OUTLINE DIMENSIONS

Dimensions shown in inches and (mm).
28-Lead SSOP
(RS-28)
0.407 (10.34)
0.397 (10.08)
28
1
0.078 (1.98) PIN 1
0.068 (1.73)
0.0256
0.015 (0.38)
0.008 (0.203)
SEATING
(0.65)
0.010 (0.25)
0.002 (0.050)
BSC
32-Leadless Chip Scale Package (LPCC)
(CP-32)
0.205 (5.20)
0.197 (5.00) SQ
0.189 (4.80)
0.010
(0.25)
REF
0.002 (0.05)
0.020 (0.50)
0.001 (0.02)
BSC
0.000 (0.00)
CONTROLLING DIMENSIONS ARE IN MILLIMETERS
DIMENSIONS MEET JEDEC MO-220-VHHD-2
15
14
0.07 (1.79)
0.066 (1.67)
8° 0.03 (0.762)
0°
0.022 (0.558)
0.009 (0.229)
PLANE
0.005 (0.127)
0.128 (3.25)
0.106 (2.70) SQ
0.049 (1.25)
25 32
PIN 1
1
24
INDICATOR
0.015 (0.38)
0.012 (0.30)
BOTTOM
VIEW
0.009 (0.23)
17 0.018 (0.45)
8
9 0.016 (0.40)
16
0.014 (0.35)
0.138 (3.50) BSC
0.039 (1.00)
0.035 (0.90)
0.031 (0.80)
