CONTACT US FIRST
CONTACT US FIRST
sauder.com
sauder.com
sauder.com
BEFORE MAKING ANY RETURNS TO THE STORE.
BEFORE MAKING ANY RETURNS TO THE RETAILER.
sauder.com/service
Visit
Prefer the phone? Give us a ring at
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Bandit Pet
Storage Cabinet
Pet Furniture Collection | Model 425667
Sauder.com
Share your journey!
to order replacement parts, view video assembly tips, or chat with a live rep.
1-800-445-1527
.
You'll love what we have in
storage.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-24
Français pg 25-28
Español pg 29-32
Lot # 541403
Purchased: __________________
2/10/20
Advertisement
Related Manuals for Sauder Bandit 425667
Summary of Contents for Sauder Bandit 425667
- Page 1 CONTACT US FIRST CONTACT US FIRST sauder.com sauder.com sauder.com BEFORE MAKING ANY RETURNS TO THE STORE. BEFORE MAKING ANY RETURNS TO THE RETAILER. sauder.com/service Visit to order replacement parts, view video assembly tips, or chat with a live rep. 1-800-445-1527 Prefer the phone? Give us a ring at Customer Service is available Monday-Friday - 9 a.m.
- Page 2 Part Identification No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identification Assembly Steps 6-24 Hammer Français 25-28 Not actual size Español 29-32 Electric drill with 1/8" or 3/8" bit Safety 33-34 (ONLY in indicated step) Warranty Page 2 www.sauder.com/service 425667...
- Page 3 TOP (1) DOOR (1) PANEL (1) BOTTOM (1) UPPER BACK (1) BOWL PLATE (1) LEFT END (1) LEFT LEG (1) BOWL PLATE BRACE (1) RIGHT END (1) BRACE (1) RIGHT LEG (1) SHELF (1) LOWER BACK (1) 425667 www.sauder.com/service Page 3...
- Page 4 ROD HANGER - 2 TIE PLATE - 1 MAGNETIC CATCH - 1 COAT HANGER - 2 BOWL - 2 ROD - 1 L-WRENCH - 1 KNOB - 1 FURNITURE TIPPING APPLIQUE CARD - 1 RESTRAINT KIT - 1 Page 4 www.sauder.com/service 425667...
- Page 5 1-9/16" HEX HEAD SCREW - 10 13/16" MACHINE SCREW - 1 BLACK 5/8" FLAT HEAD SCREW - 2 1/2" PAN HEAD SCREW - 4 SILVER 1/2" FLAT HEAD SCREW - 12 BLACK 1/2" FLAT HEAD SCREW - 10 425667 www.sauder.com/service Page 5...
- Page 6 The arrow in the HIDDEN CAM must point Arrow toward the hole in the edge of the board. Hidden Cam Hidden Cam Hole Insert the CAM SCREW or CAM DOWEL into the HIDDEN CAM. Tighten the HIDDEN CAM. Page 6 www.sauder.com/service 425667...
- Page 7 Step 1 Look for this icon. It means a video assembly tip is available at www.sauder.com/service/tips Find the numbered video or scan the QR code. å Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
- Page 8 HIDDEN CAMS. å NOTE: Be sure the WOOD DOWEL in the PANEL inserts into the hole in the BOTTOM. Groove S u r f a c i t h o u t H I D D 425667 www.sauder.com/service Page 8...
- Page 9 å Push six HIDDEN CAMS (2) all the way into the holes in the LEFT END (C) and SHELF (E). (5 used) Groove BLACK 1/2" FLAT HEAD SCREW (2 used in this step) Arrow Arrow Arrow Page 9 www.sauder.com/service 425667...
- Page 10 D E N H I D i t h f a c S u r S u r f a c H I D D E N i t h o Unfinished edge 425667 www.sauder.com/service Page 10...
- Page 11 Turn five CAM SCREWS (1) into the RIGHT END (D). å Push two HIDDEN CAMS (2) all the way into the holes in the RIGHT END (D). (5 used) BLACK 1/2" FLAT HEAD SCREW (2 used in this step) Groove Arrow Page 11 www.sauder.com/service 425667...
- Page 12 D E N H I D i t h f a c S u r I D D u t H i t h o f a c S u r These holes must be here. 425667 www.sauder.com/service Page 12...
- Page 13 ENDS (C and D) and the BOTTOM (B). Do not stand the unit upright without the å NOTE: Carefully stand your unit upright to insert the BACK fastened. The unit may collapse. BACK into the groove in the BOTTOM. Groove Page 13 www.sauder.com/service 425667...
- Page 14 Turn four CAM SCREWS (1) into the TOP (A). å Fasten the MAGNETIC CATCH to the TOP (A). Use two BLACK 5/8" FLAT HEAD SCREWS (17). Groove (4 used) BLACK 5/8" FLAT HEAD SCREW (2 used in this step) 425667 www.sauder.com/service Page 14...
- Page 15 Open the FURNITURE TIPPING RESTRAINT KIT (96) and fasten the SAFETY STRAP to the TOP (A). Use the provided short screw. å Use the FURNITURE TIPPING RESTRAINT KIT (96) for added stability. Fasten the strap to the top surface of the TOP (A) using the short screw as shown. Safety strap Groove Page 15 www.sauder.com/service 425667...
- Page 16 Fasten the LEGS (H and O) to the LOWER BACK. Use four 1/2" PAN HEAD SCREWS (19). Side Step: Make nachos. (Optional, but å NOTE: Do not completely tighten the SCREWS in this step recommended.) 1/2" PAN HEAD SCREW (4 used in this step) 425667 www.sauder.com/service Page 16...
- Page 17 LEGS (H and O). Turn eight 1-9/16" HEX HEAD SCREWS (15) a few turns using the L-WRENCH (12). å NOTE: Do not completely tighten the SCREWS in this step Middle Bar closer to this side. 1-9/16" HEX HEAD SCREW (8 used in this step) Page 17 www.sauder.com/service 425667...
- Page 18 Fasten the BRACE (J) to the LEGS (H and O). Turn two 1-9/16" HEX HEAD SCREWS (15) a few turns using the L-Wrench (12). å Completely tighten the SCREWS at this time. 1-9/16" HEX HEAD SCREW (2 used in this step) 425667 www.sauder.com/service Page 18...
- Page 19 Tighten four 2-3/8" HEX HEAD SCREWS (14) using the L-WRENCH (12). å NOTE: You should start each SCREW a few turns before completely tightening any of them. 2-3/8" HEX HEAD SCREW (4 used in this step) 425667 www.sauder.com/service Page 19...
- Page 20 Fasten two HINGES (4) to the door. Use four SILVER 1/2" FLAT HEAD SCREWS (18). BLACK 1/2" FLAT HEAD SCREW (2 used for the TIE PLATE) SILVER 1/2" FLAT HEAD SCREW (4 used for the HINGES) Page 20 www.sauder.com/service 425667...
- Page 21 Adjusting screw (horizontal) å Fasten the KNOB (11) to the DOOR (F). Use one 13/16" MACHINE SCREW (16) SILVER 1/2" FLAT HEAD SCREW (8 used for the HINGES) 13/16" MACHINE SCREW (1 used for the KNOB) Page 21 www.sauder.com/service 425667...
- Page 22 å To adjust the DOORS in or out (depth), loosen the Adjusting screw (horizontal) mounting screw one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. 425667 www.sauder.com/service Page 22...
- Page 23 BLACK 1/2" FLAT HEAD SCREWS (20). Almost time to å Place the BOWLS (7) into the slots in the BOWL PLATE (M). celebrate! With a nap. BLACK 1/2" FLAT HEAD SCREW (4 used in this step) Page 23 www.sauder.com/service 425667...
- Page 24 Step 18 å NOTE: The following instructions show your unit being fastened to a wall stud. If you are not fastening your unit to a wall stud, go to Step 19 now. å Carefully stand your unit upright against the wall in its final location. å...
- Page 25 Step 19 å -Carefully stand your unit upright against the wall in its final location. With your pencil, put a mark through the center of the hole in the SAFETY STRAP. å -Drill a 3/8" hole on the marks. å -While you squeeze the wings together, gently tap the WALL ANCHOR from the FURNITURE TIPPING RESTRAINT KIT into the hole until they are even with the surface of the wall.
- Page 26 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with a damp cloth. Wipe dry. And to celebrate, why not share your success story at sauder.com or No load Hooks 10 lbs.
- Page 27 REFERENCE DESCRIPTION QUANTITÉ REFERENCE DESCRIPTION QUANTITÉ conserver le livret pour future référence. Pour contacter Sauder en DESSUS ................1 VIS D'EXCENTRIQUE ..........16 ce qui concerne cet DESSOUS ................1 EXCENTRIQUE ESCAMOTABLE ....16 élément, faire référence EXTRÉMITÉ GAUCHE ..........1 CHEVILLE EN BOIS ...........9 au numéro de lot et...
- Page 28 REMARQUE : Ne pas complètement serrer les VIS à cette étape. GAUCHE (C). Serrer cinq EXCENTRIQUES ESCAMOTABLES. REMARQUE : S’ a ssurer de bien insérer les CHEVILLES EN BOIS dans l'EXTRÉMITÉ GAUCHE dans les trous du DESSOUS, PANNEAU et de la TABLETTE. v 425667 www.sauder.com/service Page 28...
- Page 29 PORTES vers l'intérieur ou vers l'extérieur. Serrer la vis de montage après avoir ajusté. sécurité figurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer avec un tissu humide. Essuyer. Page 29 www.sauder.com/service 425667...
- Page 30 PANEL SUPERIOR ............1 BIELA DE EXCÉNTRICO ........16 su referencia futura. Si necesita ponerse en FONDO .................1 EXCÉNTRICO ESCONDIDO ......16 contacto con Sauder en EXTREMO IZQUIERDO ..........1 PASADOR DE MADERA .........9 cuanto a esta unidad, EXTREMO DERECHO ..........1 BISAGRA ................2 refiérase al número...
- Page 31 Utilice dos TORNILLOS NEGROS DE CABEZA PERDIDA NOTA: Utilice los agujeros correspondientes indicados. de 16 mm (17). Empuje seis EXCÉNTRICOS ESCONDIDOS (2) completamente hacia abajo en los agujeros en el EXTREMO IZQUIERDO (C) y el ESTANTE (E). 425667 www.sauder.com/service Page 31...
- Page 32 Para ajustar las PUERTAS hacia atrás o hacia adelante (profundidad), afloje el tornillo de montaje una vuelta y mueva las PUERTAS hacia el interior o hacia el exterior según sea necesario. Apriete el tornillo de montaje después de hacer los ajustes. Page 32 www.sauder.com/service 425667...
- Page 33 APLICACIONES (13) y aplique las sobre cada EXCÉNTRICO ESCONDIDO visible. NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpiar con un trapo húmedo. Seque con un paño. 425667 www.sauder.com/service Page 33...
- Page 34 • La inclinación o rotura del mobiliario es • No empuje la unidad, especialmente sobre no está diseñado y provisto con ruedecitas. posible si se mueve de manera inadecuada. un piso alfombrado. • Lesión física. El mobiliario puede ser muy pesado. Page 34 www.sauder.com/service 425667...
- Page 35 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
- Page 36 BEFORE MAKING ANY RETURNS TO THE RETAILER. So, how did it go? Dear Valued Customer: Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built.
