6 - 1/4"-20 female thread
Use this 1/4"-20 female thread to attach the iRig Stream Mic Pro to its desktop stand or use the included 1/4" to
5/8" thread adapter to attach the iRig Stream Mic Pro to any mic stand.
7 - Host connection
This mini-DIN port allows iRig Stream Mic Pro to connect to your computer or mobile device.
8 - DC input for optional PSU
Use this DC input to connect the optional iRig PSU 3A (5V DC - 3A). The PSU will allows you to charge the
connected iOS device (only iOS devices with a Lightning connector will be charged).

2. Installation and setup

1. Connect one of the included cables to the mini-DIN port on the back side of iRig Stream Mic Pro.
2. Connect the cable to the host device (computer or mobile device).
3. Launch your preferred audio app or streaming software and set iRig Stream Mic Pro as your default audio
device. To do so, please refer to the documentations of the App or Software you're using.
4. Connect your headphones to the headphones port on the underside of the microphone.
5. Connect any line level signal to the Aux stereo input on the underside of the microphone. This signal will be
mixed with the signal coming out from the microphone capsules.
6. Adjust all the settings with the multi-function knob. See Section 3 on this manual for more information.
Usage Note: iRig Stream Mic Pro is a side-address microphone, which means that you should speak into the
front of the mic, and not the top of the mic. See Section 5 "Polar patterns" for more information on proper mic
placement.
