (86) 21-6687-7786
Fax: (86) 21-6687-7008
E-mail: marketing@evapcochina.com
Beijing EVAPCO Refrigeration
Equipment Co., Ltd.
Yan Qi Industrial Development District
Huai Rou County
Beijing, P.R. China, Postal Code: 101407
Phone: (86) 10 6166-7238
Fax: (86) 10 6166-7395
E-mail: evapcobj@evapcochina.com
Evapco Australia (Pty.) Ltd.
34-42 Melbourne Road
P.O. Box 436
Riverstone, N.S.W. Australia 2765
Phone: (61) 2 9627-3322
Fax: (61) 2 9627-1715
E-mail: sales@evapco.com.au
EvapTech Asia Pacific Sdn. Bhd
A wholly owned subsidiary of EvapTech, Inc.
IOI Business Park, 2/F Unit 20
Persiaran Puchong Jaya Selatan
Bandar Puchong Jaya,
47170 Puchong, Selangor, Malaysia
Phone: (60-3) 8070 7255
Fax: (60-3) 8070 5731
E-mail: marketing-ap@evaptech.com
Visit EVAPCOʼs Website at:
http://www.evapco.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATC-E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EVAPCO ATC-E

  • Page 1 For EVAPCO Authorized Parts and Service, Contact Your Local EVAPCO Representative or the Local Mr. GoodTower ® Service Provider EVAPCO, Inc. — World Headquarters & Research/Development Center EVAPCO, Inc. • P.O. Box 1300 • Westminster, MD 21158 USA : 410-756-2600 • F : 410-756-6450 • E- : marketing@evapco.com HONE...
  • Page 2 O&M Supplement  Variable Frequency Drive Lock‐out Notification    SAFETY PRECAUTIONS:  Qualified personnel should use proper care, procedures and tools when maintaining the Fan/Drive System in order to prevent  personal injury and/or property damage.     Identify and Lock‐out Harmful Resonant Frequencies  A Variable Frequency Drive (VFD) fan system, unlike traditional fixed‐speed systems, is designed to operate between 25% (15Hz)  and 100% (60Hz) speeds, which creates an opportunity for operation where resonant frequencies exist. Sustained operation at  resonant frequencies may lead to excessive vibration, fatigue of structural components, and/or drive system noise and failure.   Owners and operators must anticipate the existence of resonant frequencies and lock out frequencies during start‐up and  commissioning in order to prevent drive system operational problems and structural damage.  As a part of the normal start‐up  and commission processes, resonant frequencies should be identified and locked‐out in the VFD’s software.  The unit’s supporting structure, external piping, and accessories contribute to the overall harmonic make‐up and stiffness of the  system. The choice of VFD will also have a significant influence on how the system behaves. Consequently, not all resonant  frequencies can be determined in advance at the manufacturer’s factory during final inspection and testing.  Relevant resonant  frequencies (if they occur) can only be identified accurately after the installation in the system.  To check for resonant frequencies in the field, a run‐up and run‐down test must be performed. Additionally, VFD carrier  frequencies should be adjusted to best align the VFD with the electrical system. Refer to your drive’s start‐up procedures for  additional information and instruction.   The procedure of checking for resonant frequencies requires stepping through the VFD’s operating range at (2) Hz intervals from  the lowest operating frequency to full speed. At each step, pause long enough for the fan to reach steady‐state. Note changes in  unit vibration during this time.  Repeat from full speed to minimum speed. Should vibration‐inducing frequencies exist, the run‐ up and run‐down test will isolate the resonant frequencies which then must then be locked‐out in the VFD programming.     Page 1 of 1   ...
  • Page 3: Table Of Contents

    Operation and Maintenance Instructions Table of Contents Introduction ................. .4 Safety Precautions .
  • Page 4 ATC-E/ATWB/eco-ATC/eco-ATW 10ʼ & 12ʼ Wide Units ........
  • Page 5: Introduction

    Terminology Throughout this manual, the terms “Induced Draft” and “Forced Draft” are used. Below is a list of EVAPCO Closed Circuit Cooler and Condenser products offerings and associated terminology.
  • Page 6: Initial Storage And/Or Idle Period Recommendations

    • eco-ATW - Closed Circuit Cooler • eco-ATWE - Wet/Dry Closed Circuit Cooler • eco-ATC - Wet/Dry Evaporative Condenser Forced Draft equipment includes the following Evapco Product Models: LR Product Lines • LRWB - Closed Circuit Cooler • LRC - Evaporative Condenser LS Product Lines •...
  • Page 7: International Building Code Provision

    This includes piping, ductwork, conduit, and electrical connections. These items must be flexibly attached to the Evapco unit so as not to transmit additional loads to the equipment as a result of seismic or wind forces.
  • Page 8 Operation and Maintenance Instructions 10. Visually inspect the fan blades. Blade clearance should be approximately 3/8” (1/4” minimum) from tip of blade to the fan cowl. The fan blades should be securely tightened to the fan hub. 11. If any stagnant water remains in the system including “dead legs” in the piping, the unit must be disinfected prior to the fans being energized.
  • Page 9: Maintenance Checklist

    Operation and Maintenance Instructions MAINTENANCE CHECKLIST PROCEDURE Clean pan strainer – monthly or as needed Clean and flush pan* – quarterly or as needed Check bleed-off valve to make sure it is operative – monthly Lubricate pump and pump motor according to manufacturerʼs instructions Check operating level in pan and adjust float valve if necessary –...
  • Page 10 Operation and Maintenance Instructions MAINTENANCE CHECKLIST OPTIONAL ACCESSORIES: Coupling/Shaft – Inspect flex elements and hardware for tightness, proper torque & crack/deterioration – monthly Heater Controller – Inspect controller and clean probe ends – quarterly Heater – Inspect junction box for loose wiring and moisture –...
  • Page 11: Seasonal Shut-Down Checklist

    See fan and pump manufacturer maintenance and long term storage instructions for more detailed instructions. Basic Closed Circuit Cooler/Condenser Sequence of Operation Note: The EVAPCO WDW sequence of operation is unique and is explained in detail in the Sage Panel Control Manual, EVAPCO Bulletin 117.
  • Page 12: Fan System

    Feed grease slowly into the bearings or the seals may be damaged. A hand grease gun is recommended for this process. When introducing new grease, all grease should be purged from the bearings. Most EVAPCO units are supplied with extended grease lines to allow easy lubrication of the fan shaft bearings as shown in Table 1.
  • Page 13: Fan Shaft Sleeve Bearings - (4ʼ Wide Ls Units Only)

    ------------------ Table 2 – Sleeve Bearing Lubricants All bearings used on EVAPCO equipment are factory adjusted and self aligning. Do not disturb bearing alignment by tightening the sleeve bearing caps. Oil drippage may result from over-oiling or from using too light of an oil. Should this condition persist with correct oiling, it is recommended that a heavier weight oil be used.
  • Page 14 Operation and Maintenance Instructions On induced draft belt driven units provided with externally mounted motors (3, 4, 8, 8.5 and 17 foot wide units) and LS and PM Style forced draft units, both J-type adjustment bolts on the adjustable motor base should have an equal amount of exposed thread for proper sheave and belt alignment.
  • Page 15: Gear Drives

    Operation and Maintenance Instructions Gear Drives Induced draft units with gear drive systems require special maintenance. Please refer to the gear manufacturers recommended maintenance instructions. These will be enclosed and shipped with the unit. Air Inlet Inspect the air inlet louvers (induced draft units) or fan screens (forced draft units) monthly to remove any paper, leaves or other debris that may be blocking airflow into the unit.
  • Page 16: Sequence Of Operation For Two Fan Units With Two Speed Motors During Peak Load

    Applications using a VFD for capacity control must also use an inverter duty motor built in compliance with NEMA standard MG-1. This is an available option from EVAPCO.
  • Page 17: Recirculated Water System - Routine Maintenance

    Operation and Maintenance Instructions Recirculated Water System – Routine Maintenance Suction Strainer in Cold Water Basin The pan strainer as shown in Figures 8, 9, 10 and 11 should be removed and cleaned monthly or as often as necessary. The suction strainer is the first line of defense in keeping debris out of the system.
  • Page 18: Water Make Up Valve

    The operating level should be checked monthly to make sure the water level is correct. Refer to Table 3 for unit specific levels. Evaporative Condenser Closed Circuit Cooler Operating Model Number Footprint Water Level* ATC-E & eco-ATC Products ATWB, eco-ATW & eco-ATWE Products 50E to 165E 3ʼ and 4ʼ wide units** 6” 187E to 3714E 8.5ʼ wide thru 24ʼ wide 11”...
  • Page 19: Pressurized Water Distribution Systems

    General Information - Start-up & Maintenance -The make up valve assembly should be inspected monthly and adjusted as required. The valve should be inspected annually for leakage and if necessary, the valve seat should be replaced. The make up water pressure for the mechanical valve should be maintained between 20 and 50 PSIG.
  • Page 20: Bleed-Off Valve

    Figures 14 and 15. For EvapJet nozzles, make sure that the top edge of the “EVAPCO” logo is parallel to the top of the water distribution pipe. THREADED END CAP Figure 14 –...
