77519 English Canadian Version 06089B-2 ( For
Use With The EC96601 New CPU Only)
IMPORTANT
Read this manual before attempting to setup or use this instrument. It contains important
information regarding safe installation and use. Keep this manual for future reference. Also
save the carton, packing and proof of purchase to simplify and accelerate any needed action.
If you need assistance or service, call (800) 888-8990 between 8:00 a.m. and 4:30 p.m.
Pacific Standard Time, Monday through Friday. You can also visit our web site at:
http://www.nwbphones.com for technical support and information on our other products.
WARNING
To prevent fire or shock hazard, do not expose this product to rain or any type of excess
moisture. If accidentally dropped into water, The AC adapter should immediately be
unplugged from the wall along with the telephone line cord.
1
OWNER'S MANUAL #
Page: 1
ENGLISH CANADIAN VERSION
THIS SYMBOL IS INTENDED TO ALERT THE USER
OF THE PRESENCE OF IMPORTANT OPERATING
AND MAINTENANCE (SERVICING) INSTRUCTIONS
IN THE OWNER'S MANUAL.
®
EasyTouch
77519
Caller ID Telephone
CARTON CONTENTS
®
The EasyTouch
77519 Base & Handset
Handset Cord
Long Telephone Line Cord
Short Telephone Line Cord
Wall Mount Bracket
User's Manual
Warranty Card
Accessory Order Form
77519 ver.
06089B-2
06089B-2
Advertisement
Table of Contents
Related Manuals for Northwestern Bell 77519
Summary of Contents for Northwestern Bell 77519
- Page 1 77519 English Canadian Version 06089B-2 ( For Use With The EC96601 New CPU Only) IMPORTANT Read this manual before attempting to setup or use this instrument. It contains important information regarding safe installation and use. Keep this manual for future reference. Also save the carton, packing and proof of purchase to simplify and accelerate any needed action.
- Page 2 Use With The EC96601 New CPU Only) Introduction to Caller ID The 77519 Caller ID allows you to take advantage of the Caller Identification Delivery service offered by your local telephone company. Should you have any questions about the operation of your Caller ID, please call Northwestern Bell Phones at (800)888-8990 between 8:00 a.m.
-
Page 3: Important Safety Instructions
77519 English Canadian Version 06089B-2 ( For Use With The EC96601 New CPU Only) SAVE THESE INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: Read and understand all instructions. -
Page 4: Maintenance
13. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. 14. Do not use the telephone to report a gas leak in the vicinity of the leak. SAVE THESE INSTRUCTIONS MAINTENANCE Use a damp cloth to clean the plastic cabinet. -
Page 5: Ringer Equivalence Number
NOTICE: The ringer equivalence number (REN) assigned to each terminal device provides an indication of the maximum number of terminals allowed to be connected to a telephone interface. The terminat ion on an interface may consist of any combination of devices subject only to the requirement that the sum of the ringer equivalence numbers of all the devices does not exceed 5. - Page 6 77519 English Canadian Version 06089B-2 ( For Use With The EC96601 New CPU Only) equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment. Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together.
- Page 7 77519 English Canadian Version 06089B-2 ( For Use With The EC96601 New CPU Only) EASYTOUCH 77519 CONTROLS DIAGRAM HANDSET (FRONT VIEW) Handset Receiver Hook Switch MUTE Button TONE/PULSE Switch FLASH Button REDIAL Button Microphone BASE UNIT (BOTTOM VIEW) (Remove The Wall...
- Page 8 77519 English Canadian Version 06089B-2 ( For Use With The EC96601 New CPU Only) DESCRIPTIONS Caller ID Controls: Alphanumeric LCD panel - A three-line, liquid crystal display (LCD) panel which displays the following information: Caller Name Caller Phone Number Time of Call...
-
Page 9: Installation
INSTALLATION Installing the Backup Batteries CAUTION Disconnect the telephone line from the telephone wall modular jack before replacing batteries. Remove the battery compartment cover of the 77519 77519 ver. OWNER’S MANUAL # Page: 9 ENGLISH CANADIAN VERSION Wall Mount Bracket... - Page 10 Select a location near a telephone modular wall jack. Plug one end of the telephone line cord into the LINE jack on the rear of the 77519. Connect the other end of the telephone line cord into the telephone modular jack located on your wall.
-
Page 11: Optional Ac Adaptor
Figure 6 OPTIONAL AC ADAPTOR ® The EasyTouch 77519 does not require an AC Adaptor for normal operation. The AC Adaptor is available to reduce the replacement costs of the batteries. Even with the AC 77519 ver. OWNER’S MANUAL #... -
Page 12: Getting Started
77519 English Canadian Version 06089B-2 ( For Use With The EC96601 New CPU Only) Adaptor, batteries are still required to maintain Caller ID information in the event of a power failure. NOTE: If you wish to order the optional AC Adaptor, an Accessory Order form has provided with this unit. -
Page 13: Set Time & Date
77519 English Canadian Version 06089B-2 ( For Use With The EC96601 New CPU Only) 12:00 1/01 SET TIME/DATE The hour icon will be blinking Set Time/Date Press the UP or DOWN button to set the current hour. Press the ERASE button to shift to the minute setting. -
Page 14: Caller Id Operation
Make sure that the Call Identifier Delivery (CID) service is being provided on your telephone line by your local phone company. When CID data is sent, the unit will automatically capture and display the transmission from the phone company. - Page 15 CALL# - Shows the current call record number that is displayed on-screen. The 77519 can store up to 70 call records. NEW - Indicates that new calls have been received, but has not been reviewed yet.
-
Page 16: Telephone Operation
77519 English Canadian Version 06089B-2 ( For Use With The EC96601 New CPU Only) REPEAT-If the same person has called previously, the display will show “REPEAT”. No matter how many times the same calling party call his/her calls will just be count as one repeat call. - Page 17 Call Record - Caller ID information which is stored in the Caller ID’s call memory. Call Memory - A storage area where call records are placed. The 77519 can store up to 70 call records.
- Page 18 77519 English Canadian Version 06089B-2 ( For Use With The EC96601 New CPU Only) call. In most areas, but not all areas, the REN total of all devices should not exceed five (5). Call your local phone company to determine the maximum REN for your calling area.
-
Page 19: Troubleshooting
77519 English Canadian Version 06089B-2 ( For Use With The EC96601 New CPU Only) TROUBLESHOOTING CALLER ID SYSTEM TROUBLESHOOTING TABLE SYMPTOM SOLUTION The Caller ID Check the telephone line cord connections. LCD panel is Check the batteries for proper installation. -
Page 20: Telephone Unit Troubleshooting Table
77519 English Canadian Version 06089B-2 ( For Use With The EC96601 New CPU Only) TELEPHONE UNIT TROUBLESHOOTING TABLE SYMPTOM SOLUTION No dial tone The handset cord or telephone line cord may be loose at the connections. Push in firmly at both ends to establish good contacts. - Page 21 77519 English Canadian Version 06089B-2 ( For Use With The EC96601 New CPU Only) NOTES: 77519 ver. OWNER’S MANUAL # Page: 21 ENGLISH CANADIAN VERSION 06089B-2 06089B-2...
- Page 22 77519 English Canadian Version 06089B-2 ( For Use With The EC96601 New CPU Only) NOTES: 06089B-2 77519 ver. OWNER’S MANUAL # Page: 22 ENGLISH CANADIAN VERSION 06089B-2...
- Page 23 77519 English Canadian Version 06089B-2 ( For Use With The EC96601 New CPU Only) Distributed Exclusively Worldwide by Unical Enterprises, Inc., Industry, California, USA 77519/06089B-2 77519 ver. OWNER’S MANUAL # Page: 23 ENGLISH CANADIAN VERSION www.nwbphones.com 06089B-2 06089B-2...
