- Page 1 Regina Wood Cook Stove USE AND INSTALLATION MANUAL OMNI report number: 0528WS003S LISTED TO STANDARDS: UL 1482-2011 (R2015) ULC S627-00 Cod. 90002832 Rev.1...
-
Page 2: Table Of Contents
1.FOREWORD AND MAIN FEATURES ....................3 TECHNICAL DATA COOK STOVE REGINA ........4 2. PACKAGING ............................5 3.TRANSPORT AND INSTALLATION ....................5 4.IMPORTANT INFORMATION ......................5 5.EXHAUSTS EVACUATION ......................... 7 POSITIONING AND CONNECTION TO THE FLUE ......7 FLUE AND CHIMNEY POT............... 7 PROTECTION OF THE FLOOR ............ -
Page 3: Foreword And Main Features
All local regulations, including the ones referring to national and European norms, shall be respected when installing the cook stove. Lincar cook stoves are manufactured with top-quality materials, produced with state-of-the-art techniques and technologies, and checked and controlled by specialized technicians in order to exploit at its best the energy of wood. -
Page 4: Technical Data Cook Stove Regina
Figure 1 1.1 TECHNICAL DATA COOK STOVE REGINA Height Length 1250 Depth Weight Diameter fumes exhaust 156 (6.125”) Nominal output power Performance Heating volume m³ Average consume Kg/h Maximum permitted load Kg/h Minimum draught required CO measured with 13% of oxygen at the nominal heat 0.10... -
Page 5: Packaging
2. PACKAGING The packaging of your cook stove is designed to protect it against possible damages. Nevertheless, it could happen that the cook stove and/or the accessories could have suffered from damages during transportation. We recommend checking, immediately upon delivery, for missing components or damages to the cook stove and signalling immediately any irregularity to your retailer. - Page 6 Do not start the cook stove if glasses are scratched or broken. Avoid opening the door to clean the glass while the cook stove is operating. This operation shall be done only when the cook stove is off. Hot ashes in the ash chamber shall be removed using the provided tools and stored in a well-closed clay or metal recipient.
-
Page 7: Exhausts Evacuation
5. EXHAUSTS EVACUATION The pipes for the evacuation of exhausts represent a source of danger, both for fires or the outpouring of toxic gases. Great caution shall be paid when the exhaust pipe is connected to the flue with walls or parts of them made of wood. - Page 8 A good draught can be checked by igniting a piece of paper at the base of the exhaust pipe. If the draught is good, the flame will be attracted with strength towards the inside. The cook stove is equipped with a cast-iron chimney connector. CAUTION: Flues positioned outside the house or in cold environments shall be protected and insulated.
-
Page 9: Protection Of The Floor
5.3 PROTECTION OF THE FLOOR The cook stove shall be installed on a floor having an adequate loading capacity. If not the case, proper means shall be undertaken (e.g., load distribution plate). The cook stove shall be laid on a non-flammable floor. Should the floor be made of wood or covered with carpet, a refractory support base (steel plate or similar) shall be installed so that it overlaps at least 50 cm from the opening of the door and at least 30 cm from the sides of the cook stove. -
Page 10: Combustible
The installation shall grant an easy access to the cook stove, to the exhaust pipe and to the flue for cleaning operation. Clearances may only be reduced by means approved by the regulatory authority. With these reduced clearances, this appliance takes a minimum of space where it is installed. Whether in the living room or the dining room, the cook stove will complete your decor with its originality and heating. -
Page 11: Ignition
WARNINGS: It is advised, during the first ignitions, to bring the cook stove gradually in temperature, in order to enable all components to experience a progressive temperature increase and adjustment to dilatation. A regular maintenance by a qualified technician is necessary at least once a year. A new cook stove requires the complete drying of the paint and of the metallic inner parts. -
Page 12: Air For Combustion
Figure 8 REGINA: Nominal operating conditions, to which the performances indicated for the device refer, involve primary air (1), hearth grid lever (2) and kindling valve (4) closed, secondary air (3) open by half, 3.41 kg of wood burned in 1 hour (length between 20-25 cm) and draught of the chimney flue equal to 12 Pa. -
Page 13: Maintenance
8. MAINTENANCE In order to preserve in time the efficiency of the cook stove and the integrity of the inner parts (hearth, oven), it is important to execute a correct daily and periodical maintenance. All maintenance and cleaning operations shall be executed only when the cook stove has completely cooled down. -
Page 14: Cleaning Of The Glass Of The Hearth Door
Figure 9 Access the part underneath the oven (fumes channel) removing first the soapstone 1 and then the metal plate 2 (Figure 9), and aspire the dust and residuals. Check the cleanness of the flue, intervening if necessary. Clean off soot and incrustations from the connection pipe to the flue. Reassemble the cast-iron cooking plate, taking care to position the washer correctly on the contact edge. -
Page 15: Broken Glass Replacement
8.6 BROKEN GLASS REPLACEMENT WARNING: NEVER OPERATE COOK STOVE WHEN THE GLASS IS BROKEN OR CRACKED. Replace only with a 4 mm ceramic glass with the right shape. DO NOT USE SUBTITUTE. Steps to replace glass: Loosen partially the screws retaining the four glass supports and remove the support. (On the oven door, remove the screw completely.) ... -
Page 16: Problem Solving Grid
9. PROBLEM SOLVING GRID Problem Cause Solution Either clean the flue or make it Insufficient draught longer. Regulate the air intake according to the instructions of the manual. For long periods, at the minimum, the Incorrect regulation of the air glass dirties itself more rapidly but Soot covers the glass too quickly intake... - Page 17 FURTHER CAUTIONS: DO NOT CONNECT TO OR USE IN CONJUNCTION WITH ANY AIR DISTRIBUTION DUCTWORK UNLESS SPECIFICALLY APPROVED FOR SUCH INSTALLATIONS. DO NOT USE CHEMICALS OR FLUIDS TO START THE FIRE. DO NOT BURN GARBAGE OR FLAMMABLE FLUIDS SUCH AS GASOLINE, NAPHTHA OR ENGINE OIL.
-
Page 18: Spare Parts
10. SPARE PARTS Pos. Description Pos. Description Disc-shaped grid Hearth brick 100x345 Grid holder Oven soapstone Hearth side Oven door Fumes ring Oven door washer Cooking plate frame Glass washer Ash drawer Oven door handle Wood-stopper Oven door glass Hearth door glass Oven thermometer Hearth door Protection glass... -
Page 21: Warranty
Lincar SRL is not responsible for any damage that may be directly or indirectly caused to persons, property or pets due to the failure to adhere to the instructions contained herein and listed previously. - Page 22 During this period, it is the retailer’s responsibility to store the products in suitable places and ways in order to ensure their perfect state of preservation. Warranty service operation: The request for a warranty service operation must be forwarded to the pertinent Lincar Retailer or Service Centre. Liability: Lincar does not acknowledge any compensation for direct or indirect damages caused by or depending on the product.
- Page 23 WOOD-BURNING COOK 8.5.1 CLADDING STOVE REGINA...
- Page 24 WOOD-BURNING COOK 8.5.2 INSIDE FIREPLACE STOVE REGINA AND OVEN...
- Page 25 WOOD-BURNING COOK 8.5.3 FIREPLACE STOVE REGINA DOOR...
- Page 26 WOOD-BURNING COOK 8.5.4 OVEN DOOR STOVE REGINA...
- Page 27 WOOD-BURNING COOK 8.5.5 SPARE PARTS STOVE REGINA LIST NAME CODE PAGE FLUE RING 1610100211 5 REAR SHELF 00204385 7 NUT 1610800207 FRONT BANISTER 1611801152 9 SIDE BANISTER 1610801149 10 SPACER FOR BANISTER 1610801146 11 STAINLESS STEEL PLATE FRAME 1610204384 15 GRILL...
-
Page 28: Notes
CORISIT SRL, Via E Fermi 5, Reggiolo (RE) 42046 Italy T. +39 0522 972260 info@corisit.com www.corisit.com...
