Summary of Contents for Rohde & Schwarz SFQ

  • Page 1 T h e t e s t & me a s u r e me n t e q u i p me n t y o u n e e d a t t h e p r i c e y o u w a n t . A l l t e s t I n s t r u me n t s , I n c .
  • Page 2 Broadcasting Division Operating Manual TV TEST TRANSMITTER 2072.5501... Printed in the Federal Republic of Germany 2072.6489.12-11...
  • Page 4 EC Certificate of Conformity Certificate No.: 970017 This is to certify that: Equipment type Stock No. Designation 2072.5501.02/.10/.20/.30 TV Test Transmitter SFQ-B2 2072.6108.02 Broadband-FM-Modulator SFQ-B3 2072.7379.02 2 FM-Subcarrier SFQ-B4 2072.7479.02 2 ADR-Subcarrier SFQ-B5 2072.7579.02/.03/.04 Noise Generator SFQ-B6 2072.7679.02/.03 Input Interface SFQ-B10 2072.6166.02...
  • Page 6 Safety Instructions This unit has been designed and tested in accordance with the EC Certificate of Conformity and has left the manufacturer’s plant in a condition fully complying with safety standards. To maintain this condition and to ensure safe operation, the user must observe all instructions and warnings given in this operating manual.
  • Page 7 Safety Instructions 10. Ensure that the connections with information Electrostatics via the connectors may dam- technology equipment comply with IEC950 / age the equipment. For the safe handling and EN60950. operation of the equipment, appropriate measures against electrostatics should be im- 11.
  • Page 8 Kundeninformation zur Batterieverordnung (BattV) Dieses Gerät enthält eine schadstoffhaltige Batterie. Diese darf nicht mit dem Hausmüll entsorgt werden. Nach Ende der Lebensdauer darf die Entsorgung nur über eine Rohde&Schwarz-Kundendienststelle oder eine geeignete Sammelstelle erfolgen. Safety Regulations for Batteries (according to BattV) This equipment houses a battery containing harmful substances that must not be disposed of as normal household waste.
  • Page 10 Verwendung von Patenten Dieses Gerät enthält Technologie, die von Marconi Instruments LTD. unter den US Patenten 4609881 und 4870384 sowie unter den entsprechenden Patenten in Deutschland und anderswo zugelassen wurde. Patent Information This product contains technology licensed by Marconi Instruments LTD. under US patents 4609881 and 4870384 and under corresponding patents in Germany and elsewhere.
  • Page 12 DIVIDER OVERVIEW Preparation for Use Manual Control Remote Control Maintenance 2072.6489.12 E-11...
  • Page 14: Table Of Contents

    1.3.8 RS-232 Interface ......................1.3.4 1.3.9 KEYBOARD Connector ....................1.3.4 1.3.10 Synchronization of SFQ Data Rate without Input Interface with External Clock ... 1.3.5 Switching On ....................... 1.4.7 1.4.1 Adjusting Screen Contrast and Brightness..............1.4.7 1.4.2 Non-Volatile Memory ..................... 1.4.7 Instrument Configurations ..................
  • Page 15 Table of contents 2072.6489.12 E-11...
  • Page 16: Preparation For Use

    LED yellow; lights if SFQ is in standby mode STANDBY LED red; lights if fan is not running DISPLAY SFQ has an LCD display with CGA mode for menu display with a resolution of 640 x 200 pixels. 2072.5724.02 1.1.1...
  • Page 17 Preparation for Use Fig. 1-2 Front View MEMORY CARD Memory to PCMCIA standard with 68-pin connector. Instrument settings can be stored on the MEMORY CARD and recalled. F1 to F4 shows the help menus shows in a menu all set values F3/F4 are function keys assigned varying functions.
  • Page 18 RF N female connector, 50 Ω Only SFQ with option SFQ-B2: Output and input (loopthrough filter) for the video signal (only available if option SFQ-B2 is fitted) With internal 75 Ω termination the green LED lights. Input M1 or left channel...
  • Page 19: Rear View

    Preparation for Use 1.1.2 Rear View Fig. 1-4 Rear View AC SUPPLY CONNECTION Power switch AC supply connector X1 100/120 V : IEC127-T3.15L / 250 V 220/230 V : IEC127-T1.6L / 250 V Setting to the correct AC supply voltage is made automatically. FAN 1 Sucks in cooling air Note:...
  • Page 20: Standard Pin Assignments

    Preparation for Use 1.1.2.1 Standard Pin Assignments Fig. 1-5 Standard Pin Assignments X 40 I EXT, input for external I signals Q EXT, input for external Q signals MONITOR EXT X 18 Monitor connector, female RS 232 X 17 RS-232 connector, female IEC625/IEEE488 X 12 IEC/IEEE-bus connector, see chapter 3 10 MHz REF, input / output...
  • Page 21: Additional Pin Assignments With Sfq-Z5

    Preparation for Use 1.1.2.2 Additional Pin Assignments with SFQ-Z5 Fig. 1-6 SFQ-Z5 SFQ-Z5 Diversity Cable Set 2081.9158.02 X 30 I-OUT, Output Q-OUT, Outut 2072.5724.02 1.1.6 E-11...
  • Page 22 X 40 With the INPUT INTERFACE option SFQ-B6 fitted, this connector is used as a transport stream input for ASI. If option SFQ-B6 model 03 is fitted, this connector may also be used as an SMPTE310 input. If the INPUT INTERFACE option SFQ-B6 is fitted, this connector is used as an input for the ASI EXT.
  • Page 23: Additional Pin Assignments With Option Sfq-B10

    X 5 to X8 Note: Labelling for X6 to X8 depends on the option, the labelling for option SFQ-B17 is shown here. BER ENABLE / IFFT SYNC OUT, input/output (option B17) BER CLOCK, input (option SFQ-B17) BER DATA , input (option SFQ-B17) 2072.5724.02...
  • Page 24: Additional Pin Assignments With Sfq-B14 Iq Output/Input 2072.6266.02

    Preparation for Use 1.1.2.5 Additional Pin Assignments with SFQ-B14 IQ OUTPUT/INPUT 2072.6266.02 Fig. 1-9 SFQ-B14 X 30 With option SFQ-B14 installed I-OUT Q-OUT Q-IN I-IN 2072.5724.02 1.1.9 E-11...
  • Page 25 Preparation for Use 1.1.2.6 Additional Pin Assignments with SFQ-B27 Impulsive Noise 2110.0407.02 Fig. 1-10 SFQ-B27 X 30 With option SFQ-B27 installed Noise Gate 2072.5724.02 1.1.10 E-11...
  • Page 26: Additional Pin Assignments With Sfq-B2, -B3 And -B4

    X 5 to X8 SYNC EXT, input BASEBAND, output AF 5/6 AF connectors Note: AF connectors 3, 4, 5 and 6 are fitted but not connected when option SFQ-B2 is installed. They are only required for options SFQ-B3 and SFQ-B4. 2072.5724.02 1.1.11 E-11...
  • Page 27 Preparation for Use 2072.5724.02 1.1.12 E-11...
  • Page 28: Putting Into Operation

    Putting into Operation Putting into Operation see also section 1.1, Legend for Front and Rear View Prior to putting the instrument into operation make sure that • the setting for the available AC supply voltage is correct (see section 1.3.1), •...
  • Page 29: Connecting The Instrument

    If option SFQ-B6 INPUT INTERFACE is installed, the connector X40.3 serves as a transport stream input for ASI. If model 03 of option SFQ-B6 INPUT INTERFACE is fitted, connector X40.3 may also be used as an SMPTE310 input for certain modulation modes.
  • Page 30: External I/O Signal Feed For Vector Modulation

    I EXT, input for external signals Q EXT, input for external signals If the option SFQ-B6 INPUT INTERFACE is installed, this connector serves as a transport stream input for ASI. If the option SFQ-B6 INPUT INTERFACE is installed, this connector serves as an external clock input for ASI EXT.
  • Page 31: Feed-In Of Analog Video/Sound Signals For Fm Modulation

    The input impedance is >5 kΩ. 1.3.5.3 AF Connectors, Rear Panel (for Additional Sound Subcarriers) AF connectors (only with option SFQ-B3 fitted), or CLK and DATA connectors (only with option SFQ-B4 fitted) labelled ADR CLK / ADR DATA. 1.3.6 RF Connector The RF output provides signals between 0.3 MHz and 3.3 GHz.
  • Page 32: Synchronization Of Sfq Data Rate Without Input Interface With External Clock

    Preconditions The firmware version of SFQ should be 1.04 or higher. Preparation for Use An adapter cable is to be connected to the TS PARALLEL input on the rear of SFQ according to the following figure: View of solder contacts Fig.
  • Page 33 Coder menu and acceptance of the clock rate with F3 ACCEPT, NULL TS PACKETS can be selected as a modulation source. SFQ then generates and modulates TS packets in QAM or QPSK with a valid sync word 47 hex using the data rate determined by the sinewave generator.
  • Page 34: Switching On

    Putting into Operation Switching On The instrument is switched on by pressing the power switch at the rear and the POWER key at the front panel. For a temporary switch-off, the STANDBY mode is selected by pressing the POWER key. The red FAN LED lights if the fan is not active or defective.
  • Page 35 Putting into Operation 2072.5724.02 1.4.8 E-11...
  • Page 36: Instrument Configurations

    Instrument Configurations 1.5.1 Model .02 Slot: Module: Order No. of PCB: AC SUPPLY ........1039.1510.00 MOTHERBOARD ....... 2072.7004.04 CODER options (a coder is always fitted) SFQ-B10 DVB-T CODER 2072.6166.02 SFQ-B12 ATSC/8VSB CODER 2072.6220.02 SFQ-B13 ITU/J83B CODER 2072.6243.02 SFQ-B15 DVB-C/S CODER 2072.5976.02...
  • Page 37: Sfq Equipped With Sfq-B2, Sfq-B3, Sfq-B4 And Sfq-B6

    Putting into Operation 1.5.1.1 SFQ equipped with SFQ-B2, SFQ-B3, SFQ-B4 and SFQ-B6 Slot: Module: Order No. Of PCB: AC SUPPLY ........... 1039.1510.00 MOTHERBOARD ........2072.7004.04 CODER option SFQ-B3 FM sound subbcarriers ..... 2072.7379.02 or SFQ-B4 ADR sound subbcarriers ... 2072.7479.02 SFQ-B3 FM sound subcarriers ....
  • Page 38: Sfq Equipped With Sfq-B5, Sfq-B6, Sfq-B11 Model .02, Sfq-B11 Model .04 And Coder Option

    Putting into Operation 1.5.1.2 SFQ equipped with SFQ-B5, SFQ-B6, SFQ-B11 model .02, SFQ-B11 model .04 and coder option Slot: Module: Order No. of PCB: AC SUPPLY ..........1039.1510.00 MOTHERBOARD ........2072.7004.04 CODER option SFQ-B11 FADING SIM. 7 to 12 ....
  • Page 39 Putting into Operation 1.5.1.3 SFQ equipped with SFQ-B5, SFQ-B6, SFQ-B10, SFQ-B11 model .02, SFQ-B11 model .04, SFQ-B12, SFQ-B13, SFQ-B15, SFQ-B21 and SFQ-B23 Slot: Module: Order No. of PCB: AC SUPPLY ..........1039.1510.00 MOTHERBOARD .......... 2072.7004.04 SFQ-B10 DVB-T CODER ......2072.6166.02 SFQ-B12 ATSC/8VSB CODER .....
  • Page 40: Options

    2072.7479.02 ADR SUBCARRIER 2072.7404.02 SFQ-B4 Retrofitting of hardware see SFQ-B10 Retrofitting of hardware see SFQ-B5 Installation of Options For reasons of safety and quality (ISO9001), only adequately equipped Rohde & Schwarz service centers are allowed to install options that require the instrument to be opened or the calibration seal to be broken (examples: electrostatically safe workplace, necessary service tools, calibration facilities, etc).
  • Page 41 Putting into Operation 2072.5724.02 1.6.2...
  • Page 42 I/Q CODER Menu ...................... 2.2.4.1 2.2.4.1 Satellite ........................2.2.4.1 2.2.4.1.1 DVB-DSNG Coding ....................2.2.4.1 2.2.4.1.2 Description of Menu Items..................2.2.4.3 2.2.4.1.3 Turbo Coding (Option SFQ-B25)................2.2.4.13 2.2.4.1.4 Description of Menu Items..................2.2.4.16 2.2.4.2 DVB-C QAM ......................2.2.4.27 2.2.4.2.1 Coding ........................2.2.4.27 2.2.4.2.2 Description of Menu Items..................
  • Page 43 Table of contents Manual Control 2.2.4.7.5 Channel Coding......................2.2.4.97 2.2.4.7.6 Modulation ........................ 2.2.4.98 2.2.4.7.7 Description of Menu Items..................2.2.4.99 2.2.4.8 Input Interface......................2.2.4.111 2.2.4.8.1 Structure of the MPEG-2 Transport Stream ............2.2.4.111 2.2.4.8.2 Method of Operation of the Input Interface............. 2.2.4.112 2.2.4.8.3 MPEG-2 Transport Stream Inputs................
  • Page 44 Table of contents Manual Control 2.2.12.4.1 Software Update with External MEMORY CARD........... 2.2.12.17 2.2.12.4.2 Software Update Via Serial Interface and Detached PC ........2.2.12.18 2.2.13 SETUP / INFO - Menu ................... 2.2.13.19 2.2.13.1 HARDWARE Submenu ..................2.2.13.19 2.2.13.1.1 Calibration ......................2.2.13.21 2.2.13.2 INFO FIRMWARE Submenu..................
  • Page 45 2 APP C - ATTC RANDOM APPENDIX C ENSEMBLE 2..........B.32 B.2.12 3 APP C - ATTC RANDOM APPENDIX C ENSEMBLE 3..........B.33 Annex C SFQ - Z17 Common Interface TS OUT ..........C.1 Counting of Pins (Front view of SFQ - Z17)..............C.1 Pin Assignment ......................C.2 C.2.1...
  • Page 46: Manual Control

    2.1.1 Front Panel Operation of SFQ is started by selecting an opening menu with the cursor keys on the front panel and pressing ENTER for confirmation. By means of these keys operating menus are called up where the required instrument settings can be made.
  • Page 47: External Keyboard

    Numerals are entered via the numeric keypad or varied by means of the cursor keys. The functions of the SFQ front-panel keys correspond to those of an external keyboard with the following exceptions:...
  • Page 48: Switch-On Procedure

    Manual Control 2.1.3 Switch-On Procedure Upon switch-on a program is triggered for testing and initialization of the instrument. The program tests the hardware configuration and initializes the individual modules. Set parameters of the remote-control interface are displayed in bottom half of the screen. In the case of a fault, an error message is displayed with information on the defective unit.
  • Page 49: General Information

    Manual Control 2.1.4 General Information 2.1.4.1 Menu Operation Operating menus are in the form of pull-down menus. Subsequently opened menus do not cover up already opened menus so that the complete path is visible until its termination. Selection within a menu or submenu is made by means of the cursor keys. The selected field is either marked by a dark background or an arrow.
  • Page 50 Manual Control Fig. 2-5 Menu selection Pressing the BACK key causes a return to the previous menu level. Pressing the HOME key causes a return to the initial menu irrespective of how many submenus are open. Further selection menus can be called up directly by pressing the MEM key, SETUP/INFO and STATUS (F2) provided the operator is not in an EDIT window.
  • Page 51: Calibration

    Manual Control 2.1.4.2 Calibration SFQ features several internal calibrations in the SETUP-HARDWARE-CALIBRATING menu (see 2.2.13.1.1). In addition to ALL, VCO SYNTHESIS, RF LEVEL, LEARN TABLE and NOISE ALL, calibration of I/Q modulator is possible in this menu: I/Q Modulator: This calibration is especially important since it serves for optimizing carrier leakage, I/Q imbalance and phase error.
  • Page 52 Manual Control C/N calibration: An internal calibration is provided with optional Noise Generator SFQ-B5 model 03. It can be carried out with the F3 key in the MODULATION-NOISE menu for the selected modulation mode. Note: Calibration becomes necessary if the ambient temperature changes by more than 5°C.
  • Page 53: Software Update

    A software update of a memory card can be started under MEM-SOFTWARE UPDATE (see 2.2.12.3). 2.1.4.4 Enabling Software Options No extra hardware is required for certain options. These options can be enabled with a code, which depends on the serial number of the SFQ, in the menu SETUP-SERVICE-SOFTWARE OPTIONS (see 2.2.13.7.1.) 2072.5724.02 2.1.8...
  • Page 54: Menu Operation

    FREQUENCY → → → → The output frequency of the SFQ can be set in this menu. The output frequency is always set in [MHz]. The frequency can be entered by selecting FREQUENCY with the aid of the cursor keys and then pressing the ENTER key or by entering a number.
  • Page 55 Menu Operation CHANNEL TABLE Fig. 2.2-2 CHANNEL TABLE Here the channel table considered for the channel entry is selected. Either none or one of five available tables can chosen: USER1 to USER5, the name of the table being freely selectable (max. 6 characters). Tables may be prepared by the user in the SETUP menu and assigned a name.
  • Page 56: Rf Frequency (With Vsb Modulation)

    Fig. 2.2-3 RF FREQUENCY (with VSB modulation) In contrast to all other types of modulation of SFQ, there are up to three different ways of entering the output frequency of the spectrum in the ATSC modulation: "PILOT FREQUENCY": The pilot frequency in the output spectrum determines the frequency of the output spectrum.
  • Page 57 Menu Operation PILOT → → → → In this menu the output pilot frequency of the ATSC spectrum can be set. The unit of the set frequency is always [MHz]. In this case, the pilot frequency does not depend on the symbol rate of the modulator since it corresponds to the unmodulated carrier signal.
  • Page 58 (calculated) deviates from the entered nominal frequency. FREQUENCY SHIFT→ → → → : In this menu, the output frequency of SFQ can be assigned a shift. This modifies the frequency at the SFQ output connector. The frequency shift is always set in [MHz].
  • Page 59 Menu Operation Fig. 2.2-5 CHANNEL CHANNEL→ → → → The frequency can be set indirectly by means of a channel table. In this case the channel number is entered directly or the channels are selected one after the other with the aid of the cursor keys. The channels of the selected table are used.
  • Page 60: Rf Level Menu

    Menu Operation 2.2.2 RF LEVEL Menu Fig.: 2.2.2-1 RF LEVEL Menu In the RF LEVEL menu the parameters: RF LEVEL RF LEVEL SHIFT RF FADING POWER RF LEVEL MODE RF ALC MODE can be selected and set. RF FADING POWER only is displayed, if SETUP/INFO-PRESET-FADING-POWER is set to MAIN and Fading is switched on.
  • Page 61: Rf Level

    Fig.: 2.2.2-2 RF LEVEL SHIFT The SFQ allows the user to enter the level shift for a subsequent attenuator/amplifier, if any, in the RF LEVEL SHIFT menu. The entered SHIFT value modifies the RF output signal (N connector on SFQ).
  • Page 62 Menu Operation RF LEVEL MODE Fig.: 2.2.2-4 RF LEVEL MODE With RF LEVEL MODE selected, switchover between the NORMAL and CONTINUOUS operating modes is possible by means of the ENTER key. NORMAL In the NORMAL mode the RF level is set by means of an internal attenuator and electronic setting circuits.
  • Page 63 Menu Operation RF ALC MODE (switching internal ALC on/off) Fig.: 2.2.2-5 RF ALC MODE In the RF ALC MODE menu ALC can be switched off for certain applications. With CW and FM, ALC is normally switched on. Thus the best level accuracy to be obtained. For vector and digital modulation ALC has to be switched off.
  • Page 64 The overload protection can be reset by pressing the RF ON /OFF key. The RF output of SFQ is also protected against external DC by a DC BLOCK up to 50 V. Messages that may be displayed in the message window of the RF LEVEL menu:...
  • Page 65 Menu Operation 2072.5724.02 2.2.2.6 E-11...
  • Page 66: Modulation Menu

    Menu Operation 2.2.3 MODULATION Menu Fig.: 2.2.3-1 MODULATION Menu In the SFQ the following types of modulation can be selected: Vector modulation: DVB-S QPSK or Satellite DVB-C QAM DVB-T COFDM ITU-T J.83/B ATSC VSB I/Q EXTERNAL Frequency modulation: FM EXTERNAL Fig.: 2.2.3-2...
  • Page 67 Menu Operation [MOD ON/OFF] key The different types of modulation can be switched directly by means of the [MOD ON/OFF] key or via the modulation menus. Modulation off is indicated by OFF in the status line in the MODULATION selection window and also by an LED. Messages that may be displayed in the message window of the MODULATION menu: Message Meaning...
  • Page 68: I/Q Vector Modulation

    Menu Operation 2.2.3.1 I/Q Vector Modulation In the vector modulation modes the modulation signals for complex RF carrier modulation are applied by the I and Q inputs of the vector modulator. Example: Vector modulation The amplitude and phase of the RF-carrier can be modified in this way. More complex modulations as described in the following chapter are easy to generate in this way.
  • Page 69 Menu Operation Effect of detuning: CARRIER SUPPRESSION AMPL. IMBALANCE PHASE ERROR 2072.5724.02 2.2.3.4 E-11...
  • Page 70: Satellite

    I/Q CODER menu may differ depending on the option selected under CONSTELLATION. I/Q: NORMAL The I/Q data streams are not interchanged, i.e. the SFQ output spectrum is in the normal (non-inverted) position. CHANGED The I/Q data streams are interchanged, i.e. the SFQ output spectrum is inverted.
  • Page 71: Dvb-S Qpsk

    Menu Operation 2.2.3.1.2 DVB-S QPSK Fig.: 2.2.3-4 DVB-S QPSK Menu items: DVB-S QPSK I/Q NORMAL CHANGED Selection of normal or changed I/Q modulation. Change of I and Q signals causes the modulation sidebands to be inverted. I/Q NORMAL Normal I/Q modulation I/Q CHANGED I and Q signals changed I/Q PHASE ERROR →...
  • Page 72: Dvb-C Qam

    Any other settings concerning channel coding can be made in the I/Q CODER menu. I/Q: • NORMAL The I/Q data streams are not interchanged, i.e. the SFQ output spectrum is in the normal (non-inverted) position. • CHANGED The I/Q data streams are interchanged, i.e. the SFQ output spectrum is inverted.
  • Page 73: Dvb-T Cofdm

    Menu Operation 2.2.3.1.4 DVB-T COFDM Fig.: 2.2.3-6 DVB-T COFDM Menu items: DVB-T COFDM CONSTELLATION The type of modulation of the data carrier with COFDM can be selected under this menu item. It is also possible to select whether coding is to be performed non-hierarchically or whether two input data streams are coded hierarchically.
  • Page 74 Menu Operation Fig.: 2.2.3-7 CONSTELLATION Menu items: Non-hierarchical coding with an input data stream: • QPSK • 16 QAM • 64 QAM Hierarchical coding with two input data streams: • 16 QAM with alpha = 1 • 64 QAM with alpha = 1 •...
  • Page 75 Menu Operation Fig.: 2.2.3-8 CONSTELLATION The following can also be set: I/Q NORMAL CHANGED Selection between normal and changed I/Q control. The modulation sidebands are inverted by swapping the I and Q signals. I/Q NORMAL I/Q control is normal (normal position of spectrum). I/Q CHANGED I and Q signals are swapped.
  • Page 76: Itu-T J.83/B

    Menu Operation 2.2.3.1.5 ITU-T J.83/B Fig.: 2.2.3-9 ITU-T J.83/B Menu items: J.83/B QAM Selection between 64 QAM and 256 QAM. I/Q NORMAL CHANGED Selection of normal or changed I/Q modulation. Changing the I and Q signals inverts the modulation sidebands. I/Q NORMAL Normal I/Q modulation.
  • Page 77: Atsc Vsb

    Menu Operation 2.2.3.1.6 ATSC VSB Fig.: 2.2.3-10 ATSC VSB Menu items: ATSC VSB VSB LEVEL 8VSB is supported only. I/Q NORMAL CHANGED Selection of normal and changed I/Q signal. By changing the I and Q signal, the modulation side band will invert. I/Q NORMAL The I and Q signals are normal (normal frequency position).
  • Page 78: Isdb-T

    Menu Operation 2.2.3.1.7 ISDB-T Fig.: 2.2.3-11 Modulation menu The ISDB-T coder can be selected in the modulation menu. In this menu, layer assignment is performed, i.e. the assignment of the type of transmission, the constellation and the number of segments. The following items can also be set in this menu: Switchover between normal and changed I/Q control.
  • Page 79 Menu Operation The following combinations result from this: Fig.: 2.2.3-12 Assignment of the type of transmission Four different constellations are available: DQSPK, QPSK, 16QAM and 64QAM. Not every constellation can be used for each type of transmission. The table below shows the possible combinations: Type of transmission Constellation...
  • Page 80: I/Q External

    The display of the output level and the set C/N ratio is correct if another SFQ providing the DVB-T I and Q baseband signals delivers the input signal for the external I/Q connectors. The correction is 6.5 dB here, i.e.
  • Page 81 Switchover between modulated output signal and sinewave carrier. Notes: The BNC inputs for the I and Q signals are at the rear of SFQ (X40.1 = I, X40.2 = Q). The input impedance is 50 Ω , the nominal voltage for external vector modulation at the I/Q inputs V = 0.5 V.
  • Page 82: Modulation Fm

    For satellite transmission, frequency-modulated TV signals of the TV standards PAL, SECAM and NTSC are generated by SFQ in the FM mode. The modulation signal is a baseband signal which consists of a video signal and one or several sound subcarriers transmitted in the ranch of 5.0 to 9.0 MHz...
  • Page 83: Fm External

    The menu is opened after selection of FM EXTERNAL and pressing the ENTER key. SOURCE The input connector X30.4 for FM EXT is located at the rear of the SFQ. ON /OFF The input for the externally applied frequency can be activated and deactivated.
  • Page 84: I/Q Coder Menu

    Menu Operation 2.2.4 I/Q CODER Menu 2.2.4.1 Satellite 2.2.4.1.1 DVB-DSNG Coding Coding and error protection are in line with the European Standard EN 300 421 DVB (digital video broadcasting), "Framing structure, channel coding and modulation for 11/12 GHz satellite services". Scrambler and sync byte inversion: The incoming MPEG-2 transport stream is scrambled except for the sync word.
  • Page 85 Menu Operation Baseband filtering: In digital transmission, the I and Q baseband signals are pulse-shaped by filtering. As a result, the spectrum is limited and maximum eye aperture is obtained at the sampling points during demodulation. With DVB-S QPSK, square root raised cosine filtering with a roll-off factor α = 0.35 is used. With DVB-S 8PSK and DVB-S 16QAM, roll-off factors of α...
  • Page 86: Description Of Menu Items

    TS PARALLEL does not change the input transport stream. It must, therefore, be ensured that the transport stream applied to SFQ has exactly the displayed (calculated) input data rate. Deviations from this nominal data rate must not exceed ±50 ppm. If a deviation exceeds 50 ppm, the warning "WR CLK"...
  • Page 87 Menu Operation ASI: This is an asynchronous serial interface implemented by the "ASI" BNC connector on the rear panel. It is described in EN 50 083-9. The ASI interface changes the MPEG2 input transport stream. The incoming null packets (PID = 0x1FFF) are removed, and new null packets are inserted to attain the required data rate.
  • Page 88 Menu Operation INPUT DATA RATE Fig. 2.2.4-4 INPUT DATA RATE INPUT DATA RATE: The input data rate is a measured quantity displayed in the "MEASURE" field. The measured input data rate is displayed only if the optional INPUT INTERFACE 2 is fitted. If, under INPUT SELECT, the TS PARALLEL input interface is selected, the nominal data rate (data rate expected at the input) is displayed in the "EDIT/(INFO)"...
  • Page 89 Menu Operation SYMBOL RATE: Symbol rates from 0.1 Msymb/s to 80 Msymb/s can be set independently of the other transmission parameters. The symbol rate remains constant if other parameters – for example the code rate – are changed. Frequency accuracy of symbol rate: Data transmission (MODE = DATA): The frequency accuracy of the symbol rate is determined by the external MPEG2 generator if TS PARALLEL is selected as an input interface (under INPUT SELECT).
  • Page 90 Menu Operation MODE Fig. 2.2.4-5 MODE MODE: Under MODE, one of several operating modes can be selected. DATA: An externally applied MPEG-2 transport stream is processed and transmitted. If no MPEG-2 transport stream is present, the test transmitter detects the absence of data and automatically switches to PRBS BEFORE CONV.
  • Page 91 Menu Operation CODE RATE CODE RATE for MODULATION - CONSTELLATION = DVB-S QPSK Fig. 2.2.4-6 CODE RATE for MODULATION - CONSTELLATION = DVB-S 8PSK Fig. 2.2.4-7 CODE RATE for MODULATION - CONSTELLATION = DVB-S 16QAM Fig. 2.2.4-8 CODE RATE for MODULATION - CONSTELLATION = DVB-S 16QAM CODE RATE: For DVB-S QPSK, the following code rates are selectable: 1/2, 2/3, 3/4, 5/6, 7/8...
  • Page 92 Menu Operation ROLL OFF Fig. 2.2.4-9 ROLL OFF ROLL OFF: The following roll-off factors can be selected for square root raised cosine filtering: 0.25, 0.30, 0.35, 0.40, 0.45 For DVB-S QPSK, the standard provides for a roll-off factor α = 0.35. For DVB-S 8PSK and DVB-S 16QAM, the standard provides for a roll-off factor α...
  • Page 93 Menu Operation SYNC. BYTE INV: Sync word inversion (0x47 0xB8) in the first of each eight frames of an MPEG-2 transport stream can be switched off. REED SOLOMON: The Reed-Solomon encoder can be switched off. The first 188 bytes of a transport stream are transmitted unchanged, same as with the Reed-Solomon encoder switched on.
  • Page 94 One of three reference frequencies can be selected for internal signals: 10 MHz REF.: The symbol clock is controlled by the 10 MHz reference of SFQ. This is the recommended setting. The 10 MHz reference of SFQ can itself be used as a reference, or locked to an external 10 MHz reference signal.
  • Page 95 Menu Operation Error messages and warnings that may be output in the I/Q CODER field of the menu bar: Message Meaning Cause Remedy Warning A setting deviating Select the I/Q CODER menu: MODIFY from the standard the PRESET CODER softkey (F4) is available. was made.
  • Page 96: Turbo Coding (Option Sfq-B25)

    Turbo codes result in a coding gain that increases transmission capacity to within a few tenths of dB of the channel capacity defined by Shannon. The turbo coder implemented in the R&S SFQ is based on a proprietary method of STMicroelectronics. Turbo coding...
  • Page 97 Menu Operation Convolutional interleaver: Reed-Solomon encoding is followed by a convolutional interleaver with a depth of l = 12 and a basic delay of M = 17. The convolutional interleaver processes the data stream bytewise. The sync word is always transmitted in the "0" path, i.e. without delay. A deinterleaver at the receiving end operates in synchronism with the interleaver at the transmitter end.
  • Page 98 Menu Operation Modulation modes Modulation modes QPSK-Turbo and 8PSK-Turbo are available in the Turbo mode. Fig. 2.2.4-16 • Code rates 2/3, 3/4 are implemented for QPSK-Turbo. • Code rates 1/3, 2/3, 3/4 and 8/9 are implemented for 8PSK-Turbo. • With 8PSK-Turbo modulation, each of the eight constellation points carries 3 bits. •...
  • Page 99: Description Of Menu Items

    TS PARALLEL does not change the applied transport stream. It must, therefore, be ensured that the transport stream applied to SFQ has exactly the displayed (calculated) input data rate. Deviations from this nominal data rate must not exceed +-50 ppm. If a deviation exceeds 50 ppm, the warning WR CLK (wrong clock) is output in the I/Q CODER field of the menu bar.
  • Page 100 Menu Operation ASI: This is an asynchronous serial interface implemented by the ASI BNC connector on the rear panel. It is described in EN 50 083-9. Selection of the API interface changes the MPEG2 input transport stream. The incoming null packets (PID = 0x1FFF) are removed, and new null packets are inserted to attain the required data rate.
  • Page 101 Menu Operation INPUT DATA RATE Fig. 2.2.4-18 INPUT DATA RATE INPUT DATA RATE: The input data rate is a measured quantity displayed in the MEASURE field. The measured input data rate is displayed only if the optional INPUT INTERFACE 2 is installed. If, under INPUT SELECT, the TS PARALLEL input interface is selected, the nominal data rate (data rate expected at the input) is displayed in the EDIT/(INFO) field.
  • Page 102 Menu Operation SYMBOL RATE Symbol rates from 0.1 Msymb/s to 80 Msymb/s can be set independently of the other transmission parameters. The symbol rate remains constant if other parameters – for example, the code rate – are changed. Frequency accuracy of symbol rate: For data transmission (MODE = DATA): - The frequency accuracy of the symbol rate is determined by the external MPEG2 generator if TS PARALLEL is selected as an input interface (under INPUT SELECT).
  • Page 103 Menu Operation MODE Fig. 2.2.4-19 MODE MODE: Under MODE, one of several operating modes can be selected. DATA: An externally applied MPEG2 transport stream is processed and transmitted. If no MPEG2 transport stream is present, the test transmitter detects the absence of data and automatically switches to PRBS BEFORE CONV.
  • Page 104 Menu Operation CODE RATE CODE RATE for MODULATION - CONSTELLATION = DVB-S QPSK Fig. 2.2.4-20 CODE RATE if MODULATION - CONSTELLATION = QPSK-TURBO Fig. 2.2.4-21 CODE RATE if MODULATION - CONSTELLATION = 8PSK-TURBO CODE RATE: The following coder rates can be set for QPSK-Turbo: 2/3, 3/4 The following coder rates can be set for 8PSK-Turbo: 1/3, 2/3, 3/4, 8/9...
  • Page 105 Menu Operation ROLL OFF Fig. 2.2.4-22 ROLL OFF ROLL OFF: The following roll-off factors can be selected for square root raised cosine filtering: 0.25, 0.30, 0.35, 0.40, 0.45 SPECIAL Fig. 2.2.4-23 SPECIAL SPECIAL: PACKET LENGTH: The transport stream fed to the test transmitter normally has a frame length of 188 bytes. The frame length can be changed to 204 bytes.
  • Page 106 Menu Operation SYNC. BYTE INV: Sync word inversion (0x47 0xB8) in the first of each eight frames of an MPEG2 transport stream can be switched off. REED SOLOMON: The Reed-Solomon encoder can be switched off. The first 188 bytes of the transport stream are transmitted unchanged, the same as with the Reed-Solomon encoder switched on.
  • Page 107 One of three reference frequencies can be selected for internal signals: 10 MHz REF.: The symbol clock is controlled by the 10 MHz reference of the R&S SFQ. This is the recommended setting. The 10 MHz reference of the R&S SFQ can itself be used as a reference, or locked to an external 10 MHz reference signal.
  • Page 108 Menu Operation Error messages and warnings that may be output in the I/Q CODER field of the menu bar: Error message Meaning Cause Remedy s and warnings Warning A setting deviating MODIFY Select the I/Q CODER menu: from the standard was the PRESET CODER softkey (F4) is available.
  • Page 109 Menu Operation 2072.5724.02 2.2.4.26 E-11...
  • Page 110: Dvb-C Qam

    Menu Operation 2.2.4.2 DVB-C QAM 2.2.4.2.1 Coding Coding and error protection are in line with the European Standard EN 300 429 DVB (digital video broadcasting), "Framing structure, channel coding and modulation for cable systems". Scrambler and sync byte inversion: The incoming MPEG-2 transport stream is scrambled except for the sync word. The scrambler is initialized every eighth transport frame (one MPEG-2 transport frame corresponds to 188 bytes) at the time the sync word appears.
  • Page 111: Description Of Menu Items

    TS PARALLEL does not change the input transport stream. It must, therefore, be ensured that the transport stream applied to SFQ has exactly the displayed (calculated) input data rate. Deviations from this nominal data rate must not exceed ±50 ppm. If a deviation exceeds 50 ppm, the warning "WR CLK"...
  • Page 112 Menu Operation ASI: This is an asynchronous serial interface implemented by the "ASI" BNC connector on the rear panel. It is described in EN 50 083-9. The ASI interface changes the MPEG-2 input transport stream. The incoming null packets (PID = 0x1FFF) are removed, and new null packets are inserted to attain the required data rate.
  • Page 113 Menu Operation INPUT DATA RATE Fig.: 2.2.4-28 INPUT DATA RATE: The input data rate is a measured quantity displayed in the "MEASURE" field. The measured input data rate is displayed only if the optional INPUT INTERFACE 2 is fitted. If, under INPUT SELECT, the TS PARALLEL input interface is selected, the nominal data rate (data rate expected at the input) is displayed in the "EDIT/(INFO)"...
  • Page 114 Menu Operation USEFUL DATA RATE USEFUL DATA RATE: In the "MEASURE" field, the measured USEFUL DATA RATE is displayed. This is the input data rate after removal of the null packets. The input data stream is changed by the ASI, SPI, ASI EXT. CLOCK and SPI EXT. CLOCK input interfaces, i.e.
  • Page 115 Menu Operation MODE Fig.: 2.2.4-29 MODE: Under MODE, one of several operating modes can be selected. DATA: An externally applied MPEG2 transport stream is processed and transmitted. If no MPEG2 transport stream is present, the test transmitter detects the absence of data and automatically switches to PRBS BEFORE MAPPER to ensure uniform spectral distribution of the signal.
  • Page 116 Menu Operation ROLL OFF Fig.: 2.2.4-30 ROLL OFF: The following roll-off factors can be selected for square root raised cosine filtering: 0.1, 0.13, 0.15, 0.175, 0.2 For DVB-C QAM, the standard provides for a roll-off factor α = 0.15. SPECIAL Fig.: 2.2.4-31 SPECIAL: PACKET LENGTH:...
  • Page 117 Menu Operation SYNC. BYTE INV: Sync word inversion (0x47 0xB8) in the first of each eight frames of an MPEG-2 transport stream can be switched off. REED SOLOMON: The Reed-Solomon encoder can be switched off. The first 188 bytes of a transport stream are transmitted unchanged, same as with the Reed-Solomon encoder switched on.
  • Page 118 Menu Operation PLL (DATA): Fig.: 2.2.4-32 For data transmission, i.e. if MODE = DATA is selected, the symbol rate has to be matched to the input data rate to avoid any overflow or underflow of the input FIFO of the coder. The pull-in range of the VCXO is ±50 ppm.
  • Page 119 One of three reference frequencies can be selected for internal signals: 10 MHz REF.: The symbol clock is controlled by the 10 MHz reference of SFQ. This is the recommended setting. The 10 MHz reference of SFQ can itself be used as a reference, or locked to an external 10 MHz reference signal.
  • Page 120 Menu Operation Error messages and warnings that may be output in the I/Q CODER field of the menu bar: Message Meaning Cause Remedy Warning A setting deviating Select the I/Q CODER menu: MODIFY from the standard the PRESET CODER softkey (F4) is available. was made.
  • Page 121 Menu Operation 2072.5724.02 2.2.4.38 E-11...
  • Page 122: Dvb-S And Dvb-C

    Menu Operation 2.2.4.3 DVB-S and DVB-C Fig.: 2.2.4-35 I/Q CODER Menu Under this menu item, all settings concerning coding and error protection of the MPEG-2 transport stream (MPEG = Moving Pictures Experts Group) can be made. The submenus differ only slightly depending on the selected I/Q modulation mode.
  • Page 123 Then an internal output data stream is generated from the input data stream. The data rate of the internal output data stream is linked to the output symbol rate of SFQ. To effect this conversion of data rate, any null packets contained in the data stream are removed. The data rate thus obtained is the minimum output data rate of the module.
  • Page 124: Menu Description

    If one of the other input interfaces is selected, the clock rate of the data stream is changed. This offers the advantage that the output symbol rate of SFQ can be selected independently of the input data rate; the required corrections are performed by the INPUT INTERFACE.
  • Page 125 Menu Operation SPI: The Synchronous Parallel Interface is provided by the 25-contact TS PARALLEL sub-D connector on the rear panel. The clock rate of the data stream is changed. The output data rate is determined by an internal clock generator which can be set in the SYMBOL RATE menu. ASI: The Asynchronous Serial Interface is provided by the ASI BNC connector on the rear panel.
  • Page 126 With menu item INPUT DATA RATE selected, the measured input data rate is displayed in the window at the right of the set data rate. Whereas the SFQ does not evaluate the DVALID signal in the TS PARALLEL mode, i.e. partial transport streams are not supported, only the data where DVALID = 1 are valid in the SPI mode.
  • Page 127 Menu Operation The desired symbol rate can also be entered directly in Megasymbols per second. SFQ then calculates the required input data rate as a function of the other parameters. If the limits of the permissible input data rate (2 to 60 Mbit/s) are exceeded, the user is warned and the minimum or maximum possible symbol rate indicated.
  • Page 128 It corresponds to the frame length of the applied transport stream. Normally a 188-byte frame is applied and a 204-byte frame is obtained in the coder after the Reed Solomon error protection. When a frame length of 188 byte is set, the SFQ expects a sync word in the first byte of each frame (47 hexadecimal).
  • Page 129 Also if the signals used have been generated internally, as for example NULL TS PACKET, applying an external clock (via the synchronous parallel interface) is still useful, because the SFQ oscillator will lock to it (-> symbol rate accuracy). If the INPUT INTERFACE option is used, this is not necessary.
  • Page 130 Menu Operation ROLL OFF: Under this menu item pulse shaping can be set. The selectable roll-off factors differ depending on the selected modulation mode. A square root cosine roll-off factor is used. The following roll-off factors may be selected for QAM: 0.1 / 0.13 / 0.15 (standard value for DVB-C) / 0.175 / 0.2 Fig.: 2.2.4-41 ROLL OFF...
  • Page 131 If some of the functions are switched off, the warning MODIFY is displayed in the I/Q CODER selection field. Functions that can be switched off in the SFQ (toggle function): SCRAMBLING: Energy dispersal is disabled but the sync inversion remains active.
  • Page 132: Dvb-T Coder

    Menu Operation 2.2.4.4 DVB-T CODER Fig.: 2.2.4-45 DVB-T CODER If DVB-T is selected in the modulation menu, then settings can be made for the DVB-T coder in the I/Q CODER menu. Settings affecting the modulation of the data carrier (constellation) and the decision as to whether coding should be non-hierarchical with one input data stream or hierarchical with two data streams should be made already in the modulation menu.
  • Page 133 Menu Operation Convolutional encoder and puncturing: The convolutional interleaver is followed by the convolutional encoder with constraint length K=7. The generator polynomials are 171 (octal) and 133 (octal). A choice of different puncturing rates are available: 1/2 (not punctured), 2/3, 3/4, 5/6, 7/8. The rate 2/3 means for example that 3 output bits can be generated from 2 input bits in the convolutional encoder with puncturing.
  • Page 134 Menu Operation OFDM frame structure: The output signals are organized in frames. Each frame contains 68 OFDM symbols. Every OFDM symbol is made up of K=1705 carriers in the 2k mode and K=6817 carriers in the 8k mode. Each OFDM symbol is of duration Ts which comprises of a useful part Tu and a guard interval. The latter is sent prior to the useful part and is a cyclic continuation of the useful part.
  • Page 135 Menu Operation 7 MHz channel: Fundamental frequency: 64/8 MHz Parameter 8k mode 2k mode Number of carriers K 6817 1705 Number of data carriers 6048 1512 Duration of useful part of a OFDM 1024 µs 256 µs symbol Tu Frequency spacing between two 0.976563 kHz 3.90625 kHz neighbouring carriers 1/Tu...
  • Page 136: Hierarchical Coding

    Menu Operation 2.2.4.4.2 Hierarchical Coding High Priority M AI N I N PUT PRBS TS PA RA LLEL PRBS 2 ^2 3 -1 N ULL TS PA CKET 2 ^2 3 -1 N ULL PRBS PACKET High Pr iorit y Zweig I N PUT High Pr iorit y X6 0 ( Rear)
  • Page 137 Menu Operation Scrambler and sync byte inversion: The MPEG2 input data streams are buffered in their own FIFOs independent of each other. The operation of the two paths (high and low priority) is also independent as regards coding. The input signals are each scrambled in a scrambler (2^15 - 1) which is initiated with the prescribed value after every 8th transport frame.
  • Page 138 Menu Operation The relationship between used bandwidth and input data rate for hierarchical coding: Constellation = 16 QAM: f_in_HP = (987/1207) * rate_HP * ( 1/(1+ guard interval) ) * (4/2) * (PL_HP/188) * BW_used f_in_LP = (987/1207) * rate_LP * ( 1/(1+ guard interval) ) * (4/2) * (PL_LP/188) * BW_used Constellation = 64 QAM: f_in_HP = (987/1207) * rate_HP * ( 1/(1+ guard interval)) * (6/3) * (PL_HP/188) * BW_used f_in_LP = (987/1207) * rate_LP * ( 1/(1+ guard interval)) * (12/3) * (PL_LP/188) * BW_used...
  • Page 139: Description Of Menu Items For Non-Hierarchical Coding

    Menu Operation 2.2.4.4.3 Description of Menu Items for Non-Hierarchical Coding INPUT SELECT Fig.: 2.2.4-47 INPUT SELECT The TS PARALLEL ( SPI without stuffing) input can always be selected. If the input interface option is built in, ASI, SPI, ASI inputs can also be selected with external clock and SPI with external clock. Clock coupling: For the TS PARALLEL input the internal clock is coupled to the supplied clock.
  • Page 140 (stuffing). This is possible only if the useful data rate is less than the calculated data rate. Whereas the SFQ does not evaluate the DVALID signal in the TS PARALLEL mode, i.e. partial transport streams are not supported, only the data where DVALID = 1 are valid in the SPI mode. (see 2.2.4.5 Input Interface).
  • Page 141 Menu Operation USEFUL DATA RATE If the input interface option is built in, the incoming useful data rate is measured. The useful data rate is the data rate without null packets. The measured incoming useful data rate is displayed in [MBit/s] on the right.
  • Page 142 Menu Operation 47 (Hex) 1F (Hex) FF (Hex) 10 (Hex) – in the remaining 184 bytes of the frames (as payload) a PRBS sequence (2 – 1 or 2 – 1 depending on the setting in the PRESET-PRBS SEQUENCE menu according to ITU-T Recommendations O.151) is continuously transmitted.
  • Page 143 Menu Operation USED BANDWIDTH Fig.: 2.2.4-51 USED BANDWIDTH The setting of the USED BANDWIDTH has an immediate effect on the required channel bandwidth. The DVB-T specification stipulates the values for the following channel bandwidths: 6 MHz channel bandwidth: 5.705357 MHz USED BANDWIDTH 7 MHz channel bandwidth: 6.656250 MHz USED BANDWIDTH 8 MHz channel bandwidth:...
  • Page 144 Menu Operation FFT MODE Fig.: 2.2.4-52 FFT MODE An FFT mode of 2K or 8K can be set. The 2K mode signifies that 1705 carriers are available. 2048 carriers are available all together but 343 are set to zero. The center carrier in the 2K mode has the number 852 if the first carrier transmitted has the number 0, or the number 1024 if all carriers are counted and the first carrier has the number 0.
  • Page 145 Menu Operation SPECIAL Fig.: 2.2.4-54 SPECIAL All settings performed in the Special menu violate the normal operating state and therefore result in the message MODIFY which is displayed in the I/Q CODER window. All special settings can be cancelled by pressing the F4 - PRESET CODER key. PACKET LENGTH The frame length of the MPEG2 transport stream can be modified from 188 to 204 bytes.
  • Page 146 Menu Operation Most TPS bits are indirectly influenced by the menu settings. The submenu described below here comprises the items which allow direct modification of the TPS information. CELL ID(HEX) The eight TPS bits s to s are used to transmit a cell identifier. The 16-bit cell identifier identifies the transmitter cell from which the signal originates.
  • Page 147 Deactivates modulation of data carriers. Note: The internal signal level is reduced by 24 dB. In this case the maximum output level of the SFQ is –17.5 dBm. Carrier suppression also deteriorates by 24 dB. MOD.PILOT CARR. Deactivates modulation of pilots.
  • Page 148 Menu Operation EQUAL CW CARRIERS In the normal state, EQUAL CW CARRIERS is set to "off". The carriers are modulated if the modulation has not been explicitly switched off. The carriers have standard-conformal levels. If no other special functions have been activated, the MODIFY message is not displayed in the I/Q CODER window. The normal state can also be restored by pressing the F4=PRESET CODER key.
  • Page 149 Menu Operation Fig.: 2.2.4-57 EQUAL CW CARRIERS DISABLE CARRIERS Any number of carriers can be switched off. To switch off a carrier enter its carrier number. For 2K, counting is from 0 to 1704 and for 8K from 0 to 6816: 2K FFT mode: Carrier 0 to 2047 with center carrier being 1024.
  • Page 150 Menu Operation Examples: • Carrier 1024, carriers from 1026 to 1030, carriers form 1201 to 1030 and carrier 1444 are to be switched off: 1024.1026-1030.1201-1300.1444 • Carrier 555, carrier 557, carrier 559 and carriers from 1024 to 2000 are to be switched off: 555.557.559.1024-2000 Messages that may be displayed in the message window of the I/Q CODER menu (for non-hierarchical and hierarchical coding):...
  • Page 151: Description Of Individual Menu Items With Hierarchical Coding

    Menu Operation 2.2.4.4.4 Description of Individual Menu Items with Hierarchical Coding General: If separate settings can be made for the Low and High Priority path, e.g. the code rate, two columns will be available: EDIT HIGH PRIO (High Priority path) and EDIT LOW PRIO (Low Priority path). Settings made after the demultiplexer –...
  • Page 152 Menu Operation ASI: Asynchronous serial input. The BNC connector is located on the rear panel and labelled X40.3 (see also sticker at rear). With this input selected the incoming data stream is changed (stuffing and PCR correction). The supplied useful data rate is filled up with null packets to required data rate. The required value is calculated and set automatically.
  • Page 153 Menu Operation INPUT DATA RATE Fig.: 2.2.4-59 INPUT DATA RATE In this line and with TS PARALLEL and TS PARALLEL AUX activated, the required (calculated) input data rates are displayed on the left both in the High and Low Priority path columns. The measured input data rates are displayed on the right in the corresponding column.
  • Page 154 Menu Operation MODE: Fig.: 2.2.4-60 MODE One of the following modes for the High Priority and the Low Priority path can be selected with this menu item: DATA PRBS BEFORE CONVOL.ENC. PRBS AFTER CONVOL.ENC. NULL TS PACKET NULL PRBS PACKET PRBS BEFORE MAP.
  • Page 155 Menu Operation Note: If PRBS BEFORE MAP. is selected, the MODE for the HP and LP section is set to PRBS BEFORE MAP. When the user then selects MODE = DATA for one of the sections, the other one is also set to MODE = DATA. Note: If only an MPEG2 transport stream source is available, it can supply a path (Low or High Priority path) via an input of the MAIN group.
  • Page 156 Menu Operation SPECIAL Fig.: 2.2.4-62 SPECIAL All settings performed in the Special menu violate the normal operating state and therefore result in the message MODIFY which is displayed in the I/Q CODER window. All special settings can be cancelled by pressing the F4 - PRESET CODER key. PACKET LENGTH The frame length of the MPEG2 transport stream can be modified from 188 to 204 bytes.
  • Page 157 Menu Operation SCRAMBLER The energy dispersal (scrambler) can be switched off individually for the High and Low Priority paths. The sync word inversion (47 (Hex) -> B8 (Hex) are retained for the first of every 8 MPEG2 transport stream frames. SYNC BYTE INV The sync word inversion (47 (Hex) ->...
  • Page 158: Itu-T J.83/B

    Menu Operation 2.2.4.5 ITU-T J.83/B Fig.: 2.2.4-63 ITU-T J.83/B After selecting ITU-T J.83/B in the modulation menu, the settings for the ITU-T J.83/B coder can be made in the I/Q CODER menu. Fig.: 2.2.4-64 I/Q CODER menu The settings for J.83/B modulation and those for the I/Q modulator have been made in the modulation menu (see 2.2.3.1.5).
  • Page 159 Menu Operation Synchronization to MPEG-2 transport stream The data input signal is searched for the sync word 0 x 47. If it is found, a check is made to determine whether the packet sync appears again after 188 bytes. If this is the case without any interruptions for a specific number of times, the coder can synchronize to the input data.
  • Page 160 Menu Operation Randomizer The incoming data are scrambled in the randomizer. This means a uniform distribution of spectrum components within the 6 MHz channel. The randomizer XORs the data stream with a 3-bit PRBS sequence (pseudo random binary sequence). The generator polynomial for this sequence is: + X + α...
  • Page 161 Menu Operation Overview of warnings in the I/Q CODER menu field: NO DAT: No data stream is present FRMERR: No valid transport stream or wrong packet length UNLOCK: Error, PLL of oscillators not locked, data rate at coder input deviates by more than 10 % MODIFY: A setting in the coder is non-standard OVFLOW:...
  • Page 162: Description Of Menu Items

    Menu Operation 2.2.4.5.2 Description of Menu Items INPUT SELECT Fig.: 2.2.4-65 INPUT SELECT For coding to J.83/B, TS PARALLEL ASI, SPI, ASI with external clock and SPI with external clock can be selected as data inputs. For the TS-PARALLEL input, the data source has to be set to the required input data rate of the coder. A deviation of up to ±10 % is accepted but displayed on the coder by the message MODIFY.
  • Page 163 Menu Operation ASI: Asynchronous, serial input. The BNC connector is on the rear of the unit and labelled X40.3 (see adhesive label on rear panel). On selecting this input, the incoming data stream is modified (stuffing and PCR correction). The applied useful data rate is filled with null packets up to the required data rate.
  • Page 164 UNLOCKED message and indicates a problem with the internal PLL. Whereas the SFQ does not evaluate the DVALID signal is not evaluated in the TS PARALLEL mode, i.e. partial transport streams are not supported, only the data where DVALID = 1 are valid in the SPI mode (see 2.2.4.5 Input Interface).
  • Page 165 Menu Operation The following symbol rate is therefore obtained for 64 QAM: é QAM_symb ù é ù ∗ ú Symbol rate TS_DATA RATE ê ú ê ë ë é ∗ ù 60RS_block block symb ∗ ê ∗ block blocks ë The symbol rate for 256 QAM is calculated as follows: é...
  • Page 166 Menu Operation MODE Fig.: 2.2.4-67 MODE 64QAM, 256 QAM: With this menu item, six different possibilities can be selected. These are: DATA NULL TS PACKET NULL PRBS PACKET SYNC PRBS PRBS BEFORE TRELLIS PRBS AFTER TRELLIS DATA: If DATA is selected, the data of the external MPEG2 transport stream are used for transmission. This is the normal mode.
  • Page 167 Menu Operation Note: If TS PARALLEL is selected as the input, the externally applied clock is transferred to the coder. If the NULL TS PACKET, NULL PRBS PACKET, SYNC PRBS, PRBS BEFORE TRELLIS or PRBS AFTER TRELLIS mode is selected, the clock input interface is used. ROLL OFF The roll-off factor cannot be set by the user and is internally set in accordance with the selected mode.
  • Page 168 Menu Operation The following interleaver modes can be set: CTRL WORD Interleaver depth I Base delay J Level (4 Bit) (number of tabs) 0001 1 and 2 0011 0101 0111 1001 Reserved 1011 (cannot be set) Reserved 1101 (cannot be set) Reserved 1111 (cannot be set)
  • Page 169 Menu Operation SPECIAL Fig.: 2.2.4-70 SPECIAL All settings in the Special menu violate the normal operating mode and therefore cause the MODIFY message to be displayed in the I/Q CODER window. All special settings can be cancelled by pressing the F4-PRESET CODER key. RANDOMIZER Scrambling for energy dispersal can be switched off.
  • Page 170: Atsc 8Vsb

    Menu Operation 2.2.4.6 ATSC 8VSB Fig.: 2.2.4-71 ATSC 8VSB If ATSC VSB is selected in the modulation menu, the settings for the ATSC 8VSB coder can be set in the I/Q CODER menu. Fig.: 2.2.4-72 I/Q CODER menu The settings for the modulation mode 8VSB and the settings for the I/Q modulator have already been made in the modulation menu (see 2.2.3.1.4).
  • Page 171 Menu Operation Synchronization to the MPEG2 transport stream The data input signal is searched for sync word 0 x 47. If it is found, a check is made to determine whether the packet sync appears again after 188 bytes. If this occurs at a certain repetition rate without any interruptions, the coder can synchronize onto the input data.
  • Page 172 Menu Operation If a setting that differs from the standard coding procedure is made, the MODIFY warning is displayed in the menu bar for the I/Q coder field. By pressing the PRESET CODER (F4) key, any non-standard setting is replaced by the standard setting. The user is warned in the same field if no input data are applied: NO DAT or if the input clock is missing: NO CLK.
  • Page 173: Description Of Menu Items

    Menu Operation 2.2.4.6.2 Description of Menu Items INPUT SELECT Fig.: 2.2.4-73 INPUT SELECT Depending on whether the Input Interface option is fitted, either only TS PARALLEL (no input interface) or the ASI, SPI, ASI inputs with external clock and SPI with external clock can be selected. Clock locking: With TS PARALLEL, the internal clock locks directly onto the supplied clock.
  • Page 174 The applied clock may not deviate by more than ±10% from the standard data rate. The PCR value (PCR Program Clock Reference) is corrected. Note: The SMPTE and SMPTE EXT. CLOCK menu items are only available if model 03 of option SFQ-B6 (2072.7679.03) is installed. 2072.5724.02 2.2.4.91 E-11...
  • Page 175 PLL. Whereas the DVALID signal is not evaluated in the TS PARALLEL mode on SFQ, i.e. partial transport streams are not supported, only the data with DVALID = 1 are valid in the SPI mode. (see 2.2.4.5 Input...
  • Page 176 Menu Operation MODE Fig.: 2.2.4-75 MODE 8VSB This menu item is for selecting the following items: DATA NULL TS PACKET NULL PRBS PACKET SYNC PRBS PRBS BEFORE TRELLIS PRBS AFTER TRELLIS PRBS: A PRBS sequence (2 –1 or 2 –1, depending on the setting in the PRESET PRBS SEQUENCE menu, in line with ITU-T Recommendations O.151, pseudo random binary sequence) which ignores any headers is transmitted.
  • Page 177 Menu Operation PRBS AFTER TRELLIS: A PRBS sequence (2 –1, to ITU-T Recommendation O.151, pseudo random binary sequence) which ignores any headers is transmitted. The PRBS sequence is fed in after the trellis coder with the VSB symbol clock. Note: If TS PARALLEL is selected as the input, the internal clock will be locked to the external clock.
  • Page 178: Isdb-T

    Menu Control 2.2.4.7 ISDB-T 2.2.4.7.1 Overview In the 90s the Japanese Association of Radio Industries and Business (ARIB) developed a transmission standard for digital terrestrial broadcasting. Unlike the transmission standards already in use in the other parts of the world, the television, radio and data services are to be covered by one standard. The Japanese broadcasting standard ISDB-T (Terrestrial Integrated Services Digital Broadcasting) was established, in which these services can be transmitted separately in a large number of combinations.
  • Page 179: Transmission Parameters

    Menu Control 2.2.4.7.3 Transmission Parameters The OFDM spectrum comprises 13 segments that have a bandwidth of approx. 429 kHz. A transmission bandwidth of approx. 5.6 MHz is thus obtained and the signal is suitable for transmission in a 6 MHz channel.
  • Page 180: Channel Coding

    Menu Control 2.2.4.7.5 Channel Coding The block diagram below shows the functional design of channel coding with ISDB-T. Three identical paths are available, corresponding to the three hierarchical layers. Energy Delay Byte-wise Splitter Dispersal Adjustment Interleaving ODFM Energy Delay Byte-wise Modulation Dispersal Adjustment...
  • Page 181: Modulation

    Menu Control 2.2.4.7.6 Modulation The block diagram below shows the functional design of the OFDM modulation block with ISDB-T. Modulation Bit Interleaving Mapper Modulation Guard Channel Synthesis of Time ODFM Interval Bit Interleaving Mapper IFFT Coding Hierarchical Interleaver Frame Insertion Burst Stream Adaptation Modulation...
  • Page 182: Description Of Menu Items

    Menu Control 2.2.4.7.7 Description of Menu Items Fig. 2.2.4-79 I/Q coder menu The I/Q coder menu contains important information on the ISDB-T coder and can be used to change the parameters. The title line specifies the number of segments assigned to the different layers. This assignment is performed in the modulation menu.
  • Page 183 ASI: Asynchronous Serial Interface. This input is available only with the option input interface (SFQ-B6). The data rate of the incoming data stream is converted to a defined data rate in the input interface (32.507936 Mbit/s). The new data stream thus obtained is transferred to the ISDB-T coder in which it is converted to a valid ISDB-T data stream.
  • Page 184 Menu Control MODE Fig. 2.2.4-81 MODE In this menu, the type of the data to be transmitted can be selected for each layer. Distinction is made between the data supplied via the transport stream input and various test data. The table below describes the terms used.
  • Page 185 Menu Control Caution: Switching the input from TS PARALLEL+AUX to ASI or SPI in the INPUT SELECT menu may cause the MODE menu to be automatically switched when two or three layers were set to DATA. In this case, pattern 2 is automatically set.
  • Page 186 Menu Control TIME INTERLEAVING Fig. 2.2.4-83 TIME INTERLEAVING The time interleaving length of each layer can be separately set in this menu. The possible lengths depend on the selected ISDB-T mode as shown in the table below. The parameter I defines the time interleaving length as described in the ISDB-T specification.
  • Page 187 Menu Control ISDB-T MODE Fig. 2.2.4-84 ISDB-T MODE The ISDB-T mode can be selected in this menu. This setting is not specific to individual layers but refers to the entire transmission. Possible values are 2K, 4K and 8K. This mode is primarily used to select the length of the IFFT (Inverse Fast Fourier Transform) which has an effect on the OFDM symbol duration.
  • Page 188 Menu Control BANDWIDTH Fig. 2.2.4-86 BANDWIDTH The bandwidth of the ISDB-T spectrum can be varied in this menu. On the one hand, the nominal bandwidth of the current ISDB-T mode can be directly set. On the other hand, the bandwidth can be varied by ±1 % in the lower editing field.
  • Page 189 Menu Control SPECIAL Fig. 2.2.4-87 SPECIAL This menu contains various special settings. The table below describes the different menu items. Menu item Description SCRAMBLER This menu item refers to the energy dispersal in channel coding. Each of the three hierarchical paths has an energy dispersal block that can be activated or deactivated in common.
  • Page 190 Menu Control PID PRBS TS PACKET Fig. 2.2.4-88 PID PRBS TS PACKET PRBS TS PACKET can be selected as test data in the MODE menu. The PID of these transport stream packets can be selected separately for each of the three hierarchical layers. The entry is hexadecimal. Since the PID of the transport stream packets is 13 bits long, PIDs can be entered in the range 0000hex to 1FFFhex.
  • Page 191 Menu Control If the modulation of a carrier is switched off, the pointer points to a fixed constellation point in the diagram. This pointer position remains constant through the OFDM symbols. A PRBS sequence defines the constellation point of each deactivated carrier. This is to ensure that not all carriers point to the same point.
  • Page 192 Menu Control Error messages and warnings Error messages and warnings can be displayed in the I/Q CODER field of the main menu bar. The following table provides an overview of the possible errors and warnings. Message Meaning Cause Remedy ERROR An error has occurred.
  • Page 193 Menu Control 2072.5724.02 2.2.4.110 E-11...
  • Page 194: Input Interface

    Input Interface 2.2.4.8 Input Interface The INPUT INTERFACE option SFQ-B6 provides up to three transport stream inputs in addition to the TS PARALLEL input integrated in the basic unit, depending on the selected type of modulation. • Asynchronous serial interface (ASI) •...
  • Page 195: Method Of Operation Of The Input Interface

    SFQ as Useful Datarate. To ensure correct operation of SFQ, this data rate should be smaller than the maximum possible data rate of the selected type of modulation. The maximum possible data rate is displayed on the front panel of SFQ in the EDIT (INFO) field in the line Useful Datarate.
  • Page 196 TS PARALLEL input, i.e. the only difference between the SPI and the TS PARALLEL input is that the stuffing function is activated or de-activated. The SPI input of SFQ is on the rear of the unit. The following table shows the pin assignment of the 25- contact trapezoidal connector:...
  • Page 197: Input For External Clock

    Input Interface SMPTE 310M input The synchronous, serial transport stream interface (SMPTE 310M) uses a constant data rate of 19.392658 Mbit/s and can only be selected with ATSC 8VSB. Biphase mark coding is used for transmission. This data coding method offers the advantage that the clock information is included in the data signal and that the electrical DC component is eliminated.
  • Page 198: Partial Transport Streams

    Input Interface 2.2.4.8.5 Partial Transport Streams DVB DOCUMENT A010 specifies three transmission formats for the synchronous, parallel interface in (see Fig.: 2.2.4-92, Fig.: 2.2.4-93 and Fig.: 2.2.4-94). The DVALID signal controls the validity of data in the presence of a continuous clock signal. CLOCK DATA [7...0] Sync...
  • Page 199 DVALID = 0 after a transport packet. Whereas the SFQ does not evaluate the DVALID signal in the TS PARALLEL mode, i.e. partial transport streams are not supported, only the data where DVALID = 1 are valid in the SPI mode. Fig.: 2.2.4-95 and Fig.: 2.2.4-96 show examples of partial transport streams.
  • Page 200: Baseband Menu

    Menu Operation 2.2.5 BASEBAND Menu Fig.: 2.2.5-1 BASEBAND menu The whole modulation signal is processed in the baseband. It consists of: VIDEO (external source), ENERGY DISPERSAL, SUBCARRIER FM, SUBCARRIER ADR and NOISE. The menu item: CW / MODULATION allows a switchover between modulated and unmodulated RF carriers. The complete baseband signal is switched off;...
  • Page 201: Video

    REAR X 30.3 75 Ω Ω Ω Ω After selection of one of the two BNC inputs the video signal can be applied via the rear of SFQ. AUTOM. VIDEOSWITCH Under this menu item the video input connectors are assigned to a standard.
  • Page 202 SYNC. EXT An external sync pulse can be applied via the rear X..Level: -2 to -4 V. External synchronization is necessary for scrambled video signals. The sync separator in SFQ cannot process scrambled video signals. PREEMPHASIS ON / OFF The preemphasis for the video signal can be switched on or off under this menu item.
  • Page 203: Energy Dispersal

    Menu Operation 2.2.5.2 ENERGY DISPERSAL Fig.: 2.2.5-6 ENERGY DISPERSAL ON /OFF The energy dispersal signal can be switched on and off. DEVIATION Input value for the energy dispersal deviation; 0 to 4 MHz . The nominal level with video modulation is 2 MHz .
  • Page 204: Baseband - Subcarrier Fm

    Menu Operation 2.2.5.3 BASEBAND - SUBCARRIER FM List of FM subcarriers Fig.: 2.2.5-7 BASEBAND - SUBCARRIER FM With line SUBCARRIER FM selected in the BASEBAND menu all available FM subcarriers are listed. The individual subcarriers can be switched on/off with the F3 (ON/OFF) key. The F4 (ALL OFF) key allows to switch off all FM subcarriers at the same time.
  • Page 205 Menu Operation Audio input of FM subcarrier The audio input (AUDIO INPUT) of the FM subcarrier can be toggled between internal and external sources. The external audio input is a differential input with an input resistance >5 kΩ. The nominal input level is +9 dBm (600 Ω).
  • Page 206 Menu Operation Selection of preemphasis Fig.: 2.2.5-10 Selection of preemphasis 50 µs, 75 µs or J17 can be selected as audio preemphasis. The preemphases have a different characteristic which is reflected by the following expression. 50 µ µ µ µ s, 75 µ µ µ µ s 2 π...
  • Page 207: Baseband - Subcarrier Adr

    Menu Operation 2.2.5.4 BASEBAND - SUBCARRIER ADR List of ADR subcarriers Fig.: 2.2.5-11 List of ADR subcarriers With line SUBCARRIER ADR selected in the BASEBAND menu all available ADR subcarriers are listed. The individual subcarriers can be switched on/off with the F3 (ON/OFF) key. The F4 (ALL OFF) key allows to switch off all ADR subcarriers at the same time.
  • Page 208 Menu Operation Data source of ADR subcarrier Fig.: 2.2.5-13 Data source of ADR subcarrier Menu item DATA SOURCE of the ADR subcarrier allows to select one of several data sources: INTERNAL With the internal data source selected a MUSICAM data stream is generated by a DSP. EXTERNAL NORM.
  • Page 209 Menu Operation Data mode Fig.: 2.2.5-14 Data mode Under menu item DATA MODE, the I path can be exchanged with the Q path before the modulator (I/Q NORMAL / I/Q CHANGED toggle function). An artificial bit error rate can be switched off and on (BER ON/OFF toggle function).
  • Page 210 Menu Operation Internal MUSICAM generator The following menu items are only effective with the internal data source selected. The MUSICAM data stream is coded according to ISO/IEC 11172-3. MUSICAM mode Fig.: 2.2.5-16 MUSICAM mode SINGLE, DUAL or STEREO mode can be selected under menu item MUSICAM MODE. Audio data Fig.: 2.2.5-17 AUDIO DATA...
  • Page 211 Menu Operation 2072.5724.02 2.2.5.12 E-11...
  • Page 212: Special Menu

    [ms]. A minimum step time of 30 ms can be entered, the maximum is 1000 ms. Note: To achieve the minimum STEP TIME of 30 ms, automatic fading is deactivated upon starting the sweep and the RF ALC off mode is switched to TABLE (see information in display of SFQ). 2072.5724.02 2.2.6.1 E-11...
  • Page 213: Sweep Center/Span

    This menu item facilitates the sweep definition for RF jitter measurements. Upon entry of the sweep limits (START/STOP) the SFQ automatically sets the minimum step width and the minimum STEP TIME (30 ms) of the frequency steps (STEP FREQUENCY) that is required to perform a sawtooth sweep with the stated SWEEP FREQUENCY.
  • Page 214 This menu item facilitates the sweep definition for RF jitter measurements. Upon entry of the sweep limits (CENTER/SPAN) the SFQ automatically sets the minimum step width and the minimum STEP TIME (30 ms) of the frequency steps (STEP FREQUENCY) that is required to perform a sawtooth sweep with the stated SWEEP FREQUENCY.
  • Page 215: Ber Submenu

    Menu Operation 2.2.6.3 BER submenu BER MEASUREMENT Input values for influencing the BER measurement see chapter 2.2.9 BER INPUT BER PRBS SEQUENCE 2072.5724.02 2.2.6.4 E-11...
  • Page 216: Noise

    The set receiver bandwidth is used for calculating the C/N ratio. Since the bandwidth of the noise signal generated by the SFQ is in any case wider than the set receiver bandwidth [10 MHz or 60 (80) MHz], realistic conditions can be simulated.
  • Page 217 Menu Operation C/N SHIFT: SFQ features very good C/N accuracy, especially with the self-calibrating model 03 of the noise generator. This menu item increases the accuracy further. Using a spectrum analyzer and the Carrier off function, it is easy to check the equality of C (carrier) and N (noise) at 0 dB C/N and to correct slight deviations by modifying the C/N shift.
  • Page 218 2. When the noise generator is switched on, the RF ALC OFF MODE is preset to TABLE. 3. In the SFQ the noise signal is added to the useful signal at 300 MHz. Through the subsequent conversion to the output frequency the noise spectrum may be mirrored at 0 Hz depending on the bandwidth.
  • Page 219: Impulsive Noise

    2.2.7.2 Impulsive Noise If the option SFQ-B27 is installed, the menu item NOISE is extended by two additional instructions: IMPULSIVE: If IMPULSIVE is set to ON, the impulsive noise can be switched on and off by X30.3 at the rear side (Level: TTL high impedance, High-Level = Noise on).
  • Page 220: Fading

    If the fading simulator is switched on with only one path at 0 dB, the average power at the RF output of SFQ is the same as with the fading switched off. If further paths are switched on, the output signals of these paths are superimposed.
  • Page 221 Menu Operation The Fading menu item is accessed via the modulation menu. Fig.: 2.2.8-2 FADING FADING: The fading modulator can be switched on or off. Fig.: 2.2.8-3 PARAMETER SET PARAMETER SET: One of five editable sets can be selected. The sets can be selected or edited in SETUP/FADING PARAMETER (see 2.2.8.1).
  • Page 222: Fading Parameter Submenu

    Menu Operation 2.2.8.1 FADING PARAMETER Submenu Fading simulation settings are accessible in the SETUP FADING PARAMETER menu. Note: Please observe the setting of SETUP - PRESET - FADING -REFERENCE (see chapter 2.2.13.5.). The user can create five different fading parameter sets. These can be filled either by predefined standardized settings or by individual values.
  • Page 223 The preset values of the desired fading scenarios can be copied into the selected set of fading parameters. Fig.: 2.2.8-8 RED6 DVB-T Some of the presets for fading parameter sets need 12 paths. These can only be selected if SFQ is equipped with two fading simulator modules. 2072.5724.02 2.2.8.4...
  • Page 224 Menu Operation Fig.: 2.2.8-9 ET50 As soon as one of the parameters of a predefined fading parameter set is varied manually, the prefix USER will be added to the parameter designation. Fig.: 2.2.8-10 USER EASY3 Note: If modified parameter sets are activated within the MODULATION menu, MODIFY will be displayed in the message window of the MODULATION menu.
  • Page 225 Menu Operation The name of the fading parameter set currently edited is displayed at the top left of the fading value table. The name of the fading parameter set selected for transmission in the modulation menu is displayed in the status line of the menu after ”ACTIVE SET:”. The operating state of the fading simulator is also indicated with OFF or ON.
  • Page 226 Menu Operation PATH Display of paths for the following parameters. These parameters can be set separately for each path. STATE Switching on and off a path. If the cursor is placed onto a path in the diagram, it may be switched on and off by pressing one of the unit keys (toggle function).
  • Page 227 Menu Operation FREQENCY Entry of the ratio of the actual Doppler frequency shift to the Doppler frequency setting with Ricean fading or FDOP fading switched on. The actual RATIO Doppler frequency shift depends on the simulated angle of incidence of the discrete component.
  • Page 228 Menu Operation DOPPLER FREQ Entry of the magnitude of the maximum Doppler Frequency shift (cf. FREQ RATIO). On changing the Doppler frequency f the parameter SPEED is automatically adjusted. ⋅ 2 998 10 With it is Note: If SPEED has been selected as the parameter under SETUP - PRESET - FADING –REFERENCE, the selected DOPPLER FREQ will be recalculated when the RF frequency varies, whereas the SPEED remains constant.
  • Page 229: Special Level Conditions In Case Of Fading

    FREQUENCY RATIO. Fig.: 2.2.8-15 Two equal paths with P.DOPPLER profiles exhibiting same FREQUENCY RATIO Note: In the special cases shown above the resulting RF sum power does not agree with the RF LEVEL indicated in the SFQ menu. 2072.5724.02 2.2.8.10 E-11...
  • Page 230: Ber (Bit Error Ratio) Measurement

    -1 to ITU-T Rec. O.151) 2.2.9.1 Inputs 2.2.9.1.1 Serial Input Three BNC connectors for clock, data and enable (TTL level) are provided on the rear of the SFQ. X8: BER data input X7: BER clock input X6: BER enable input The inputs are internally terminated into 75 Ω.
  • Page 231: Operating Menu

    Menu Operation Pin assignment: 25-pin Sub-D connector X61 TS PARALLEL AUX Signal line Signal line Clock A Clock B System Gnd System Gnd Data 7 A(MSB) Data 7 B Data 6 A Data 6 B Data 5 A Data 5 B Data 4 A Data 4 B Data 3 A...
  • Page 232: Ber: Display

    Menu Operation 2.2.9.2.2 BER: Display The currently measured BER is displayed here. After the BER value, two values are indicated in brackets (events*1E6/proposal*1E6). The same values as those in the line below the menu bar are displayed. Fig.: 2.2.9-1 BER INPUT The proposal is calculated based on the assumption that 1000 errors should occur for a sufficient accuracy of the result due to the statistical distribution of bit errors.
  • Page 233: Ber Input: Serial/Parallel

    Menu Operation 2.2.9.2.3 BER INPUT: SERIAL/PARALLEL Selecting the input: Selection can be made between the serial input (BNC connector, TTL level) and the parallel input (Sub- D connector, LVDS level). With the parallel input selected, a conflict may occur if the input is used as AUX transport stream input with DVB-T hierarchical coding (see Parallel Input).
  • Page 234 Menu Operation Parallel input: The data and the clock can be applied to connector X61 TS PARALLEL AUX with the LVDS (low voltage differential signalling) level. If the option is activated on input interface 2, the data is applied via TS PARALLEL (X60).
  • Page 235 Menu Operation Fig.: 2.2.9-5 The user is warned if input X61 (TS PARALLEL AUX) is already used as the AUX input for the hierarchical DVB-T coding but the parallel input is to be used for the BER measurement. In this case, the parallel input is not available for BER measurement.
  • Page 236: Ber Prbs Sequence

    -1 or a PRBS 2 -1 is to be evaluated. Both are implemented according to ITU-T Rec. O.151. If the SFQ is used as the data source, the selection should be the same as the setting in SETUP-PRESET-PRBS SEQ. Fig.: 2.2.9-7 2072.5724.02...
  • Page 237: Applications

    AUX (X61) BER Measurement Input = PARALLEL Mode =NULL PRBS PACKET MPEG2 Transport Stream (LVDS) SFQ setting - coder: Mode = NULL PRBS PACKET Special: Reed Solomon = OFF SFQ setting - preset: PRBS = 2^23 –1 SFQ setting - special:...
  • Page 238 Menu Operation Slight changes of the input error rate in this range result in very strong changes of the output BER. The measurement results are very susceptible to inaccuracies of the interference source, e.g. the noise power in the measurement of the C/N versus BER. Moreover, the measurement time largely increases with small BERs, e.g.
  • Page 239 Menu Operation Pin assignment of COMMON INTERFACE (DVB Document A017): Signal Function Signal Function Ground Ground I/O Data bit 3 CD1# Card detect 1 I/O Data bit 4 MDO3 MP data out 3 I/O Data bit 5 MDO4 MP data out 4 I/O Data bit 6 MDO5 MP data out 5...
  • Page 240: Application 2: Ber Measurement After Demapper For Dvb-T

    BER Measurement (TTL) (TTL) DATA X8 Input = SERIAL Clock Daten SFQ setting - coder: Mode = PRBS BEFORE MAPPER SFQ setting - preset: PRBS = 2^23 -1 SFQ setting - special: BER = ON BER INPUT = SERIAL CLOCK = NORMAL (also INVERTED, if possible)
  • Page 241 Menu Operation 2072.5724.02 2.2.9.12 E-11...
  • Page 242: Help Menu

    Menu Operation 2.2.10 HELP Menu The corresponding help page is displayed by pressing the F1 key. 2.2.11 STATUS Menu Call up status menu by pressing F2 (STATUS). Exit the status menu by pressing F2 again (EXIT). 2.2.11.1 Satellite (-B23) Fig. 2.2.11-1 2072.5724.02 2.2.11.1...
  • Page 243 Menu Operation Lefthand column: Modulation settings: I/Q PHASE ERROR [DEG] selected phase error in degrees CARRIER SUPPRESS. selected carrier leakage in % I/Q AMPL. BALANCE selected amplitude imbalance in % I/Q MODE [NORMAL, CHANGED] I and Q data streams interchanged/ not interchanged CONSTELLATION [DVB-S QPSK,...
  • Page 244: Dvb-C Qam (-B21)

    Menu Operation 2.2.11.2 DVB-C QAM (-B21) Fig.: 2.2.11-2 Lefthand column: Modulation settings: PHASE ERROR [DEG] selected phase error in degrees CARRIER SUPPRESS. selected carrier leakage in % I/Q AMPL. BALANCE selected amplitude imbalance in % I/Q MODE [NORMAL, CHANGED] I and Q data streams interchanged/ not interchanged QAM TYPE [16, 32, 64, 128, 256]...
  • Page 245: Dvb-S Qpsk (-B15)

    Menu Operation 2.2.11.3 DVB-S QPSK (-B15) In the QPSK status menu the following parameters are displayed: Fig.: 2.2.11-3 DVB-S QPSK In the left-hand column the settings of the QPSK modulator: I/Q PHASE ERROR [DEG] Phase error of I/Q signal CARRIER SUPPRESS. Carrier suppression I/Q AMPL.
  • Page 246: Dvb-C Qam (-B15)

    Menu Operation 2.2.11.4 DVB-C QAM (-B15) In the QAM status display the following parameters are displayed: Fig.: 2.2.11-4 DVB-C QAM In the left-hand column the settings of the QPSK modulator: I/Q PHASE ERROR [DEG] Phase error of I/Q signal CARRIER SUPPRESS. Carrier suppression I/Q AMPL.
  • Page 247: Dvb-T Cofdm

    Menu Operation 2.2.11.5 DVB-T COFDM Fig.: 2.2.11-5 DVB-T COFDM with non-hierarchical coding In the left-hand column the settings of the COFDM modulator: I/Q PHASE ERROR [DEG] Phase error of I/Q signal CARRIER SUPPRESS. Carrier suppression I/Q AMPL. BALANCE I/Q amplitude imbalance I/Q MODE [NORMAL/CHANGED] I and Q normal/changed...
  • Page 248 Menu Operation Fig.: 2.2.11-6 DVB-T COFDM with hierarchical coding In the left-hand column the settings of the COFDM modulators: I/Q PHASE ERROR [DEG] Phase error of I/Q signal CARRIER SUPPRESS. Carrier suppression I/Q AMPL. BALANCE I/Q amplitude imbalance I/Q MODE [NORMAL/CHANGED] I and Q normal/changed CONSTELLATION...
  • Page 249: Itu-T J.83/B

    Menu Operation 2.2.11.6 ITU-T J.83/B Fig.: 2.2.11-7 Status menu J.83/B Press key F2 to display the status menu. The J.83/B modulation settings are displayed in the left column. I/Q PHASE ERROR [DEG] Phase error of I/Q signal CARRIER SUPPRESS. Carrier suppression I/Q AMPL.
  • Page 250: Atsc Vsb

    Menu Operation 2.2.11.7 ATSC VSB Fig.: 2.2.11-8 ATSC VSB The ATSC modulation settings are displayed in the left column. I/Q PHASE ERROR [DEG] Phase error of I/Q signal CARRIER SUPPRESS. Carrier suppression I/Q AMPL. BALANCE I/Q amplitude imbalance I/Q MODE I and Q normal/changed VSB LEVEL [8VSB, 16VSB]...
  • Page 251: Isdb-T

    Menu Operation 2.2.11.8 ISDB-T Fig.: 2.2.11-9 State menu of the ISDB-T coder The F2 key is used to change from the Coder menu to the State menu. In this menu, all states of the ISDB-T coder are grouped in a window. Pressing the F2 key again opens the Coder menu. The left column contains the modulator settings.
  • Page 252: Iq External

    Menu Operation 2.2.11.9 IQ EXTERNAL The following parameters are shown in the IQ EXTERNAL status display: Fig.: 2.2.11-10 IQ EXTERNAL In the I/Q EXTERNAL mode, external modulation signals can be applied to the modulation inputs I (X40.1) and Q (X40.2) to subject the RF carrier to complex modulation. The following parameters are shown in the IQ EXTERNAL status display: I/Q PHASE ERROR [DEG]...
  • Page 253: Baseband Subc. Fm

    Menu Operation 2.2.11.11 BASEBAND SUBC. FM The following parameters are shown in the BASEBAND SUBC.FM status display: Fig.: 2.2.11-12 BASEBAND SUBC. FM Press key F2 to call the status menu. The submenu for the FM subcarriers (BASEBAND SUBC. FM) can be chosen in the horizontal menu bar. This status menu provides a clear overview of all information concerning the FM subcarriers.
  • Page 254: Memory Menu

    Menu Operation 2.2.12 MEMORY Menu Use the MEM hardkey to call the MEMORY menu. Fig.: 2.2.12-1 MEMORY Menu The following actions can be selected and performed in the MEMORY menu: STORE INTERN. RECALL INTERN. STORE EXTERN. RECALL EXTERN. SPECIAL FUNCTIONS SOFTWARE UPDATE ADR DATA UPDATE 2.2.12.1...
  • Page 255 Menu Operation Fig.: 2.2.12-3 START RECALL Selecting STORE INTERNAL or STORE EXTERNAL results in the display of an overview of all occupied memory locations, a maximum of 99 locations being available. After selection of a memory location via the FILE NO., a short comment can be entered via COMMENT using either the editor provided in the program and operated with the aid of the cursor keys or a PC keyboard.
  • Page 256: Loading Of Instrument Setups

    Menu Operation The following types of memory cards may also be used: Intel Series1: AMD Series A: TI Series I: iMC001FLKA TMS28F010A 1MBIT AmC001AFLKA iMC002FLKA AmC002AFLKA iMC004FLKA AmC004AFLKA Intel Series2: AMD Series B: SST Flash Chips: iMC004FLSA AmC002BFLKA iMC010FLSA iMC020FLSA Intel AMD Series C: Atmel:...
  • Page 257: Copying Of Device-Specific Calibration Data

    Menu Operation 2.2.12.3.2 Copying of Device-Specific Calibration Data The device-specific calibration data can be copied from the internal to the external memory card and vice versa via the MEM - SPECIAL FUNCTIONS - REPLIC.CALIBRATION menu. This process is for instance necessary when replacing a 4 MB MEMORY CARD by a 10 MB MEMORY CARD. If the REPLIC.CALIBRATION menu is selected with Enter, the calibration data found are displayed in the INTERNAL and EXTERNAL columns and the direction of the copying process in the REPLICATE CALIBRATION column.
  • Page 258: Software Update

    Menu Operation If both the external and the internal MEMORY CARD contain calibration data, a corresponding message is displayed in a window and copying cannot be started in the REPLICATE CALIBRATION column. 2.2.12.4 Software Update 2.2.12.4.1 Software Update with External MEMORY CARD The MEMORY CARD with the program update is inserted into the front-panel slot and the appropriate menu is activated.
  • Page 259 Menu Operation 2.2.12.4.2 Software Update Via Serial Interface and Detached PC The serial PC interface (COM1 or COM2) has to be connected to the RS232 interface of SFQ via a null modem cable. The cable must have the following pin assignment:...
  • Page 260: Setup / Info - Menu

    This menu provides service functions. 2.2.13.1 HARDWARE Submenu The HARDWARE submenu allows the user to check the setup of the system. TV Test Transmitter SFQ comes in a basic version equipped with various options. FUNCTION CIRCUIT FUNCTION CIRCUIT displays the current block diagram.
  • Page 261 Menu Operation EQUIPMENT The EQUIPMENT submenu lists all modules installed, stating their order numbers (Ident No), codes and change indices (CI). If the module produces an error upon initialization, this error will be shown in the ERROR REPORT column. Fig.: 2.2.13-3 EQUIPMENT NUMBERS Upon calling up NUMBERS, the order number and the serial number of the basic unit are displayed.
  • Page 262: Calibration

    I/Q imbalance have to be calibrated. All calibration routines are run internally for all coders. The calibration should be called after an SFQ warmup time of >1 hour or if there are temperature variations of more than 5°C.
  • Page 263: Info Firmware Submenu

    Menu Operation RF ALC LEARN TABLE The correction values for the function ALC OFF MODE -TABLE (level control voltage from the table) are regenerated. NOISE ALL The NOISE calibration for all modulation modes present is performed. If the noise calibration of a modulation fails, FAILED is displayed in the right part of the window.
  • Page 264: Communication Submenu

    Menu Operation 2.2.13.4 COMMUNICATION Submenu Fig.: 2.2.13-7 COMMUNICATION submenu The COMMUNICATION submenu allows the user to set the IEC/IEEE-bus address and to select the settings of the serial as well as of the remote-control interface. Ranges: 100; 300; 600; 1200; 2400; 9600; 19200 BAUDRATE: DATABITS: STOPBITS:...
  • Page 265 The IFFT sync signal can be selected for output at the rear panel or not. As a prerequisite the appropriate coaxial cable must be connected to X6 at the rear panel. The connector is assigned two functions if option SFQ-B17 (BER measurement) is fitted. As soon as the BER measurement is activated, the IFFT sync output is disabled.
  • Page 266: Channel Table Submenu

    Menu Operation 2.2.13.6 CHANNEL TABLE Submenu Fig.: 2.2.13-9 CHANNEL TABLE submenu Five frequency tables with up to 99 entries can be created in the CHANNEL TABLE submenu. A name of up to 5 characters can be assigned to such a table. A user-defined channel table can be selected in the RF FREQUENCY menu.
  • Page 267: Service Submenu

    VALUE. NOISE OFFS. For adaptation of the C/N ratio after installation of option SFQ-B2 or of the optional standard noise generator (SFQ-B5 2072.7579.02). If a self-calibrating noise generator is fitted (SFQ-B5 2072.7579.03), this menu item is replaced by the DIVERSITY OFFSET menu item.
  • Page 268: Enabling Software Options

    If the user has received these files by e-mail, he must detach the two files and copy them into the same directory. After connecting the serial connecting cable between PC and SFQ, LOAD2SFQ.EXE can be executed. The user will be asked for the PC interface used (COM1 or COM2).
  • Page 269: Special Keys

    Menu Operation 2.2.14 Special Keys With the RF key the RF output signal is switched off. With the MOD key all modulation signals of the currently used system are switched off: Digital modulation: The vector-modulated RF carrier is set to CW (continuous wave). Analog modulation: The video and AF frequencies of the FM subcarriers are switched off.
  • Page 270 Menü-Übersicht / Menu Overview Anhang/Annex A Der Menübaum / Menu Tree Die Menü-Bedienung erfolgt über die Cursor- Menu operation is by means of the cursor keys and Tasten und die schrittweise Änderung von by inrementing or decrementing data variables. Datenvariablen. Mit der HOME-Taste gelangt man in das The HOME key is used for calling up the following Einstiegsmenü...
  • Page 271: Rf Frequency

    Menü-Übersicht / Menu Overview A.1 RF FREQUENCY |- FREQUENCY --------------------<wert / value > (except ATSC / VSB) |- PILOT ------------------------------<wert / value > (only ATSC / VSB) |- ACTUAL CENTER --------------<wert / value > (only ATSC / VSB) |- NOMINAL CENTER ------------<wert / value > (only ATSC / VSB) |- FREQUENCY SHIFT -----------<wert / value >...
  • Page 272: Modulation

    Menü-Übersicht / Menu Overview A.3 MODULATION A.3.1 DVB-S QPSK |- DVB-S QPSK---------------------|- I/Q ------------------------ |- NORMAL |- CHANGED |- I/Q PHASE ERROR------------------------------------------ <wert / value> |- CARRIER SUPRESSION ---------------------------------- <wert / value> |- I/Q AMPL. IMBALANCE ------------------------------------ <wert / value> |- NOISE------------------- |- NOISE --------------------------- ON/OFF |- C/N ------------------------------- <wert / value>...
  • Page 273: Satellite

    Menü-Übersicht / Menu Overview A.3.2 SATELLITE |- SATELLITE ----------------------|- CONSTELLATION --- |- DVB-S QPSK |- DVB-S 8PSK |- DVB-S 16 QAM |- QPSK TURBO |- 8PSK TURBO |- I/Q ------------------------ |- NORMAL |- CHANGED |- I/Q PHASE ERROR------------------------------------------ <wert / value> |- CARRIER SUPRESSION ---------------------------------- <wert / value>...
  • Page 274: Dvb-C Qam

    Menü-Übersicht / Menu Overview A.3.3 DVB-C QAM |- DVB-C QAM ----------------------|- QAM --------------------- |- 16 QAM |- 32 QAM |- 64 QAM |- 128 QAM |- 256 QAM |- I/Q ------------------------ |- NORMAL |- CHANGED |- I/Q PHASE ERROR------------------------------------------ <wert / value> |- CARRIER SUPRESSION ---------------------------------- <wert / value>...
  • Page 275: Dvb-T Cofdm

    Menü-Übersicht / Menu Overview A.3.4 DVB-T COFDM |- DVB-T COFDM ------------------|- CONSTELLATION --- |- QPSK |- 16 QAM |- 64 QAM α |- HIERARCH. 16 QAM α |- HIERARCH. 16 QAM α |- HIERARCH. 16 QAM α |- HIERARCH. 64 QAM α...
  • Page 276: Atsc Vsb

    Menü-Übersicht / Menu Overview A.3.5 ATSC VSB |- ATSC VSB ------------------------|- VSB LEVEL ------------ |- 8 VSB |- I/Q ------------------------ |- NORMAL |- CHANGED |- I/Q PHASE ERROR------------------------------------------ <wert / value> |- CARRIER SUPRESSION ---------------------------------- <wert / value> |- I/Q AMPL. IMBALANCE ------------------------------------ <wert / value> |- NOISE------------------- |- NOISE --------------------------- ON/OFF |- C/N ------------------------------- <wert / value>...
  • Page 277: Itu-T J.83/B

    Menü-Übersicht / Menu Overview A.3.6 ITU-T J.83/B |- ITU-T J.83/B----------------------|- QAM --------------------- |- 64 QAM |- 256 QAM |- I/Q ------------------------ |- NORMAL |- CHANGED |- I/Q PHASE ERROR------------------------------------------ <wert / value> |- CARRIER SUPRESSION ---------------------------------- <wert / value> |- I/Q AMPL. IMBALANCE ------------------------------------ <wert / value> |- NOISE------------------- |- NOISE --------------------------- ON/OFF |- C/N ------------------------------- <wert / value>...
  • Page 278: Isdb-T Bst-Ofdm

    Menü-Übersicht / Menu Overview A.3.7 ISDB-T BST-OFDM |- ISDB-T BST-OFDM |- LAYER ASSIGNMENT [A|BC] |- PORTION---------|- PART DIFF DIFF |- PART DIFF COHE |- PART COHE COHE |- DIFF DIFF DIFF |- DIFF DIFF COHE |- DIFF COHE COHE |- COHE COHE COHE |- CONSTELLATION |- DQPSK |- QPSK...
  • Page 279: External

    Menü-Übersicht / Menu Overview A.3.8 EXTERNAL |- I/Q EXTERNAL ------------------|- I/Q INPUT SIGNAL -- |- NOMINAL (0.0 dB) |- DVB-T FROM SFQ (6.5 dB) |- EDIT CORRECTION----- <wert / value> |- I/Q ------------------------ |- NORMAL |- CHANGED |- I/Q PHASE ERROR---------------------------------- <wert / value>...
  • Page 280: I/Q Coder

    Menü-Übersicht / Menu Overview A.4 I/Q CODER A.4.1 DVB-S QPSK |- INPUT SELECT------------------|- ASI |- SPI |- TS PARALLEL |- ASI EXT.CLOCK |- SPI EXT.CLOCK |- INPUT DATA RATE ------------<wert / value> ------ <messwert / measure value > F3 = ACCEPT |- USEFUL DATA RATE ---------------------------------- <messwert / measure value >...
  • Page 281: Satellite

    Menü-Übersicht / Menu Overview A.4.2 SATELLITE |- INPUT SELECT------------------|- ASI |- SPI |- TS PARALLEL |- ASI EXT.CLOCK |- SPI EXT.CLOCK |- INPUT DATA RATE ------------<wert / value> ------ <messwert / measure value > |- USEFUL DATA RATE ---------------------------------- <messwert / measure value > |- SYMBOL RATE -----------------<wert / value>...
  • Page 282: Dvb-C Qam (I/Q Coder)

    Menü-Übersicht / Menu Overview A.4.3 DVB-C QAM (I/Q Coder) |- INPUT SELECT------------------|- ASI |- SPI |- TS PARALLEL |- ASI EXT.CLOCK |- SPI EXT.CLOCK |- INPUT DATA RATE ------------<wert / value> ------ <messwert / measure value> F3 = ACCEPT |- USEFUL DATA RATE ---------------------------------- <messwert / measure value> |- SYMBOL RATE -----------------<wert / value>...
  • Page 283: Dvb-C (Cspl Coder)

    Menü-Übersicht / Menu Overview A.4.4 DVB-C (CSPL Coder) |- INPUT SELECT------------------|- ASI |- SPI |- TS PARALLEL |- ASI EXT.CLOCK |- SPI EXT.CLOCK |- INPUT DATA RATE ------------<wert / value> ------ <messwert / measure value > |- USEFUL DATA RATE ---------------------------------- <messwert / measure value > |- SYMBOL RATE -----------------<wert / value>...
  • Page 284: Dvb-T Cofdm

    Menü-Übersicht / Menu Overview A.4.5 DVB-T COFDM HIGH PRIO LOW PRIO / NONHIERARCHICAL |- INPUT SELECT------------------|- ASI |- SPI |- TS PARALLEL |- ASI EXT.CLOCK |- SPI EXT.CLOCK HIGH PRIO LOW PRIO / NONHIERARCHICAL |- INPUT DATA RATE ------------<wert / value> -----------------<messwert / measure value> HIGH PRIO LOW PRIO / NONHIERARCHICAL |- USEFUL DATA RATE ---------------------------------------------<messwert / measure value>...
  • Page 285: Atsc Vsb

    Menü-Übersicht / Menu Overview A.4.6 ATSC VSB |- INPUT SELECT------------------|- SPI |- ASI |- TS PARALLEL |- SPI EXT.CLOCK |- ASI EXT. CLOCK |- SMPTE |- SMPTE EXT. CLOCK |- INPUT DATA RATE ------------<wert / value> ------------------------------- <messwert / measure value > |- USEFUL DATA RATE ----------------------------------------------------------- <messwert / measure value >...
  • Page 286: Itu-T J.83/B

    Menü-Übersicht / Menu Overview A.4.7 ITU-T J.83/B |- INPUT SELECT------------------|- SPI |- ASI |- TS PARALLEL |- SPI EXT.CLOCK |- ASI EXT. CLOCK |- INPUT DATA RATE ------------<wert / value> ------------------------------- <messwert / measure value > |- USEFUL DATA RATE ----------------------------------------------------------- <messwert / measure value > |- SYMBOL RATE -----------------<wert / value>...
  • Page 287: Isdb-T Bst-Ofdm

    Menü-Übersicht / Menu Overview A.4.8 ISDB-T BST-OFDM |- INPUT SELECT------------------|- SPI |- ASI |- TS PARALLEL + AUX |- INPUT DATA RATE ------------<messwert / measure value > LAYER A LAYER B LAYER C |- USEFUL DATA RATE MAX ----------------------------------------<messwert / measure value > LAYER A LAYER B LAYER C...
  • Page 288 Menü-Übersicht / Menu Overview |- SPECIAL -------------------------|- SCRAMBLER -------------------------- ON/OFF |- REED SOLOMON--------------------- ON/OFF |- BYTE INTERL. ------------------------ ON/OFF |- BIT INTERL. --------------------------- ON/OFF |- FREQ. INTERL. ----------------------- ON/OFF |- ALERT BROADC. F. ----------------- ON/OFF |- PID PRBS TS PACKET ------------- |- A..C (HEX)----- <wert / value> |- EDIT CARRIERS ---------------------- |- DATA ------------ ON/OFF |- SP --------------- ON/OFF |- CP --------------- ON/OFF...
  • Page 289: Baseband

    Menü-Übersicht / Menu Overview A.5 BASEBAND |- VIDEO -----------------------------|- VIDEO------------------- |- ON |- OFF |- DEVIATION ------------ <wert / value> |- DEVIATION +/- ------- |- "+" |- "-" |- INPUT SELECT------- |- FRONT 1M |- FRONT 75 Ω |- REAR1 X30.2 75Ω...
  • Page 290 Menü-Übersicht / Menu Overview |-SUBCARRIER ADR - -----------|--- 1 --- |- SUBCARRIER-- ------- |- ON |- OFF |- RF FREQUENCY ----- <wert / value> |- RF DEVIATION ------- <wert / value> 10 |- DATA SOURCE ------- |- INTERNAL 11 | |- EXTERNAL NORM.
  • Page 291: Special

    Menü-Übersicht / Menu Overview A.6 SPECIAL |- SWEEP START/STOP |-START ------------------------------ <wert / value> |-STOP-------------------------------- <wert / value> |-STEP FREQ. ---------------------- <wert / value> |-STEP TIME ------------------------ <wert / value> F4: SWEEP ON/OFF |- SWEEP SPAN |-CENTER --------------------------- <wert / value> |-SPAN-------------------------------- <wert / value>...
  • Page 292: Memory

    Menü-Übersicht / Menu Overview A.7 MEMORY |- STORE INTERNAL. |- STORE NO. ---------------------- 1 to 30 |- COMMENT |- START STORE |- START DELETE |- RECALL INTERNAL |- RECALL NO ---------------------- 1 to 30 |- START RECALL |- STORE EXTERNAL. |- STORE NO.
  • Page 293: Setup

    Menü-Übersicht / Menu Overview A.8 SETUP |- HARDWARE------------- |- FUNCTION. CIRCUIT - Bild FUNCTIONAL CIRCUIT Display of block diagram |- EQUIPMENT------------- Bild Bestückung, STATUS Display of equipment list with STATUS O.K. / ERROR etc. |- NUMBERS --------------- Bild Fertigungsnummern ... / Display of Order Nos... |- CSPL CODER INFO --- START SELFTEST <ergebnis / result>...
  • Page 294 Menü-Übersicht / Menu Overview SETUP (Fortsetzung / cont'd) |- PRESET ------------------ |- LEVEL UNIT- ------------ |- DBM |- DBUV |- MV |- FREQ. RESOLUTION - |- .000 MHZ |- .000 000 MHZ |- 10 MHZ REFERENCE- |- INTERNAL |- EXTERNAL |- BEEPER ------------------ |- ON/OFF |- DIAGNOSTIC------------ |- ON/OFF |- TS CLOCK EXT.
  • Page 295 Menü-Übersicht / Menu Overview SETUP (Fortsetzung / cont'd) |- CHANNEL TABLE |- USER1 -------------------- |- CHANNEL |- USER2 |- NAME |- USER3 |- USER4 |- USER5 |-FADING PARAMETER |- USER DEFINED 1------ |- PATH STATE ----------<wert / value[PATH 1..12]> |- USER DEFINED 2 |- USER DEFINED 3 |- PROFILE ----------------<wert / value[PATH 1..12]>...
  • Page 296 Menü-Übersicht / Menu Overview SETUP (Fortsetzung / cont'd) |- SERVICE ----------------- |- SOFTWARE OPTIONS |- DIAGNOSTICS---------- |- ADDRESS ----------------<wert / value> |- POINT ---------------------<wert / value>-- <Result> |- DIVERSITY OFFSET -- |- OFFSET I -----------------<wert / value> |- OFFSET Q ---------------<wert / value> |- 10 MHz ADJUST-------- <wert / value>...
  • Page 297 Menü-Übersicht / Menu Overview 2072.5724.02 A.28 D/E-11...
  • Page 298: Dvb-Profile

    Anhang / Annex Fading Parameter Anhang/Annex B Fading Parameter B.1 DVB-Profile B.1.1 Übersicht / Overview Cluster Name Erläuterung / Explanation SCPI Quelle / Source Geändert / Modified Version EASY3 MOTIVATE WG: EASY, 3km/h EASY3 DVB-T Mobile Profile (SFN) ITIS in Darmstadt 0 dB ECHO ETSI TR101 290: 0 dB ECHO, Tg/2=112us, 50 km/h ECHO...
  • Page 299: User Defined 1-5

    Anhang / Annex Fading Parameter B.1.2 USER DEFINED 1-5 PATH 1 PATH 2 PATH 3 PATH 4 PATH 5 PATH 6 PATH 7 PATH 8 PATH 9 PATH 10 PATH 11 PATH 12 PATH STATE PROFILE RAYLEIGH RAYLEIGH RAYLEIGH RAYLEIGH RAYLEIGH RAYLEIGH RAYLEIGH...
  • Page 300: Easy3 - Motivate Wg: Easy, 3 Km/H

    Anhang / Annex Fading Parameter B.1.3 EASY3 - MOTIVATE WG: EASY, 3 km/h Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 2 PATH 4 PATH 5 PATH 6...
  • Page 301: Db Echo - Etsi Tr101 290: 0 Db Echo, Tg/2=112Us, 50 Km/H

    Anhang / Annex Fading Parameter B.1.4 0 dB ECHO - ETSI TR101 290: 0 dB ECHO, Tg/2=112us, 50 km/h Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3...
  • Page 302: Fx Echo - Etsi Tr101 290: Echo, Fixed Reception

    Anhang / Annex Fading Parameter B.1.5 FX ECHO - ETSI TR101 290: ECHO, FIXED RECEPTION Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3 PATH 4 PATH 5...
  • Page 303: Echo - Etsi Tr101 290: Echo, Portable Reception

    Anhang / Annex Fading Parameter B.1.6 PT ECHO - ETSI TR101 290: ECHO, PORTABLE RECEPTION Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3 PATH 4 PATH 5...
  • Page 304: Sfn Echo - Etsi Tr101 290: Echo, Dense Sfn

    Anhang / Annex Fading Parameter B.1.7 SFN ECHO - ETSI TR101 290: ECHO, DENSE SFN Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3 PATH 4 PATH 5...
  • Page 305: Tu6 - Etsi Tr101 290: Typical Urban, 50 Km/H

    Anhang / Annex Fading Parameter B.1.8 TU6 - ETSI TR101 290: TYPICAL URBAN, 50 km/h Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 2 PATH 4 PATH 5...
  • Page 306: Ra6 - Etsi Tr101 290: Typical Rural Area, 100 Km/H

    Anhang / Annex Fading Parameter B.1.9 RA6 - ETSI TR101 290: TYPICAL RURAL AREA, 100 km/h Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 2 PATH 4...
  • Page 307: Rc6 Anx B - En300744: Annex B / Rice 6 Path

    Anhang / Annex Fading Parameter B.1.10 RC6 ANX B - EN300744: ANNEX B / RICE 6 PATH Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3 PATH 4...
  • Page 308: Rl6 Anx B - En300744: Annex B / Rayleigh 6 Path

    Anhang / Annex Fading Parameter B.1.11 RL6 ANX B - EN300744: ANNEX B / RAYLEIGH 6 PATH Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3 PATH 4...
  • Page 309: Red Ht100 - Cost 207: Reduced Hilly Terrain, 100 Km/H

    Anhang / Annex Fading Parameter B.1.12 RED HT100 - COST 207: REDUCED HILLY TERRAIN, 100 km/h Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 2 PATH 4...
  • Page 310: Et50 - Cost 207: Equalization Test, 50 Km/H

    Anhang / Annex Fading Parameter B.1.13 ET50 - COST 207: EQUALIZATION TEST, 50 km/h Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 2 PATH 4 PATH 5...
  • Page 311: Validate100 - Validate: Recommendation, 100 Km/H

    Anhang / Annex Fading Parameter B.1.14 VALIDATE100 - VALIDATE: RECOMMENDATION, 100 km/h Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 2 PATH 4 PATH 5 PATH 6...
  • Page 312: Red6 Dvb-T - Reduced Dvb-T Annex B, 6 Paths

    Anhang / Annex Fading Parameter B.1.15 RED6 DVB-T - REDUCED DVB-T ANNEX B, 6 PATHS Erforderliche Anzahl von Pfaden / Necessary number of paths: Hinweis: Nur bis Version 01.20 Note: Only up to version 01.20 Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2...
  • Page 313: Rc12 Anx B - Cost 207: Annex B / Rice 12 Paths

    Anhang / Annex Fading Parameter B.1.16 RC12 ANX B - COST 207: ANNEX B / RICE 12 PATHS Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3...
  • Page 314: Rl12 Anx B - Cost 207: Annex B / Rayleigh 12 Paths

    Anhang / Annex Fading Parameter B.1.17 RL12 ANX B - COST 207: ANNEX B / RAYLEIGH 12 PATHS Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3...
  • Page 315: Red12 Dvb-T - Reduced Dvb-T Annex B, 12 Paths

    Anhang / Annex Fading Parameter B.1.18 RED12 DVB-T - REDUCED DVB-T ANNEX B, 12 PATHS Erforderliche Anzahl von Pfaden / Necessary number of paths: Hinweis: Nur bis Version 01.20 Note: Only up to version 01.20 Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2...
  • Page 316: Tu3 12Paths - Cost 207: Typical Urban, 3 Km/H, 12 Paths

    Anhang / Annex Fading Parameter B.1.19 TU3 12PATHS - COST 207: TYPICAL URBAN, 3 km/h, 12 PATHS Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 2 PATH 4...
  • Page 317: Tu50 12Paths - Cost 207: Typical Urban, 50 Km/H, 12 Paths

    Anhang / Annex Fading Parameter B.1.20 TU50 12PATHS - COST 207: TYPICAL URBAN, 50 km/h, 12 PATHS Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 2 PATH 4...
  • Page 318: Ht100 12Paths - Cost 207: Hilly Terrain, 100 Km/H, 12 Paths

    Anhang / Annex Fading Parameter B.1.21 HT100 12PATHS - COST 207: HILLY TERRAIN, 100 km/h, 12 PATHS Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 2 PATH 4...
  • Page 319: Attc-Profile

    Anhang / Annex Fading Parameter B.2 ATTC-Profile B.2.1 Übersicht / Overview Cluster Name Erläuterung / Explanation SCPI Quelle / Source Geändert / Modified Version ATTC A APP A ATTC STATIC MULTIPATH APPENDEX A ENSEMBLE A AA_Static ATTC ab 01.24 ATTC B APP A ATTC STATIC MULTIPATH APPENDEX A ENSEMBLE B AB_Static...
  • Page 320: A App A - Attc Static Multipath Appendex A Ensemble A

    Anhang / Annex Fading Parameter B.2.2 A APP A - ATTC STATIC MULTIPATH APPENDEX A ENSEMBLE A Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3 PATH 4...
  • Page 321: B App A - Attc Static Multipath Appendex A Ensemble B

    Anhang / Annex Fading Parameter B.2.3 B APP A - ATTC STATIC MULTIPATH APPENDEX A ENSEMBLE B Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3 PATH 4...
  • Page 322: C App A - Attc Static Multipath Appendex A Ensemble C

    Anhang / Annex Fading Parameter B.2.4 C APP A - ATTC STATIC MULTIPATH APPENDEX A ENSEMBLE C Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3 PATH 4...
  • Page 323: D App A - Attc Static Multipath Appendex A Ensemble D

    Anhang / Annex Fading Parameter B.2.5 D APP A - ATTC STATIC MULTIPATH APPENDEX A ENSEMBLE D Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3 PATH 4...
  • Page 324: E App A - Attc Static Multipath Appendex A Ensemble E

    Anhang / Annex Fading Parameter B.2.6 E APP A - ATTC STATIC MULTIPATH APPENDEX A ENSEMBLE E Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3 PATH 4...
  • Page 325: F App A - Attc Static Multipath Appendex A Ensemble F

    Anhang / Annex Fading Parameter B.2.7 F APP A - ATTC STATIC MULTIPATH APPENDEX A ENSEMBLE F Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3 PATH 4...
  • Page 326: G App A - Attc Static Multipath Appendex A Ensemble G

    Anhang / Annex Fading Parameter B.2.8 G APP A - ATTC STATIC MULTIPATH APPENDEX A ENSEMBLE G Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3 PATH 4...
  • Page 327: 15Us App B - Attc Echo Rejection Appendix B 15Us Echo

    Anhang / Annex Fading Parameter B.2.9 15us APP B - ATTC ECHO REJECTION APPENDIX B 15us ECHO Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3 PATH 4...
  • Page 328: App C - Attc Random Appendix C Ensemble 1

    Anhang / Annex Fading Parameter B.2.10 1 APP C - ATTC RANDOM APPENDIX C ENSEMBLE 1 Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3 PATH 4...
  • Page 329: App C - Attc Random Appendix C Ensemble 2

    Anhang / Annex Fading Parameter B.2.11 2 APP C - ATTC RANDOM APPENDIX C ENSEMBLE 2 Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3 PATH 4...
  • Page 330: App C - Attc Random Appendix C Ensemble 3

    Anhang / Annex Fading Parameter B.2.12 3 APP C - ATTC RANDOM APPENDIX C ENSEMBLE 3 Erforderliche Anzahl von Pfaden / Necessary number of paths: Preset Werte (F4) sind 5% Grau schattiert Preset values (F4) are 5% grey PATH 1 PATH 2 PATH 3 PATH 4...
  • Page 331 Anhang / Annex Fading Parameter 2072.5724.02 B.34 D/E-11...
  • Page 332: Annex Csfq - Z17 Common Interface Ts Out

    LVDS signals are then available at a 25-contact sub-D connector (contact assignment: EN 50083-9) via a cable supplied with the adapter card. The MPEG-2 signal can be applied to the SFQ (BER measurement) or routed to an MPEG-2 decoder, e.g. DVMD, via a standard parallel cable (25-contact sub-D connector/25-contact sub-D connector).
  • Page 333: Pin Assignment

    Common Interface TS out SFQ-Z17 Pin Assignment COMMON INTERFACE (DVB Document A017) and connected pins of COMMON INTERFACE TS OUT SFQ-Z17: Common interface SFQ-Z17 Signal Function Signal Function Ground Ground Data bit 3 Data bit 4 Data bit 5 Data bit 6...
  • Page 334 SFQ-Z17 Common Interface TS out Common interface SFQ-Z17 Signal Function Signal Function MDO3 MP data out 3 MDO4 MP data out 4 MDO5 MP data out 5 MDO6 MP data out 6 MDO7 MP data out 7 CE2# Card enable 2...
  • Page 335: Pin Assignment Of 25-Contact Sub-D Connector On The Cable Of Sfq-Z17

    Common Interface TS out SFQ-Z17 Pin Assignment of 25-Contact Sub-D Connector on the C.2.1 Cable of SFQ-Z17 Signal line Signal line Clock A Clock B System Gnd System Gnd Data 7 A(MSB) Data 7 B Data 6 A Data 6 B...
  • Page 336 Table of contents Remote Control Remote Control ..................3.1 Introduction........................3.1 Brief Instructions......................3.1 Switchover to Remote Control..................3.1 3.3.1 Setting the Device Address ....................3.2 3.3.2 Displays in Remote-Control Mode..................3.2 3.3.3 Return to Manual Control ....................3.2 IEC/IEEE-Bus Messages ....................3.3 3.4.1 Interface Messages ......................
  • Page 337 Table of contents Remote Control Status Reporting System.................... 3.8.4 3.8.1 Structure of an SCPI Status Register ................3.8.4 3.8.2 Overview of Status Registers ..................3.8.6 3.8.3 Description of Status Registers ..................3.8.7 3.8.3.1 Status Byte (STB) and Service Request Enable Register (SRE) ........3.8.7 3.8.3.2 IST Flag and Parallel Poll Enable Register (PPE) ............
  • Page 338: Remote Control

    Select output power CALL IBWRT(generator%, "sour:pow -10 dBm") A German-standard TV signal on channel 2 is available at the output of the SFQ with an output power of -10 dBm. 3. Return to manual operation: Press [LOCAL] key on the front panel.
  • Page 339: Setting The Device Address

    Remote Control 3.3.1 Setting the Device Address The factory-set IEC/IEEE-bus address is 28. The address can be changed either manually in the SETUP menu or via the IEC/IEEE bus. Addresses between 0 and 30 can be selected. Manually: • Press [SETUP / INFO] key •...
  • Page 340: Iec/Ieee-Bus Messages

    Remote Control IEC/IEEE-Bus Messages The messages transmitted on the data lines of the IEC/IEEE bus (see Appendix A3) can be subdivided into two groups: – interface messages and – device-dependent messages. 3.4.1 Interface Messages Interface messages are transmitted on the data lines of the IEC/IEEE bus, with the control line "ATN" being active.
  • Page 341: Structure And Syntax Of Device-Dependent Messages

    Remote Control Structure and Syntax of Device-Dependent Messages 3.5.1 SCPI Introduction SCPI (Standard Commands for Programmable Instruments) describes a standardized command set for the programming of devices regardless of the type of instrument or manufacturer. The goal of the SCPI Consortium is to standardize device-specific commands to a large extent.
  • Page 342 Remote Control Fig. 3-1 Tree structure of SCPI command system, SOURce being shown as an example Optional keywords: In some command systems it is possible to insert or to omit certain keywords. These keywords are shown in the instrument manual in square brackets.
  • Page 343: Structure Of A Command Line

    Remote Control 3.5.3 Structure of a Command Line A command line may contain one or several commands. It is terminated by a <New Line>, a <New Line> with EOI or an EOI together with the last data byte. QuickBASIC automatically generates an EOI together with the last data byte.
  • Page 344: Parameters

    No prefix is allowed for the units DBM and DB. For voltages, additional logarithmic units in the form of dB<prefix>V are supported. As a rule, numeric values are inadmissible for queries of the SFQ. This does not apply however to the special numeric values described below.
  • Page 345 Remote Control UP/DOWN UP, DOWN increments or decrements the numeric value by one step. The step size can be adjusted for each parameter set via UP, DOWN with the aid of the associated step command (see List of Commands, Appendix C3). Boolean parameters Boolean parameters represent two states.
  • Page 346: Overview Of Syntax Elements

    Remote Control 3.5.6 Overview of Syntax Elements The following list provides an overview of the syntax elements. The colon separates the keywords of a command. In a command line, the colon following a semicolon identifies the highest command level. The semicolon separates two commands in a command line. It does not change the path. The comman separates several parameters of a command.
  • Page 347: Description Of Commands

    3.6.1 Notation In the following sections, all commands implemented in the SFQ are tabulated according to the command system and described in detail. The notation is largely in line with the SCPI standard. The SCPI conformity information is given in a table in Appendix C3.
  • Page 348 Remote Control Special characters For some commands there is a choice of keywords having the same effect. These keywords are stated in the same line and separated by a vertical bar. Only one of these keywords need to be stated in the header of the command.
  • Page 349 Remote Control 2072.5724.02 3.12 E-11...
  • Page 350 Common Commands 3.6.2 Common Commands Die Common Commands sind der Norm IEEE The common commands are based on the IEEE 488.2 (IEC 625.2) entnommen. Gleiche Befehle 488.2 (IEC 625.2) standard. A specific command haben unterschiedlichen Geräten gleiche has the same effect in different devices. The Wirkung.
  • Page 351: Common Commands

    (see section 3.7). *OPT? OPTION IDENTIFICATION QUERY fragt die im Gerät enthaltenen Optionen gemäß Requests identification of the device options SFQ Datenblatt ab. according to SFQ data sheet. Beispiel für eine Geräteantwort: Example of a device response: "SFQ-B5,SFQ-B6,SFQ-B8,SFQ-B9,SFQ-10, "SFQ-B5,SFQ-B6,SFQ-B8,SFQ-B9,SFQ-10, SFQ-B11,SFQ-B12,SFQ-B13,SFQ-B15, SFQ-B11,SFQ-B12,SFQ-B13,SFQ-B15, SFQ-B16,SFQ-B17"...
  • Page 352 *TST? SELF TEST QUERY löst alle im SFQ implementierten Selbsttests aus Triggers all selftests implemented in the SFQ and und gibt einen Fehlercode in dezimaler Form aus. outputs an error code in decimal form. *WAI WAIT-to-CONTINUE erlaubt die Abarbeitung der nachfolgenden Befehle...
  • Page 353: Calibrate Subsystem

    Common Commands 3.6.3 CALIBRATE Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes CALibrate:DC:OFFSet:INTern CALibrate:DC:OFFSet:EXTern RF_Level CALibrate:ALL MODulation SYNThesis CSPL ISDBt NOISe:ALL CALibrate:RF_Level CALibrate:RF_Level:DATE All modulation modes / CALibrate:MODulation Alle Modulationen CALibrate:MODulation:DATE CALibrate:MODulation:ONCE Only modulation mode currently set / Nur für die eingestellte Modulation CALibrate:SYNThesis...
  • Page 354 Common Commands Diese Befehle bewirken alle eine Kalibration. These commands cause a calibration. Im Einzelnen haben die Befehle folgende Wirkung: The individual commands have the following effect: CALibrate:DC:OFFSet:INTern Kalibrierung des DC Offset bei FM Modulation Calibrates the DC offset for FM modulation CALibrate:DC:OFFSet:EXTern Kalibrierung des DC Offset bei FM Modulation bei Calibrates the DC offset for FM modulation with...
  • Page 355 Calibrates the noise generators 2 or 3 for all alle im jeweiligen SFQ möglichen internen digitalen internal digital modulation modes possible in the Modulationen. Die Abfrage liefert PASS oder FAIL SFQ. PASS or FAIL is returned in response to a query. CALibrate:NOISe:ALL:DATE Abfrage des Datums, wann der Rauschgenerator Queries the date of the last calibration of the noise zuletzt für alle internen digitalen Modulationen...
  • Page 356: Diagnostic Subsystem

    Common Commands 3.6.4 DIAGNOSTIC Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes nur Abfrage DIAGnostic:CARDs[:STATe] query only nur Abfrage 1.Param.: Adresse 2.Param.: Punkt <Wert / value> | MINimum | MAXimum DIAGnostic:POSition query only <Wert / value> | MINimum | MAXimum 1st parameter: address 2nd parameter: test point...
  • Page 357: Output Subsystem

    Common Commands 3.6.5 OUTPUT Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes OUTPut[:STATe] <Wert / value> | OFF | ON Das Subsystem OUTPUT dient zum Schalten des The OUTPUT is used to switch off the RF output. RF Ausgangs. OUTPut[:STATE] schaltet das Ausgangssignal des Geräts ein und Switches the output signal of the instrument on...
  • Page 358: Read Subsystem

    NO_BER_SYNC Das Subsystem READ dient zum Abfragen von The READ subsystem is used to query values Werten, die der SFQ selbst errechnet bzw. calculated or generated by the SFQ. generiert. READ:FM[:BASeband]:DEViation Mit diesem Befehl wird das Ergebnis des Summen- This command determines the sum deviation.
  • Page 359 Common Commands READ:IQCoder:DATarate Mit diesem Befehl wird der Messwert This command queries the measured data rate for eingespeisten Datenrate bei DVB-C, SATELLITE, DVB-C, SATELLITE, VSB or J.83/B. VSB oder J.83/B abgefragt. READ:IQCoder:SYMBols[:RATE] Abfrage der Symbolrate, die sich aus der Messung Queries the symbol rate which results from the des externen ASI bzw.
  • Page 360 Common Commands READ:IQCoder:ISDBt:USEFul[:RATE]:A? MAXimum Abfrage der maximal möglichen Nutzdatenmenge, Queries the maximum possible useful data rate for die bei ISDB-T-Modulation bei den derzeitigen transmission in layer A for the current coder Einstellungen in Layer A übertragen werden kann. settings for ISDB-T modulation. READ:IQCoder:ISDBt:USEFul[:RATE]:B? Abfrage der im eingespeisten Transportstrom Queries the layer B program data contained in the...
  • Page 361: Route Subsystem

    Common Commands 3.6.7 ROUTE Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes ROUTe:FM[:BASeband]:VIDeo:INPut FR1M | FR75 | RE1 | RE2 | AUTO | FRONt1m | FRONt75 | REAR1 | REAR2 ROUTe:MONitor INTernal | EXTernal ROUTe:REFerence:CLOCk INTernal | EXTernal nur Abfrage ROUTe:REFerence:STATe query only Subsystem...
  • Page 362: Sense Subsystem

    Common Commands 3.6.8 SENSE Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes SENSe:BER:MEASurement <numeric> | OFF | ON SENSe:BER[:INPut][:SELect] SERial | PARallel SENSe:BER[:INPut]:SERial:DATA NORMal | INVerted SENSe:BER[:INPut]:SERial:CLOCk NORMal | INVerted SENSe:BER[:INPut]:SERial:ENABle ALWays | HIGH | LOW SENSe:BER[:INPut]:PARallel[:MODE] NORMal | INVerted | NULL | PID SENSe:BER:PRBS[:SEQuence] P23_1 | P15_1 Das Subsystem SENSE dient zum Einstellen der...
  • Page 363: Source Subsystem

    Common Commands 3.6.9 SOURCE Subsystem 3.6.9.1 SOURce:DM Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes [SOURce]:DM:CW:STATe <Wert/ value> | OFF | ON S4 | (QPSK | )* Satellite DVB-S QPSK [SOURce]:DM:FORMat S8 | Satellite DVB-S 8PSK S16 | Satellite DVB-S 16QAM S4T | Satellite QPSK Turbo S8T |...
  • Page 364 Selection of I/Q level correction with external Einspeisung eines nominalen I/Q Signals oder nominal I/Q signal fed in or DVB-T signal applied to eines DVB-T Signals in einen externen SFQ (z.B. an external SFQ (e.g. for diversity operation). für Diversity Betrieb) 2072.5724.02...
  • Page 365: Source:fm Subsystem

    Common Commands 3.6.9.2 SOURce:FM Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes AC | DC [SOURce]:FM:EXTernal:COUPling <Wert / value> | MAXimum | MINimum [SOURce]:FM:EXTernal:DEViation [HZPP] NORMal | INVerted [SOURce]:FM:EXTernal:POLarity <Wert / value> | MAXimum | MINimum [SOURce]:FM:EXTernal:IMPedance [Ω] <Wert / value > | OFF | ON [SOURce]:FM: EXTernal:STATe EXTernal | INTernal [SOURce]:FM:SOURce...
  • Page 366 Common Commands [SOURce]:FM:EXTernal:COUPling Kopplung Modulationssignals Coupling modulation signal Modulation mit externer Einspeisung. modulation with external feed. [SOURce]:FM:EXTernal:DEViation Hub bei FM-Modulation mit externer Einspeisung. Sets the deviation of the external signal for FM. [SOURce]:FM:EXTernal:POLarity Polarität des Hubs bei FM-Modulation mit externer Selects the deviation polarity of the external signal Einspeisung.
  • Page 367 Common Commands [SOURce]:FM[:BASeband]:SUBCarrier:ADR[1|2|3|4|5|6|7|8|9|10|11|12]:AUDio:LEFT:VOLume Pegel linken Audiokanals eines ADR- Sets the level of the left audio channel of an ADR Unterträgers bei FM-Modulation. subcarrier for FM. [SOURce]:FM[:BASeband]:SUBCarrier:ADR[1|2|3|4|5|6|7|8|9|10|11|12]:AUDio:LEFT[:STATe] Ein-/Ausschalten des linken Audiokanals eines Switches the left audio channel of an ADR ADR-Unterträgers bei FM-Modulation. subcarrier for FM on and off.
  • Page 368 Common Commands Einheit Bemerkung Befehl / Command Parameter Unit Notes <Wert / value> | MAXimum | MINimum [SOURce]:FM[:BASeband]:SUBCarrier:ADR[ [HZ] 1|2|3|4|5|6|7|8|9|10|11|12]:AUDio: RIGHt:FREQuency <Wert / value> [ DB ] | MAXimum | [SOURce]:FM[:BASeband]:SUBCarrier:ADR[ MINimum 1|2|3|4|5|6|7|8|9|10|11|12]:AUDio: RIGHt:VOLume <Wert / value> | OFF | ON [SOURce]:FM[:BASeband]:SUBCarrier:ADR[ 1|2|3|4|5|6|7|8|9|10|11|12]:AUDio: RIGHt[:STATe]...
  • Page 369 Common Commands [SOURce]:FM[:BASeband]:SUBCarrier:ADR[1|2|3|4|5|6|7|8|9|10|11|12]:AUDio:RIGHt:FREQuency Frequenz des rechten Audiokanals eines ADR- Sets the frequency of the right audio channel of an Unterträgers bei FM-Modulation. ADR subcarrier for FM. [SOURce]:FM[:BASeband]:SUBCarrier:ADR[1|2|3|4|5|6|7|8|9|10|11|12]:AUDio:RIGHt:VOLume Pegel des rechten Audiokanals eines ADR- Sets the level of the right audio channel of an ADR Unterträgers bei FM-Modulation.
  • Page 370 Common Commands Einheit Bemerkung Befehl / Command Parameter Unit Notes <Wert / value> | MAXimum | MINimum [SOURce]:FM[:BASeband]:SUBCarrier:FM [HZPP] [1|2|3|4|5|6]:AUDio:DEViation <Wert / value> | MAXimum | MINimum [SOURce]:FM[:BASeband]:SUBCarrier:FM [HZ] [1|2|3|4|5|6]:AUDio:FREQuency <Wert / value> | OFF | ON [SOURce]:FM[:BASeband]:SUBCarrier:FM [1|2|3|4|5|6]:AUDio:LPASs[:STATe] EXTernal | INTernal [SOURce]:FM[:BASeband]:SUBCarrier:FM [1|2|3|4|5|6]:AUDio:SOURce <Wert / value>...
  • Page 371 Common Commands [SOURce]:FM[:BASeband]:SUBCarrier:FM[1|2|3|4|5|6]:AUDio:DEViation Frequenzhub der FM-Audio-Modulation eines FM- Sets the frequency deviation of audio Unterträgers bei FM-Modulation. modulation signal of an FM subcarrier for FM. [SOURce]:FM[:BASeband]:SUBCarrier:FM[1|2|3|4|5|6]:AUDio:FREQuency Frequenz des Audiosignals eines FM-Unterträgers Sets the audio signal frequency of an FM bei FM-Modulation. subcarrier for FM.
  • Page 372 Common Commands Einheit Bemerkung Befehl / Command Parameter Unit Notes [SOURce]:FM[:BASeband]:VIDeo:COUPling <Wert / value> | AC | DC [SOURce]:FM[:BASeband]:VIDeo:CLAMping: <Wert / value> | OFF | ON SYNC [SOURce]:FM[:BASeband]:VIDeo:CLAMping: HARD | SOFT TYPE [SOURce]:FM[:BASeband]:VIDeo:CLAMping[ <Wert / value> | OFF | ON :STATe] <Wert / value>...
  • Page 373 Common Commands [SOURce]:FM[:BASeband]:VIDeo:COUPling Kopplung des Videosignals bei FM-Modulation (AD Coupling of the video signal for FM modulation (AD / DC). / DC). [SOURce]:FM[:BASeband]:VIDeo:CLAMping:SYNC Ein-/Ausschalten der Klemmung auf ein externes Switches clamping to an external sync signal for Synchronisationssignal bei FM-Modulation. FM on and off.
  • Page 374: Source:frequency Subsystem

    Common Commands 3.6.9.3 SOURce:FREQuency Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes [SOURce]:FREQuency:CENTer <Wert / value> | MAXimum | MINimum [HZ] [SOURce]:FREQuency:CHANnel <Wert / value> | MAXimum | MINimum | UP | DOWN [SOURce]:FREQuency:CHANnel:TABLe NONE | USR1 | USR2 | USR3 | USR4 | USR5 | USER1 | USER2 | USER3 | USER4 | USER5 [SOURce]:FREQuency[:CW]...
  • Page 375 Common Commands [SOURce]:FREQuency[:CW] [SOURce]:FREQuency:FIXed Die beiden Kommandos sind gleichbedeutend und These two commands have the same function. dienen zur Einstellung einer festen Trägerfrequenz. They set a fixed carrier frequency. [SOURce]:FREQuency:MODE Unterscheidung des Frequenz-Modes zwischen Selects the frequency mode for normal (CW or Normalbetrieb bzw.
  • Page 376: Source:channel Subsystem

    Common Commands 3.6.9.4 SOURce:CHANnel Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes [SOURce]:CHANnel:TABLe:SET USR1 | USR2 | USR3 | USR4 | USR5, Table set <numeric>, Channel Number <numeric> [ HZ | AHZ | FHZ | PHZ | [HZ] Channel Frequency NHZ | UHZ | KHZ | MHZ | GHZ | THZ | PEHZ | EXHZ ] [SOURce]:CHANnel:TABLe:ASSign...
  • Page 377: Source:iqcoder Subsystem

    Common Commands 3.6.9.5 SOURce:IQCoder Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes <Wert / value> CSPL Coder: [SOURce]:IQCoder:DVBC:DATarate [ MB ] | MAXimum | MINimum nur Abfrage (veraltet / obsolete, legacy code: query only [SOURce]:IQCoder:QAM:DATarate) [SOURce]:IQCoder:DVBC:INPut TSP | TS PARALLEL ASI | (veraltet / obsolete, legacy code: SPI |...
  • Page 378 Common Commands Einheit Bemerkung Befehl / Command Parameter Unit Notes [SOURce]:IQCoder:DVBC[:SPECial]: <Wert / value> | OFF | ON Nur mit / only with SYNC[:BYTE]:INVersion CSPL Coder [SOURce]:IQCoder:DVBC[:SPECial]:PLL:INT REF10 | TCXO | VCXO Nur mit / only with CSPL Coder [SOURce]:IQCoder:DVBC FIFO | TS Nur mit / only with [:SPECial]:PLL:DATA...
  • Page 379 Common Commands Einheit Bemerkung Befehl / Command Parameter Unit Notes [SOURce]:IQCoder:SAT[:SPECial]: <Wert / value> | OFF | ON INTerleave (veraltet / obsolete, legacy code: [SOURce]:IQCoder:QPSK[:SPECial]:INTerleave) [SOURce]:IQCoder:SAT[:SPECial]: <Wert / value> | OFF | ON REEDsolomon (veraltet / obsolete, legacy code: [SOURce]:IQCoder:QPSK[:SPECial]:REEDsolomon) [SOURce]:IQCoder:SAT[:SPECial]: <Wert / value>...
  • Page 380 Common Commands Einheit Bemerkung Befehl / Command Parameter Unit Notes [SOURce]:IQCoder:COFDM:LOCKed? LOCK | LOCKED UNL | UNLOCKED NOCL | NO CLOCK NOD | NO DATA FRER | FRAME ERROR OVERFL | OVERFLOW UNDERFL | UNDERFLOW WICL WRONG CLOCK nur Abfrage query only [SOURce]:IQCoder:COFDM:LOCKed:LOW? LOCK | UNL | NOCL | NOD | FRER |...
  • Page 381 Common Commands Einheit Bemerkung Befehl / Command Parameter Unit Notes [SOURce]:IQCoder:COFDm[:SPECial]: <numeric> | OFF | ON CONV[:INTerleaver][:LOW] [SOURce]:IQCoder:COFDm[:SPECial]: <numeric> | OFF | ON CONV[:INTerleaver]:HIGH [SOURce]:IQCoder:COFDm[:SPECial]:BIT <numeric> | OFF | ON [:INTerleaver] [SOURce]:IQCoder:COFDm[:SPECial]: <numeric> | OFF | ON SYMBol[:INTerleaver] [SOURce]:IQCoder:COFDm[:SPECial]: <numeric> MIN: “#0000“...
  • Page 382 Common Commands Einheit Bemerkung Befehl / Command Parameter Unit Notes [SOURce:]IQCoder:VSB:ROLLoff <numeric> | MAXimum | MINimum [SOURce:]IQCoder:VSB:SYMBols[:RATE] <numeric> | MAXimum | MINimum [SOURce:]IQCoder:VSB <numeric> | OFF | ON [:SPECial]:RANDomizer [SOURce:]IQCoder:VSB <numeric> | OFF | ON [:SPECial]:INTerleave [SOURce:]IQCoder:VSB [:SPECial]: <numeric> | OFF | ON PILot[:STATe] [SOURce:]IQCoder:VSB <numeric>...
  • Page 383 Common Commands Einheit Bemerkung Befehl / Command Parameter Unit Notes [SOURce]:IQCoder:ISDBt:AC:MOD <numeric> | OFF | ON [SOURce]:IQCoder:ISDBt:ACData[1|2] ALL1 | PRBS [SOURce]:IQCoder:ISDBt:BANDwidth <numeric> [ HZ | AHZ | FHZ | PHZ | NHZ | UHZ | KHZ | MHZ | GHZ | THZ | PEHZ | EXHZ] MAXimum | MINimum [SOURce]:IQCoder:ISDBt:CONStel:A C_DQpsk | C_QPsk | C_16qam |...
  • Page 384 Common Commands Einheit Bemerkung Befehl / Command Parameter Unit Notes [SOURce]:IQCoder:ISDBt:SEGMents:B <numeric> [SOURce]:IQCoder:ISDBt:SEGMents:C <numeric> [SOURce]:IQCoder:ISDBt:SEGMents[:STATe] <numeric>, <numeric> | OFF | ON [SOURce]:IQCoder:ISDBt:SP <numeric> | OFF | ON [SOURce]:IQCoder:ISDBt:SP:MOD <numeric> | OFF | ON [SOURce]:IQCoder:ISDBt:TIME[:INTerleaving]: <numeric> [SOURce]:IQCoder:ISDBt:TIME[:INTerleaving]: <numeric> [SOURce]:IQCoder:ISDBt:TIME[:INTerleaving]: <numeric> [SOURce]:IQCoder:ISDBt:TMCC <numeric>...
  • Page 385 Common Commands SOURCE:IQCODER subsystem provides Das Subsystem SOURCE:IQCODER enthält die commands for I/Q modulation. Befehle zur den I/Q Modulationen. [SOURce]:IQCoder:DVBC:DATarate ([SOURce]:IQCoder:QAM:DATarate) Eingestellte Datenrate bei DVB-C Modulation. Bei Sets the data rate for DVB-C. Verwendung eine CSPL Coders ist nur die Abfrage möglich [SOURce]:IQCoder:DVBC:INPut ([SOURce]:IQCoder:QAM:INPut)
  • Page 386 Common Commands [SOURce]:IQCoder:SAT:DATarate ([SOURce]:IQCoder:QPSK:DATarate) Eingestellte Datenrate bei SATELLITE Modulation. Sets the data rate for SATELLITE. [SOURce]:IQCoder:SAT:INPut ([SOURce]:IQCoder:QPSK:INPut) Eingangsinterface bei SATELLITE-Modulation. Für Selects the input interface for SATELLITE. The alle Eingänge außer TS-Parallel ist die Option input interface option is required for all inputs Input Interface nötig.
  • Page 387 Common Commands [SOURce]:IQCoder:COFDm:INPut[:LOW] Eingangsinterface nichthierarchischer Input interface for non-hierarchical constellation or Constellation oder des Low Priority Zweigs bei of low-priority path for hierarchical COFDM hierarchischer COFDM-Modulation. Für alle modulation. Option input interface is required for all Eingänge außer TS-Parallel ist die Option Input inputs except TS PARALLEL.
  • Page 388 Common Commands [SOURce]:IQCoder:COFDM:LOCKed:LOW? Abfrage des Synchronisationszustandes des Low Queries the synchronization of low-priority path for Priority Zweigs hierarchischer COFDM- hierarchical COFDM modulation. The following Modulation. Folgende Zustände sind möglich. states are possible: LOCK (locked) für eingerastet, LOCK for locked, UNL (unlocked) für nicht eingerastet, UNL for unlocked, WICL (wrong input clock) für Taktabweichungen WICL for wrong input clock...
  • Page 389 Common Commands [SOURce]:IQCoder:COFDm:PILot Abschaltung aller Piloten bei COFDM-Modulation. Switch-off of all pilots for COFDM modulation. [SOURce]:IQCoder:COFDm:PILot:MOD Abschaltung der Modulation der Piloten bei Switch-off of modulation of pilots for COFDM COFDM- Modulation. modulation. [SOURce]:IQCoder:COFDm:TPS Abschaltung aller TPS (Transmission Parameter Switch-off of all TPS (Transmission Parameter Signalling) - Träger bei COFDM-Modulation.
  • Page 390 Common Commands [SOURce]:IQCoder:COFDm[:SPECial]:CONV[:INTerleaver]:HIGH Ein-/Ausschalten des Convolutional Interleavers Switch-on/off of convolutional interleaver of high- des High Priority Zweigs bei hierarchischer priority path for hierarchical COFDM modulation. COFDM-Modulation. [SOURce]:IQCoder:COFDm[:SPECial]:BIT[:INTerleaver] Ein-/Ausschalten des Bitinterleavers bei COFDM- Switch-on/off interleaver COFDM Modulation. modulation. [SOURce]:IQCoder:COFDm[:SPECial]:SYMBol[:INTerleaver] Ein-/Ausschalten Symbolinterleavers Switch-on/off of symbol interleaver for COFDM COFDM-Modulation.
  • Page 391 Common Commands [SOURce]:IQCoder:COFDm:IFFT:SYNC[:OUTPut] IFFT Synchronisationssignals des DVB-T Coders Switches IFFT synchronization signal of DVB-T auf die Ausgangsbuchse schalten coder to output connector. [SOURce]:IQCoder:VSB:DATarate Eingestellte Datenrate Modulation Queries the data rate for VSB modulation. abfragen. [SOURce]:IQCoder:VSB:INPut Eingangsinterface bei VSB-Modulation. Für alle Input interface for VSB modulation.
  • Page 392 Common Commands [SOURce]:IQCoder:VSB[:SPECial]:PILot:Value Pegel des Pilot Trägers bei VSB-Modulation. Level of pilot carrier for VSB modulation. [SOURce]:IQCoder:J83B:DATarate Eingestellte Datenrate bei J.83/B Modulation Queries the data rate for J.83/B modulation. abfragen. [SOURce]:IQCoder:J83B:INPut Eingangsinterface bei J.83/B-Modulation. Für alle Input interface for J.83/B modulation. The optional Eingänge außer TS-Parallel ist die Option Input input interface is required for all inputs except TS Interface nötig.
  • Page 393 Common Commands [SOURce]:IQCoder:ISDBt:AC Alle Auxiliary Channel Träger bei ISDB-T werden Switch-on/off of all auxiliary channel carriers for ein-/ausgeschaltet (I = 0, Q = 0). ISDB-T (I = 0, Q = 0). [SOURce]:IQCoder:ISDBt:AC:MOD Die Modulation aller Auxiliary Channel Träger bei Switch-on/off of modulation of all auxiliary channel ISDB-T wird ein-/ausgeschaltet.
  • Page 394 Common Commands [SOURce]:IQCoder:ISDBt:LOCKed? Abfrage des Synchronisationszustandes des I/Q Queries the synchronization of the I/Q coder to the Coders auf den eingespeisten Datenstrom bei applied data stream for ISDB-T modulation. ISTB-T-Modulation. [SOURce]:IQCoder:ISDBt:MODE:A Art der zu übertragenden Daten für Layer A bei Type of data to be transmitted in layer A for ISDB-T ISDB-T.
  • Page 395 Common Commands [SOURce]:IQCoder:ISDBt:TIME[:INTerleaving]:B Länge des Time Interleavings von Layer B Setting of length of time interleaving of layer B. [SOURce]:IQCoder:ISDBt:TIME[:INTerleaving]:C Länge des Time Interleavings von Layer C Setting of length of time interleaving of layer C. [SOURce]:IQCoder:ISDBt:TMCC Alle TMCC Träger werden ein-/ausgeschaltet (I = Switch-on/off of all TMCC carriers (I = 0, Q = 0).
  • Page 396: Source:modulator Subsystem

    Common Commands 3.6.9.6 SOURce:MODulator Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes [SOURce]:MODulator[:STATe] <Wert / value> | OFF | ON Das Subsystem SOURCE:MODULATOR enthält The SOURCE:MODULATOR subsystem provides den Befehl zum Schalten der Modulation. the command for switching the modulation on and off.
  • Page 397: Source:noise Subsystem

    Common Commands 3.6.9.7 SOURce:NOISe Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes [SOURce]:NOISe[:STATe] <Wert / value> | OFF | ON [SOURce]:NOISe:CN <Wert / value> [ DB ] | MAXimum | MINimum [SOURce]:NOISe:DVBS:CN:SHIFt <Wert / value> [ DB ] | MAXimum | MINimum [SOURce]:NOISe:DVBC:CN:SHIFt <Wert / value>...
  • Page 398 Common Commands Das Subsystem SOURCE:MODULATOR enthält The SOURCE:MODULATOR subsystem provides den Befehl zur Bedienung des Rauschgenerators. the control commands for the noise generator. [SOURce]:NOISe[:STATe] Ein-/Ausschalten des Rauschgenerators. Switches the noise generator on and off. [SOURce]:NOISe:CN Verhältnis Träger zu Rauschen des Rausch- Sets the C/N ratio of the noise generator.
  • Page 399: Source:fsim Subsystem

    Common Commands 3.6.9.8 SOURce:FSIM Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes SOURce:FSIM:SELECT [?] 1 | 2 | 3 | 4 | 5 SOURce:FSIM:PRESET[1|2|3|4|5] EASY3 | ECHO | FX_echo | T_echo Keine Abfrage | SFN_echo | TU6 | RA6 | no query RC6_anx_b | RL6_anx_b | RED_ht100 | ET50 | VALidate100 |...
  • Page 400 Common Commands [SOURce]:FSIMulator:SELECT Auswahl des auszusendenden Parameter Sets des Selection of fading simulator parameter set to be Fading Simulators. sent. [SOURce]:FSIMulator:PRESET[1|2|3|4|5] Vorbelegung von Parameter Sets des Fading Presetting of fading simulator parameter set. Simulators. [SOURce]:FSIMulator[:STATe] Ein-/Ausschalten des Fading Simulators. Switch-on/off of fading simulator. [SOURce]:FSIMulator:SPEed:UNIT Umschalten der Geschwindigkeitseinheit zwischen Selection of speed units m/s, km/h and mph...
  • Page 401 Common Commands [SOURce]:FSIMulator:PATH[1|2|3|4|5|6|7|8|9|10|11|12]:DELay Signalverzögerung für einen einzelnen Pfad des Signal delay of a fading simulator path. Fading Simulators. [SOURce]:FSIMulator:PATH[1|2|3|4|5|6|7|8|9|10|11|12]:LOGNormal:STATe Ein-/Ausschalten des Log-Normal-Fading für einen Switch-on/off of log-normal fading of a fading einzelnen Pfad des Fading Simulators. simulator path. [SOURce]:FSIMulator:PATH[1|2|3|4|5|6|7|8|9|10|11|12]:LOGNormal:LCONstant Geländekonstante für Log-Normal-Fading eines Terrain constant for log-normal fading of a fading einzelnen Pfads des Fading Simulators.
  • Page 402: Source:power Subsystem

    Common Commands 3.6.9.9 SOURce:POWer Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes [SOURce]:POWer[:LEVel]:MODE NORMal | CONTinuous [SOURce]:POWer[:LEVel][:IMMediate] <Wert / value> [ DBM ] | MAXimum | [:AMPLitude] MINimum [SOURce]:POWer[:LEVel][:IMMediate]: <Wert / value> [ DB ] | MAXimum | SHIFt MINimum SOURce:POWer:ALC:MODE OFF | ON | AUTO...
  • Page 403 Common Commands [SOURce]:POWer:ALC:MODE Ein/Ausschalten der automatischen Pegelregelung. Switches ALC on and off. In the AUTO mode ALC Im AUTO-Mode ist während QPSK, QAM und I/Q is switched off during QPSK, QAM and I/Q external External Modulation ALC ausgeschaltet. Bei FM modulation.
  • Page 404: Source:sweep Subsystem

    Common Commands 3.6.9.10 SOURce:SWEep Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes [SOURce]:SWEep:STEP <Wert / value> [ HZ | AHZ | FHZ | PHZ | NHZ | UHZ | KHZ | MHZ | GHZ | THZ | PEHZ | EXHZ ] | MAXimum | MINimum [SOURce]:SWEep:DWELL <Wert / value>...
  • Page 405: Status Subsystem

    Common Commands 3.6.10 STATUS Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes nur Abfrage STATus:OPERation[:EVENt]? query only nur Abfrage STATus:OPERation:CONDition? query only STATus:OPERation:ENABle 0 to 32767 keine Abfrage STATus:PRESet no query STATus:QUEStionable [:EVENt]? nur Abfrage query only nur Abfrage STATus:QUEStionable:CONDition? query only STATus:QUEStionable:ENABle...
  • Page 406: System Subsystem

    Common Commands 3.6.11 SYSTEM Subsystem Einheit Bemerkung Befehl / Command Parameter Unit Notes [1|2|3|4|5|6|7|8|9| SYSTem:BASeband:ADR 10|11|12] :PRESet SYSTem:BASeband:ENERgy[:DISPersal]: PRESet [1|2|3|4|5|6] SYSTem:BASeband:FM :PRESet nur Abfrage SYSTem:BASeband:PRESet query only SYSTem:BASeband:VIDeo:PRESet SYSTem:BEEPer:STATe <Wert / value> | OFF | ON SYSTem:CODer:PRESet SYSTem:COMMunicate:GPIB[:SELF]:ADDRes <Wert / value> | MAXimum | MINimum SYSTem:COMMunicate:REMote OFF | GPIB | SERial | BOTH SYSTem:COMMunicate:SERial[:RECeive]:BA...
  • Page 407 Common Commands SYSTem:BASeband:ADR[1|2|3|4|5|6|7|8|9|10|11|12]:PRESet stellt die Preset-Werte für die Parameter des Sets the preset values for the parameters of the Menüs eines ADR SUBCARRIER ein ADR SUBCARRIER menu (see Menu Operation). (siehe Menübedienung). SYSTem:BASeband:ENERgy[:DISPersal]:PRESet stellt die Preset-Wert für die Parameter des Sets the preset values for the parameters of the ENERGY DISPERSAL Menüs ein.
  • Page 408 Common Commands SYSTem:COMMunicate:SERial[:RECeive]:PACE stellt den Handshake für die Fernbedienung über Sets the handshake for remote control via serial serielle Schnittstelle ein. OFF bedeutet kein interface. OFF means no handshake, XON means Handshake, XON bedeutet Handshake mit XON handshake with XON and XOFF, ACK means und XOFF, ACK bedeutet Handshake mit den handshake with the handshake lines RTS and Handshake Leitungen RTS und CTS.
  • Page 409 Common Commands SYSTem:INFormation? Abfrage der installierten Hardware. Zurückgegeben Query of installed hardware. A variable string wird ein variabler String, der folgendermaßen formatted as follows is returned: formatiert ist: ”MAIN:<MAIN-version>.<MAIN-Subversion>, ”MAIN:<MAIN version>.<MAIN subversion>, <MAIN-Jahr>,<MAIN-Monat>,<MAIN-Tag>, <MAIN year>,<MAIN month>,<MAIN day>, BIOS:<BIOS-version>.<BIOS-Subversion>, BIOS:<BIOS version>.<BIOS subversion>, <BIOS-Jahr>,<BIOS-Monat>,<BIOS-Tag>, <BIOS year>,<BIOS month>,<BIOS day>, FMSUB:<FMSUB-Version>.<FMSUB-Subversion>,...
  • Page 410: Unit Subsystem

    Common Commands SYSTem:MODulation:PRESet stellt die Preset-Werte für die Parameter des Sets the preset values for parameters of the Modulation-Menüs ein (siehe Menübedienung). MODULATION menu (see Menu Operation). SYSTem:TIME stellt die Uhrzeit ein. Die erste Zahl ist die Stunde Sets the time. The first number is the hour (24- (24-Stunden-Zählung), die zweite die Minute und hour clock), the second the minute, the third the die dritte die Sekunde.
  • Page 411 Common Commands 2072.5724.02 3.74 D/E-11...
  • Page 412: Device Model And Command Processing

    Remote Control Device Model and Command Processing The device model shown in Fig. 3.7-1 has been configured under the aspect of processing IEC/IEEE- bus commands. The individual components operate independently of each other and simultaneously. They communicate with each other by means of so-called messages. Input unit with IEC/IEEE...
  • Page 413: Command Identification

    Remote Control 3.7.2 Command Identification The command identification analyzes the data received from the input unit, proceeding in the order in which the data are received. Only a DCL is given priority but a GET (Group Execute Trigger) for instance is processed only after the previously received commands are executed. Any identified command is forwarded immediately to the data set but not immediately executed.
  • Page 414: Output Unit

    Remote Control 3.7.5 Output Unit The output unit collects the information requested by the controller from the data set management. It processes the information in line with SCPI rules and makes it available to the output buffer. The output buffer has a capacity of 1024 characters. If the requested information is longer, it will be made available in portions in a way that is not noticeable to the controller.
  • Page 415: Status Reporting System

    Remote Control Status Reporting System The status reporting system (see Fig. 3.8-1) stores all information on the current operating status of the device, eg that an AUTORANGE is being performed at present, and on errors occurred. The information is stored in the status registers and in the error queue. The status registers and the error queue can be queried via the IEC/IEEE bus.
  • Page 416 Remote Control CONDition register The CONDition register is directly written by the hardware or the summary bit of the next lower register. Its content reflects the current device status. This register can only be read but neither written nor cleared. Reading the register does not change its content.
  • Page 417: Overview Of Status Registers

    Remote Control 3.8.2 Overview of Status Registers -&- not used -&- not used -&- free -&- free -&- free -&- free -&- -&- free free -&- free -&- free -&- free -&- free -&- free -&- free -&- free -&- free -&- free...
  • Page 418: Description Of Status Registers

    Remote Control 3.8.3 Description of Status Registers 3.8.3.1 Status Byte (STB) and Service Request Enable Register (SRE) The Status Byte Register is already defined in IEEE 488.2. Since it collects all the information of the other lower-order registers it gives a rough overview on the device status. Its function corresponds to that of the CONDition register of an SCPI register and assumes the highest level in the SCPI hierarchy.
  • Page 419: Ist Flag And Parallel Poll Enable Register (Ppe)

    Remote Control 3.8.3.2 IST Flag and Parallel Poll Enable Register (PPE) Similar to the SRQ, the IST flag combines the complete status information in a single bit. It can be queried by a parallel poll (see section 3.8.4.3) or by the query *IST?. The Parallel Poll Enable Register (PPE) determines which bits of the STB affect the IST flag.
  • Page 420: Status:operation Register

    Remote Control 3.8.3.4 STATus:OPERation Register This register contains information in the CONDition register on operations currently performed by the device or in the EVENt register on operations performed by the device since the last readout. It can be set by the commands STATus:OPERation:CONDition or STATus:OPERation[:EVENt] and read by the queries STATus:OPERation:CONDition? or STATus:OPERation[:EVENt]?.
  • Page 421: Use Of Status Reporting Systems

    Remote Control 3.8.4 Use of Status Reporting Systems For an efficient use of the status reporting system, the information contained therein has to be transferred to the controller and further processed. There are various methods which are described in the following. Detailed program examples are given in Appendix D3 3.8.4.1 Service Request, Use of Hierarchical Structure Under certain conditions, the device may send a service request (SRQ) to the controller.
  • Page 422: Parallel Poll

    Remote Control 3.8.4.3 Parallel Poll In the parallel poll mode each of up to eight devices is requested simultaneously by a single command from the controller to transmit 1 information bit on the data lines, ie to pull the data line assigned to it to logic 0 or 1.
  • Page 423: Resetting The Status Reporting System

    Remote Control 3.8.5 Resetting the Status Reporting System Table 3.8-5 contains the various commands and events causing a reset of the status reporting system. None of the commands with the exception of *RST and SYSTem:PRESet affects the functional device settings. In particular DCL does not clear the device settings. Table 3.8-5 Resetting device functions Switching on AC Event...
  • Page 424: Appendix A3 Iec/Ieee-Bus Interface

    IEC/IEEE-Bus Interface Appendix A3 IEC/IEEE-Bus Interface The device is equipped with an IEC/IEEE-bus interface as standard. The IEEE 488 connector is located at the rear. For remote control of the device, a controller may be connected via this interface by means of a screened cable.
  • Page 425: Bus Lines

    IEC/IEEE-Bus Interface A.1.1 Bus Lines 1. Data bus with 8 lines DIO 1 to DIO 8 Transmission is bit-parallel and byte-serial in ASCII/ISO code. DIO 1 is the least-significant and DIO 8 the most-significant bit. 2. Control bus with 5 lines IFC (Interface Clear), active LOW resets the interfaces of connected devices to a defined initial condition.
  • Page 426: Interface Functions

    IEC/IEEE-Bus Interface A.1.2 Interface Functions Devices controlled via IEC/IEEE bus may be provided with different interface functions. The interface functions of FSQ are listed in Table A3-1. Table A-1 Interface functions Control Interface function character Source handshake Acceptor handshake L3..L4/LE3..LE4 Listener T5..T8/TE5..TE8 Talker, capability to answer serial poll...
  • Page 427: Interface Messages

    IEC/IEEE-Bus Interface Interface Messages Interface messages are sent to the device on data lines, the ATN line being active LOW. They are used for communication between device and controller. A.1.1 Common commands Common commands are in the code range 10 to 1F hex. They affect all devices on the bus without any addressing being required.
  • Page 428: Addressed Commands

    IEC/IEEE-Bus Interface A.1.2 Addressed commands The addressed commands are in the code range 00 to 0F hex. They only affect devices addressed as a listener. Table A-3 Addressed commands Command QuickBASIC command Function in the device (Selected Device IBCLR (device%) Interrupts processing of received commands and Clear) sets the command processing software to a defined...
  • Page 429 IEC/IEEE-Bus Interface 2072.5724.02 3.A.6 E-11...
  • Page 430: List Of Error Messages

    List of Error Messages Appendix B List of Error Messages The list below contains all error messages that could occur in the device during remote control. The meaning of negative error codes is specified by SCPI, positive error codes identify device-specific errors.
  • Page 431 List of Error Messages Text displayed upon an error queue query Error number Explanations -109 Missing parameter Fewer parameters were received than required. Example: The command SOURce:FM:INTernal:FREQuency requires a frequency parameter to be specified. -110 Command header error An error was detected in the header. -111 Header separator error Header contains a character which is not a legal separator.
  • Page 432 List of Error Messages Text displayed upon an error queue query Error number Explanations String data error -150 Command contains faulty string data. Invalid string data -151 Command contains an invalid string data element. Example: an END message was received before the terminal quote character. String data not allowed -158 A string data element was encountered but was not allowed by the device at this point.
  • Page 433 List of Error Messages Execution errors - error encountered upon command execution, causes bit 4 in the ESR register to be set Text displayed upon an error queue query Error number Explanations Execution error -200 Error encountered upon command execution. Invalid while in local -201 The command is not executable while the device is in local due to a hard local control element.
  • Page 434 List of Error Messages Text displayed upon an error queue query Error number Explanations Data questionable -231 The measurement accuracy is suspect. Hardware error -240 A command cannot be executed because of a hardware problem in the device. Hardware missing -241 The command cannot be executed because of a missing device hardware.
  • Page 435 List of Error Messages Text displayed upon an error queue query Error number Explanations illegal macro label -273 The macro label defined in the DMC* command was a legal string syntax but could not be accepted by the device. Example: the label was too long, the same as a common command header or contained invalid header syntax.
  • Page 436 List of Error Messages Device-specific error - causes bit 3 in the ESR register to be set Text displayed upon an error queue query Error number Explanations Device-specific error -300 SM3-specific error that cannot be defined more precisely. System error -310 A system internal error has occurred.
  • Page 437: Device-Dependent Error Messages

    List of Error Messages Device-Dependent Error Messages Device-dependent errors - device-dependent error, causes bit 3 in the ESR register to be set Text displayed upon an error queue query Error number Explanations Frequency underrange Frequency below the guaranteed limit value. Output unlevelled Level control loop out of function.
  • Page 438: Commands With Scpi Conformity Information

    Liste der SCPI-Befehle / List of SCPI Commands Anhang/ Appendix C Liste der Befehle mit SCPI-Konformitätsinformation / List of Commands with SCPI Conformity Information Das Gerät unterstützt die SCPI-Version 1995.0. The instrument supports SCPI version 1995.0. Für die Fernsteuerung wurden weitgehend Befehle Commands specified or accepted by this SCPI verwendet, die in dieser SCPI-Version festgelegt version are mostly used for remote control.
  • Page 439 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command nicht / non CALibration:DC:OFFSet:EXTern SCPI nicht / non CALibration:DC:OFFSet:INTern SCPI nicht / non CALibration:ALL SCPI nicht / non CALibration:LEVel SCPI nicht / non CALibration:LEVel:DATE SCPI nicht / non...
  • Page 440 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command nicht / non READ:FM[:BASeband]:DEViation? 22.5 MHZPP SCPI READ:FM[:BASeband]:ENERgy[:DISPersal]: nicht / non DOUBle[:STATe]? SCPI nicht / non READ:IQCoder:DATarate? SCPI nicht / non READ:IQCoder:Packetlength? SCPI nicht / non READ:IQCoder:SYMBols[RATE]? SCPI...
  • Page 441 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command ROUTe:FM[:BASeband]:VIDeo:INPut FR1M | FR75 | RE1 | RE2 | AUTO | nicht / non FRONt75 FRONt1m | FRONt75 | REAR1 | SCPI REAR2 nicht / non ROUTe:MONitor INTernal | EXTernal...
  • Page 442 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command nicht / non [SOURce:]DM:CW:STATe <numeric> | OFF | ON SCPI [SOURce:]DM:FORMat S4 | (QPSK | )* nicht / non S8 | SCPI S16 | S4T | S8T | C16 |...
  • Page 443 Liste der SCPI-Befehle / List of SCPI Commands Nach / to Befehl / Parameter SCPI-Info Command *RST [SOURce:]FM:EXTernal:COUPling AC | DC SCPI [SOURce:]FM:EXTernal:DEViation <numeric> [ HZ | AHZ | FHZ | PHZ | nicht / non 22.5 MHZPP NHZ | UHZ | KHZ | MHZ | GHZ | THZ SCPI | PEHZ | EXHZ | HZPP | AHZPP | FHZPP | PHZPP | NHZPP | UHZPP |...
  • Page 444 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command [SOURce:]FM[:BASeband]:SUBCarrier:ADR[1| <numeric> [ HZ | AHZ | FHZ | PHZ | nicht / non 1.02 KHZ 2|3|4|5|6|7|8|9|10|11|12]:AUDio:LEFT: NHZ | UHZ | KHZ | MHZ | GHZ | THZ SCPI FREQuency | PEHZ | EXHZ ] | MAXimum |...
  • Page 445 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command [SOURce:]FM[:BASeband]:SUBCarrier:ADR[1| <numeric> | OFF | ON nicht / non 2|3|4|5|6|7|8|9|10|11|12]:STATe SCPI [SOURce:]FM[:BASeband]:SUBCarrier:ADR[1| OFF | DAT1 | DAT2 | DAT3 | DAT4 nicht / non 2|3|4|5|6|7|8|9|10|11|12][:DATA]:ANCillary SCPI [SOURce:]FM[:BASeband]:SUBCarrier:ADR[1|...
  • Page 446 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command [SOURce:]FM[:BASeband]:VIDeo:COUPling AC | DC nicht / non SCPI [SOURce:]FM[:BASeband]:VIDeo:CLAMping: <numeric> | OFF | ON nicht / non SYNC SCPI [SOURce:]FM[:BASeband]:VIDeo:CLAMping:T HARD | SOFT nicht / non HARD SCPI...
  • Page 447 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command [SOURce:]FREQuency:CENTer <numeric> [ HZ | AHZ | FHZ | PHZ | SCPI 150 MHZ NHZ | UHZ | KHZ | MHZ | GHZ | THZ | PEHZ | EXHZ ] | MAXimum | MINimum [SOURce:]FREQuency:CHANnel:TABLe...
  • Page 448 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command [SOURce]:FREQuency:ACTual:CENTer <numeric> [ HZ | AHZ | FHZ | PHZ | nicht / non 1000MHz + NHZ | UHZ | KHZ | MHZ | GHZ | THZ | SCPI (10.7622377622 PEHZ | EXHZ ]...
  • Page 449 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command <numeric> [ MB ] | MAXimum | nicht / non 38.015 MB [SOURce:]IQCoder:DVBC:DATarate MINimum SCPI (veraltet / obsolet, legacy code: [SOURce:]IQCoder:QAM:DATarate) TSP | ASI | SPI | ASX | SPX nicht / non [SOURce:]IQCoder:DVBC:INPut SCPI...
  • Page 450 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command <numeric> [ MB ] | MAXimum | nicht / non 38.015 MB [SOURce:]IQCoder:SAT:DATarate MINimum SCPI [SOURce:]IQCoder:QPSK:DATarate TSP | ASI | SPI | ASX | SPX nicht / non [SOURce:]IQCoder:SAT:INPut SCPI...
  • Page 451 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info Nach / to *RST Command [SOURce]:IQCoder:COFDm:INPut[:LOW] TSP | SPI | ASI | ASX | SPX | nicht / non SPIAUX | TSPAUX SCPI [SOURce]:IQCoder:COFDm:INPut:HIGH TSP | SPI | ASI | ASX | SPX | nicht / non SPIAUX SPIAUX | TSPAUX...
  • Page 452 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info Nach / to *RST Command [SOURce]:IQCoder:COFDm[:SPECial]: <numeric> | OFF | ON nicht / non SCRamble[:LOW] SCPI [SOURce]:IQCoder:COFDm[:SPECial]: <numeric> | OFF | ON nicht / non SCRamble:HIGH SCPI [SOURce]:IQCoder:COFDm[:SPECial]: <numeric>...
  • Page 453 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command [SOURce:]IQCoder:VSB:DATarate <numeric> [ MB ] | MAXimum | nicht / non 17.00000000MB MINimum SCPI [SOURce:]IQCoder:VSB:INPut TSP | ASI | SPI | ASX | SPX | SMPTe nicht / non | SMX SCPI...
  • Page 454 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command [SOURce:]IQCoder:J83B:DATarate <numeric> [ MB ] | MAXimum | nicht / non 24.00000MB *) MINimum SCPI [SOURce:]IQCoder:J83B:INPut TSP | ASI | SPI | ASX | SPX nicht / non SCPI [SOURce:]IQCoder:J83B:INTerleaver:MODE <numeric>...
  • Page 455 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command [SOURce]:IQCoder:ISDBt:AC <numeric> | OFF | ON nicht / non SCPI [SOURce]:IQCoder:ISDBt:AC:MOD <numeric> | OFF | ON nicht / non SCPI [SOURce]:IQCoder:ISDBt:ACData[1|2] ALL1 | PRBS nicht / non SCPI [SOURce]:IQCoder:ISDBt:BANDwidth...
  • Page 456 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command [SOURce]:IQCoder:ISDBt:TIME[:INTerleavin <numeric> nicht / non g]:A SCPI [SOURce]:IQCoder:ISDBt:TIME[:INTerleavin <numeric> nicht / non g]:B SCPI [SOURce]:IQCoder:ISDBt:TIME[:INTerleavin <numeric> nicht / non g]:C SCPI [SOURce]:IQCoder:ISDBt:TMCC <numeric> | OFF | ON nicht / non SCPI [SOURce]:IQCoder:ISDBt:TMCC:MOD...
  • Page 457 Liste der SCPI-Befehle / List of SCPI Commands Nach / to Befehl / Parameter SCPI-Info Command *RST [SOURce:]MODulator[:STATe] <numeric> | OFF | ON nicht / non SCPI [SOURce:]NOISe[:STATe] <numeric> | OFF | ON nicht / non SCPI [SOURce:]NOISe:CN <numeric> [ DB ] | MAXimum | nicht / non 0 dB MINimum...
  • Page 458 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command SOURce:FSIMulator:SELECT 1 | 2 | 3 | 4 | 5 nicht / non SCPI SOURce:FSIMulator:PRESET[1|2|3|4|5] EASY3 | ECHO | FX_echo | PT_echo nicht / non | SFN_echo | TU6 | RA6 | RC6_anx_b SCPI | RL6_anx_b | RED_ht100 | ET50 |...
  • Page 459 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command [SOURce:]POWer:ALC:LEARn nicht / non SCPI [SOURce:]POWer:ALC:MODE OFF | ON | AUTO nicht / non AUTO SCPI [SOURce:]POWer:ALC:OFFMode TABLe | HOLD nicht / non HOLD SCPI [SOURce:]POWer:ALC:SEARch...
  • Page 460 Liste der SCPI-Befehle / List of SCPI Commands Befehl / Parameter SCPI-Info nach / to *RST Command SYSTem:BASeband:ADR[1|2|3|4|5|6|7|8|9|10| nicht / non 11|12]:PREet SCPI SYSTem:BASeband:ENERgy[:DISPersal]: nicht / non RESet SCPI nicht / non SYSTem:BASeband:FM[1|2|3|4|5|6]:PRESet SCPI nicht / non SYSTem:BASeband:PRESet? SCPI nicht / non SYSTem:BASeband:VIDeo:PRESet SCPI SYSTem:BEEPer:STATe...
  • Page 461 Liste der SCPI-Befehle / List of SCPI Commands 2072.5724.02 3C.24 D/E-11...
  • Page 462: Appendix 3D

    'Sets response time to 1 s REM ************************************************************************ 3D.1.4 Initialization of Device The IEC/IEEE-bus status registers and SFQ settings are reset to a defined initial state. REM ------------ Initializing thee instrument -------- REM InitDevice CALL IBWRT(generator%, "*CLS") 'Resets the status register CALL IBWRT(generator%, "*RST")
  • Page 463: 1.5 Sending Device Setting Commands

    3D.1.6 Switchover to Manual Control REM -------- Switching the instrument to manual control ------ CALL IBLOC(generator%) 'Sets SFQ to local REM *********************************************************************** 3D.1.7 Readout of Device Settings The settings made in the example 3 are called up again using the short form of the commands.
  • Page 464: 1.8 Command Synchronization

    Program Examples 3D.1.8 Command Synchronization The synchronization procedures in the example below are described in chapter 3, section 3.7.6, Command Sequence and Command Synchronization. REM -------- Examples for command synchronization -------- REM Command CAL:MOD requires a relatively long time for execution. REM It must be ensured that results are only queried REM after calibration has been completed.
  • Page 465: 1.9 Service Request

    Program Examples 3D.1.9 Service Request The service request routine requires a further initialization of the device, in the course of which the appropriate bits in the transition and enable registers are set. REM ---- Example for initializing SRQ in the case of errors ------ CALL IBWRT(generator%,"*SRE 168") 'Enables a service request for STAT:OPER,STAT:QUES and ESR registers...
  • Page 466 Program Examples Radout of event status register, output buffer and error/event queue in subroutine. REM -------- Subroutine for individual STB bits ------ Outputqueue: 'Reads the output buffer Nachricht$ = SPACE$(100) 'Provides space for response CALL IBRD(generator%, Nachricht$) PRINT "Nachricht im Ausgabepuffer :"; Nachricht$ RETURN Failure: 'Reads error queue...
  • Page 467 Program Examples 2072.5724.02 3D.6 E-11...
  • Page 468 Table of contents Maintenance and Troubleshooting Maintenance ..................4.1 General ..........................4.1 Cleaning .......................... 4.1 Storage ..........................4.1 Function Check / Mechanical Check ................4.1 Pin assignment important Connectors ................ 4.2 4.5.1 MONITOR Connector ....................... 4.2 4.5.2 RS-232 Connector......................4.2 4.5.3 IEC/IEEE-Bus Connector ....................
  • Page 469 Maintenance and Troubleshooting Table of contents 2072.6489.12 E-11...
  • Page 470: Maintenance

    Maintenance Maintenance General Note: This chapter describes troubleshooting down to module level . For a more detailed fault finding refer to the Service Manual with the Order No. 2072.6489.22 The instrument requires no regular maintenance. Generally maintenance is confined to cleaning the instrument.
  • Page 471: Pin Assignment Important Connectors

    Maintenance Pin assignment 4.5.3 IEC/IEEE-Bus Connector important Connectors 4.5.1 MONITOR Connector Pin assignment X12: DIO 1 DIO 2 DIO 3 DIO 4 12 15 NRFD NDAC Pin assignment X18: green blue SHIELD DIO 5 Intens./N.C. DIO 6 6...11 GND DIO 7 N.C.
  • Page 472: Keyboard Connector

    Maintenance 4.5.4 KEYBOARD Connector 4.5.5 TS-PARALLEL Connector Pin assignment X15: DATA RESET Pin assignment X60 / X61 Pin Labelling Signal CLOCK A data word clock ground DATA BIT 7 A (MSB) data bit 7 (most-significant bit) DATA BIT 6 A data bit 6 DATA BIT 5 A data bit 5...
  • Page 473 Maintenance 2072.5724.02 E-11...

Table of Contents
