  • ENGLISH, page 16
●Language selection:In the setting mode, short press the left and right keys to switch to language selection
long press the right key to enter,
●Handheld mode:In the setting mode, short press the left and right buttons to switch to the handheld mode
long press the right button to enter
complete.The product is right-handed by default and can be set according to your own usage habits. The logic of switching
to the left hand is reversed.
●Voltage gear: In the setting mode, short press the left and right buttons to switch to the voltage gear type
, long press the right button to enter
Hand Held
Vol Select
Birghtness
voltage gears of 9V/12V/15V/20V, after the switch is completed, the long press any button to exit, the default is 20V, and
the customer can set it according to the power parameters of the charger to avoid the phenomenon that the charger starts
over-current protection due to insufficient power, and the device is forced to shut down with a black screen. When this
phenomenon occurs, just wait for the charger to recover, and enter the setting page to re-select the appropriate gear when
there is no heating or no soldering iron tip.
●The product will automatically shut down after 30 minutes of inactivity in the dormant state

7.Firmware upgrade

●The device is powered off, press the left button, use the USB Type-c data cable to connect the computer to power on the
device, and enter the Bootloader interface to upgrade the firmware.
●Choose the corresponding serial port number, open the selected file when ready is displayed on the left, and click to burn.
switch left and right, and long press any key to exit when the switch is complete.
中文
English
,switch left and right, long press any key to exit after switching is
Left
Right
9 12 15
17
,after entering, switch left and right to the four
20
,
Child Lock
Language
Hand Held
,
Language
Hand Held
Vol Select
