Eicon Networks Diva ADSL USB Quick Start Manual

Introduction
Thank you for choosing the Eicon Networks Diva ADSL USB.
The Diva ADSL USB is plug-and-play, and installation is a simple
procedure. However, please read through this guide carefully to
ensure a smooth installation process.
Package Contents
Your package should include the following:
Diva ADSL ADSL
USB Cable
Please note:
• The Diva ADSL USB is compatible with USB-equipped
computers running Windows 98, Windows Millennium
Edition, Windows 2000 and Windows XP. It cannot be used
with Windows 95, Windows NT, or Macintosh.
• The Diva ADSL USB draws power through the USB cable and
does not require a separate power adapter.
• An ADSL filter (sold separately) must be acquired in order to
connect the ADSL cable to your phone outlet. Additionally,
you must connect an ADSL filter to every phone device
(telephone, fax machine) that shares the same wiring as the
ADSL connection.
Diva ADSL USB
Quickstart Guide
USB Diva
Quickstart
Cable CD-ROM
www.eicon.com
Dial-Up Networking Required
Note: The following applies to Windows 98/Me only.
As the Diva ADSL USB uses a Dial-Up Network connection in
order to connect to the Internet, Microsoft Dial-Up Networking
software must already be present for the installation to work.
To verify if Dial-Up Networking is installed:
• Windows 98: Double-click 'My Computer' from the Windows
desktop. You should see a folder named 'Dial-Up Networking'.
• Windows Me: Click 'Start' then 'Settings'. You should see a
menu item named 'Dial-Up Networking'.
If Dial-Up Networking is not present, follow the instructions
below to install the software, or consult the online help for your
operating system.
Note: You may be asked to insert your Windows installation
CD-ROM during this process.
Click 'Start' then 'Settings', then select 'Control Panel'.
1.
Double-click 'Add/Remove Programs'.
2.
Click the 'Windows Setup' tab.
3.
Select 'Communications' from the list, then click 'Details'.
4.
Select the 'Dial-Up Networking' check box, then click 'OK'.
5.
Click 'OK' again to close the 'Add/Remove Software' dialog
6.
box, then follow the onscreen instructions. If you are asked to
restart your computer, do so.
ENGLISH
