Owner's Manual
1. Read the Owner's Manual thoroughly before first use.
2. Charge the LiftPlus for six hours before using it for the first time. If the LiftPlus battery
completely discharges, recharging will take 72 hours. See page 5 for battery and
charging information.
3. The lead screw requires regular lubrication for proper working condition. See page 12
for maintenance schedule.
1-800-MAGLINE (624-5463)
LiftPlus
Important Startup Instructions
Serial #: _________________________________
Date of Purchase: ________________________
Lite
®
1
www.magliner.com
Advertisement
Table of Contents
Related Manuals for Magliner LiftPlus Lite
Summary of Contents for Magliner LiftPlus Lite
- Page 1 72 hours. See page 5 for battery and charging information. 3. The lead screw requires regular lubrication for proper working condition. See page 12 for maintenance schedule. Serial #: _________________________________ Date of Purchase: ________________________ 1-800-MAGLINE (624-5463) www.magliner.com...
-
Page 2: Table Of Contents
Replacement Parts ........................14-15 Warranty Magliner products have a one (1) year warranty unless otherwise specified from the date of purchase against defects in workmanship or material. Any part or component, except items covered by warranties of other manufacturers, returned to the factory or service center freight prepaid by the owner, found upon examination by Magline, Inc. -
Page 3: General Safety Instructions
! If you have any questions regarding your new ® Magliner product please call our customer service department at 1-800-MAGLINE (624-5463) or (989) 512-1000. Please read this manual thoroughly to become familiar with the safe operation and maintenance of your new LiftPlus system. -
Page 4: Liftplus Lite Unit
LiftPlus Lite Unit Lift Screw Up/Down Upper Handle Switch Front Rollers Quick Change Latch Column Electrical Interface On/Off Panel Switch Lower Handlebars Column Handle Wheel Circuit Breaker Casters Column Channels Rear Rollers Battery Compartment Side Plates Floor Lock Trolley Caster Brake... -
Page 5: Charging The Battery
General Charging Warnings • Use only the Magliner 15V charger designated for use with LiftPlus. Charge using a grounded 120V electrical outlet. • Do not operate the unit when the battery charger is plugged in. -
Page 6: Introduction/Assembly
• Ensure that the right and left locking pins are securely connecting the lift section to the chassis, and the detent pin that secures the attachment, before using (see page 8). 2. If your model includes the optional caster brake, lock the casters in place to ensure the chassis remains stationary. Unlocked Locked 1-800-MAGLINE (624-5463) www.magliner.com... - Page 7 4. Place the platform on the lift section at the quick change latch. Make sure to properly align the platform hinge with the quick change latch. Please Note: You may reposition quick change latch to attach the platform at a comfortable height. 1-800-MAGLINE (624-5463) www.magliner.com...
-
Page 8: Disassembly
The pin must be threaded through the opening on the left side of the quick change latch to fully secure the platform. Aligning Platform to Quick Change Latch Right Side Left Side Disassembly 6. Lock the casters and reverse the above steps for disassembly. 1-800-MAGLINE (624-5463) www.magliner.com... -
Page 9: Using The Liftplus Lite
2. Reset the circuit breaker by pressing the button down until you hear a click. It will not reset for the first few seconds after tripping. 3. If the circuit breaker tips repeatedly, contact Magline. Circuit Breaker Normal Tripped 1-800-MAGLINE (624-5463) www.magliner.com... -
Page 10: End Of Day
The bottom edges of the platform are sharp and can easily damage surfaces. Transporting the LiftPlus Lite Remove the attachment from the lift section; place the lift attachment carefully into vehicle. Secure the detent pin into the quick change adapter so that the pin and lanyard are not damaged. -
Page 11: Replacing The Battery
If the unit appears sluggish even after charging or if the battery does not hold its charge for very long, the battery may need to be replaced. Use only Magliner replacement parts. The battery has a warranty of six (6) months. -
Page 12: Maintenance
Lifting and lowering motions should be smooth. Attachments/ Daily Inspect for wear and damage; replace as needed. Accessories Tighten any loose connections to the battery terminals. Battery Connections Weekly Check for any cracked or damaged wires; replace parts as needed. 1-800-MAGLINE (624-5463) www.magliner.com... -
Page 13: Troubleshooting Guide
LiftPlus Labels WARNING Read all labels before use. Do not exceed rated weight capacity - 150 lbs 1-800-MAGLINE (624-5463) • www.magliner.com Platform Label WARNING Falling Hazard. Do not stand on lift platform. Do not exceed rated weight capacity - 150 lbs. -
Page 14: Replacement Parts
Circuit breaker - 15A, 32VDC, 250 VAC (includes power supply wiring 64076 harness) Electrical board 63025 Hand grip 532144 Handle, U-Loop 301188 Handlebar kit 86078 Lift screw assembly (includes #4 pulley, 531117) 531121 Limit switch (used for upper and lower) 62067 1-800-MAGLINE (624-5463) www.magliner.com... - Page 15 Floor brake 33051 Plug for round tube 530115 Plug for square tube 530123 Washer, thick - 5/8” 80705 Washer, thin - 5/8” x 1/32” 80707 Wheel - 1075 microcellular foam, HDPE hub - 10” x 2-3/4” 111075 1-800-MAGLINE (624-5463) www.magliner.com...
