Grading Scrapers
GS0548 & GS0560
Table of Contents
!
Read the Operator's Manual entirely. When you see this symbol,
the subsequent instructions and warnings are serious - follow
without exception. Your life and the lives of others depend on it!
Cover photo may show optional equipment not supplied
with standard unit.
For an Operator's Manual and Decal Kit in French or
Spanish Language, please see your Land Pride dealer.
303-474M
Operator's Manual
Printed 1/20/23
39850
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Land Pride GS0548
Summary of Contents for Land Pride GS0548
- Page 1 Your life and the lives of others depend on it! Cover photo may show optional equipment not supplied with standard unit. For an Operator’s Manual and Decal Kit in French or Spanish Language, please see your Land Pride dealer. Printed 1/20/23...
-
Page 2: Machine Identification
Serial Number Machine Height Machine Length Machine Width Machine Weight Delivery Date First Operation Accessories Dealer Contact Information Name: Street: City/State: Telephone: Email: California Proposition 65 WARNING: Cancer and reproductive harm - www.P65Warnings.ca.gov GS0548 & GS0560 Grading Scrapers 303-474M 1/20/23... - Page 3 Land Pride assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Land Pride reserves the right to revise and improve its products as it sees fit. This publication describes the state of this product at the time of its publication, and may not reflect the product in the future.
- Page 4 Land Pride products. App on your smart phone, open the App, Refer to Parts Manual QR point your phone on the QR code and Locator on this page for take a picture. detailed instructions. GS0548 & GS0560 Grading Scrapers 303-474M 1/20/23...
-
Page 5: Safety At All Times
Important Safety Information Important Safety Information Listed below are common practices that may or may not be applicable to the products described in this manual. Safety at All Times Look for the Safety Alert Symbol Careful operation is your best The SAFETY ALERT SYMBOL indicates there is a potential hazard assurance against an accident. - Page 6 Replace parts on this implement using the correct tools and follow all shutdown procedures equipment. with genuine Land Pride parts only. before leaving the operator’s seat to Do not alter this implement in a way Always properly match the wheel perform maintenance.
-
Page 7: Avoid High Pressure Fluids
Use Seat Belt and ROPS Keep Riders Off Lights and Devices Machinery Land Pride recommends the use of a CAB or roll-over-protective- A Slow moving power machine Never carry riders on the tractor or structures (ROPS) and seat belt can create a hazard when driven implement. - Page 8 Important Safety Information Listed below are common practices that may or may not be applicable to the products described in this manual. Avoid crystalline Silica Be aware of and follow OSHA If possible, change into disposable (or other local, State, or Federal) or washable work clothes at the (quartz) Dust guidelines for exposure to airborne...
- Page 9 Important Safety Information This page left blank intentionally. 1/20/23...
-
Page 10: Safety Labels
Spray soapy water onto the cleaned area. all damaged or missing labels. Order new labels from your Peel backing from label and press label firmly onto the nearest Land Pride dealer. To find your nearest dealer, surface. visit our dealer locator at www.landpride.com. -
Page 11: Using This Manual
Table of Contents Introduction Introduction Owner Assistance Land Pride welcomes you to the growing family of new product owners. This Grading Scraper has been The dealer should complete the Online Warranty designed with care and built by skilled workers using Registration at the time of purchase. -
Page 12: Tractor Requirements
Refer to the Parts Manual if unsure. Make sure working parts move freely, and Operator’s bolts are tight. Manual Make sure all safety labels are correctly Page 6 located and legible. Replace if damaged. GS0548 & GS0560 Grading Scrapers 303-474M 1/20/23... - Page 13 5/8"-11 x 1 3/4" GR5 cap screws (#5), lock washers (#12), and hex nuts (#11) as shown. Do not tighten bolts at this time. 39852 Hitch and Shank Set-up Figure 1-1 1/20/23 GS0548 & GS0560 Grading Scrapers 303-474M...
-
Page 14: Point Hook-Up
6. Return to the tractor and slowly operate controls up and down to check for clearance between scraper NOTE: Land Pride’s Quick Hitch can be attached to frame, tractor tires and tractor drawbar. Move or the tractor to provide quick and easy 3-point hook- remove drawbar if it interferes with scraper. -
Page 15: Section 2: Adjustments
Adjust shank (#2) up or down to the desired depth and then replace shank retainer clip (#1). 8. Repeat steps 7 & 8 with remaining shanks. 39854 1/2" (1.3 cm) Above Skid Shoes Shank Settings Figure 2-1 1/20/23 GS0548 & GS0560 Grading Scrapers 303-474M... -
Page 16: Operating Checklist
Never go under equipment Safety Information” starting on page 1. supported by concrete blocks or hydraulics. Concrete can break, hydraulic lines can burst, and/or hydraulic controls can be actuated even when power to hydraulics is off. GS0548 & GS0560 Grading Scrapers 303-474M 1/20/23... - Page 17 3-point hitch. Whether you have chosen our produce dust containing crystalline silica. Trenching, GS0548 or GS0560 the working or grading principals are sawing, and boring of material containing crystalline silica the same. Simply lower your Grading Scraper until the can produce dust containing crystalline silica.
-
Page 18: Section 4: Accessories
Scrapers. This will allow the grading scraper to be used while traveling forward and when backing-up. 39855 Part No. Description 303-470A GS0548: 48" (122 cm) GRADER BLADE KIT 303-473A GS0560: 60" (152 cm) GRADER BLADE KIT Rear Mounting Grader Blades Figure 4-1 GS0548 & GS0560 Grading Scrapers 303-474M... -
Page 19: Shank Tips
Reattach blades and torque flange nuts (#3) Replace any worn, damaged, or illegible safety labels by to 150 ft-lbs. Replace grader blades when both edges are obtaining new labels from your Land Pride dealer. worn out. DANGER To avoid serious injury or death: Always secure equipment with solid, non-concrete supports before working under it. -
Page 20: Skid Shoes
They are also available in touch-up bottles with brush, quarts, and gallon sizes by adding Order only genuine Land Pride parts from your local Land TU, QT, or GL to the end of the aerosol part number. Pride dealer when replacing skid shoe components. -
Page 21: Section 6: Specifications & Capacities
31 1/8" (79.1 cm) 12" (30.5 cm) GS0548 = 48" (1.22 m) 44 3/8" (1.13 m) GS0560 = 60" (1.52 m) GS0548 = 51 3/8" (1.30 m) GS0560 = 63 3/8" (1.61 m) 39859 1/20/23 GS0548 & GS0560 Grading Scrapers 303-474M... -
Page 22: Section 7: Features & Benefits
Replaceable and full length skid shoes. Makes for easier operation and long unit life. Reversible skid shoes. Extends the life of the skid shoes. Heavy duty frame construction. Assures long lasting reliability and performance. GS0548 & GS0560 Grading Scrapers 303-474M 1/20/23... -
Page 23: Section 8: Torque Values Chart
Torque tolerance + 0%, -15% of torquing values. Unless otherwise specified use torque values listed above. All locknuts or lubricated fasteners: Use 75% of torque value. (i.e. 1/2"-13 GR5 = 76 ft-lb; 75% of 76 or .75 x 76 = 57 ft-lb) 1/20/23 GS0548 & GS0560 Grading Scrapers 303-474M... -
Page 24: Warranty
This Warranty is limited to the repair or replacement of any defective part by Land Pride and the installation by the dealer of any such replacement part, and does not cover common wear items. Land Pride reserves the right to inspect any equipment or parts which are claimed to have been defective in material or workmanship. - Page 26 Corporate Office: P.O. Box 5060 Salina, Kansas 67402-5060 USA www.landpride.com...
