  • Page 1 KWID vehicle user manual...
  • Page 3 It is well worth taking a few minutes to read this manual to familiarise yourself with the information and guidelines it contains about the vehicle and its functions and new features.If certain points are still unclear, our Renault authorised dealers will be pleased to provide you with any additional information.
  • Page 5 Sections Getting to know your vehicle ....... Driving ..............Your comfort ............Maintenance ............Practical advice ............ Technical specifications ........Alphabetical index ..........Radio ..............

  • Page 7: Table Of Contents

    Section 1: Getting to know your vehicle Keys, radio frequency remote control: general information ....... . Locking and unlocking the doors .

  • Page 8: Keys, Radio Frequency Remote Control: General Information

    KEYS, RADIO FREQUENCY REMOTE CONTROL: general information The remote control unit operating range This varies according to the environ- ment. It is therefore important when handling the remote control to ensure that you do not lock or unlock the ve- hicle by inadvertently pressing the but- tons.

  • Page 9: Locking And Unlocking The Doors

    LOCKING AND UNLOCKING THE DOORS Manual control Locking the doors without From the inside the radio frequency remote Push in button 2 to lock and lift button 2 From the outside control to unlock. It is impossible to open the Unlock the driver door using the key in door if 2 is pushed in.

  • Page 10: Opening And Closing The Doors

    OPENING AND CLOSING THE DOORS Opening the doors from the Opening from the inside Child safety outside Pull handle 2. If equipped, this feature is to make it im- possible for the rear doors to be opened With the doors unlocked (refer to the from the inside, move lever 3 on each information on “Locking/unlocking the rear door and check from the inside that...

  • Page 11: Engine Immobiliser

    ENGINE IMMOBILISER (Depends on vehicle) Any unauthorised work Engine Immobiliser prevents the ve- carried out on the engine hicle being driven by anyone not in immobiliser (computers, possession of the vehicle’s coded wiring, etc.) could be dan- ignition key. gerous. Work must be carried out by qualified personnel.

  • Page 12: Front Seats

    FRONT SEATS To tilt the seatback Lift knob 2 upward to unlock recliner mechanism.Tilt the seat back to desired position and release knob. Ensure seat back is locked properly after release. Move forward or backward Lift the lever 1 to release and move the seat forward or backward.Release the lever 1 in desired position of seat and For safety reasons, carry...

  • Page 13: Seat Belts

    SEAT BELTS (1/2) Adjusting your driving position (depending on the vehicle) – Sit well back in your seat (having removed your coat or jacket etc.). This is essential to ensure your back is positioned correctly. – adjust the distance between the seat and the pedals.
  • Page 14 SEAT BELTS (2/2) ß Seat belt reminder light(Driver/Front Passenger seats) It lights up when the ignition is ON and if the driver/front passenger (if seated) seat belt is not fastened, the light flashes and a beep sounds for about 2 minutes when the vehicle reaches a speed of approximately 20 Km/h and above.
  • Page 15 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (1/6) Depending on the vehicle, they will con- – Have the entire restraint sist of: system checked following – seat belt inertia reel pretensio- an accident. ners; – No operation whatso- –...
  • Page 16 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (2/6) Load limiter (in driver side) Airbags for driver and front passenger Above a certain severity of impact, this mechanism is used to limit the force of Fitted to the driver and passenger side. the belt against the body so that it is at The presence of this equipment is in- an acceptable level.
  • Page 17 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (3/6) Operating faults Operation å This system is only operational when This warning light 2 will light up the ignition is switched on. on the instrument panel when the igni- In a severe frontal impact, the air bags tion is switched on and then go out after inflate rapidly, cushioning the impact...
  • Page 18 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (4/6) The following cases cause the pre- In a frontal impact with another vehi- In a side impact with another vehicle tensioners or airbags to operate. cle of an equivalent or higher category, of an equivalent or higher category, at with an impact area equal to or greater an impact speed equal to or greater...
  • Page 19 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (5/6) In the following examples, the pre- In the following examples, the pre- – in the event of a side impact, affect- tensioners and airbags could oper- tensioners and airbags might not ing the front of the vehicle;...
  • Page 20 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (6/6) All of the warnings below are given so that the air bag is not obstructed in any way when it is inflated and also to prevent the risk of serious injuries caused by items which may be dislodged when the air bag inflates. Warnings concerning the driver’s air bag –...

  • Page 21: Child Safety: General Information

    CHILD SAFETY: general information (1/2) Carrying children Children, and adults, must be correctly seated and strapped in for all journeys. The children being carried in your vehi- cle are your responsibility. A child is not a miniature adult. Children are at risk of specific injuries as their muscles and bones have not yet fin- ished growing.
  • Page 22 CHILD SAFETY: general information (2/2) Using a child seat Child seat attachment via the seat belt Set a good example by always fas- The level of protection offered by the tening your seat belt and teaching child seat depends on ability to restrain The seat belt must be adjusted in your child: child and on its installation.

  • Page 23: Child Safety: Fitting A Child Seat

    CHILD SAFETY: fitting a child seat (1/4) Some seats are not suitable for fitting In the rear side seat child seats. The diagram on the follow- A carrycot can be installed across the ing page shows you how to attach a vehicle and will take up at least two child seat.
  • Page 24 CHILD SAFETY: fitting a child seat (2/4) The table below summarises the information already shown in the diagram on the following pages, to ensure the applicable regu- lations are respected. Seating Position Rear Outboard Weight of Front passenger Mass Group Rear Centre the child seat...
  • Page 25 CHILD SAFETY: fitting a child seat (3/4) Refer to the “Child safety equipment” booklet available from the network to choose the seat suited to your child and rec- ommended for your vehicle. X = Seat not suitable for fitting child seats. U = Seat which allows a child seat with “Universal”...
  • Page 26 CHILD SAFETY: fitting a child seat (4/4) Child seat attached using the belt ¬ Seat which allows a child seat with “Universal” approval to be attached by a seat belt. ² Seat not suitable for fitting child seats. Using a child safety system which is not approved for this vehicle will not correctly protect the baby or child.

  • Page 27: Mirrors

    MIRRORS Door mirrors without manual Door mirror with electrical Interior rear view mirror 4 adjustment lever adjustment 3 The interior rear-view mirror 4 is manu- ally adjustable. When driving at night, Adjust the door mirrors 1 according to – position A to adjust the right-hand tilt the mirror to avoid being dazzled by rear vision by touching the periphery of door mirror;...

  • Page 28: Driving Position, Right-Hand Drive

    DRIVING POSITION, RIGHT-HAND DRIVE (1/2) 1.22...
  • Page 29 DRIVING POSITION, RIGHT-HAND DRIVE (2/2) The presence of the equipment DEPENDS ON THE VEHICLE VERSION AND COUNTRY. 1 Left side air vent 10 Stalk 19 Hazardous switch 2 Left side speaker – direction indicator lights, 20 USB/AUX port(for changing + media connect) 3 Location for passenger airbag –...

  • Page 30: Warning Lights

    WARNING LIGHTS (1/4) The presence and operation of the warning lights DEPEND ON THE EQUIPMENT AND COUNTRY. á Main beam headlight tell-tale Over Speed Warning beep light. Primary Warning Dipped beam headlight tell- When vehicle speed exceeds around tale. 80 km/h (50 MPH), a beep sounds in- Left-hand direction indicator termittently until the driver reduces the tell-tale.
  • Page 31 WARNING LIGHTS (2/4) The presence and operation of the warning lights DEPEND ON THE EQUIPMENT AND COUNTRY.  Ò Handbrake “on” warning Warning light malfunction Power steering warning light and brake circuit inci- (red or orange) light dent warning light Warning light (orange) Warning light (orange) This comes on when the ignition is...
  • Page 32 WARNING LIGHTS (3/4) The presence and operation of the warning lights DEPEND ON THE EQUIPMENT AND COUNTRY. Ô Ä À Coolant temperature warn- Warning light for monitor- Oil pressure warning light ing display ing exhaust gas This comes when ignition is This bar display comes ON when igni- It comes on when the ignition is ON and goes out after few seconds.
  • Page 33 WARNING LIGHTS (3/4)  Warning light for the elec- tronic stability program (ESP) There are several reasons for the warn- ing light to come on: see “Electronic Stability Program ESC with understeer control and traction control” in Section 2  ESP OFF WARNING LIGHT This lights up when the igni- tion is switched on and goes out after...

  • Page 34: On-Board Computer

    ON-BOARD COMPUTER (1/3) d) Average Fuel Consumption (from For the first few kilometres after pres- last reset). sing the reset key you will notice that e) Current Fuel Consumption. the range increases as you travel. This f) Estimated Fuel range (DTE - distance range takes into account the average to empty).
  • Page 35 ON-BOARD COMPUTER (2/3) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Interpreting the display selected DISPLAY Total distance recorder Trip distance recorder Fuel used (since the last time the reset button was pressed) Average fuel consumption (since the last time the reset button was pressed) This value is displayed after driving 400 metres.
  • Page 36 ON-BOARD COMPUTER (3/3) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Interpreting the display selected DISPLAY Current fuel consumption Estimated range with remaining fuel Distance travelled (since the last time the reset button was pressed) Average speed (since the last time the reset button was pressed) 1.30...

  • Page 37: Exterior Lighting And Signals

    EXTERIOR LIGHTING AND SIGNALS á Main beam headlights With the dipped beam head- lights lit, push stalk 3. The indicator on instrument panel comes on.To return to dipped headlight,pull the stalk 3 upward. Switching off the lights Turn the end of stalk 3 until the symbol is opposite mark 2.

  • Page 38: Headlight Height Adjustment

    HEADLIGHT HEIGHT ADJUSTMENT Loading condition Position Only Driver Zero Driver + front passenger Zero Driver + Trunk Driver + All passengers Driver + All passengers+Trunk Headlight height Adjustment: Knob A is used to adjust height of the headlight beam according to load.Turn control A anticlockwise to lower the beams and clockwise to raise them.

  • Page 39: Audible And Visual Signals

    AUDIBLE AND VISUAL SIGNALS é Horn 1 Hazard warning lights Direction indicators Press on the centre or sides of the high- Press switch 2. Move stalk 3 parallel to the steering lighted (horn pad) to use the horn. wheel and in the direction you are going This switch activates all four direction to turn it.
  • Page 40 WINDSCREEN WASHING / WIPING Windscreen Washing If you switch off the ignition before switching off the windscreen wiper the With the ignition on, pull blade will stop at random on the wind- stalk 1 towards you(depending on the screen. After switching the ignition back version).

  • Page 41: Fuel Tank (Filling With Fuel)

    FUEL TANK (1/2) Fuel filler cap: this is specific to the vehicle type. If you have to replace it, make sure the new cap is of the same type. Contact an approved dealer. It is essential to use unleaded petrol. Using leaded petrol will damage the antipollution system and may lead to a loss of warranty.
  • Page 42 FUEL TANK (2/2) Filling up with fuel With the ignition off, insert the nozzle fully before turning it on to fill the fuel tank (risk of splashing). Keep the nozzle in this position throughout the entire filling operation. When the pump cuts out automatically at the end of the filling procedure, a maximum of two further filling attempts may be made, as there must be suffi-...
  • Page 43 Section 2: Driving (Advice on use relating to fuel economy and the environment) Running in, Ignition switch ............Starting / Stopping the engine .

  • Page 44: Running In, Ignition Switch

    RUNNING IN, IGNITION SWITCH Running in Ignition on position M For the first 1,000 km, do not exceed The ignition is switched on: 80 km/h in the highest gear. – the engine may be started. You may only expect top performance from your vehicle after approximately Start position D 3,000 kms.

  • Page 45: Starting/Stopping The Engine

    STARTING/STOPPING THE ENGINE Starting the engine Special note Depending on the vehicle, accessories In cold condition: switch on the ignition Never leave your vehicle (e.g. radio) stop working either when for several seconds before starting the with the key or remote con- the engine is switched off or when the engine, so that it is easier to start the trol inside and never leave...
  • Page 46 STARTING/STOPPING THE ENGINE Starting problems Operating faults such as: – faulty ignition, running out of fuel or To avoid damage , do not keep trying disconnected spark plugs resulting to start the engine (by pushing or towing in the engine misfiring or cutting out the vehicle) without having identified when driving.

  • Page 47: Gear Lever, Hand Brake

    GEAR LEVER, HAND BRAKE (1/2) Gear change indicators Depending on the gradient Depending on the vehicle, to obtain op- and/or vehicle load, it may timum consumption levels, an indicator be necessary when statio- light on the instrument panel lets you nary to apply the brake by know the best time to move up or down at least a further two notches and...
  • Page 48 GEAR LEVER, HAND BRAKE (2/2) Make sure that the hand- brake is properly released when driving (red indi- cator light off), otherwise overheating, or even damage, may occur. Handbrake Note: To release - Apply hand brake fully when par- Firmly press and hold the brake pedal. king on a slope;...

  • Page 49: Advice: Antipollution, Fuel Economy And Driving

    ADVICE: antipollution, fuel economy and driving (1/3) Engine adjustments Your vehicle has been designed with Have your vehicle adjusted and respect for the environment in mind checked by an authorised dealer, in ac- – ignition: this does not require ad- for its entire service life.
  • Page 50 (vehi- cle battery, oil filter, air filter, batter- ies, etc.) and oil containers (empty or filled with used oil) must be dis- posed of through authorised Renault Dealer. – In all cases, comply with local legis- lation.
  • Page 51 ADVICE: antipollution, fuel economy and driving (3/3) Exhaust gas monitoring – Poor weather conditions, flooded roads. Do not drive through water if it system is higher than the lower edge of the This system detects operating faults wheel rim. in the vehicle’s antipollution system. These faults may cause mechanical –...

  • Page 52: Driver Correction Devices, Aids

    DRIVER CORRECTION DEVICES, AIDS (1/4) ABS (anti-lock braking Depending on the vehicle, this is com- posed of: system) – the (anti-lock braking Under heavy braking, the ABS prevents system); the wheels from locking, allowing the In an emergency, apply firm and –...
  • Page 53 DRIVER CORRECTION DEVICES, AIDS (2/4) Emergency brake assist with Operating faults electronic brake distribution   – If the warning light on the in- (depending on the vehicle) strument panel comes on while you This system supplements the ABS are driving, the brakes will still and helps reduce vehicle stopping dis- work normally without ABS;...
  • Page 54 DRIVER CORRECTION DEVICES, AIDS (3/4) Electronic stability program Operating principle ESC with understeer control A sensor in the steering wheel detects and traction control the direction selected by the driver. Other sensors throughout the vehi- Electronic Stability Program ESC cle measure the actual direction. The (depending on the vehicle) system compares driver input to the This system helps you to keep control...
  • Page 55 DRIVER CORRECTION DEVICES, AIDS (4/4) Hill start assistance (depending on vehicle) This function assists the driver when starting on hills. It prevents the vehicle from rolling forwards or backwards by The hill start assistance automatically applying the brakes when system cannot completely the driver lifts their foot off the brake prevent the vehicle from pedal to depress the accelerator pedal.

  • Page 56: Tyre Pressure Loss Warning

    TYRE PRESSURE LOSS WARNING (1/5) Low t re pressure warning Operating conditions If the vehicle is being driven with low In the following situations, the system  risk coming into action late or not func- tyre pressure 1 will illuminate. tioning properly: When the low pressure warning light il- –...
  • Page 57 TYRE PRESSURE LOSS WARNING (2/5) – after switching the wheels of the Resetting procedure This function is an addi- same axle (you must not switch be- Ignition on, vehicle stationary: tional driving aid. tween the front and rear wheels). - press button B briefly several times The function does not take It should always be done after checking to select the function “SET TYRE...
  • Page 58 In the event of a puncture, change the The light remains on after one minute. tyre or consult an authorised dealer. contact your Renault dealer as soon as It is not recommended to drive the ve- possible for tyre replacement.
  • Page 59 TYRE PRESSURE LOSS WARNING (4/5) Tyre repair product and inflation kit System to be checked  Only use equipment approved by the Warning light 1 flashes for sev- network, otherwise the system risks eral seconds, then stays on. This warn- late activation or incorrect operation.
  • Page 60 TYRE PRESSURE LOSS WARNING (5/5) The information on the instrument panel signals any potential tyre pressure faults (e.g. deflated or punctured tyre). Text warning Indicator lights Messages Readings in cluster RR TYRE PR.LOW When the tire pressure loss warning is displayed in Yellow A d j u s t Ty r e RL TYRE PR.LOW...

  • Page 61: Automated Manual Transmission

    AUTOMATED MANUAL TRANSMISSION (1/4) Gear Rotary Shifter 1 Gear shift pattern Display This allows you to engage forward Align the letters R/N/D to the red The engaged gear (R/N/D) is indicated pointer. on the instrument panel display 2. gear, reverse and neutral. A where R/N/D stands for: In case, gear is not engaged properly, letter R or D will blink on the cluster...
  • Page 62 AUTOMATED MANUAL TRANSMISSION (2/4) Starting the engine Creeping Similar to a vehicle equipped Switch ON ignition. To start engine, Creeping moves the vehicle without with a manual gearbox, this keep the key in ignition and wait for pressing the accelerator pedal and vehicle is also not able to 3 seconds to initiate starting sequence.
  • Page 63 AUTOMATED MANUAL TRANSMISSION (3/4) Driving in automatic mode However, if the system does not shift When stopped at traffic lights, with the automatically, shift gear knob to “N” gear engaged in D, keep the vehicle When ignition is switched ON, start the and again shift to R/D in brake pedal stationary by continuously pressing the vehicle in neutral “N”...
  • Page 64 AUTOMATED MANUAL TRANSMISSION (4/4) Accelerating and overtaking Precautions in Drive mode Towing your automated manual transmission vehicle – Slowly press the accelerator pedal to – If the vehicle is kept stationary on a accelerate gradually. slope for too long without applying If the gear is engaged in R/D, the brakes or handbrake, it will strain –...

  • Page 65: Parking Distance Control

    PARKING DISTANCE CONTROL Operating principle Operating faults Ultrasonic sensors, fitted in the vehi- When the system detects an operating cle’s rear bumper, measure the dis- fault, there will be a three-second con- tance between the vehicle and an ob- tinuous beep as a warning. Please con- stacle when reversing.
  • Page 66 REVERSING CAMERA (1/2) Operation Note: make sure that the reversing This function is an addi- camera is not obscured (by dirt, mud, Depending on the variants,when tional aid. It cannot, there- snow, etc.). using reverse gear, the camera 1 fore, under any circum- sends a view of the area behind the stances replace the vigi- vehicle to the multimedia display 2 to-...
  • Page 67 REVERSING CAMERA (2/2) Static guide line 3: The static guide line 3 has coloured markers A, B and C showing the dis- The screen shows a reverse image. tance behind the vehicle: The frames are a representation This gauge remains fixed and indicates –...
  • Page 68 2.26...
  • Page 69 Section 3: Your comfort Air vents, air outlets ............. . Heating, Ventilation, Air conditioning .
  • Page 70 AIR VENTS, air outlets (1/2) 1 Left side air vents 2 Windscreen demisting vents 3 Centre air vents 4 Right side vents 5 Control panel 6 Driver footwell heater outlets 7 Front passenger footwell heater out- lets...

  • Page 71: Air Vents, Air Outlets

    AIR VENTS, air outlets (2/2) Air flow Centre Air Vents (depends on the vehicle) Lateral Air vents (Left and Right) – To move the front vanes up/down, – To open, press on the groove 2 until move the centre knob 4 upwards/ it is open as far as required.

  • Page 72: Heating, Ventilation, Air Conditioning

    HEATING, VENTILATION, AIR CONDITIONING (1/2) Adjusting the ventilation fan speed. Turn control 3 from 0 to 4. The further to the right it is positioned, the more air is blown into the passenger compart- ment. If you want to shut off the flow of air completely and stop the system, set control 3 to 0.
  • Page 73 HEATING, VENTILATION, AIR CONDITIONING (2/2) Switching passenger Rapid demisting Air recirculation is used to: compartment isolation mode/ – to isolate the passenger compart- – Turn control 1 on full hot position. air recirculation mode on. ment from the external atmosphere. –...

  • Page 74: Air Conditioning: Information And Advice On Use

    – Reduction in de-icing, demisting Advice for reducing consumption or air conditioning performance. and helping to preserve the environ- Contact an approved Renault Dealer. ment. – No cold air is being produced. Drive with the air vents open and the Check that the controls are set cor- windows closed.

  • Page 75: Windows

    WINDOWS Electric window Electric windows Manual window winders Depending on the variants, use 3 to Depending on the version, turn handle 4 Dashboard switches raise/lower the rear passenger win- to lower or raise the window to the de- Press the bottom of switch 1 or 2 to dows to the desired height.

  • Page 76: Sun Visor/Grab Handle/Interior Lighting

    SUN VISOR/GRAB HANDLE/INTERIOR LIGHTING Front sun visor Rear Grab handle 2 Courtesy light This feature depends on the vehicle This feature depends on the vehicle This feature depends on the vehicle version. version. version. Lower the sun visor 1 over the wind- This offers support and can be held Press switch 3 to screen or unclip it and turn it over the...

  • Page 77: Passenger Compartment Storage

    PASSENGER COMPARTMENT STORAGE Glove Box 1 Centre console storage 2 Ticket holder 3 Pull handle 1 to open lower glove box Front door storage 4 Ensure that no hard, heavy or pointed objects are placed in the “open” storage compartments in such a way that they may fall onto passen- gers during sudden turning, braking or in the event of an accident.

  • Page 78: Accessories Socket

    ACCESSORIES SOCKET Accessories socket 1, 3 It is provided for connecting accesso- ries approved by our technical depart- Connect accessories with ment. a maximum power of 120 watts (12 V) only. USB / Aux port 2 When several accessory sockets are used at the same time, the total power of the connected accessories must not exceed 180 watts.
  • Page 79 REAR SEATS When refitting the seat- back, make sure it is cor- rectly locked in place. If seat covers are fitted, make sure these do not prevent the seatback latch from locking in. Make sure that the seat belts are positioned correctly.

  • Page 80: Boot

    BOOT To open To close From the inside Pull the lever 2, then lift the boot lid. Lower the tail gate from point 3 using From the outside your hands and properly close it. Once the tail gate is opened, you can Insert the key in the tail gate lock 1, turn access parcel shelf A.

  • Page 81: Longitudinal Roof Bars

    LONGITUDINAL ROOF BARS Depending on the vehicle, it is equipped with longitudinal style roof bars 1.These roof bars are meant only for aesthetic purpose and do not carry any load. For information on the range of equipment adapted to your vehi- cle, we advise you to consult an ap- proved dealer.Refer to the manufac- turers instructions on how to fit and...

  • Page 82: Multimedia Equipment

    MULTIMEDIA EQUIPMENT (1/2) If your vehicle is not fitted with an audio system, one can be fitted and locations have been provided for the radio 1. To install any equipment, please con- sult an authorised dealer. Refer Multimedia manual for more de- tails.
  • Page 83 MULTIMEDIA EQUIPMENT (2/2) Steering wheel controls – 7 Mute. – 8 Answer the call/call attend. On equipped vehicles, use: – 3 select the audio source. – 4 Scroll to navigate the list with press function. – 5 Volume decrease “-”. –...
  • Page 84 3.16...
  • Page 85 Section 4: Maintenance Bonnet ............... . Engine Oil - Topping up, filling .

  • Page 86: Bonnet

    BONNET In the event of even a slight impact involving the radia- tor grille or bonnet, have the bonnet lock checked by an approved Dealer as soon as pos- sible. When working in the engine compartment, ensure that the windscreen wiper stalk is in the park position.

  • Page 87: Engine Oil - Topping Up, Filling

    ENGINE OIL LEVEL: topping up, filling (1/3) It is normal for an engine to use oil for Once the operation has been com- lubrication and cooling of moving parts pleted, ensure that the dipstick is guided and it is normal to top up the level be- in as far as it will go or that the “cap- tween oil changes.
  • Page 88 ENGINE OIL LEVEL: topping up, filling (2/3) – Unscrew cap 1. – top up the level (as a guide, the ca- pacity between the minimum and maximum reading on the dipstick 2 is approximately 0.85 litres,(depending on the engine). – wait for approximately 20 minutes to allow the oil to flow into the engine.
  • Page 89 ENGINE OIL LEVEL: topping up, filling (3/3) Oil change Service interval: refer Maintenance Document for your vehi- cle. Oil change capacity Please refer to the maintenance docu- ment for your vehicle, or contact an au- thorised dealer. Always check the engine oil level using the dipstick, as explained previously (it should never fall below the minimum.

  • Page 90: Levels

    LEVELS (1/2) Level 1 It is normal for the level to drop as the brake shoes become worn, but it must never drop lower than the “MINI” warn- ing line. If you wish to check the disc and drum wear yourself, you should obtain the document explaining the checking pro- cedure from the network or the manu- facturer’s web site.

  • Page 91: Filters

    LEVELS (2/2) / FILTERS Filters Checking intervals Check the coolant level regularly The replacement of filter elements (very severe damage is likely to be (air filter, cabin filter, fuel filter, etc.) is caused to the engine if it runs out of scheduled in the maintenance opera- coolant).

  • Page 92: Battery

    BATTERY The charge status of your battery can decrease especially if you use your ve- hicle: – for short journeys. – for driving in town. – when the temperature drops. – after extended use of consumers (radio etc.) with the engine switched off.

  • Page 93: Tyre Pressure

    TYRE PRESSURE Adhere to the tyre pressures (including Un-Laden Laden the emergency spare wheel). The tyre Tyre Condition Condition pressures should be checked at least Location once a month and additionally before any long journey. Front Tyre pressures should always be checked when the tyres are cold, ignore higher pressures which may be Rear...

  • Page 94: Bodywork Maintenance

    BODYWORK MAINTENANCE (1/3) You should A well-maintained vehicle will last Respect local regulations about wash- longer. It is therefore recommended to ing vehicles (e.g. do not wash your ve- Wash your car frequently, with the maintain the exterior of the vehicle reg- hicle on a public highway).
  • Page 95 BODYWORK MAINTENANCE (2/3) What you should not do Wash the vehicle in bright sunlight or Degrease or clean using freezing temperatures. high-pressure cleaning Do not scrape off mud or dirt without equipment or by spray- pre-wetting. ing on products not ap- Allow dirt to accumulate on the exterior.
  • Page 96 BODYWORK MAINTENANCE (3/3) Vehicles with a matte paint Using a roller type car wash Cleaning the headlights, finish sensors and cameras Return the wiper stalk to the park po- sition.Check mounting This type of paint requires certain pre- Use a soft cloth or cotton wool. If this external accessories, additional lights cautions.

  • Page 97: Interior Trim Maintenance

    INTERIOR TRIM MAINTENANCE (1/2) instrument panel Textiles (seats, door trim, etc) A well-maintained vehicle will last longer. It is therefore recommended to (e.g. instrument panel, clock, exterior Vacuum-clean the textiles regularly. maintain the interior of the vehicle regu- temperature display, radio display, etc.) larly.
  • Page 98 INTERIOR TRIM MAINTENANCE (2/2) Removal/replacing removable You should not: equipment originally fitted in You are strongly advised not to po- the vehicle sition objects such as deodorants, scents, etc. near air vents, as this could If you need to remove equipment in damage your dashboard trim.
  • Page 99 Section 5: Practical advice Puncture, emergency spare wheel ..........Wheel trim, tools .

  • Page 100: Puncture, Emergency Spare Wheel

    PUNCTURE, EMERGENCY SPARE (1/2) To store the wheel in the storage location: Repeat the steps in the reverse order to fit back the spare wheel in the same location. Spare Wheel This is located in the luggage compart- ment. To access it : –...
  • Page 101 PUNCTURE, EMERGENCY SPARE (2/2) Note: ensure that the emergency spare wheel or punctured wheel are correctly positioned.Check that the boot carpet is correctly positioned in its bump stops to prevent it from being damaged. If the emergency spare wheel has been stored for several years, have it checked by your Dealer to ensure that it is safe to use.

  • Page 102: Wheel Trim, Tools

    WHEEL TRIM, TOOLS Central wheel trim with Accessing the tools visible wheel bolts Never leave tools unse- (example: wheel trim 1) Jack 2 and Wrench 3 cured in the vehicle: there Depending on the version,the bolts are is a risk that they may be Jack 2 is in a jack pouch and is placed directly accessible directly or after re- thrown about during brak-...

  • Page 103: Changing A Wheel

    CHANGING A WHEEL (1/2) Switch on the hazard warn- ing lights.Keep the vehicle away from traffic and on a level surface where it will not slip (if necessary, place a solid support under the jack base).Apply the parking brake and engage a Removing the Wheel Place the jack under the body ,and gear (first or reverse).
  • Page 104 CHANGING A WHEEL (2/2) Refitting the Carwheel Ensure the wheel is fastened sufficient If the vehicle is parked on enough, so that removing stud will not by aligning one of holes to the stud in the hard shoulder, you must cause the wheel to come out off the the wheel drum/disc.

  • Page 105: Tyres

    TYRES (1/3) The tyres are the only contact between When the tread has worn down to the the vehicle and the road, so it is essen- wear warning strips, these strips will tial to keep them in good condition. become visible 2: it is then necessary You must make sure that your tyres to replace your tyres because the tread rubber is now only 1.6 mm deep at...
  • Page 106 TYRES (2/3) Tyre pressures The pressures should be checked cold: ignore higher pressures which may be Adhere to the tyre pressures (including reached in hot weather or following a the emergency spare wheel). The tyre high speed journey. pressures should be checked at least If the tyre pressures cannot be checked once a month and additionally before when the tyres are cold, increase the...
  • Page 107 TYRES (3/3) Use in winter Studded tyres Fitting new tyres This type of equipment may only be Chains For safety reasons, this op- used for a limited period and as laid For safety reasons, fitting snow eration must be carried out down by local legislation.
  • Page 108 FRONT LIGHTS-CHANGING BULBS Dipped beam headlight Main beam headlight Direction Indicator light – Remove cover A. – Remove cover B. Turn the bulb holder 4 a quarter of a turn and take out the bulb. – Remove bulb connector 2.Unclip –...

  • Page 109: Lighting - Changing The Bulbs

    LIGHTING: changing bulbs Courtesy lights 1 LED Daytime running lights 2 Rear lighting 3 (Brake lights/ Direction indicator lights/ Please consult an authorised dealer. Please consult an authorised dealer. Reversing lights) Please consult an authorised dealer. The bulbs are under pres- sure and can break when replaced.

  • Page 110: Radio Frequency Remote Control: Batteries

    Recommended battery: Contact ap- Insert a minus screw driver into the slit ies. proved Renault Dealer for replacement of the Decor shell and twist it to sepa- of the battery. rate the Decor shell from the lower part.

  • Page 111: Fuses

    FUSES (1/3) Removing the fuses Remove the fuse, located at the back of flap A from position 1. To remove the fuse, slide the fuse. It is not advisable to use the free fuse locations. The engine may be hot Passenger compartment fuses A when working in close prox- If any electrical component does not...
  • Page 112 FUSES (2/3) Allocation of fuses in the passenger compartment (the presence of certain fuses DEPENDS ON THE VEHICLE EQUIPMENT LEVEL) 5.14...
  • Page 113 FUSES (3/3) Number Allocation Number Allocation Number Allocation Stop Light Switch, Radio/ Accessories relay Starter - Manual Ultra Low cost Transmission / Automated Manual transmission Reverse light relay Rear Light Switch Roof Light Second row Accessory Windshield Motor socket Cluster Left-hand main beam Front Dual Window Lift Low Beam...

  • Page 114: Battery: Troubleshooting

    BATTERY: troubleshooting (1/2) To avoid all risk of sparks: Connecting a battery charger – Ensure that all electrical equipments The battery charger must be com- (courtesy lights, etc.) are switched patible with a battery with nominal voltage of 12 volts. off before disconnecting or recon- necting the battery.
  • Page 115 BATTERY: troubleshooting (2/2) Starting the vehicle using the battery from another vehicle If you have to use the battery from an- other vehicle to start, obtain suitable jump leads (with a large cross section) from an approved dealer or, if you al- ready have jump leads, ensure that they are in perfect condition.

  • Page 116: Windscreen Wiper - To Lift/Replace Wiper Blades

    WINDSCREEN WIPER - TO LIFT/REPLACE WIPER BLADES To lift the wiper arm 1 Refitting a wiper blade – Switch ON the ignition; To refit the wiper blade, proceed in re- verse order to removal. Make sure that – Move the wiper stalk from park po- the blade is correctly locked in posi- sition A (make sure the windscreen tion.

  • Page 117: Towing

    TOWING It is prohibited to hang the car to lower arm or Rear Axle. To hang car there is a Do not remove the key from specific place provided. the ignition when the vehi- cle is being towed. When engine stopped, steering and braking as- sistance are not operational.

  • Page 118: Accessories

    ACCESSORIES Electrical and electronic accessories Before installing this type of accessory, make sure it is compatible with your vehicle. You can get advice from an au- thorised dealer. Connect accessories with a maximum power of 120 watts only. Fire hazard. No work may be carried out on the vehicle’s electrical or radio circuits, except by authorised dealers: an incorrectly connected system may result in damage being caused to the electrical equipment and/or the components connected to it.

  • Page 119: Operating Faults

    OPERATING FAULTS (1/3) The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact an approved dealer as soon as possible. The starter is activated POSSIBLE CAUSES WHAT TO DO Warning lights dim or fail to come on; Battery terminals disconnected, Retighten them, reconnect them or clean the starter does not run.
  • Page 120 OPERATING FAULTS (2/3) On the road POSSIBLE CAUSES WHAT TO DO Vibrations. Tyres not inflated to correct pres- Check the tyre pressures; if this is not the cause, have sures, incorrectly balanced or their condition checked by an approved dealer. damaged.
  • Page 121 OPERATING FAULTS (3/3) On the road POSSIBLE CAUSES WHAT TO DO The engine overheats. The coolant Engine cooling fan not working. Stop the vehicle,switch off the engine and con- temperature indicator light comes tact an approved dealer. Coolant leaks. Stop the vehicle, switch off the engine and check the coolant reservoir: it should contain fluid.
  • Page 122 5.24...
  • Page 123 Section 6: Technical specifications Identification plates ............. . Engine specifications .

  • Page 124: Identification Plates

    IDENTIFICATION PLATES Vehicle Identification Number The information shown on the vehi- cle identification plate should be quoted on all correspondence or orders. Open up the insulator to access the Vehicle Identification number Plate. Vehicle identification plate A : Identification number.
  • Page 125 SPECIFICATIONS Versions 1.0 12V Engine type BR10DE (see engine plate) Cubic capacity (cc) Petrol. The use of unleaded petrol is essential. Type of fuel octane rating It is preferable to use fuel with octane rating 91 and higher. Depending on vehicle, the engine is compatible with E10 petrol. Only use spark plugs specified for your vehicle’s engine.

  • Page 126: Technical Information For The Emergency Services

    TECHNICAL INFORMATION FOR THE EMERGENCY SERVICES The QR Code on the A label allows emergency workers using a tablet or smartphone to immediately access the technical information useful for working on the vehicle in the event of an acci- dent Ensure that the A label is always visible and present on the windscreen as well as the rear screen...

  • Page 127: Dimensions

    DIMENSIONS (in metres) 0.704 2.424 0.604 1.391 3.732 1.579 1.474 (*) 1.490(**) 1.364 (*) unladen-without roof style bars (**) unladen-with roof style bars...

  • Page 128: Replacement Parts And Repairs

    REPLACEMENT PARTS AND REPAIRS Original parts are based on strict specifications and are subject to highly specialized tests. Therefore, they are of atleast the same level of quality as the parts fitted originally. If you fit genuine replacement parts always to your vehicle, it will perform well. Furthermore, repairs carried out within manufactur- ers network using original parts are guaranteed according to the conditions set out on the reverse of repair order.

  • Page 129: Service Sheets

    SERVICE SHEETS (1/4) Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□...
  • Page 130 SERVICE SHEETS (2/4) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 131 SERVICE SHEETS (3/4) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 132 SERVICE SHEETS (4/4) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...

  • Page 133: Anticorrosion Check

    ANTICORROSION CHECK (1/4) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.11...
  • Page 134 ANTICORROSION CHECK (2/4) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.12...
  • Page 135 ANTICORROSION CHECK (3/4) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.13...
  • Page 136 ANTICORROSION CHECK (4/4) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.14...
  • Page 137 ALPHABETICAL INDEX (1/3) accessories................ 5.20 dashboard............... 1.22 – 1.23 accessories socket ............3.10 dimensions ................6.5 adjusting your driving position ..........1.6 doors................1.3– 14 air bag...............1.9 →1.14 driving ........ 1.22 – 1.23, 2.2 → 2.4, 2.7 → 2.13 air conditioning ............3.4 → 3.6 air vents ..............3.2 – 3.3 electric door locking ............. 1.3 anti-corrosion check ..........6.11→ 6.14 electric windows ..............
  • Page 138 ALPHABETICAL INDEX (2/3) fuses ..............5.13 → 5.15 lighting: exterior ................. 1.30 Interior ................3.8 gear lever..............2.5 – 2.6 lights .................. 1.30 glove box ................3.9 lights: grab handle................3.8 dipped beam headlights ..........1.30 main beam headlights ..........1.30 side lights ..............1.30 handbrake..............
  • Page 139 ALPHABETICAL INDEX (3/3) radio frequency remote control/key towing hitch................ 5.19 use ................. 1.2 transporting children ..........1.15 →1.20 rear seat ................3.11 trip computer and warning system......1.27 →1.29 rear view mirrors ..............1.21 trunk door ................3.12 remote control door locking tyre pressure..............4.9, 5.8 batteries ...............
  • Page 143 Your RENAULT vehicle is manufactured to meet the regulations and environmental requirements of the country where such RENAULT v ehicle is originally sold. Incase you relocate it to another country, it may be very difficult to make modifications to comply with the regulations and environmental requireme- nts of that c ountry and it may be difficult to perform repair service in that country.
  • Page 144 It is the authorised RENAULT Dealer’s discretion to decide whether it is appropriate to repair or replace the defective part, w hilst keeping the Customer informed, 24/7 assistance services as defined in the “Renault Assistance”...
  • Page 145 Misuse, abuse, negligence, improper driving habits, theft etc. of the vehicle; 4.6.4 Damage from stress, like use of vehicles in races, rallies, etc., 4.6.5 Use of parts other than Renault Genuine Parts. 4.6.6 Any device and/or accessories not supplied by RIPL. 4.6.7 Modifications, alterations, tampering or improper repair.
  • Page 146 Manufacturer have been carried out; 5.1.4 have the defect covered by the RENAULT New Vehicle Warranty confirmed as soon as possible, by a Renault a uthorised workshop in writing. If the vehicle is un -roadworthy, the...
  • Page 147 RENAULT authorized network and not observing the manufacturer’s recommendations on the subject. 5.3 By way of consideration f or the parts supplied by RIPL und er the RENAULT New Vehicle Warranty, parts replaced under this warranty legally become the property of RIPL.
  • Page 148 In this case, the Customer m ust advise Renault Assistance as soon as they exit the motorway or similar highway. 6.5 WARNING: Renault Assistance will not be liable for any costs accrued by the Customer without prior written consent from Renault.
  • Page 149 In addition to the RENAULT New Vehicle Warranty, RENAULT guarantees the bodywork and sub frame of all RENAULT vehicles in the Schedule I from perforation from the interior, due to steel panel corrosion c aused by a manufacturing, material or protective product application...
  • Page 150 Customer. 7.4 The Renault Anticorrosion Warranty does not cover: 7.4.1 any damage which is not covered by the RENAULT New Vehicle Warranty, as defined at the start of this booklet; 7.4.2 Mechanical components which are not an integral part of the bodywork or sub-frame (wheel rims, exhaust system, etc.).
  • Page 151 7.5.6 Repairs on any deterioration must be made as soon as possible. 7.5.7 The application of the RENAULT Anticorrosion Warranty is also subject to bodywork and sub- frame repairs being carried out in accordance with RENAULT recommendations. 7.5.8 The repair or replacement of components under the conditions described in the “ field of application”...
  • Page 152 8.4 The RENAULT Paintwork Warranty does not cover: 8.4.1 any damage which is not covered by The RENAULT New Vehicle Warranty, as defined at the start of this booklet; 8.4.2 damage due to force majeure events: lightning, fire, floods, earthquakes, war , riots and attacks;...
  • Page 153 All disputes arising out of this Warranty will be subject to the jurisdiction of Courts in Chennai only. EXTENDED WARRANTY Renault offers “ Renault Secure” Integrated Extended Warranty and Roadside Assistance Program on select models, in addition to the new vehicle warranty. Kindly Contact 1800 315 44 44 (Toll Free number) or your nearest Renault Dealer for more details.

Table of Contents
