CyberPowerPC Tracer Liquid Cooling Box Service Manual page 2

2
Prepare your Liquid Cooling Box
1.Read the User Manual before operating Liquid Cooling Box.
2.Check if the (black and silver) connectors are attached to the
Water Tubes firmly.
3.Gently remove the Hexagon Water Stoppers on the Liquid Cooling
Box (do not throw it away, store it aside as it will be used later).
4.Gently attach (tighten the screws) the black connectors on the
Water Tubes to the Liquid Cooling Box, make sure it is attached
firmly and avoid twisting tubes.
5.Place the Liquid Cooling Box horizontally on the desk.
Gently remove the Hexagon
Water Stoppers by loosening the
screw and store aside.
Attach the black connectors to the Liquid Cooling Box firmly by
tightening the screw. Avoid from twisting tubes while and after
attaching to the Liquid Cooling Box.
CAUTION: Do not use wrench to lock the water pipe.
Tighten with fingers can prevent water leakage.
Improper force may damage the joint.
