Page 2: Table Of Contents
Content Safety Precautions ............1 Application guidelines ............5 Product Feature ..............6 Product Installation ............7 Component Names●Control Panel ........12 Application method ............16 Display and alarm ............. 22 Cleaning and Maintenance ..........26 FAQ .................. 28 Refrigeration Schematic • Circuit Diagram ....... 29 Specifi... -
Page 3: Safety Precautions
Safety Precautions Dear Haier Customers: Thank you for choosing Haier blood bank refrigerator, please make sure you have carefully read and observed the contents with following signs in the manual, for better understanding of this manual and better use of this product, to prevent personal injuries and refrigerator damage. - Page 4 Model Rated voltage(VAC) Rated frequency(Hz) equivalent(Tonnes) Under all conditions marked with , It is necessary to consult the documentation to HXC-106 220-240V~ 50/60 0.001 Actions or operations undesratnd , the potential risks and know any countermeasures that must be taken.
-
Page 5: Manual
Do not ground the refrigerator through gas pipes, water supply pipes, telephone lines or lighting conductors. These types of connections can cause electric shock. Do not touch electric parts such as power plugs or switches with wet hands to prevent electric Name HXC-106 HXC-158 HXC-158B shock. -
Page 6: Battery
The angle of inclination shall not be greater than 45° when the refrigerator is handled or moved. Name Blood Bank Refrigerator Be aware of the danger of tripping when working with the refrigerator to avoid managing the unit Model HXC-1308 HXC-1308B or personal injury. -
Page 7: Application Guidelines
4±1℃ temperature if possible. Voltage 115V/60Hz • For HXC-106/158/158B/358/358B/608/608B,when humidity is too high,the condensation Rated power / current 560W/7.5A phenomenon may happen at the cabinet mouth.Open the cover of the switch board right side of machine,turn on the heater swtich,this can solve the problem.Otherwise,turn off the heater switch to... -
Page 8: Product Feature
Product Feature Haier blood bank refrigerators are applicable for the storage of whole blood, medicine, biological Name Blood Bank Refrigerator products and other laboratory products that need to be stored at a temperature of 4℃ . Haier blood Model HXC-608 HXC-608B... -
Page 9: Product Installation
Name Blood Bank Refrigerator Model HXC-358 HXC-358B •Ambient temperature: 18℃ to 38℃ with exception of HXC-106/1308/1308B at 16℃ to 32℃ . Range Exterior dimensions of 18℃ to 25℃ is ideal. 720x690x1730 (W x D x H) (mm) •Ambient humidity: below 85% RH . - Page 10 > 30cm from the top Condenser/Evaporater Fin tube type Inspect the accessories inside the refrigerator Temperature Control Microprocessor controlled against the packing list. Contact Haier service should there any discrepancy. Refrigerant R600a 80g R600a 80g R600a 75g > 10cm from...
- Page 11 •HXC-106 5.Standing Do not immediately turn on the refrigerator after it is installed in place. Let it sit for 24 hours before power up to ensure a normal operation. 6. Installation of the Handle Handle installation of products shall be conducted in the following steps: ①...
- Page 12 Initially Powering Up •HXC-1308/1308B Initial power up and operation must meet the following procedures. While the refrigerator is empty, plug in the power socket to a dedicated socket that meets the voltage requirement. Once the unit is powered up, the audible alarm is turned on. Turn on the battery switch and press the buzz cancel button to silence the alarm.
- Page 13 Wiring diagram •This refrigerator should be maintained by a dedicated personnel. The person in charge should examine the operating condition and record it. If the stored temperature is out of acceptable range, remove the products, correct the faults and reload the unit. •HXC-158/158B/358/358B/608/608B •This refrigerator is a blood bank designed to operate at 4℃...
-
Page 14: Component Names●Control Panel
Component Names●Control Panel Refrigeration Schematic • Circuit Diagram Component Names Refrigeration diagram •HXC-158/158B/358/358B/608/608B Light switch Control panel Evaporator Condenser Interior light Filter dryer Temperature measurement box Capillary Door handle Compressor Shelf Suction tube Air-emission tube Blood storage basket (or drawer) Door ajar alarm switch Door lock USB port（optional）... - Page 15 •HXC-1308/1308B If you have any questions about the operation of the refrigerator, please refer to the table frequent asked questions as follows. Call Haier technical support if you Light switch Control panel still have questions. Do not disassemble and repair the refrigerator by yourself.
- Page 16 Temperature recorder and chart paper •The temperature recorder is standard on the product ( optional for HXC-158). If additional chart paper is needed, please contact Haier Biomedical. The ordering cycle is 1 ~ 2 months. Consult us by phone for detailed information.
- Page 17 •Clean the water container; Screws at the bottom •Reverse the procedure and install the water container •HXC-106 back in place. At normal conditions, clean the box once a month is sufficient. However, at high ambient and humidity conditions, clean the box 3 times a month.
-
Page 18: Application Method
Application method Temperature display Automatic recovery of alarm The audible alarm of this series of refrigerator has the following characteristics. The refrigerator is set to reach appropriate temperature automatically before leaving the factory: •When the system is in a n alarm mode, press the Buzzer Cancel key on the display board and the 4℃... -
Page 19: Key
TEMP.SET Light Display Alarm items Initiation of Alarm Buzzing Note fl ashing requirements Delay 2 min •HXC-158/158B/358/358B/608/608B/106 (delay 1 – 12 min Opening the door (including is adjustable, To change the control setting from the original 4 ℃ to 4.5 ℃ , perform the procedures as follow. Door opening slight opening) enables the set by user... - Page 20 HXC-1308/1308B Automatic Defrosting Light Display Alarm items Initiation of Alarm Buzzing Note fl ashing requirements There are two automatic defrosting periods controlled by the controller. When the temperature of Remote alarm contacts upper or lower temperature 1.Periodical Defrosting reverse and audible measurement box is Over alarm starts.
-
Page 21: Display And Alarm
Display and alarm HXC-158/158B/358/358B/608/608B/106 •Power supply The recorder power is supplied by alternating current (AC) in normal condition when the refrigerator operates. If AC power supply breaks down, LED indicator lamp on the recorder fl ashes and alarm Alarm or safety Phenomenon Alarm indication Buzzer alarm... - Page 22 •Adjustment of Calibration of the Recorder USB function module The recorder is accurately adjusted before leaving the plant. It will not be affected even if the power is cut off . If adjustment is required, please perform a calibration according to the following •...
