- Page 1 CooLift ® Owner’s Manual For CooLift models with electric hydraulic lift, no propulsion (CTA-- models) IMPORTANT: Read entire manual before operating Serial #: _________________________________ Date of Purchase: ________________________ 1-800-MAGLINE (624-5463) Page 1 www.magliner.com...
- Page 2 Magline, Inc. Alterations of Magliner products void any warranty or liability on the part of Magline, Inc. Magline, Inc. does not guarantee product capacity if alterations are made.
-
Page 3: Table Of Contents
Introduction, Safety Instructions ......................4 Operating Labels ...........................5 General Specifications ..........................6 CooLift Pallets ............................7 Controls -- General Operation ......................8-11 Battery Instructions ........................12-14 Manual Operation ..........................15 Troubleshooting ..........................16-17 Replacement Parts List ......................... 18-20 Inspection / Maintenance Checklist....................21-27 1-800-MAGLINE (624-5463) Page 3 www.magliner.com... -
Page 4: Introduction, Safety Instructions
• Keep the Magliner CooLift in an upright position at all times. • Do not utilize Magliner CooLift as a lifting device for anything other than a CooLift pallet. • Do not use the Magliner CooLift to transport people. •... -
Page 5: Operating Labels
CooLift Capacity: ® 1,200 lbs. with 43" CooLift pallet 1-800-MAGLINE (624-5463) ® 1,350 lbs. with 48” CooLift pallet www.magliner.com ® 1,500 lbs. with 53" CooLift pallet U.S. Patent No. 8,282,111 & 8,894,076 ® WARNING WARNING Keep hands and feet Always stand clear... -
Page 6: General Specifications
Battery cells Sealed lead acid - maintenance free Fluid Specifications Brake fluid DOT 3 or DOT 4 Hydraulic fluid MIL-PRF-5606 CTA43 CTA48 CTA53 CooLift with CooLift with CooLift without bulk head bulk head bulk head 1-800-MAGLINE (624-5463) Page 6 www.magliner.com... -
Page 7: Coolift Pallets
Ergonomically placed hand holes for easy carrying Anti-slip tape reduces product from shifting Buttons for attaching beginning of stretch wrap Pallet design allows for any size pallet to stack on top of any other size pallet. 1-800-MAGLINE (624-5463) Page 7 www.magliner.com... -
Page 8: Controls -- General Operation
1) Engage the holding brake whenever leaving the CooLift unattended. 2) Pallets on the Magliner CooLift should always be in the down position when not moving. 3) Keep hands, feet and all items clear of the moving parts of the CooLift. - Page 9 CooLift ® 1-800-MAGLINE (624-5463) Page 9 www.magliner.com...
- Page 10 1) Engage the holding brake whenever leaving the CooLift unattended. 2) Pallets on the Magliner CooLift should always be in the down position when not moving. 3) Keep hands, feet and all items clear of the moving parts of the CooLift.
- Page 11 Figure 1: CooLift secured under a loaded pallet with the holding brake engaged Transporting a pallet with the Magliner CooLift 1) When transporting a pallet with the CooLift the operator should always use caution on natural grades. Be positioned uphill from cart when descending, use brake to control speed and make no sharp turns.
-
Page 12: Battery Instructions
Only use authorized Magliner CooLift replacement parts. Battery Life The Magliner CooLift is powered by two 12-volt storage batteries. The pump motor draws current from the batteries based on the amount of effort required to meet load being lifted. Testing and research has been done to ensure a fully-charged battery will allow the user to go through a normal workday without recharging the system;... - Page 13 To reduce risk of electrical shock, unplug the charging unit from the AC power supply source before attempting any maintenance or cleaning. Always unplug the charging unit before operating the Magliner CooLift. Always use battery chargers supplied by Magline, Inc. Other battery charging units could cause damage to your batteries or personal injury.
- Page 14 Full charge is indicated by scrolling across 10 bars • A partially charged battery is indicated by scrolling across two to nine bars • When the main power switch is OFF, the battery meter will not display 1-800-MAGLINE (624-5463) Page 14 www.magliner.com...
-
Page 15: Manual Operation
CooLift ® Manual Operation of the Magliner CooLift The CooLift can be raised and lowered manually if the need arises due to a critically low or non- existent power situation using the manual hand pump handle provided with the unit. To operate the pump in the manual mode, insert the handle into the pump handle receiver located at the top of the slotted cutout on the rear access panel of the cart and begin a pumping motion to raise the lift deck. -
Page 16: Troubleshooting
Have all electrical connections been checked? Is the internal charger switch in the ON position? Is the power plug plugged in the charger socket? Is the charger output cord plugged into the battery pack charger port? 1-800-MAGLINE (624-5463) Page 16 www.magliner.com... - Page 17 Check the continuity of the operator on/off switch. Hydraulic or brake fluid has dripped into the drip pan underneath the CooLift deck. Wipe up any fluid that may have leaked into the drip pan using shop towels. 1-800-MAGLINE (624-5463) Page 17 www.magliner.com...
-
Page 18: Replacement Parts List
Cord grip - PG-16 309122 Cord grip - PG-21 309124 Cord grip hex lock nut - PG-9 309178 Cord grip hex lock nut - PG-16 309123 Cord grip hex lock nut - PG-21 309125 Corner post assembly 309108 1-800-MAGLINE (624-5463) Page 18 www.magliner.com... - Page 19 Pan head machine screw - 1/4”-20 x 3/4” long with locking patch 80257 Pan head machine screw - 1/4”-20 x 1” long 80102 Pan head machine screw - 1/4”-20 x 1-1/2” long 80105 Pan head machine screw - 1/4”-20 x 1-3/4” long 80106 1-800-MAGLINE (624-5463) Page 19 www.magliner.com...
- Page 20 Wiring harness to connect cabinet charge port to on/off toggle switch 62030 Wiring harness to connect circuit breaker to on/off toggle switch 62020 Wiring harness to connect circuit breaker to pump 62022 Wiring harness to connect pump to on/off toggle switch 62021 1-800-MAGLINE (624-5463) Page 20 www.magliner.com...
-
Page 21: Inspection / Maintenance Checklist
CooLift ® 1-800-MAGLINE (624-5463) Page 21 www.magliner.com... - Page 22 CooLift ® 1-800-MAGLINE (624-5463) Page 22 www.magliner.com...
- Page 23 CooLift ® 1-800-MAGLINE (624-5463) Page 23 www.magliner.com...
- Page 24 CooLift ® 1-800-MAGLINE (624-5463) Page 24 www.magliner.com...
- Page 25 CooLift ® 1-800-MAGLINE (624-5463) Page 25 www.magliner.com...
- Page 26 CooLift ® 1-800-MAGLINE (624-5463) Page 26 www.magliner.com...
- Page 27 CooLift ® 1-800-MAGLINE (624-5463) Page 27 www.magliner.com...
- Page 28 CooLift ® ® MAGLINE INC. Standish, Michigan 48658 1-800-MAGLINE (624-5463) www.magliner.com Form # 98358 May 2019 REV CooLift ® is a registered trademark owned by © Copyright 2009-2019, Magline, Inc. Swift Water Logistics Patent: www.magliner.com/patents 1-800-MAGLINE (624-5463) Page 28 www.magliner.com...
