- Page 1 ML4035 | User Manual ML4035 User Operation Manual www.multilaneinc.com multilaneinc.com...
- Page 2 (c)(1) and (2) of the Commercial Computer Software -- Restricted Rights clause at FAR 52.227-19, as applicable. MultiLane SAL products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material. Specifications and price change privileges reserved.
-
Page 3: Table Of Contents
ML4035 | User Manual Contents General Safety Precautions .......................... 5 Preface ................................5 Contact MultiLane SAL ..........................6 Product Description: ............................. 7 Overview ..............................7 Model and Package Content ........................8 Hardware Package ..........................8 Software Package..........................8 API Library and Documentation......................8 User Guide and Documentation ...................... - Page 4 Figure 1: ML4035 GUI Main Page ....................... 10 Figure 2: ML4035 Front View ........................11 Figure 3: ML4035 connected to PC via Ethernet ..................12 Figure 4: ML4035 connected to PC Wirelessly ................... 12 Figure 5: ML4035 with USB connection ..................... 13 Figure 6: Connect Via Ethernet ........................
-
Page 5: General Safety Precautions
Refer to the power section to know the power dissipation values Preface This is the user operation manual for the ML4035. It covers the following information: ▪ Describes the capabilities of the instrument: How to install it and its software. -
Page 6: Contact Multilane Sal
(Architecture, PRD, HW/FW/SW design implementation and characterization). Address MultiLane SAL Houmal Technology Park Askarieh Main Road Houmal Website www.multilaneinc.com Sales support sales@multilaneinc.com Support support@multilaneinc.com If any further help is needed, please contact MultiLane SAL, by sending general enquiries to info@multilaneinc.com. multilaneinc.com... -
Page 7: Product Description
The state-of-the-art solutions we provide are fully automated and engineered for the sole purpose of providing our customers with accurate and reliable measurements while also saving them valuable time. Multilane’s ML4035 is the newest kid on the block, joining our large and diverse collection of successful products. -
Page 8: Model And Package Content
It also includes a reference clock input port as well as an external reference clock output port. Software Package The ML4035 package includes the driver as well as multiple SW for different applications (free of charge). • ML-TDA GUI: Default GUI which allows full user control over the ML4035 and manual measurements. -
Page 9: Key Features
ML4035 | User Manual Key Features • High Resolution TDR/TDT measurements • Determination of the magnitude and polarity of any back reflected signal • Quadruple differential 56GBd NRZ/PAM4 Pulse Pattern Generator • Quadruple differential Error Detector • Quadruple differential TDR & 35GHz Digital Sampling Oscilloscope •... -
Page 10: Product Software
ML4035 | User Manual Product Software Figure 1: ML4035 GUI Main Page The instrument includes the following software & driver: ▪ ML4035 TDA SW ▪ ML4035 ETH Configuration Software. ▪ MultiLane ML4035 USB driver. Instrument GUI runs on Windows XP (32/64 bit), Windows 7,8 and 10. -
Page 11: Hardware Overview
ML4035 | User Manual Hardware Overview With a total of 24 ports, the ML4035 allows 400G BER tests, NRZ & PAM4 eye diagram measurements, as well as medium impedance characterization and S-parameter evaluation on 4-channels simultaneously. Figure 2: ML4035 Front View... -
Page 12: How To Connect This Instrument
ML4035 | User Manual How to connect this instrument This section covers the connection options of the instrument, addressing the following topic: ML4035 Fast Ethernet / USB Connections method. ▪ NOTE. This release supports Ethernet connection for the software applications (note that the IP should be in the same range of the network). -
Page 13: Connecting Through Usb Cables
ML4035 | User Manual Connecting Through USB cables Connect a USB Mini-B type cable between the instrument and the PC. This connection method is only used to upgrade the firmware. Figure 5: ML4035 with USB connection multilaneinc.com... -
Page 14: Installation
ML4035. Connect to the Instrument via Ethernet: • Connect an ethernet cable between the PC and the ML4035’s RJ45 connectors to be able to control it. • In order to connect via Ethernet, the IP address of the board is required. -
Page 15: Figure 7: Ethernet Configuration
ML4035 | User Manual Figure 7: Ethernet Configuration The instrument is now powered up and connected through Ethernet. In the next section, the measurements that can be performed by the ML4035 along with the needed calibrations will be addressed. multilaneinc.com... -
Page 16: Standard Software (For Characterization And R&D)
The ML4035’s uppermost ports act as both receivers and transmitters. This allows them to transmit a fast 12ps rise time pulse and receive its reflections then display it with respect to time. -
Page 17: Tdr Measurement
One of the most popular applications made possible by TDR is cable matching. To match cables using the ML4035 and its software, first start by connecting up to four cables to the negative port the four available differential channels and terminate the positive ports with 50Ω. -
Page 18: Figure 11: Cable Matching
ML4035 | User Manual Figure 11: Cable Matching Figure 12: TDR Measurement multilaneinc.com... -
Page 19: Locating Faults & Discontinuities
Figure 13: Velocity of Propagation Insertion Loss In addition to time-domain reflectometry, the ML4035 provides frequency domain S-parameter measurement capability. As opposed to a traditional frequency-domain network analyzer that would use a frequency sweep for these measurements, Multilane’s time-domain equivalent solution takes... -
Page 20: Calibration
• Select the channel(s) on which the calibration will be performed. • Click on “Calibration” followed by “Run” to start the calibration process. • Connect the ML4035’s selected PPG channels (labeled “TX”) to the reference circuit’s inputs and the DSO channels (labeled “CH”) to their respective outputs and press “Confirm”. -
Page 21: Figure 16: S21 Calibration Wizard
ML4035 | User Manual Figure 16: S21 Calibration Wizard Figure 17: S21 Calibration Plot multilaneinc.com... -
Page 22: Insertion Loss Measurement
ML4035 | User Manual Insertion Loss Measurement • After completing the calibration, disconnect the reference circuit and connect the ML4035’s transmitting channel to the DUT’s input. • Connect the DUT’s output to the ML4035’s receiving channel. • Measurements can either be differential or single ended. For single ended measurement, only the negative port is used for each channel and the second is terminated with a 50Ω... -
Page 23: De-Embedding
Figure 21: De-Embedding Return Loss The ML4035’s TDR/DSO ports can also be used to measure insertion loss. Similarly to insertion loss, the ML4035 performs a TDR measurement in time domain and then converts it to the frequency domain, resulting in return loss measurements. -
Page 24: Gating
• Click on “Calibration” followed by “Run” to start the calibration process. • As instructed by the calibration wizard, successively terminate the cables coming out of the ML4035’s TDR/DSO channels with 2.92mm open, 50Ω, then short connectors, pressing “Next setup” between each step. -
Page 25: Return Loss Measurement
ML4035 | User Manual • Apply markers at the points of difference between the main setup’s impedance profile and the other two and press “Apply Gating”. • Close the page to exit the calibration wizard. Figure 25: Applying Markers Return Loss Measurement •... -
Page 26: Figure 26: Return Loss Measurement
ML4035 | User Manual Figure 26: Return Loss Measurement Measurements and masks can be loaded in the software by pressing “Measurement” on the bottom right side of the page. The available measurements for return loss are loss at Nyquist and the return loss mask,...
