baby&child ARIANE Assembly Instruction

Parts Included
A [1] DRESSER
B [4] FOOT
T O O L S N E E D E D
- Phillips head screwdriver (not provided)
ASSEMBLY INSTRUCTION
Note: On the bottom of the dresser are holes with pre-installed nuts
that correspond to the threaded rods pre-installed in the legs.
1. Align and insert the threaded rod of the leg into the hole and
turn clockwise to tighten. Please see sketch below.
2. Attach one of the mounting brackets near the top back edge of
the furniture piece by inserting the shorter screws.
3. Determine the final position of the furniture piece. Mark
location on the wall approximately 2" below the bracket
mounted to the back of the furniture.
4. Drill a starter hole into the wall stud. If wall stud is not available,
drill a hole into the wall and insert plastic anchor. Gently tap the
anchor until the flange of the anchor is flush with the wall.
5. Attach the second bracket by inserting the longer screw
through the bracket and into the wall.
6. Place the furniture so the bracket on the back edge is in line
with the bracket in the wall.
7. Lace one end of the nylon restraint strap down through each
bracket. Bring both ends together and slide the beaded end until
it snap locks into the keyhole slot.
8. To double lock; return the beaded end back through the
keyholes as shown.
9. Check to make sure the Restraint strap is securely laced and
locked to the brackets.
NO.
1
2
3
4
5
B
A
ITEM DESCRIPTION
Plastic brackets
Restraint straps
Phillips screws M4x30mm
Phillips screws M4x20mm
Plastic anchors
A
B
QTY.
4pcs
2pcs
4pcs
4pcs
4pcs
