Complete Soft Top, CJ & YJ with Full Doors
2
3
5
PHONE: M-F 8am - 5pm EST 1-800-449-6649 | EMAIL: techsupport@omix-ada.com
1
2
8
Components
1. Main Skin......................................................................(1)
2. Quarter Windows(Left and Right).............................(2)
3. Rear Window...............................................................(1)
4. Bow Assembly w/ Connecting Tubes........................(1)
5. Tailgate Bar w/ Mini Tonneau & Hardware..............(1)
6. Off-Road Organizer....................................................(1)
7. Soft Top Storage Bag..................................................(1)
8. Windshield Channel w/ Hardware............................(1)
9. Tub Belt Rail Kit w/ Hardware.....................................(1)
OMIX-ADA
FOR WARRANTY INFORMATION VISIT: www.Omix-Ada.com
Copyright © 2020 Omix-Ada
6
TECHNICAL SUPPORT
®
, Inc.
®
Part # 13782.35
4
7
9
Page 1/10
