Additional Information; Specifications; Warranty - iLine microsystems microINR expert Instructions For Use Manual

10. ADDITIONAL INFORMATION

10.1 SPECIFICATIONS

• Dimensions of the meter: 164 x 70 x 43 mm.
• Weight: 370 g (battery included).
• Interface: High resolution capacitive color touchscreen (3.5 in) and barcode reader.
• Memory: 2,000 patient results / 500 plasma control results with their date and time.
• Power supply:
- Battery: Lithium 6,000 mAh; 3.7 V
- Power supply: Model No. GTM96180-1507-2.0 by GlobTek Inc.
- Input: 100-240V, 50-60 Hz, 0.6 A
- Output: 5V dc, 3A
• Battery life: *approximately 100 tests.
• Automatic power-off: programmable 5-15-30-45 or 60 min.
• Operation conditions:
- Temperature: 15 º C - 35 º C.
- Maximum relative humidity: 80%.
- Maximum altitude: 3.048 m.
- Keep the meter away from direct sunlight during the test.
• Meter storage and transport temperature: -20 º C to 50 º C.
• Measurement range: 0.8 – 8.0 INR (9.6 – 96.0 s).
• Sample volume: at least 3 µL.
• Bluetooth: Low Energy 5.0 backwards compatible with 4.X versions. Data transfer via Bluetooth through
proprietary communication protocol based on the standard 11073-10418.
• Wi-Fi: IEEE 802.11 b/g/n wireless connectivity. Data transfer via Wi-Fi through communication protocol
standard POCT1-2A.
• Ethernet: data transfer through communication protocol standard POCT1-2A and when connected to the
ethernet adaptor (available separately).
• Memory data extraction via USB-C connection.
*Test conducted at 22 º C with a 10-minute period between tests.

10.2 WARRANTY

iLine Microsystems guarantees that the microINR Expert meter is free of material and manufacturing
defects on the purchase date.
The statutory warranty provisions on consumer rights in relation to the purchase of goods in the country of
purchase shall apply.
This warranty does not cover component damaged due to inadequate storage in ambient conditions outside
the defined range, accidents or modifications, misuse or mishandling. The buyer must submit a written
warranty complaint to the manufacturer within the respective warranty period to claim indemnity for
material or manufacturing defects.
