Irig Stream Mic Pro Overview - IK Multimedia iRig Stream MIC PRO User Manual

English

1. iRig Stream Mic Pro overview

1
6
2
3
7
8
4 5
1 - Dual capsule
The dual capsule array delivers four pickup patterns: cardioid, omni, fig-8, stereo.
2 - Multi-function knob
This single knob allows you to control all the features of the microphone including microphone gain, mute,
headphone volume, overall streaming level, loopback, monitor mix, patterns and HPF. See Section 3 in this
manual for more information.
3 - LED ring
The 11 segment LED meter and the backlit symbols give you important informations about the iRig Stream Mic
Pro operating status and audio streaming level. See Section 3 in this manual for more information.
4 - Aux input
It is possible to connect any line level source to this 1/8" jack stereo input. This signal can come from an mp3
player, a computer or an audio mixer. When the multi-function knob operates as streaming level control it will
adjusts the overall volume that is recorded/streamed. To adjust the volume of the device connected to the Aux
input, use the volume controls of that device.
5 - Headphone output
1/8" (3.5mm) headphone jack.
4
