- Page 1 OmniAC20 Installation Guide Version: 1.6...
-
Page 2: How To Install The Device
How to Install the Device? Installation Environment Please refer to the following recommendations for installation. 10ft KEEP DISTANCE AVOID GLASS AVOID DIRECT KEEP EFFECTIVE REFRACTION SUNLIGHT DISTANCE AND EXPOSURE 11.81 to 78.74inch (30 to 200cm) Device Installation With Backplate: Attach the mounting template sticker to the wall, and drill holes according to the mounting paper. - Page 3 With Back Cover ★: Attach the mounting template sticker to the wall, and drill holes according to the mounting paper. Fix the Back Cover on the wall using wall mounting screws. Attach the device to the Back Cover. Fasten the device to the Back Cover with a security screw. ①...
-
Page 4: Wiring Diagram
Wiring Diagram Power Connection Recommended AC Adapter 1) 12V ± 10%, at least 3A. 2) To share the power with other devices, use an AC Adapter with higher current ratings. Ethernet Connection Connect the device and computer software over an Ethernet cable. As shown in the example below: Default IP address: 192.168.1.201 IP address: 192.168.1.130... - Page 5 Wiegand & RS485 Reader Connection +12V 12V-OUT INWD1 INWD0 +12V Wiegand WD1-OUT Reader WD0-OUT 485- 485B 485+ 485A Access Controller 485 Reader Note: 485A and 485B can be connected to the Barrier gate or the 485 Reader, separately, but cannot be connected to the gate and reader at the same time.
-
Page 6: Lock Relay Connection
Lock Relay Connection The system supports Normally Opened Lock and Normally Closed Lock. The NO LOCK (normally unlocked when power-on) is connected with 'NO' and 'COM' terminals, and the NC LOCK (normally locked when power-on) is connected with 'NC' and 'COM' terminals. Take NC Lock as an example below: 1)Device not sharing power with the lock 2)Device sharing power with the lock... - Page 7 Copyright © 2025 ARMATURA LLC. All rights reserved.
