Bay Networks CLAM Supplementary Manual

Issue 4.0
Hide thumbs Also See for CLAM:

Advertisement

Quick Links

Download this manual See also: Reference Manual, Installation Manual
CLAM B
RIDGE
A
DDENDUM
Issue 4.0
All rights reserved. This document may not be in whole or in part copied,
photocopied, reproduced, translated or reduced to any electronic medium or machine-
readable form without the prior written permission of Bay Networks Inc.
The information contained in this manual is believed to be accurate. However, no
responsibility whatsoever is assumed by Bay Networks Inc. for its use, nor for any
infringements of patents or other rights of third parties resulting from its use.
All trade marks are acknowledged.
1996 Scorpion Logic Ltd. A Bay Networks company
ISSUE 4.0
MAN-CLAM-BRIDGE-ADDENDUM

Advertisement

loading
Need help?

Need help?

Do you have a question about the CLAM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bay Networks CLAM

Summary of Contents for Bay Networks CLAM

  • Page 1 CLAM B RIDGE DDENDUM Issue 4.0 All rights reserved. This document may not be in whole or in part copied, photocopied, reproduced, translated or reduced to any electronic medium or machine- readable form without the prior written permission of Bay Networks Inc.
  • Page 2 MAN-CLAM-BRIDGE-ADDENDUM ISSUE 4.0...
  • Page 3 The purpose of this addendum is to document the changes introduced between Release 3 and Release 4 software. This addendum should be read in conjunction with the CLAM Bridge Reference Manual Issue 3.0 to provide a full description of the configuration and operation of the CLAM Bridge.
  • Page 4 ___________________________________________________________________________________ (co po) Enter command : If a CLAM WAN is installed in the unit, it will be automatically detected and the port will be displayed in addition to any other ports on the unit. If a WAN port is available it should be configured with reference to one of the following two sections 2.1.1 HDLC P...
  • Page 5 This parameter should be set to the actual line speed at which (BITS/S) the interface is being clocked . Although the CLAM Bridge does not generate clocks this parameter is used to configure internal timers which optimise use of the link.
  • Page 6 DISABLED turns data compression off. ENABLED allows the system to use its standard bandwidth optimisation algorithm for compression. This should be used on all links up to 256Kbps. FAST should be used on links with speeds greater than 256 Kbps to maintain maximum throughput on the line. The advantage of using compression depends on the data type and line speed increases.

  • Page 7: Remote Unit Name

    EXP+BKUP means that when Demand Threshold values are met (see below), packets defined as EXPEDITEd in the Type Filter Table will be sent by the first additional link dialled up. It also allows the use of the BACKUP facility to dial the Remote Unit Name destination (see below) if the usual link fails.
  • Page 8 DEMAND Specifies the percentage loading on the link which must be THRESHOLD reached over the period of time in Demand Period (see below) before dialled-up bandwidth is requested. Each time this threshold is reached, additional bandwidth will be requested. This means that a link can request multiple connections to the same destination to add bandwidth.
  • Page 9 DEMAND Dial-up connections can be used to provide bandwidth on PRIORITY demand and backup of leased lines. This parameter determines the priority of this port when using a dial-up circuit for additional bandwidth. Should this port require the use of a backup dial-up circuit that is already in use, the Demand Priority will be compared with the priority used by the port which is already using the dial-up circuit.
  • Page 10 ROTOCOL RIORITISATION Local Area Networks can support many different types of protocols, each with different transmission characteristics and requirements. It is possible for one protocol to adversely affect other protocols on the LAN by taking too much bandwidth. This problem is made worse by inserting a remote bridge link, due to the lower speed of the link compared to the LANs at either end.
  • Page 11 the Demand Threshold, the first ISDN channel still carries EXPEDITED data, and a second ISDN channel is set up for normal data. If Backup is enabled and the leased circuit fails, the first ISDN channel is set up and initially carries both EXPEDITED and normal data. EXPEDITED data still has priority.
  • Page 12 To configure an HDLC or ISDN port for Bandwidth on Demand, use the command CONF PORT to EDIT the Demand and Threshold parameters. Use this command if Backup is needed on an HDLC port. The field Backup/Demand Mode on the form EDIT HDLC PORT has extra options, which specify if EXPEDITED or NON-expedited (normal) data will cause Bandwidth on Demand to be allocated: EXP.DATA...
  • Page 13 2.1.2 PPP P ORTS N.CLAM.mmm SYSTEM NAME ___________________________________________________________________________________ Port Number :WAN1 Port Name :PPP Link 1 STP Priority Line Speed(bits/s):2000000 ___________________________________________________________________________________ ^E - Submit ___________________________________________________________________________________ Figure 2.3 Please refer to the HDLC Ports screen and parameter descriptions above for details.
  • Page 14 RIDGE ONFIGURATION The Bridge Configuration menu is accessed by typing CO BR at the command line prompt. N.CLAM.mmm SYSTEM NAME ___________________________________________________________________________________ PARAM ADDRESS TYPE ___________________________________________________________________________________ ___________________________________________________________________________________ (co br) Enter command : Figure 2.4 The menu now has two additional menu items, these are described below: Access the Static ARP configuration form.
  • Page 15 2.2.1 G ENERAL RIDGING This configuration menu is reached by typing CO BR PAR at the command line. N.CLAM.mmm SYSTEM NAME ___________________________________________________________________________________ Ageing Time(Sec) Learning Action on Match Filter Multicast Type Matching Unmatched Type Action : Learn Src on Multicast: Learn Novell 802.3...

  • Page 16: Static Arp

    2.2.2 TATIC The Static ARP list is obtained by typing CO BR ARP at the command line prompt. N.CLAM.mmm SYSTEM NAME ___________________________________________________________________________________ IP Address MAC Address 1.1.1.1 222222222222 EDIT - Edit Entry ADD - Add Entry ___________________________________________________________________________________ ___________________________________________________________________________________ (co br arp) Enter command : Figure 2.6...

  • Page 17: Sap Filters

    2.2.3 SAP F ILTERS The SAP Filter list is obtained by typing CO BR SAP from the command line prompt. N.CLAM.mmm SYSTEM NAME ___________________________________________________________________________________ Name Server* ADD <name> - Add filter DELETE - Delete filter ___________________________________________________________________________________ ___________________________________________________________________________________ (co br sap) Enter command : Figure 2.7...
  • Page 18 DDENDUM Name The server or service for which SAP and RIP entries should be learned. The * wildcard character can be used instead of one or multiple characters in the name. The wildcard must be the last character in the name string. In the example above the entry Server* will learn all SAPs starting with the string ‘Server’...

  • Page 19: Isdn Configuration

    ISDN C ONFIGURATION The ISDN Bridge configuration menu is accessed by typing CO ISDN at the command line prompt. N.CLAM.mmm SYSTEM NAME ___________________________________________________________________________________ AUTHORISE - Remote Bridge Authorisation AUTOCALL ISDN Automatic Calls BANDS ISDN Time Bands NUMBERS ISDN Numbers ISDN Calling Line Id...
  • Page 20 2.3.1 TA L The TA list is obtained by typing CO IS TA at the command line prompt. N.CLAM.mmm SYSTEM NAME ___________________________________________________________________________________ Card Slot Type Base 1 BRIETSI EDIT - Edit Entry ___________________________________________________________________________________ ___________________________________________________________________________________ (co isdn ta) Enter command : Only PRI TAs and North American BRI TAs can be edited as other BRI TAs have no configurable parameters.
  • Page 21 DDENDUM Page 19...
  • Page 22 DDENDUM Page 20...
