- Page 1 EN INSTALLATION, USE AND MAINTENANCE INSTRUCTION SU-DD2-L STONE...
- Page 2 SU-DD2-L...
- Page 3 TO THE ATTENTION ● It is not allowed to cook food over open flames (flambé) or operate gas hobs without pots or pans OF THE USER on them under the hood itself (the flames sucked into the hood might damage the appliance). ●...
-
Page 4: Table Of Contents
CONTENTS INSTALLING THE COOKER HOOD ..................5 HOW TO USE THE COOKER HOOD .................18 Grease filter removal, mounting the activated charcoal filter ..........20 Electrical connection of the cooker hood ................21 HOW THE COOKER HOOD WORKS .................22 CLEANING THE COOKER HOOD ..................26 OPERATIONAL ANOMALIES .....................27 REPLACING THE LIGHT ....................27 AFTER SALES SERVICE ....................28... -
Page 5: Installing The Cooker Hood
INSTALLING THE COOKER HOOD 1. Before carrying out the appliance installation, please check that all components are not damaged, in such a case contact your retailer and do not carry out any installation operation. Before the installation of the Downdraft, please remove the safety piece you can see in the picture (Fig. 1). Furthermore, please read carefully all of the following installation instructions. - Page 6 3. Make a rectangular hole 837x100 mm for the 880mm version or 1137x100 mm for the 1180mm ver- sion in the rear part of the hob, it is necessary to obtain the radius 10 on each corner of the rectangular opening (see fig.
- Page 7 assemble part A with B and C with D (fig. 4). Fig. 4 5. Install the preassembled accessories in correspondence with the hole drilled (fig. 5), bearing in mind that they can cover different types of furniture from a minimum dimension of 860mm to a maximum dimension of 1000mm.
- Page 8 Fix the width of the pairs of accessories using the screws supplied in the special slots, n. 2 screws on each side (fig. 6) taking care not to screw them completely. Fig. 6 Position the accessories against the base of the hob (A + B side 1 / C + D side 2 of the rectangular hole see fig.
- Page 9 and fix them on both sides with screws (fig. 8). Fig. 8 Warning: the accessories must be fixed in correspondence with the rectangular hole (each pair on each long side) at a maximum distance of 107mm (fig. 9) Fig. 9 SU-DD2-L...
- Page 10 (for an good assembly take the components “E - F” fig.10 and insert them between the accessories, respectively E for the left part and F for the right part, see fig.11, in order to check the correct positioning at the height above said). Fig.
- Page 11 Further expedient fix the accessories so that the screws previously inserted to lock the width do not go beyond the rectangular hole (see fig. 12), this to prevent the downdraft from hitting the screws during installation. Fig. 12 Before proceeding to the next point, remember to tighten the screws left slow and check that everything is stable.
- Page 12 7. Install the downdraft in the hole made, inserting it from above (fig. 14), Fig. 14 Place the downdraft brackets on the adjustment screws previously preassembled in the E - F compo- nents (fig. 15). Fig. 15 SU-DD2-L...
- Page 13 Glue the part left over from the previous cut made on the worktop to the support supplied (fig. 16.1). The part to be glued must weigh a maximum of 5kg and must respect the following dimensions: 833 mm x 97 mm_R8 mm (880 version) 1133 mm x 97 mm_R8 mm (1180 version) Fig.
- Page 14 If the downdraft is not aligned, act on the screws previously seen in fig. 15 until correct alignment is achieved. Fasten the downdraft to the cabinet using the two brackets supplied (fig. 17). Fig. 17 Having verified the correct position and stability of the product, proceed to glue the additional surface on the top of the downdraft.
- Page 15 Position the filters (fig. 20). Fig. 20 In the version of the Downdraft equipped with internal motor, install the power unit orienting the air outlet to the desired position, either downwards or upwards (Fig. 21). The motor can be installed either on the front or rear side of the downdraft.
- Page 16 9. For versions with external motor, place the suctioning unit (external motor) in a suitable area and fit the exhaust air flue as illustrated. Then fit the air outlet ducts between the external motor and the down- draft. Select an air outlet from the five possibilities (Fig. 22) and fit the union supplied with the appliance. Fig.
- Page 17 connecting the three connectors (9 pole connector for the actuator control and the safety control, 4 pole connector for led lamp turn on and push-button connector) (Fig. 24). Fig. 24 11. Connect the internal motor or te eternal motor’s cable to the terminal board found in- side te plastic box of the downdraft wiring.
-
Page 18: How To Use The Cooker Hood
HOW TO USE THE COOKER HOOD This appliance is intended to suck cooking fumes, greases and steam. It has been designed to work in both suctioning mode, with outside evacuation, and filtering mode. Outside - discharge version The cooker hood can be mounted in the version with outside discharge of suctioned air: in this case it is necessary to connect the exhausting channel to the outside (exhausting pipes are not supplied with the products.) Non-return valve blockage... - Page 19 In case of outside air discharge installation, fit a non-return valve to prevent wind and back air from entering. Filtering mode In case fumes and vapour cannot be evacuated outside, the appliance can be used in the filtering mode. Activated charcoal filters are required for this type of cooker hood. Air recycled through the charcoal fil- ters is recirculated into the kitchen, thanks to a duct conveying the air on one side of the cabinet (Fig.27) Fig.
-
Page 20: Grease Filter Removal, Mounting The Activated Charcoal Filter
GREASE FILTER REMOVAL, MOUNTING THE ACTIVATED CHARCOAL FILTER The removal and fitting of the grease and carbon filters need to be carried out with the downdraft in the open position. To open the downdraft, push the key. Then remove the front panel, pushing the upper part of each side at the same time. -
Page 21: Electrical Connection Of The Cooker Hood
ELECTRICAL CONNECTION OF THE COOKER HOOD WARNING Place the metal box containing the electronic components at a distance of no less than 65 cm from gas- operated cook tops or in any case, 65 cm from the suctioning surface of the cookerhood. NOTA We recommend installing the metal box containing the electronic components at least 10 cm above floor level and at a suitable distance from all heat sources (e.g. -
Page 22: How The Cooker Hood Works
HOW THE COOKER HOOD WORKS A: Light ON/OFF key The light switches on and off only when the carriage is fully OPEN. Pressing this button with the carriage closed will cause the carriage to open and then the light will switch on.The button also serves to switch off the light if it is on. - Page 23 IF THE PRODUCT WORKS WITH SUPPLIED REMOTE CONTROL Remote control (Fig.11). channel radio control for cooker hood remote. At first ignition, keep pressed the lighting button for 5 seconds. RC001 ADIO ONTROL Radio control used for the remote operation of ducted cooker hoods. TECHNICAL DATA - Alkaline battery powered: 12 V mod.
- Page 24 Generating a new transmission code: The radio control system is provided with preset codes. Should new codes be required, proceed as follows: Press simultaneously buttons: for two seconds. When Leds light on, press buttons: (within 5 seconds). Leds flashing 3 times indicate the procedure is completed. WARNING! This operation deletes permanently the preset codes.
- Page 25 Other functions: Automatic turn off: After 4 hours of continuous working from the last setup, the appliance turns off and closes automatically. Grease filters saturation: After 30 hours of working, the speed indicators “D” will all flash simultaneously, signaling the grease filters saturation.
-
Page 26: Cleaning The Cooker Hood
CLEANING THE COOKER HOOD Careful maintenance ensures proper operation and good performances over time. CAUTION The hood must be disconnected from the electrical network, both by unplugging the appliance from the socket and activating the magnetic circuit breaker (safety cut-out), before removing the metal grease filters. -
Page 27: Operational Anomalies
OPERATIONAL ANOMALIES PROBLEM SOLUTION Check that: ● There is not a power outage. ● A specific speed has actually been selected. ● The 9 pole connection is inserted properly. The cooker hood ● The red reset key, found over the electrical system box, is pushed. does not work... -
Page 28: After Sales Service
2. Using an appropriate tool, remove the LED bar from its seat, disconnect it electronically throught the appropriate connector then replace it with a LED bar with same characteristics. AFTER SALES SERVICE Any maintenance operation on your appliance should be carried out by: ●... - Page 29 The symbol on the product or on its packaging indicates that this product may not be treated as house- hold waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent poten- tial negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
- Page 30 Three Year Limited Warranty YOU MUST REGISTER THE PURCHASE OF YOUR PRODUCT ON LINE AT www.siriuscappe.com/usa/warranty.htm TO CONVALIDATE YOUR WARRANTY. YOU CAN FIND THE DATA OF YOUR HOODS ON A LABEL INSIDE THE HOOD. JUST REMOVE THE GREASE FILTER TO READ IT. WARRANTY SERVICE To qualify for warranty service, you must notify Sirius After sale service at the email address stated below or call toll free USA 1-877-474-8770 and provide the model number, description of...
