- Page 1 OWNERS’S MANUAL 19-38 Combo Brush 110 Volt Cord Installation Lagunatools.com...
- Page 2 Confirm power cord is NOT plugged in before installation. Confirm power cord and plug are designed and rated for 110 Volt/15 amp, 14 gauge minimum, with ground. IMPORTANT: Refer to picture and diagram on next page when following these instructions. IMPORTANT: GFIC protected receptacles tend to trip unnecessarily (e.g.
- Page 3 Hot (black) terminal clamp connection with orange clamp Neutral (white) terminal clamp connection with orange clamp Neutral Connection (white) Ground Connection (green) Strain Relief Tension Nut Power Cord Hot (live, Connection (black)
- Page 4 LAGUNA TOOLS 744 Refuge Way Suite 200 Grand Prairie TX 75050 Ph: 800.234.1976 www.lagunatools.com 041122...
