3.4 Loopback

OFF ON
When the loopback symbol is lit green, you can turn on or off the loopback feature by rotating the knob: CW
rotation will activate the loopback and the LED ring will turn on, CCW rotation will deactivate the loopback and
the LED ring will turn off.
When you move the knob to activate or deactivate the loopback, the LED ring will temporarily show you the
current status. After 2 seconds the LED ring will return showing the peak level.
With the loopback function turned on, the audio that is input to the iRig Stream Mic Pro from your host via USB
is returned back to the host. The Streaming level controls the overall level that is recorded/streamed.
The loopback level can also be controlled with the host volume's control.
Press the knob to get to the Monitor mix control.

3.5 Monitor mix control

100% 50/50 100%
When the monitor mix symbol is lit green, you can adjust the mix between the microphone signal and the sound
from the connected host in your headphones.
When you move the knob to change the monitor mix, the LED ring will temporarily show you the current status.
After 2 seconds the LED ring will return showing the peak level.
By default, the monitor mix control is set to 50/50 with the central LED on. This is useful, for example, when you
need to hear yourself clearly above the playback from your host.
Press the knob to get to the Polar patterns control.
