REAR VIEW
1
1
Mains Power Cord supplies power to recorder.
pg. 4
2 AV1 IN / O U T Connector enables AV connec-
tion to TV or second recorder; input recordable
when "AU-1" selected.
3 ANT. IN Connector enables connection of aerial.
pg. 4
DISPLAY PAN EL
1
1 B.E.S.T. Picture System D isplay lights from
bottom to top while B.E.S.T. is active.
2
Symbolic M ode Indicators
PLAY:
FF/REW VARIABLE
SHUTTLE SEARCH:
3 "Timer" Indicator lights when TIMER has been
pressed to engage Timer mode.
4
PD C Indicator lights when PDC has been
engaged for timer recording.
5 Counter M emory Indicator lights when the
video recorder is in the Counter Memory mode.
pg. 15
6 Channel D isplay shows preset position where
the station currently being received is stored.
(Ex.) Preset position 1 will be displayed as "CH 1".
M ode shows external input mode selected.
Clock D isplay shows current time.
Downloaded from: https://www.usersmanualguide.com/
pg. 4, 28
2 3 4 5
SPLPEP
REMAIN
8 9 0
pg. 20
STILL:
SLOW:
RECORD:
RECORD PAUSE:
pg. 23, 25
pg. 22, 24
pg. 9, 42
2
AV1 IN / OUT
AV2 IN
4
4
AV2 IN Connector enables connection of
satellite receiver or second recorder; input
recordable when "AU 2" selected.
5
RF O U T Connector enables connection to
aerial terminal of TV receiver.
6
M
7 Instant REVIEW Indicator blinks after timer-
recording and shows how many programmes
have been timer-recorded.
8
"Cassette Loaded" M ark lights once a cassette is
inserted; remains lit until cassette ejected or
power turned off.
9
Tape Speed Indicators display mode of record-
ing; light during Record or Play mode.
* EP is for NTSC playback only.
0
Tape Remaining Time Indicator displays time
remaining on tape when certain buttons are
pressed.
!
Counter shows time elapsed since playback or
recording began.
REM AIN displays time remaining from current
tape position to end of tape.
Counter, Preset Position*, Clock and REMAIN
Display appear alternately when D ISPLAY is
pressed.
* Preset Position is not displayed during playback.
3
ANT. IN
RF OUT
5
7
REVIEW
!
pg. 14
pg. 19
49
pg. 30, 28
pg. 4
pg. 18
