- Page 1 OmniAC20CAPQ Installation Guide Version: 1.1...
- Page 2 How to Install the Device? Installation Environment Please refer to the following recommendations for installation. 10ft KEEP DISTANCE AVOID GLASS AVOID DIRECT KEEP EFFECTIVE REFRACTION SUNLIGHT DISTANCE AND EXPOSURE 0.3-2.5m Device Installation With Backplate: Attach the mounting template sticker to the wall, and drill holes according to the mounting paper.
- Page 3 With Back Cover ★: Attach the mounting template sticker to the wall, and drill holes according to the mounting paper. Fix the Back Cover on the wall using wall mounting screws. Attach the device to the Back Cover. Fasten the device to the Back Cover with a security screw. ①...
- Page 4 Wiring Diagram Power Connection Recommended AC Adapter 1) 12V ± 10%, at least 1500mA. 2) To share the power with other devices, use an AC Adapter with higher current ratings. Ethernet Connection Connect the device and computer software over an Ethernet cable. As shown in the example below: Default IP address: 192.168.1.201 IP address: 192.168.1.130...
- Page 5 Wiegand Reader Connection +12V 12VOUT INWD0 Wiegand INWD1 Reader WD1-OUT WD0-OUT 485A Access Controller 485B Note: 485A and 485B can be connected to the Barrier gate or the 485 Reader, separately, but cannot be connected to the gate and reader at the same time.
- Page 6 Door Sensor, Exit Button, Auxiliary Connection Smoke Detector Detector Power ExitButton Door Sensor Lock Relay Connection The system supports Normally Opened Lock and Normally Closed Lock. The NO LOCK (normally unlocked when power-on) is connected with 'NO' and 'COM' terminals, and the NC LOCK (normally locked when power-on) is connected with 'NC' and 'COM' terminals.
- Page 7 Alarm Connection Alarm Power BELL+ BELL- Alarm...
