OPERATING THE VACUUM

On/Off Switch

1. The on/off button is positioned on
the top of the machine (Fig.1).

Operation

1. To release the power cord turn the
lock on the top cover (Fig.2)
2. Lift up the top cover (Fig.3)
3. Lift up and remove the power cord
(Fig. 4)
8
Fig. 1
Fig. 2
Fig. 3
Fig. 4
4. Return the cover into position and
lock (Fig.5)
5. Ensure the power cord is fully
extended before use.
6. Ensure a dust bag is fitted before
use (Fig.6)
7. Press the on/off button to turn the
vacuum cleaner on. (Fig 7)
8. Adjust suction by sliding the airflow
adjuster located on the hose handle
Tip: for maximum suction, keep the
adjuster closed.
OPERATING THE VACUUM
Fig. 5
Fig. 6
Fig. 7
Fig. 8
9
