ICAM-520/500 Series
Smart Camera
Startup Manual
Packing List
Before installation, please ensure that the following items
have been included in your shipment:
1. ICAM-520/500 smart camera x 1
2. Startup manual x 1
If any of the above items are missing or damaged, contact
your distributor or sales representative immediately.
Caution: DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED. REPLACE ONLY WITH THE
SAME OR EQUIVALENT TYPE RECOMMENDED BY THE
MANUFACTURER, DISCARD USED BATTERIES AC-
CORDING TO THE MANUFACTURER'S INSTRUCTIONS.
Attention: DANGER D'EXPLOSION SI LA BATTERIE EST
INEXACTEMENT REMPLACÉE. REMPLACEZ SEULE-
MENT AVEC LA MÊME CHOSE OU LE TYPE ÉQUIVA-
LENT RECOMMANDÉ PAR LE FABRICANT, JETTENT
LES BATTERIES UTILISÉES INSTRUCTIONS DE S
SELON FABRICANT DES'.
For more information on this and other Advantech
products, please visit our website at
http://www.advantech.com
For technical support services, please visit our support
website at
http://support.advantech.com
This manual is for the the ICAM-500/520.
Part No. 204V050000
Printed in Taiwan
Edition 1
December 2022
Specifications
Sensor
• SONY IMX296, 1.6MP @ 60fps , Global shutter, Mono-
chrome/Color
Processor
• ICAM-520:
NVIDIA Xavier NX
6-core NVIDA Camel ARM
CPU: 6MB L2 + 4MB l3 (Max. operating frequency:
1.9GHz)
GPU: 384-core NVIDIA Volta GPU with 48 Tensor
• ICAM-500:
NVIDIA Jetson Nano
CPU: Quad Core ARM Cortex A57 (Max. operating
frequency: 1.43GHz)
GPU: Maxwell GPU, 128 CUDA core, performance up to
512 GFLOPS (FP16)
Image Signal Processor
• Mono: Brightness, Sharpness, Dark noise correction
(Default enable)
• Color: Brightness, Color debayering, Sharpness, Auto
with balance and CCM
Memory, Storage
• ICAM-520:
NVIDIA Xavier NX
8 GB LPDDR4/16GB eMMC
• ICAM-500
NVIDIA Jetson Nano
4 GB LPDDR4/16GB eMMC
Optical
• 12 mm variable focal length:
FOV 40 x 29.3 mm @ 100 mm working distance
FOV 364.5 x 263.7 @ 900 mm working distance
• 16mm variable focal length:
FOV 33.9 x 25.3 mm @ 100 mm working distance
FOV 305.4 x 228.2 @ 900 mm working distance
• LED illumination:
8 x PWM white/red LEDs, programmable
Synchronization
• Hardware Trigger/software Trigger/free-run
ICAM-500/520 Startup Manual 1
