Thitronik WiPro III + safe.lock Installation Manual

For fiat ducato x250

Advertisement

Quick Links

WiPro III + safe.lock Installation Manual
Disclaimer:
This installation manual is intended for
professional service companies. Appropri-
ate background knowledge about work on
vehicle electrics and electronics is there-
fore required.
Improper interventions into the vehicle
electronics and their components can un-
der certain circumstances cause them to
no longer function as intended. This can
considerably endanger the installer (work,
e.g., on the airbag system) and the road-
worthiness of the vehicle and can result
not only in property damage, but also in
personal injury.
Therefore, have all work on the vehicle
electronics carried out by a qualified shop.
1
Fiat Ducato X250
Euro 4 (2006–2011)
Thitronik GmbH is not liable for damage to
property and/or personal injury resulting
from improper, incorrect or only partially
completed installation work. The installing
service company is obligated to ensure
that its connection work neither is faulty
in itself nor can lead to faults or dangers
on the vehicle.
The instructions in the WiPro installation
manual remain applicable. Unused inputs
and outputs must be isolated.
Should the given vehicle conditions differ
from those described herein, please con-
tact the manufacturer or our technical
support team.
Updated 12/20

Advertisement

loading
Need help?

Need help?

Do you have a question about the WiPro III + safe.lock and is the answer not in the manual?

Questions and answers

Summary of Contents for Thitronik WiPro III + safe.lock

  • Page 1 Fiat Ducato X250 Euro 4 (2006–2011) Disclaimer: This installation manual is intended for Thitronik GmbH is not liable for damage to professional service companies. Appropri- property and/or personal injury resulting ate background knowledge about work on from improper, incorrect or only partially vehicle electrics and electronics is there- completed installation work.
  • Page 2 Undo the screws next to the steering wheel on the left and right. Undo the second screw next to the steering Remove the panel. wheel on the left. WiPro III + safe.lock Installation Manual – Fiat Ducato X250, Euro 4...
  • Page 3 Connect the control lines for the central lock- ing system as follows: Cable colour on WiPro III Cable colour on vehicle Function safe.lock blue/yellow → blue/black front doors pink/violet → blue rear doors WiPro III + safe.lock Installation Manual – Fiat Ducato X250, Euro 4...
  • Page 4 CAN low and high must be tapped from the same plug insert! Insert the plug inserts again; install connector. Place red bracket horizontally and insert con- nector again. The connector is secured when the red bracket is vertical. WiPro III + safe.lock Installation Manual – Fiat Ducato X250, Euro 4...
  • Page 5 Drill an 8mm hole for the LED and insert the LED. Connect the red/black wire of the LED with a white connector to the counterpart on the WiPro cable set. WiPro III + safe.lock Installation Manual – Fiat Ducato X250, Euro 4...
  • Page 6 Insert the power supply wire into pin 46, insert the plug inserts again and install the connector again. The connector is secured when the red lever snaps into vertical position. WiPro III + safe.lock Installation Manual – Fiat Ducato X250, Euro 4...
  • Page 7 3. Open contact is still being signalled > pull out the connector for the power supply or remove F39 (with closed con- tacts) > reconnect the power supply. WiPro III + safe.lock Installation Manual – Fiat Ducato X250, Euro 4...
  • Page 8 Mounting of wireless magnetic contacts 868 to windows, doors, hatches etc. Item no.: 100757, 100758...
  • Page 9 1. The orientation of the transmitter housing on the window frame depends on the available space (frame profile, distance to the roller blind or window). Variant lying Variant lying left right Magnet Magnet Transmitter housing Transmitter housing Window frame Window frame 2.
  • Page 10 Alternative mounting variants Should upright mounting on the window Variant upright Variant windowpane frame or mounting on the windowpane be necessary, e.g., for space reasons, the transmitter LED must also be aligned pointing away from the magnet. Door or hatch mounting Fixing options Ideally, the transmitter housing is aligned and The wireless magnetic contacts are ideally...
  • Page 11 Alignment of circuit board in transmitter housing (as-delivered condition) and positions of components. Top view of Cross section Bottom view of circuit board circuit board Transmitter Transmitter cover Reed Battery switch Transmitter housing Long housing leg Short housing leg Battery Battery Positioning the magnet As long as the magnet is in the yellow area, its...

This manual is also suitable for:

868100757100758
