IMPORTANT SERVICE INFORMATION
Read this manual before attempting to setup or use this instrument. It contains important
information regarding safe installation and use. Keep this manual for future reference.
Also save the carton, packing and proof of purchase to simplify and accelerate any needed
action. If you need assistance or service, call (800) 888-8990 between 8:00 a.m. and 4:30 p.m.
Pacific Standard Time, Monday through Friday. You can also visit our web site at
http://www.nwbphones .com for technical support and information on our other products.
WARNING
To prevent fire or shock hazard, do not expose this product to rain or any type of excess
moisture. If accidentally dropped into water, the AC power cord should immediately be
unplugged from the wall.
THIS SYMBOL IS INTENDED TO ALERT THE USER OF
THE PRESENCE OF IMPORTANT OPERATING AND
MAINTENANCE (SERVICING) INSTRUCTIONS IN THE
OWNER'S MANUAL
THIS SYMBOL IS INTENDED TO ALERT THE USER OF
THE PRESENCE OF UNINSULATED
VOLATAGE" WITHIN THE PRODUCT'S ENCLOSURE THAT
MAY BE OF SUFFICIENT MAGNTUDE TO CONSTITUTE A
RISK OF ELECTRIC SHOCK TO PERSONS
Easy Touch
1
OWNER'S MANUAL #
1
PAGE #
.
®
Clock Telephone
CARTON CONTENTS
• Base & Handset
• Handset Cord
• Telephone Line Cord
• User's Manual
• Warranty Card
• Memory Index Card
• Accessory Order Form
28507 ver. 12189A-1
English Version
DANGEROUS
.
28507
12189A-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Easy Touch 28507 and is the answer not in the manual?

Questions and answers

Related Manuals for Northwestern Bell Easy Touch 28507

Summary of Contents for Northwestern Bell Easy Touch 28507

  • Page 1 IMPORTANT SERVICE INFORMATION Read this manual before attempting to setup or use this instrument. It contains important information regarding safe installation and use. Keep this manual for future reference. Also save the carton, packing and proof of purchase to simplify and accelerate any needed action.

  • Page 2: Important Safeguards

    IMPORTANT SAFEGUARDS When using your telephone equipment, basic safety precautions should always This product should be operated be followed to reduce the risk of fire, only from the type of power source electric shock, and injury to persons, indicated on the marking label. If including the following: you are not sure of the type of Read and understand all...

  • Page 3: Maintenance

    If liquid has been spilled into CONTACTING SUCH POWER LINES the product. OR CIRCUITS AS CONTACT WITH If the product has been THEM IS ALMOST INVARIABLY exposed to rain or water. FATAL. If the product does not operate Be sure that the antenna system is normally by following the grounded so as to provide some operating instructions.
  • Page 4 TO NATIONAL ELECTRICAL CODE with local codes for possible special disposal instructions. Do not open or mutilate the batteries. Released electrolyte is ANTENNA LEAD IN corrosive and may cause damage to WIRE the eyes or skin. It may be toxic if GROUND swallowed.

  • Page 5: Fcc Notice

    11. Always disconnect all telephone company may discontinue your line cords from the wall modular service temporarily. If possible, they jacks before installing or replacing will notify you in advance. But if batteries. advance notice is not practical, you will be notified as soon as possible. FCC NOTICE You will be advised of your right to file a complaint with the FCC.
  • Page 6 ® EASYTOUCH 28507 CONTROLS DIAGRAM E3 Button E2 Button E1 Button Volume Control Handset MEMORY Button PULSE/TONE Switch Review UP FLASH Button Review DN REDIAL Button Call Back/ STORE Button Alarm Mode ENTER/DEL TUNING Switch Button Volume Switch ON/OFF/AUTO/ BUZZ AM/FM NEW CALL SLEEP/SNOOZE...
  • Page 7 NOTES: • This LED will turn off once you have reviewed all your call records and Message Waiting messages. • Message Waiting is an optional DESCRIPTIONS service provided by your local phone company. Caller ID Controls: Alphanumeric LCD panel - A three- Telephone Controls: line,liquid crystal display (LCD) panel which displays the following...

  • Page 8: Installation

    that the polarities as shown on figure 1 are followed. Clock Alarm /Radio Controls: Replace the battery compartment Option Button Uses: cover. Alarm Set---Used this button to program the desired alarm time. Press once to OFF the alarm. TIME SET Button – Used to set the current time /date.

  • Page 9: Set Time & Date

    NOTE: If no activate buttons are pressed for 15 second, the LCD display will automatically change to STANDBY/MODE. The first digit will be blinking AC Power Plug SET AREA CODE GETTING STARTED Area Cord Setting Press the Review UPor DOWN button Caller ID Initial Setup: to select the first digit area code After the battery installation and...
  • Page 10 change to show the normal When a phone call comes in, this status. unit will capture the Caller ID date sent from the phone company in between the first and second ring, 12:00 PM 1/01 the LCD panel will display the Caller ID information such as name (if TOTAL00 NEW 00 available), phone number (if...
  • Page 11 “MSG” icon will flash on the left Press either one of the UP or DOWN side of the LCD panel. buttons to display the call record to Once you have retrieved the be deleted. message, the “MSG” icon will Quickly tap the DELETE button twice. disappear from the panel and the After you have deleted the call record, NEW CALL LED Indicator will turn...
  • Page 12 11 Numbers—Long Distance Code “1” + 3 Digit Area Code + 7 Digit Phone Number. Ending a Call Note: If the caller’s area code does not Upon completion of a call, return the match the area code you set in 28507, handset in its cradle, or depress the hook 11numbers will appear on the display.
  • Page 13 Press E1, E2 or E3 button respectively Press the Memory button for each of the three emergency Press the desired Memory Location numbers you wish to store. button (0-9). Replace HANDSET to BASE. CLOCK/ALARM OPERATION IMPORTANT: When programming Setting the Time/Date emergency numbers and/or making test 1.

  • Page 14: Troubleshooting

    repeatedly until the LCD displays “ Press the button temporarily halts the STANDBY MODE” alarm from sounding when the alarm rings. After about nine minutes. The alarm will resume sounding again. Each press of this TIME DATE button will resume sounding 9 minutes cater to “Turn Off”...
  • Page 15 information will not be correctly received. If you have a telephone answering device (TAD) connected with the unit, set the TAD to answer after two rings or more. If it is a blocked call or an out-of-area call, the caller’s name and/or phone number will not appear on the display.
  • Page 16 printed on your phone contact your phone company to see if some phones require more ringing power than is normal. • Static Try a different phone; if the problem still exists, the fault is not with the 28507. • Some atmospheric conditions such as very low humidity can cause static build -up.
