Commercial Series TriTech and TriTech AM
detectors
6.3

EOL resistor loop combinations

Notice!
i
When wiring the detector, use either external resistors wired into the terminals, or the built-
in resistors for the same output. Do not use both.
6.3.1

Single EOL loop - Alarm and Tamper

TriTech
Bosch Security Systems B.V.
9 to 15 VDC
2 1
Tritech
NC NC T
NC
NC
1
2
Installation manual
T
T
T
1 2
2022.01 | 01 | F.01U.401.708
Wiring | en 23
1
