- Page 1 Residential space heating appliances f ired by: Wood Mod. 135GN Mod. 145GN USING INSTRUCTIONS AND MAI NTENANCE Equipments built in conformity with European Norms for marking Cod. 90003018 Rev. 2 1/20...
-
Page 2: Table Of Contents
135GN-145GN GB Dear Customer, While we thank you for the preference you granted us, we remind you to read carefully the present handbook because it gives You important warnings with particular attention to the installation, utilization, maintenance and to the security of the product in addition to condition of guarantee . -
Page 3: Installation
135GN-145GN GB 1 INS TALLATION RES ERVED TO INS TALLER 1.1 Normative and prescriptions • Read carefully the contents of this handbook, it contains important information and instructions for installation, use, maintenance and product safety. • The appliance must be installed inside an environment considered suitable for installation and use by competent authorities. - Page 4 135GN-145GN GB SECURITY DISTANCES • From flammable object : − A > 400 mm B > 175 mm C > 200 mm • From flammable object and from principal wall in rein forced concrete : − A > 800 mm B >350 mm...
-
Page 5: Connection
135GN-145GN GB 1.4 Connection • Before connection check technical data reported in the technical plate ( Chap. 4 ) and control that it correspond to the ones required in the order. • All heating biomass equipment especially wood appliance has to evacuate the combustion products in a flue built in conformity with normative in force. - Page 6 135GN-145GN GB CHIMNEY OR FLUE • The chimney or flue should have the following characteristics: − It’ s advisable read, follow and respect what indicated in the paragraphe 1.1 − Good sel of combustion products, impermeable and completely insulated as normative condiction −...
- Page 7 135GN-145GN GB Inclination Roof Re Flux Area Highness Z ( m) C (°) 1,85 1,00 0,50 1,50 1,30 0,80 1,30 2,00 1,50 1,20 2,50 2,10 Re-flux Chimney pot area wind damping Chimney Revolving P ot Wind chimney pot for strong...
- Page 8 135GN-145GN GB CONNECTION TO FLUE • The connect the heating equipment to the flue / chimney checking that the exhaust pipe don’t take up the free section of flue. • Employ only tubes supplied by seal gasket. • To not use horizontal tubes ( max 1 meter ) and curves.
-
Page 9: Technical Details
135GN-145GN GB 1.5 Technical Details Description Mod. 135GN 145GN Width Depth Height Appliance weight Exhaust Fume Ø Max. termic power output 11.0 Nominal heat output Emissions of CO : (to 13% O2) 0.330 0.320 Efficiency : 68.0 73.0 Heating volume (favourable insulation) -
Page 10: Using
135GN-145GN GB 2 US ING - RES ERVED TO US ER 2.1 Important warnings • To read carefully this section’s instruction which are very important for use, maintenance and appliance safety. • This handbook has to be ridden completely, in case of lack it can be consider an improper use of the equipment so a not right use of it. -
Page 11: Starting
135GN-145GN GB 2.3 Starting • The appliance should set at work only after having completed the following operations: complete assembling, connection to exhaust fumes duct and to the heating plant. A new appliance needs to complete the drying process of the paint. During the first heatings you can notice the following situations: - During the first ignitions the appliance may exhale bad smell. - Page 12 135GN-145GN GB LOADING - TO RESTART WITH EMB ERS ( Moderates flames ) In case of starting with embers, go on as follows : • Thicken the embers on centre foyer . • Open totally the prime air and the fumes valve •...
- Page 13 135GN-145GN GB PRIME AIR VALVE Fig.5 The equipment is supplies by a regulation prime air, placed in the back part of the equipment. P lease use the poker in equipment. Prime Air Valve Fig. 5 Closed Open FUMES VALVE Fig.6...
- Page 14 135GN-145GN GB REGULATIONS • For a good compromise between the best heating performance and the fuel consumption, we recommend the following regulations : during the normal functioning phase, the fire intensity regulation can be regulated with the prime air flask and the fumes valve.
-
Page 15: Maintenance And Cleaning
135GN-145GN GB 3 MAINTENANCE AND CLEANING RESERVED TO USER Important warnings • Every maintenance and cleaning operations must be done when the appliance is light off and cold. • The appliance conditions must be checked by our qualify staff. - Page 16 135GN-145GN GB clean Components to Plate Small plate Oven plane Fig.7 • Successively with appropriate equipments (brush, shovel, exhaust fan,…) You must to remove the deposited bunching. After to have executed the cleaning, reassemble the pieces to execute a correct assemblage of the parts.
-
Page 17: Extraordinary Maintenance
135GN-145GN GB 3.2 Extraordinary maintenance (to be carried out by qualified staff only) • At least once a year a general control on the appliance should be effected by a specialized technician. • It is advisable that every year a specialized after-sales service effects the following maintenance operations: −... -
Page 18: Possible Failure And Its Solution
Every intervention has be done from qualify staff ! Lincar S.p.A is not responsible for damages to thing or people due to a wrong installation, equipment tampering, improper use, bad maintenance or no observation of normative in force. - Page 19 135GN-145GN GB Note:_______________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ 19/20...
-
Page 20: Technical Data Plate
135GN-145GN GB 4 Technical data plate. You find here enclosed a copy of technical data plate Lincar S.p.A. Via E. Fermi, 5 – 42046 Reggiolo (RE) – Italy – Tel. +39 0522 972260 – Fax +39 0522 973625 www.lincar.it info@lincar.it...
