blackburn OUTPOST BIKE & CAMP 7108800 Quick Start Manual

OUTPOST BIKE & CAMP
Multi-Purpose Front Light
Éclairage avant multi-usages
Part# 7108800

ON/OFF:

1. Push button to power on.
2. Click to cycle modes.
3. Hold down 1 second to power off.
Light powers back on in the last mode used.

FUEL GAUGE:

GREEN = 100% to 75% battery capacity
ORANGE = 75% to 25% battery capacity
RED = <25% battery capacity
When battery capacity is 25-35 minutes or less, red indicator
light will remain on constant until light reaches 0%.
Indicator will flash green when fully charged.
Fully charge light before first use.

BIKE MODE:

1. Secure light to handlebar with supplied mount.
2. Tap power button once for BIKE MODE. (Power button will be green)
3. Select mode. See chart.

CAMP/headlamp MODE:

1. Double-tap power button for CAMP MODE, (power button will be blue).
2. Gently pull Hook/Cord away from the light body.
3. Secure Hook to Catch.
4. Place around your forehead, lens facing forward.
5. Press Retraction button, cord will gently form to your forehead.
6. Use appropriate light mode as needed.
Removal: gently lift the headlamp/cord off your forehead, push down
and hold the Retract button.

AMBIENT LIGHT:

1. Place on flat surface or use cord to hang from a fixed object.
2. Double-tap power button for CAMP MODE, (Power button will be blue).
3. Extend the silicone diffuser shade.
Use appropriate mode as needed. See chart.
CLEANING & storage:
Keep the light clean and dry. Wipe off dust/dirt after each use.
Never submerge the light in water.
WARNING: WHILE IN USE, THE LIGHT WILL BECOME HOT TO THE TOUCH. USE WITH CAUTION. NEVER LET CHILDREN PLAY WITH THE LIGHT.
FOLLOW ALL INSTRUCTIONS CAREFULLY. MISUSE OF THE LIGHT MAY CAUSE INJURY. WHEN USING HOOK AND CATCH, BE SURE THEY ARE
ENGAGED PROPERLY PRIOR TO RETRACTION - FAILURE TO DO SO COULD LEAD TO SERIOUS EYE INJURY. TO REDUCE THE RISK OF STRANGULATION,
DO NOT PLACE THE LIGHT CORD AROUND YOUR NECK. DO NOT STARE DIRECTLY INTO THE BEAM OR SHINE IT DIRECTLY INTO THE EYES OF ANYONE
AROUND YOU. ALWAYS CARRY A SECOND SPARE LIGHT AND BATTERIES. THIS LIGHT IS EXTREMELY BRIGHT – DO NOT AIM DIRECTLY INTO EYES.
UK ONLY: WHEN USED FOR CYCLING, THIS LIGHT SHOULD BE USED IN CONJUNCTION WITH BRITISH STANDARD 6102/3 CYCLE LIGHT.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or
relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit di erent from that to which the receiver is connected. •
Consult the dealer or an experienced radio/TV technician for help. Shielded interface cable must be used with the equipment in order to comply with the limits for a digital device pursuant to Subpart B of
Part 15 of FCC Rules. Speci cations and designs are subject to change without any notice or obligation on the part of the manufacturer.
™
HOOK / 2FT CORD
CORDON DE CROCHET
KORDEL EINHAKEN
RETRACT BUTTON
SE RÉTRACTER
EINFAHREN
DIFFUSER
DOUX
WEICH
BIKE MODE
FL-1 STANDARD
CAMP/LANTERN MODE
FL-1 STANDARD
IP-65
POWER/FUEL
MARCHE/ARRÊT/JAUGE DE CHARGE
EIN/AUS/KAPAZITÄTSANZEIGE
CATCH
AGRAFE
BLITZ LOW STROBE
400 200
200
LUMENS LUMENS
LUMENS
1 2 8
hr
hrs hrs
HIGH LONG BURN
100 40
LUMENS LUMENS
3.5
8
hrs hrs
FL-1 STANDARD
1
m
BIKE MODE
MODE VÉLO
FAHRRADMODUS
QUICK RECOIL, USE CAUTION.
ENROULAGE RAPIDE, À UTILISER AVEC PRÉCAUTIONS.
VORSICHT GUMMIZUG – KANN BLITZSCHNELL ZURÜCKSCHNAPPEN!
CAMP/HEADLAMP MODE
LAMPE FRONTALE
CAMPING-/STIRNLAMPENMODUS
CAMP/HEADLAMP MODE
LAMPE FRONTALE
CAMPING-/STIRNLAMPENMODUS
CAMP/HEADLAMP MODE
LAMPE FRONTALE
CAMPING-/STIRNLAMPENMODUS
