Certificate of Quality
checker:
Manufacturer: Haier Medical and Laboratory Products Co., Ltd.
Address: Haier Industrail Park, Economic Technology Development
Zone. Qingdao 266510.P.R.China
Web:www.haiermedical.com
Version:1st,2016
Dedicated code:0270501029
V13026
Blood Bank Refrigerator
Operation Manual
Read the Operation Manual carefully before using your appliance.
Keep the Operation Manual in a safe place.
Appearance , color and layout of the door may vary.
Translation of the original instruction.
The scope of the product application: For providing a storage environment of 2
Model:
HXC-158
HXC-158B
HXC-358
HXC-358B
HXC-608
HXC-608B
HXC-1308
HXC-1308B
~6
.
℃
℃
Advertisement
Related Manuals for Haier HXC-158B
Summary of Contents for Haier HXC-158B
- Page 1 HXC-358B HXC-608 HXC-608B Certificate of Quality HXC-1308 HXC-1308B checker: Manufacturer: Haier Medical and Laboratory Products Co., Ltd. Address: Haier Industrail Park, Economic Technology Development Zone. Qingdao 266510.P.R.China Web:www.haiermedical.com Version:1st,2016 Dedicated code:0270501029 Read the Operation Manual carefully before using your appliance.
-
Page 3: Product Feature
Automatic evaporation of condensate water, user-friendly design of safety door latch, etc. We apologize that the Haier blood bank refrigerator provided for you may be a little different from the figure in the manual due to product improvement. The manual may be subject to changes... -
Page 4: Table Of Contents
Content: Product Feature............Content..............Safety Precautions........... Precautions for Use..........Product Installation ........... Component Names Control Panel......Application method ........... Alarm................ Cleaning and Maintenance........FAQ................Refrigeration Schematic & Circuit Diagram....Specification............. -
Page 5: Safety Precautions
Safety Precautions Dear users: Packing List Thanks for your choice of Haier blood bank refrigerator; please make sure you have carefully read and observed the contents with following signs in the manual, for better understanding of this Name HXC-158 HXC-158B manual and better use of this product, to prevent personal injuries and refrigerator damage. - Page 6 Specification Apply the dedicated power supply marked on the nameplate of refrigerator to prevent fire or electric shock. If voltage below 198V or above 242V is applied, automatic voltage regulator above 4000W Name Blood Bank Refrigerator and appropriate for motor load shall be installed. Model HXC-1308 HXC-1308B...
- Page 7 Do not store corrosive articles such as acid or alkali in the refrigerator. To prevent damage to internal components or electrical parts. Specification Do not place packaging plastic bags within the reach of children to prevent suffocation accidents. Blood Bank Refrigerator Name Do not climb onto or place articles on the refrigerator as personal injuries or refrigerator Model...
-
Page 8: Precautions For Use
Precautions for Use The refrigerator battery may be low when the refrigerator is restarted after it has been Specification out-of-service for a long time; make sure the battery switch is set at “ON” and charge the storage battery, which will be full after continuous running of refrigerator about a week. Name Blood Bank Refrigerator Model... -
Page 9: Product Installation
Product Installation Specification Installation environment Blood Bank Refrigerator Name Ambient temperature: 18°C to 38°C (temperature of HXC-1308/1308B: 16 ~ 32°C), 18°C to 25°C are optimal and air conditioning system is used as necessary. Model HXC-358 HXC-358B Ambient humidity: below 85%Rh. External dimensions (W X D X H) 720x690x1730 Avoid excessive dust. - Page 10 1. Remove the packing material and packaging tape Blood Bank Refrigerator Name Remove the all packing materials and packaging Model HXC-158 HXC-158B tapes for transportation. External dimensions (W X D X H) 560×570×1530 （mm） Internal dimensions (W X D X H) 460×370×950...
- Page 11 5. Standing Circuit Diagram（HXC-1308/1308B） Do not switch on the power after the refrigerator is placed, leveled and cleaned. Switch on the power after it is put on standing for more than 24h, to ensure normal performance of refrigerator. 6. Installation of the Handle Handle installation of products shall be conducted in thefollowing steps: ①.
- Page 12 Initial Power-on Circuit Diagram（HXC-158/158B/358/358B/608/608B） Initial start-up and continuous operation shall comply with the following regulations: When the refrigerator is empty, connect the power line to dedicated socket that meets the standard. Make sure that the power supply is the rated voltage. After power-on, the audible alarm may ring.
- Page 13 Refrigeration Schematic & Circuit Diagram This product shall be in charge by a specially-assigned person. The person shall examine Refrigeration Schematic the operating condition and record it. If the temperature is too high or too low, articles shall be transferred into other refrigerators. Storage of articles can restart until the fault is removed.
-
Page 14: Component Names Control Panel
Component Names Read here firstly. This chapter explains to you various faults and phenomena that are potential to happen and their solutions. Call the Haier after-sale service if the question hasn’t been resolved after HXC-158/158B/358/358B/608/608B operation. Do not disassemble and repair the refrigerator by yourself. - Page 15 Deactivate the refrigerator HXC-1308/1308B 灯开关 板 控制面板 面 制 控 关 开 灯 Cut off the power and switch the battery to “o” side if the refrigerator is out of service for a long time. Open the door of the refrigerator and take out the internal shelf; Make a thorough cleaning to the refrigerator;...
- Page 16 Cleaning and Maintenance Control Panel Component Cleaning In order to prevent from getting an electrical shock or personal injury, make sure that the power of refrigerator is cut off before conducting any repair to the HXC-158/158B/358/358B/608/608B refrigerator. Make sure that you do not intake any drug or suspended particulate around the refrigerator when you are maintaining the refrigerator, or else it may be harmful to your health.
-
Page 17: Application Method
Application method Automatic recovery of alarm Temperature displayer The refrigerator of this series has the function of automatic recovery of alarm: The refrigerator is set to reach appropriate temperature automatically before leaving the factory: Press the key of buzzer cancel on the display board when there is alarm and it can stop the 4℃±1℃... - Page 18 Light Display SN. Alarm items Conditions of alarm start Buzzing Note flashing requirements Temperature setting High temperature controller detects the temperature inside Alarm of Alarm of simultaneous Display the actual Alarm of simultaneous the product is ≥ 12; at the time, To modify the temperature set value, for example, the original set value 4°C is to be modified as super high temperature excess...
- Page 19 HXC-1308/1308B Light Display SN. Alarm items Conditions of alarm start Buzzing Note flashing requirements Button operation Display Display board displays the Display the temperature in box alternation between the mean value of temperature of both Control sensor is in short circuit Display“TS”（Please do the next operation upper and lower or broken circuit, fault code: E3...
- Page 20 HXC-1308/1308B Temperature recorder （HXC-158/158B/358/358B/608/608B） Refrigerator temperature recorders of 6-inch standard panel can be chosen for Light Display SN. Alarm items Conditions of alarm start Buzzing Note flashing requirements HXC-158/158B/358/358B/608/608B to record the temperature change in box. Start remote alarm, Installation and Operation When any temperature of upper and buzzing alarm and lower display temperature is...
- Page 21 Alarm Maintenance and change of emergency battery of the recorder HXC-158/158B/358/358B/608/608B When the green LED of recorder flashes, there are two checking methods: 1. Discharge the emergency battery. If the LED lamp is off and the recorder stops operation, it Alarm indicates that there is problem on the recorder main power (220V/50HZ).
- Page 22 Adjustment of Calibration of the Recorder Note: The recorder is accurately adjusted before leaving the plant. It will not be affected even if the power Among the setting procedures of aforementioned 1P-5P, they can be adjusted by selecting is cut off. If adjustment is required, please conduct it according to the following procedures: parameter to be adjusted through “Sensor”...
- Page 23 Head cap and lock latch – protect the temperature recorder. Uplift the lock latch slightly and pull USB function module (optional) the head cap to open it. Press the lock latch after closing the door to fasten the head cap; Film button –...
- Page 24 The adjustment modes of temperature measurement tap position and record period. After retightening hold-down bolt and pressing Key 3# again, the recorder will switch to the After normal power-on of machine, press and hold Key 3# for at least about 5s, when a “click” is process of paper calibration.
