Summary of Contents for ARMATURA OmniAC30CAPQ

  • Page 1 OmniAC30CAPQ Quick Start Guide Version: 1.1...
  • Page 2: Terminal Block

    Overview Flash Near-infrared Flash Camera & Palm Collector Microphone 5-inch Touchscreen Card Reading Area Speaker Reset Button Terminal Block 12V-OUT RS232-RXD RS232-TXD 485B 485A 12V-OUT WD1-OUT WD0-OUT IWD1 IWD0 12V-OUT...
  • Page 3: Installation Environment

    Installation Environment Please refer to the following recommendations for installation. 10ft KEEP DISTANCE AVOID GLASS AVOID DIRECT KEEP EFFECTIVE REFRACTION SUNLIGHT DISTANCE AND EXPOSURE 0.3-2.5m Recommended Palm Gestures KEEP EFFECTIVE KEEP SPACES DO NOT KEEP DISTANCE OF BETWEEN YOUR FINGERS 18 to 40 cm YOUR FINGERS CLOSE...
  • Page 4: Device Installation

    Device Installation With Backplate ★: Attach the mounting template sticker to the wall, and drill holes according to the mounting paper. Fix the Backplate on the wall using wall mounting screws. Attach the device to the Backplate. Fasten the device to the Backplate with a security screw. ①...
  • Page 5 With Back Cover: Attach the mounting template sticker to the wall, and drill holes according to the mounting paper. Fix the Back Cover on the wall using wall mounting screws. Attach the device to the Back Cover. Fasten the device to the Back Cover with a security screw. ①...
  • Page 6: Standalone Installation

    Standalone Installation Smoke Alarm Detector Door Sensor Exit Button Reader Lock TCP/IP Power Connection +12V AC Adapter DC12-3A Recommended AC Adapter 12V ± 10%, at least 3000mA. To share the power with other devices, use an AC Adapter with higher current ratings.
  • Page 7: Ethernet Connection

    Ethernet Connection Connect the device and computer software over an Ethernet cable. As shown in the example below: Default IP address: 192.168.1.201 IP address: 192.168.1.130 Subnet mask: 255.255.255.0 Subnet mask: 255.255.255.0 Click on [COMM.] > [Ethernet] > [IP Address] , input the IP address and click on [OK]. Note: In LAN, the IP addresses of the server (PC) and the device must be in the same network segment when connecting to the software.
  • Page 8: Printer Connection

    Printer Connection 12V-OUT RS232-RXD RS232 Cable RS232-TXD Printer Door Sensor, Exit Button, Auxiliary Connection Detector Smoke Detector Power Door Sensor Alarm ExitButton Alarm Power...
  • Page 9: Lock Relay Connection

    Lock Relay Connection The system supports Normally Opened Lock and Normally Closed Lock. The NO LOCK (normally unlocked when power-on) is connected with 'NO' and 'COM' terminals, and the NC LOCK (normally locked when power-on) is connected with 'NC' and 'COM' terminals. Take NC Lock as an example below: 1)Device not sharing power with the lock Lock...
  • Page 10: User Registration

    User Registration When there is no super administrator set in the device, click on to enter the menu. Add a new user and set User Role to Super Admin, then the system requests for the administrator’s verification before entering the menu. It is recommended to register a super administrator initially for security purposes.
  • Page 11 Ethernet and Cloud Server Settings Click on > [COMM.] > [Ethernet] to set the network parameters. If the TCP/IP communication of the device is successful, the icon will be displayed in the upper right corner of the standby interface. Click on >...
  • Page 12: Access Control Settings

    Access Control Settings Click on > [Access Control] to enter the access control management interface and set relevant parameters of access control. Main Menu Access Control Options Access Control Access Control Options Gate Control Mode User Mgt. System User Role COMM.
  • Page 13 Health Protection > [System] > [Health Protection] to enable mask detection. Click on You can Enable Mask Detection function, and enable the Deny Access Without Mask and the Trigger External Alarm, the device will send an alarm prompt when the user doesn’t wear a mask, meanwhile the user will be for- bidden to access, as shown in the following figure.
