- Page 1 CooLift ® Owner’s Manual For CooLift models with manual hydraulic lift (CMH-- models) IMPORTANT: Read entire manual before operating Serial #: _________________________________ Date of Purchase: ________________________ 1-800-MAGLINE (624-5463) Page 1 www.magliner.com...
-
Page 2: Warranty
Magline, Inc. Alterations of Magliner products void any warranty or liability on the part of Magline, Inc. Magline, Inc. does not guarantee product capacity if alterations are made. - Page 3 CooLift ® Table of Contents Introduction, Safety Instructions ......................4 Operating Labels ...........................5 General Specifications ..........................6 CooLift Pallet ............................7 Controls -- General Operation ......................8-11 Troubleshooting ...........................12 Replacement Parts List ......................... 13-14 Inspection / Maintenance Checklist....................15-20 1-800-MAGLINE (624-5463) Page 3 www.magliner.com...
-
Page 4: General Safety Instructions
• Keep the Magliner CooLift in an upright position at all times. • Do not utilize Magliner CooLift as a lifting device for anything other than a CooLift pallet. • Do not use the Magliner CooLift to transport people. •... -
Page 5: Safety Instructions
• Use caution on natural grades; operator should be positioned uphill from cart when descending, use brake to control speed, no sharp turns • Always apply holding brake and lower lift before unloading pallet or leaving CooLift unattended 1-800-MAGLINE (624-5463) Page 5 www.magliner.com... - Page 6 Extended exposure to subfreezing temperatures will adversely affect CooLift performance and increase cycle time. CMH43 CooLift with bulk head 1-800-MAGLINE (624-5463) Page 6 www.magliner.com...
- Page 7 Ergonomically placed hand holes for easy carrying Anti-slip tape reduces product from shifting Buttons for attaching beginning of stretch wrap Pallet design allows for any size pallet to stack on top of any other size pallet. 1-800-MAGLINE (624-5463) Page 7 www.magliner.com...
-
Page 8: User Controls
G) Lift Assist Handle (optional) - handles pivot upward to give additional leverage when lifting back of CooLift Deck Operation of the Magliner Manual CooLift The CooLift deck is raised and lowered using the hand pump handle provided with the unit. - Page 9 CooLift ® 1-800-MAGLINE (624-5463) Page 9 www.magliner.com...
- Page 10 1) Engage the foot brake whenever leaving the CooLift unattended. 2) Pallets on the Magliner CooLift should always be in the down position when not moving. 3) Keep hands, feet and all items clear of the moving parts of the CooLift.
- Page 11 Figure 2: CooLift strapped into truck for transport pallet with the foot brake engaged Transporting a pallet with the Magliner CooLift 1) When transporting a pallet with the CooLift the operator should always use caution on natural grades. Be positioned uphill from cart when descending, use brake to control speed and make no sharp turns.
- Page 12 The deck is in the up position and will not go down. Is there any foreign matter in the linkage system? Hydraulic or brake fluid has dripped underneath the CooLift deck. Wipe up any fluid that may have leaked using shop towels. 1-800-MAGLINE (624-5463) Page 12 www.magliner.com...
- Page 13 Hex lock nut - 5/16”-18 80676 Hex lock nut - 3/8”-16 80603 Hex lock nut flange - 3/8”-16 80624 Hex socket head cap screw - 5/16”-18 x 1” long 80038 Hydraulic cylinder assembly (includes items below with *) 315094 1-800-MAGLINE (624-5463) Page 13 www.magliner.com...
- Page 14 Spacer for master cylinder - vinyl 304273 Straight cotter pin 81142 Washer - flat, 6mm 80772 Washer - 1-1/4” x .796 x .0478 for front axle/casters 80723 Washer - SAE 5/16” 80761 Washer for center CooLift wheel 80718 1-800-MAGLINE (624-5463) Page 14 www.magliner.com...
- Page 15 CooLift ® 1-800-MAGLINE (624-5463) Page 15 www.magliner.com...
- Page 16 CooLift ® 1-800-MAGLINE (624-5463) Page 16 www.magliner.com...
