Summary of Contents for blackburn Neuro

Page 1 ENGLISH...
Page 2: Table Of Contents
PROGRAM HEART RATE LEVELS SHIPPING AND SLEEP MODES OPERATING THE HEART MONITOR CHANGING THE BATTERY IN THE BLACKBURN NEURO CYCLOMETER PROGRAM ALTIMETER CHANGING THE BATTERY IN THE WIRELESS SPEED & CADENCE TRANSMITTER OPERATING THE RIDE TIME AND TOTAL TIME CHRONOGRAPHS...
Page 3: Warnings And Cautions
Blackburn has gone to great expense to assure these are the WARNING—Blackburn cyclometers and heart rate monitors are training and fitness tools. Before beginning finest and most reliable cyclometers you can buy.
Page 4: Care And Maintenance
CARE AND MAINTENANCE FCC & CE WARNINGS Blackburn cyclometers contain many delicate electronic components which may be damaged by excessive CE—The CE logo is used to mark compliance with the European Union exposure to heat, shock or general abuse. Treated with care, your cyclometer is capable of delivering many Directives 89/336/EEc and 99/5/EEC years of reliable service.
Page 5 All Blackburn Neuro models are capable of monitoring heart rate using our new 2.4GH UHF digital transmission transmission system offers significant performance advantages over previous generations of wireless system. If your Neuro unit was not supplied with a heart rate transmitter one may be purchased from your cyclometers.
Page 6: How This Product Works
ZIP- TIES front can change the current altitude display by several hundred feet or more. To simplify the calibration process the Blackburn Neuro allows you to store your home altitude to memory and HEART RATE TRANSMITTER calibrate the unit to this altitude at any time using a PRESS &...
Page 7: Resetting The Computer To Its Default Settings
DEFAULT SETTINGS Two “hidden” keys are located on the bottom of the computer each with specific SHIPPING MODE—Your new Blackburn Neuro computer comes to the dealer in SHIPPING MODE. In this mode ALL CLEAR KEY (AC) functions. Use a toothpick or other small pointed object to press these keys and the LCD display is totally blank.
Page 8: Changing The Battery In The Blackburn Neuro Cyclometer
CYCLOMETER CADENCE TRANSMITTER Blackburn Neuro computers are powered by a CR2032 3v Lithium Battery. Under normal conditions, this battery The Wireless Speed & Cadence Transmitter uses a CR 2032 3v Lithium battery. Under normal conditions, you should last for approximately 300-350 hours depending on the quality of the battery.
Page 9: Changing The Battery In The Heart Rate Transmitter
Neuro 5.0 and 6.0 units are supplied from the factory with heart rate transmitters. The Neuro 4.0 unit can be upgraded to heart rate functionality with the additional purchase of a Blackburn Digital heart rate transmitter from your Blackburn dealer.
Page 10: Keys And Their Functions
KEYS AND THEIR FUNCTIONS QUICK PRESS VS. PRESS & HOLD There are two key actions used to program and operate the Neuro computer. QUICK PRESS—The key is pressed quickly and then immediately released. This is the most common key action and is used for most operations.
Page 11 KEYS AND THEIR FUNCTIONS KEYS AND THEIR FUNCTIONS C Y C L O M E T E R...
Page 12: Sections Of Lcd Display
SECTIONS OF LCD DISPLAY SECTIONS OF LCD DISPLAY �� C Y C L O M E T E R...
Page 13 �� SECTIONS OF LCD DISPLAY SECTIONS OF LCD DISPLAY LOWER DATA WINDOW The Lower Data Window shows a wide range of secondary functions. This window is controlled by the MODE and OPTION keys. Pressing the MODE key scrolls through the following primary information groups.
Page 14: Bike One/Bike Two Setting
BIKE ONE/BIKE TWO SETTING PAIRING TRANSMITTERS TO THE COMPUTER UNIT Blackburn Neuro Computers allow you to program two separate bike functions. Most functions are totally Each Speed/Cadence and Heart Rate transmitter is programmed with its own unique signal which must be independent.
Page 15 BEFORE the system will allow you to pair a heart rate or second bike transmitter. (Complete second bike Lower Data Line will show DONE along with the SPD and CAD Icons above it for kits are available from your Blackburn Retailer) a period of 5-seconds, before advancing automatically to the pairing sequence 2.
Page 16: Installing The Computer On Your Bike
All Blackburn Neuro cyclometers are heart rate compatible. If your unit was not supplied with a Heart 3. Adjust and position the sensor and magnet so they pass within 1-3mm of each other. Fully tighten the zip- NOTE: ties once you have everything properly aligned.
Page 17 Do not over tighten the mounting screw or you may damage the bracket. There are two molded plastic shims supplied with the Neuro computer brackets. The THIN shim allows NOTE: the bracket to fit Oversized 31.8 mm handlebars. The THICK shim allows the bracket to fit standard 26.0mm handlebars.
Page 18: Linking Transmitters To Computer For Use
LINK FROM SLEEP MODE computer should LOCK into the bracket with an AUDIBLE “CLICK”. If you do not hear a click or if the Neuro computer body is not flush with the back edge of the bracket the computer is not locked in place and may come Any time the computer is activated out of SLEEP MODE, the LINK sequence starts out.
Page 19: Basic Operation
�� Once you have paired separate transmitters for Bike 1 and Bike 2, your Blackburn Neuro will automatically recognize which bike it is mounted on during the LINK process and configure itself accordingly. �� ...
Page 20 BASIC OPERATION BASIC OPERATION UPPER DATA WINDOW FLOW SEQUENCES STEP BY STEP—CHANGING THE UPPER DATA WINDOW INFORMATION 1. By Default the Upper Data Window is Blank (no display data) when you install a new battery. This diagram shows the information which is displayed in the Upper Data Window. You may choose to show 2.
Page 21: Program Wheel Size, Units And Chronograph
Circumference MEASURED WHEEL SIZE Blackburn Neuro Computers use the rolling circumference of your wheel and tire combination to determine speed and distance. The more accurate this setting, the more accurate your ride information will be. However, If your wheel/tire size is not one of the pre-programmed sizes, or if you desire absolute accuracy, you may variations of less than 30mm from the actual circumference will have very little impact on the overall accuracy enter an exact wheel circumference into the system.
Page 22 PROGRAM WHEEL SIZE, UNITS AND CHRONOGRAPH PROGRAM WHEEL SIZE, UNITS AND CHRONOGRAPH MEASURING WHEEL SIZE USING ROLLOUT METHOD STEP BY STEP—ENTER A PRE-PROGRAMMED WHEEL SIZE 1. From Sleep Mode, press any key twice to bypass the LINK Sequence. You may also program the unit The roll-out method is the most accurate method for determining the circumference of your wheel/tire after the unit has completed the LINK sequence and is active.
Page 23 �� PROGRAM WHEEL SIZE, UNITS AND CHRONOGRAPH PROGRAM WHEEL SIZE, UNITS AND CHRONOGRAPH �� ...
Page 24: Odometers, Weekly And Annual Ride Time
ODOMETERS, WEEKLY AND ANNUAL RIDE TIME STEP BY STEP—SET SPEED AND DISTANCE UNITS In addition to tracking data for individual rides, your new Blackburn Neuro cyclometer comes with a highly- 1. Upon entering the SET Speed and Distance units display, M/H (Miles per Hour) advanced long term ride memory system which tracks your weekly and yearly ride time and distance.
Page 25 �� ODOMETERS, WEEKLY AND ANNUAL RIDE TIME ODOMETERS, WEEKLY AND ANNUAL RIDE TIME ODOMETERS, WEEKLY AND ANNUAL RIDE TIME DISPLAYS STEP BY STEP—SETTING THE PROGRAMMABLE ODOMETERS 1. From Sleep Mode, press any key twice to bypass the LINK Sequence. You may also program the unit after the unit has completed the LINK sequence and is active.
Page 26: Program Time Of Day
STEP BY STEP—SETTING THE TIME OF DAY Blackburn Neuro Computers are equipped with a clock which shows time of day in either 12 or 24 hour formats. There is also a programming option which allows you to turn the clock off so it does not show up in the normal operation sequence, reducing the number of key strokes needed to move through the displays.
Page 27: Program Heart Rate Levels
2. Starting in the Heart Rate Display in the Lower Data Window. system. Once programmed, the Neuro heart rate system will track the amount of time you have spent in each of your 5 levels as well as displaying your heart rate and current training level on the display in real time. The PRESS &...
Page 28 PROGRAM HEART RATE LEVELS OPERATING THE HEART MONITOR STEP BY STEP—SETTING THE HEART RATE ZONE Once you are wearing a properly paired heart rate transmitter and have performed the LINK sequence, the operation of the Heart Rate Monitor system is automatic. When a heart rate display is selected in the Upper or Lower Data Window your heart rate reading will display automatically.
Page 29: Operating The Heart Monitor
REVIEW HEART RATE DYNAMIC MEMORY The Neuro 6.0 is equipped with an extremely sensitive pressure sensing altimeter with a resolution of 1’ or 0.5m. The altimeter system will display your current altitude, your distance climbed and your current % Grade. The The Neuro units are equipped with an exclusive feature called DYNAMIC MEMORY™.
Page 30 The Neuro 6.0 calculates % grade using distance and the changes in altitude NOTE: measured by the altimeter. The grade display is updated once every 2-4 seconds using the distance and altimeter data from the previous 20-seconds.
Page 31: Operating The Ride Time And Total Time Chronographs
From an initial reading of zero, the Total Time Chronograph starts automatically as soon as it sees a speed The Neuro computers allow you to clear the Maximum Speed and Cadence values independently of all other input or is manually started using a QUICK PRESS of the START/STOP key.
Page 32: Operating The Lap Chronograph/Interval Chronograph System
INTERVAL CHRONOGRAPH SYSTEM STEP BY STEP—PROGRAMMING THE LAP/INTERVAL CHRONOGRAPH Blackburn Neuro cyclometers come with a second, independent and highly sophisticated chronograph system which is capable of being programmed to track individual laps or to prompt the user through an interval (CONTINUED) workout.
Page 33 OPERATING THE LAP CHRONOGRAPH/ OPERATING THE LAP CHRONOGRAPH/ INTERVAL CHRONOGRAPH SYSTEM INTERVAL CHRONOGRAPH SYSTEM STARTING AND STOPPING THE LAP CHRONOGRAPH STARTING AND STOPPING THE INTERVAL CHRONOGRAPH 1. Starting in the LAP Chronograph screen you will see LAP 1 and 0:00:00 alternating on the display every The operation of the Interval Chronograph system is slightly different than that second.
Page 34 OPERATING THE LAP CHRONOGRAPH/ OPERATING THE LAP CHRONOGRAPH/ INTERVAL CHRONOGRAPH SYSTEM INTERVAL CHRONOGRAPH SYSTEM REVIEWING THE LAP CHRONOGRAPH MEMORY STARTING AND STOPPING THE INTERVAL CHRONOGRAPH (CONTINUED) 1. Once you have finished timing a LAP you may review it and the stored information for the segment. From the Interval Chronograph display QUICK PRESS the START/STOP key to...
Page 35: Operating Race Display System
2. Only data from the WORK portion of each Interval is stored in memory. No information related to the Blackburn Race Display. When activated, the race display shuts off the active display of all of the Neuro’s ride REST portion is stored.
Page 36: Operating The Backlight System
OPERATING THE BACKLIGHT SYSTEM TECHNICAL DATA BATTERIES The Neuro units are equipped with Blackburn’s exclusive UltraNightglow™ electroluminescent backlight system for use when operating the unit is low light conditions. Computer Battery—CR 2032 3v Lithium Wireless Transmitter Battery—CR 2032 3v Lithium When activated, the UltraNightglow™...
Page 37: Warranty And Repair
TECHNICAL DATA WARRANTY AND REPAIR FUNCTIONS AND OPERATIONAL RANGES BELL SPORTS/BLACKBURN ELECTRONICS LIMITED LIFETIME WARRANTY (CONTINUED) FOR THE UNITED STATES AND CANADA INTERVAL Chronograph Function BELL SPORTS INC. hereby warrants, to the original purchaser, this product to be free from defects in material INTERVAL Time—25 Intervals—0:05—30:00 for both work and rest—5.0 second programming resolution.
