Summary of Contents for Dimplex LVT20-AU
- Page 1 INSTRUCTION MANUAL Laverton 2kW Electric Stove Model: LVT20-AU For domestic household use only. 08/55057/0 Issue 2 OCN 11925...
- Page 2 IMPORTANT THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/ OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY Please read the operating instructions carefully before using your product for the first time and keep them in a safe place.
- Page 3 • Although this appliance complies with safety standards, we do not recommend its use on deep pile carpets or on long hair type of rugs • The appliance must be positioned so that the plug is accessible. • If the supply cord is damaged it must be replaced by the manufacturer or service agent or a similarly qualified person in order to avoid a hazard.
- Page 4 WARNING: KEEP BATTERIES OUT OF REACH OF CHILDREN • Swallowing may lead to serious injury in as little as 2 hours or death, due to chemical burns and potential perforation of the oesophagus. • If you suspect your child has swallowed or inserted a button battery immediately call the 24-hour Poisons Information Centre on 13 11 26 (in Australia) or 0800 764 766 (in New Zealand) for fast, expert advice.
- Page 5 Exposed to the Near water If the power cable weather outdoors wires are frayed or cut Where small children No extension leads or Where the power may be left unattended power boards cable may be damaged On a slope or Where there is risk Where it may be uneven surface...
-
Page 6: Specifications
LED effect Remote Control Warranty 2 Years Dimensions (w x d x h) 444w x 340d x 680h For greater precision, please always refer to the rating label placed on the product. Product Dimensions Fig. 1 Laverton LVT20-AU Laverton LVT20-AU... - Page 7 Setup General Information The fire incorporates a flame effect, which can be used with or without heat, so that the comforting effect may be enjoyed at any time of the year. To reduce heat loss and to prevent any chimney up draft affecting the operation of your stove fire, we recommend that the chimney flue is sealed off.
- Page 8 Fuel Bed Assembly Your fire has been supplied with a range of fuel bed material’s, all models contain a 5-piece log set together with a loose set of crystals and vermiculite pieces to complete the fire effect. See Fig.2 below Note: Each log has a number engraved on the surface to help with identification.
- Page 9 Fuel Bed Assembly Step 1 Fig. 3 Step 2 Step 3 Between logs 3 & 4 sweep the vermiculite apart to clearly expose the underlying fuel bed base in the three circle marked areas shown above.
- Page 10 Fuel Bed Assembly Step 4 Using the 130g bag of crystals supplied, first place some crystals into the three clear fuel bed circles created in step 3, fill the exposed fuel bed area fully with crystals as shown. The remainder of the crystals can then be placed anywhere else on the fuel bed.
- Page 11 Control Panel & Remote WARNING: FAILURE TO FOLLOW THESE OPERATING INSTRUCTIONS MAY RESULT IN INJURY AND/OR DAMAGE. NOTE: The Remote Control is packaged in a red box. The battery is also stored in this box and must be installed in the remote control before operation. CAUTION: The remote handset requires a button cell battery (CR2032) to operate.
-
Page 12: Operation
Operation Operating Instructions (Remote)- See Figure 4 Dis- Func- Description play tion Press Once to turn the product ‘ON’. Press a second time to p ss a second time to put the product into ‘STANDBY’. Red indicator light will show Power / upon display for 10 seconds. - Page 13 Operation Operating Instructions (Controls)- See Figure 5 Icon Description Press Once to turn the product ‘ON’. Press a second time to put the product into ‘STANDBY’ (When returning from ‘STANDBY’ mode the product will return to previous settings unless the product has been unplugged, in which case it will reset to factory settings) ‘FLAME EFFECT’...
-
Page 14: Warranty
Warranty Please refer to the warranty card in the box for warranty information. For any troubleshooting advice, please contact the relative Customer Care Centre below. Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd 8 Lakeview Drive, 38 Harris Road, East Tamaki,... - Page 16 Supplied by Glen Dimplex Australia 8 Lakeview Drive, Scoresby, Victoria, 3179 © Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of Glen Dimplex Australia.
