USING THE AIR PUMP
1. Connect the air hose to the air pump by screwing the hose into
the end of the Air Pump.
2. Connect the other end of the air hose to the valve stem of the
item you are inflating. Adaptor is needed before inflating sport
balls including soccer, basketballs and footballs.
Air
Pump
NOTE: When inflating items of 10 PSI or less, inflate in short
bursts and check after each burst by feel or with a calibrated
measuring device to determine accurate pressure. Pressure
required for most sports balls is too low for accurate reading
on tool gauge.
3. Connect air pump to power (choose either of the 3 options
mentioned in previous section).
TECH-5000P
See detailed diagram below
Screw air hose
to air pump here
Air
Hose
Adapter Pins (if needed)
Power
Button
Vehicle Tires
Narrow
Ball Pin
Adaptor
Adaptor
Wide
Adaptor
Other Inflatibles
Requiring Adapter Pins
