Operating instructions

Installation manual
!! Please read carefully before use !!
Manual Revision 1.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the c.a.s. and is the answer not in the manual?

Questions and answers

Summary of Contents for Thitronik c.a.s.

  • Page 1: Operating Instructions

    Thitronik providing solutions... C.A.S. aravan larm ystem Operating instructions Installation manual !! Please read carefully before use !! Manual Revision 1.3...
  • Page 2: Table Of Contents

    C.A.S. operating instructions Contents Section Page Contents Handling the system Mode of operation, accessories, disclaimer Controlling the system with the handheld transmitter Alarm storage Activating the panic alarm Running the system without the supply voltage Tamper protection Opening the signal contact (ventilation function) Signal transmitter battery low Changing the signal transmitter battery 1.9.1...
  • Page 3: Handling The System

    Therefore, be wise and do not leave any valuables on view or where they are easily accessible in the vehicle and do not leave the vehicle unlocked. Thitronik does not accept any liability for stolen valuables or damage to the vehicle caused by a break-in.
  • Page 4: Controlling The System With The Handheld Transmitter

    C.A.S. operating instructions Page 2 1.2 Controlling the system with the handheld transmitter  Any button arms the system. Integrated LEDs flash once and an internal buzzer* sounds once.  Any button disarms the system. Integrated LEDs flash twice and an internal buzzer* sounds twice. If the system is disarmed after an alarm event, instead of the buzzer sounding twice it gives out one long continuous sound.
  • Page 5: Tamper Protection

    C.A.S. operating instructions C.A.S. operating instructions Page 2 Page 3 1.6 Tamper protection C.A.S. has different methods of protection to prevent the system from being tampered with. 1. Stray-field protection on the wireless magnetic contacts and the cable loops When the system is activated and the contact is closed, if another magnet approaches (to bypass the contact) the main alarm is activated immediately.
  • Page 6: Changing The Signal Transmitter Battery

    C.A.S. operating instructions Page 4 1.7 “Open contact” signal (ventilation function) When locking, the interior beeper emits a series of short beeps. This means that the system has detected that one of the wireless magnetic contacts is open.  I f none of the contacts have been opened intentionally, check all the secured openings.
  • Page 7: Changing The Transmitter Battery, Handheld Transmitter

    C.A.S. operating instructions Page 5 1.9.1 Changing the handheld transmitter battery – Unscrew the 3 screws on the back of the handheld transmitter and open the casing. – Remove the printed circuit board and remove the battery. – Replace the battery with one of the same type (CR2032). –...
  • Page 8: Sequence Of A Gas Alarm (Accessory)

    C.A.S. operating instructions Page 6 1.9.5 Sequence of a gas alarm If an assigned wireless gas alarm sends out an alarm signal because a critical gas concentration has been reached, this will signal an alarm whether the system is armed or not. ...
  • Page 9: Using The Gsm/Gps Combimodule (Accessory)

    C.A.S. operating instructions Page 7 2.1 Using the GSM/GPS Combimodule (optional) If a GSM/GPS Combimodule (Item no: THA-2-00027) has been connected, there are numerous additional functions and alarm options available. – Alarm message if there is a break-in, gas or, if the cable loop is triggered, with information on the type of incident, time of incident, position and speed.
  • Page 10 C.A.S. operating instructions Page 8 2.1 Using the GSM/GPS Combimodule (optional) Activating by SMS: Send an SMS with “arm” to the number for the GSM module. After receiv- ing the SMS, the system acknowledges the process with a single flash from all 4 LEDs and a status message by SMS.
  • Page 11 C.A.S. operating instructions Page 9 2.1 Information on using the GSM/GPS Combimodule (optional) SIM card used: In order to use the GSM module, you require the SIM card of a mobile phone supplier. We recommend using a card from T-mobile or Vodafone. However, cards from other suppliers are also generally suitable.
  • Page 12 C.A.S. installation manual Page 10 Installation manual C.A.S. Please read carefully before installation...
  • Page 13: Scope Of Delivery

    C.A.S. installation manual Page 11 3.1 Scope of delivery C.A.S. base, handheld transmitter, wireless magnetic contact with 2 different self-adhesive pads, 1 x warning sticker, installation manual, PG gland, connecting cable, operating instructions 3.2 Installation instructions Since there is a risk of causing a short circuit when working on the vehicle electrical equipment, the negative pole of the battery must be disconnected if an on-board voltage supply has been installed.
  • Page 14: Storing Contacts Or Other Transmitters

    C.A.S. Installation Manual Page 12 3.6 Table 1 Program selector switch Switch Switch Switch Switch Switching Status Acoustic Visual and by phone enquiry signal acoustic call pos- for arm / alarm when sible phone disarm the supply call pos- voltage drops sible out.
  • Page 15: Diagrams

    C.A.S. Installation Manual Page 13 3.9 Diagrams Diagram 1 Diagram 2 max. 22mm GSM/GPS Combimodule (Accessories) Diagram 3 < < > > 1 2 3 4 Diagram 4...
  • Page 16: Disconnecting Contacts Or Other Transmitters

    C.A.S. installation manual Page 14 3.9.1 Disconnecting contacts or other transmitters Transmitters can only be deleted by erasing the memory.  Hold down the “RX” button on the printed circuit board (Diagram 1, Page 13) until the central unit gives out a long beep. All the transmitters are now erased. 3.9.2 Installing the wireless contacts ...
  • Page 17: Installing The Cable Loop (Accessory)

    C.A.S. installation manual Page 15 3.9.4 Installing the cable loop (accessory) C hoose a suitable place for installation at the back of the vehicle or on one of the sides. You can also obtain further holders as accessories (Item no: THA-2-00026) to use the cable loop for other areas of the vehicle. ...
  • Page 18: Connecting The Central Unit

    C.A.S. installation manual Page 16 3.9.6 Connecting the central unit  Connect the connection cable fed through the base of the central unit to the connection terminals as follows (A, Diagram 1): blue > – 12 V (Earth) brown > +12 V Now connect the end fed into the vehicle likewise to +12 V and Earth.
  • Page 19 C.A.S. installation manual Page 17 3.9.8 Programming the GSM/GPS Combimodule  O nce the SIM card has been inserted and the holder locked, briefly press the “GSM” button (D, Diagram 1) on the printed circuit board of the central unit. ...
  • Page 20: Performing An Alarm Test

    C.A.S. installation manual Page 18 3.9.9 Performing an alarm test After the central unit has been installed and connected, a test alarm should be carried out with each assigned transmitter (wireless magnet contact, cable loop and wireless gas alarm). A test alarm can only be performed with the cover closed since protect or tamper contact cannot be activated with the cover open.
  • Page 21 C.A.S. installation manual Page 19 4.1 Troubleshooting Problem: When arming the system, the signal for “contact open” sounds although all the contacts are closed. Possible causes: 1 . Transmitter and magnet are not aligned correctly. The arrows on the housing are not pointing to each other. Solution: 1.
  • Page 22 C.A.S. installation manual Page 20 4.1 Troubleshooting Problem: A contact is not being received, despite the fact that the distance to the central unit is short. Possible causes: 1. The contact is not assigned. 2. There is metal, such as a gas box etc. shielding the transmitter from the unit. Solution: 1.
  • Page 23: Technical Specifications

    C.A.S. installation manual Page 21 4.2 Technical specifications Supply voltage: 12 V Current consumption: approx. 25 mA without GSM/GPS Combimodule approx. 35 mA with GSM/GPS Combimodule Assignable transmitters max: Transmitter frequency: 433.9 MHz Transmitting power: <10 mW Range max: up to 100 m in the open Average battery life: 2 years Battery type (transmitter):...
  • Page 24 Thitronik providing solutions... Manufacturer: Thitronik GmbH Redderkoppel 5 D 24159 Kiel (Germany) web: www.thitronik.de e-mail: kontakt@thitronik.de Tel.: +49 (0)431-66 66 811 Fax: +49 (0)431-66 66 827...
