  • Page 1 OmniAC20CAPQ Quick Start Guide Version: 1.1...
  • Page 2: Terminal Block

    Overview Near-infrared Flash Microphone Camera & Palm Collector 2.4-inch Touchscreen Doorbell Button Card Reading Speaker Terminal Block BELL+ BELL- INWD0 12VOUT INWD1 WD1-OUT WD0-OUT 485A 12VIN 485B 12VIN 12VIN...
  • Page 3: Installation Environment

    Installation Environment Please refer to the following recommendations for installation. 10ft KEEP DISTANCE AVOID GLASS AVOID DIRECT KEEP EFFECTIVE REFRACTION SUNLIGHT DISTANCE AND EXPOSURE 0.3-2.5m Recommended Palm Gestures KEEP EFFECTIVE KEEP SPACES DO NOT KEEP DISTANCE OF BETWEEN YOUR FINGERS 18 to 40 cm YOUR FINGERS CLOSE...
  • Page 4: Device Installation

    Device Installation With Backplate: Attach the mounting template sticker to the wall, and drill holes according to the mounting paper. Fix the Backplate on the wall using wall mounting screws. Attach the device to the Backplate. Fasten the device to the Backplate with a security screw. ①...
  • Page 5 With Back Cover ★: Attach the mounting template sticker to the wall, and drill holes according to the mounting paper. Fix the Back Cover on the wall using wall mounting screws. Attach the device to the Back Cover. Fasten the device to the Back Cover with a security screw. ①...
  • Page 6: Standalone Installation

    Standalone Installation Smoke Alarm Detector Door Sensor Exit Button Reader Lock TCP/IP Power Connection Recommended AC Adapter 12V ± 10%, at least 1500mA. To share the power with other devices, use an AC Adapter with higher current ratings.
  • Page 7: Ethernet Connection

    Ethernet Connection Connect the device and computer software over an Ethernet cable. As shown in the example below: Default IP address: 192.168.1.201 IP address: 192.168.1.130 Subnet mask: 255.255.255.0 Subnet mask: 255.255.255.0 Click on [COMM.] > [Ethernet] > [IP Address] , input the IP address and click on [OK]. Note: In LAN, the IP addresses of the server (PC) and the device must be in the same network segment when connecting to the software.
  • Page 8 RS485 Connection 12VOUT INWD0 INWD1 485 Reader WD1-OUT +12V WD0-OUT 485+ 485A 485- 485B Door Sensor, Exit Button, Auxiliary Connection Smoke Detector Detector Power ExitButton Door Sensor...
  • Page 9: Lock Relay Connection

    Lock Relay Connection The system supports Normally Opened Lock and Normally Closed Lock. The NO LOCK (normally unlocked when power-on) is connected with 'NO' and 'COM' terminals, and the NC LOCK (normally locked when power-on) is connected with 'NC' and 'COM' terminals. Take NC Lock as an example below: 1)Device not sharing power with the lock 2)Device sharing power with the lock...
  • Page 10: User Registration

    User Registration When there is no super administrator set in the device, click on to enter the menu. Add a new user and set User Role to Super Admin, then the system requests for the administrator’s verification before entering the menu. It is recommended to register a super administrator initially for security purposes.
  • Page 11: Ethernet Settings

    Ethernet Settings Click on > [COMM.] > [Ethernet] to set the network parameters. If the TCP/IP communication of the device is successful, the icon will be displayed in the upper right corner of the standby interface. Access Control Setting > [Access Control] to enter the access control management Click on interface and set relevant parameters of access control.
  • Page 12 Health Protection > [System] > [Health Protection] to enable mask detection. Click on When the Allow Unregistered People to Access is enabled, optionally, set Enable Capture of Unregistered Person to save the temperature data.
