IMPORTANT SERVICE INFORMATION
Read this manual before attempting to setup or use this instrument. It contains important
information regarding safe installation and use. Keep this manual for future reference.
Also save the carton, packing and proof of purchase to simplify and accelerate any needed
action. If you need assistance or service, call (800) 888-8990 between 8:00 a.m. and 4:30
p.m. Pacific Standard Time, Monday through Friday. You can also visit our web site at
http://www.nwbphones.com for technical support and information on our other products.
WARNING
To prevent fire or shock hazard, do not expose this product to rain or any type of excess
moisture. If accidentally dropped into water, the AC adaptor should immediately be
unplugged from the wall along with the telephone line cord.
THIS SYMBOL IS INTENDED TO ALERT THE USER OF
THE PRESENCE OF IMPORTANT OPERATING AND
MAINTENANCE (SERVICING) INSTRUCTIONS IN THE
OWNER'S MANUAL
EasyTouch
20 NUMBER MEMORY/CID/SPEAKERPHONE
1
OWNER'S MANUAL#76510 ver.11159A-1
Page1
English Version
.
®
II 76510
CARTON CONTENTS
Handset and Base Unit
Handset Cord
Long Telephone Line Cord
Short Telephone Line Cord
Wall Mount Bracket
User's Manual
Warranty Card
Accessory Order Form
11159A-1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Northwestern Bell 76510-1
Summary of Contents for Northwestern Bell 76510-1
-
Page 1: Important Service Information
To prevent fire or shock hazard, do not expose this product to rain or any type of excess moisture. If accidentally dropped into water, the AC adaptor should immediately be unplugged from the wall along with the telephone line cord. THIS SYMBOL IS INTENDED TO ALERT THE USER OF... -
Page 2: Important Safety Instructions
13. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. 14. Do not use the telephone to report a gas leak in the vicinity of the leak. SAVE THESE INSTRUCTIONS MAINTENANCE Use a damp cloth to clean the plastic cabinet. -
Page 3: Installation Precautions
If requested, provide this information to your telephone company. The REN is useful to determine the quantity of devices you may connect to your telephone line and still have all of those devices ring when your 11159-A... - Page 4 REN, you should call your local telephone company to determine the maximum REN for your calling area. If your telephone causes harm to the telephone network, the telephone company may discontinue your service temporarily. If possible, they will notify you in advance.
- Page 5 76510 English I/B version EasyTouch II 76510 CONTROLS DIAGRAM DELETE REVIEW Button Button STORE Button MEMO Button Handset TONE * Button FLASH REDIAL HOLD Button Button Button w/ LED Indicator DC 6V LO/HI JACK RECEIVER Switch OWNER’S MANUAL#76510 ver.11159A-1 Page5 English Version 11159A-1 REVIEW...
-
Page 6: Caller Id Display
One-Touch Memory Buttons - The ® Easy Touch II 76510 can store up to 10 telephone numbers into memory (up to 16 digits each), and you can then dial any of the stored phone numbers by just pressing one of the keypad buttons located below the LCD panel. -
Page 7: Battery Installation
Desktop Use Install the desk/wall bracket in the desk position. Set the unit on the selected desktop and connect the telephone line cord to the TEL. LINE jack on the rear of the base unit. Connect the opposite end of telephone line cord to the telephone modular wall jack. -
Page 8: Caller Id Operation
Connect the opposite end of the telephone line cord to the telephone modular wall jack. Align the wall mounting slots with the studs located on the modular wall plate and slide the base down to lock in place. See figure 3 below. -
Page 9: Set Time & Date
Make sure that your local phone company is providing the Call Identifier Delivery (CID) service on your telephone line. When CID data is sent, OWNER’S MANUAL # 76510 ver.11159A-1 PAGE # 9 English Version ®... -
Page 10: Option Button
regarding definitions of terms, refer to the Glossary section. Clear Message Waiting Indicator Press and hold the DELETE button, followed by the REVIEW ► button to clear the message waiting. Reviewing Call Records If you have received new calls, the New Call LED indicator will blink and the LCD panel will display the total number of calls stored. - Page 11 Stutter Dial tone. Please consult with your local telephone service provider for information regarding your Message Waiting Service. LINE ERROR On rare occasions, the Caller ID information sent by the telephone company may have an error in the 11159-A...
-
Page 12: Telephone Operation
If a line error is detected in the transmission, the LCD panel will display “LINE ERROR ”. TELEPHONE OPERATION Dialing Mode (PULSE/TONE Switch) If your home is equipped with touch-tone dialing service, set the PULSE/TONE switch to TONE position. - Page 13 On-Hook state. Press the one-touch (01-10) buttons to view stored record. Press the STORE button once and dial the telephone number you want to store. (Number will not dial out) Press the one-touch memory location(01-10) where you want the phone number stored.
-
Page 14: Glossary Of Terms
The REN is used to determine how many phones can be connected to the same telephone line while still having all those devices ring when you receive a call. In most areas, but not all areas, the REN total of all devices should not exceed five (5). -
Page 15: Troubleshooting
Glossary section of the user’s manual for definitions. On rare occasions, the Caller ID information sent by the “LINE telephone company may have an error in the transmission. This is not the fault of your Caller ID unit. It can only capture and ERROR”... -
Page 16: Telephone Unit Troubleshooting Table
Push in firmly at both ends to establish good contacts. No dial tone Test the phone at a different telephone wall jack and listen for a dial tone. Test a different phone in the wall jack and listen for a dial tone.
