- Page 1 Instruction and Maintenance Handbook Trike type : Pixel 303 XC 615 Route de l’Aérodrome, 07200 Lanas, France Téléphone: +33 (0)4 75 93 66 66 • Fax: +33 (0)4 75 35 04 03 • info@aircreation.fr http://www.aircreation.fr GDMANPixel303-1F Version 0010...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ..............2 Amendment Record Sheet ............ 4 Table of Amendments ................4 Amendments ..................4 General..................5 About this Document ................5 Drawings ....................6 Figure 3-1 : Pixel 303 in 3 Perspectives ..................6 Technical specifications –... - Page 3 Emergency procedures ..............13 5.9.1 Power failure on take-off ..................13 5.9.2 Power failure at altitude ..................13 5.9.3 Restart the engine in flight ..................14 5.9.4 Engine fire ......................14 5.10 Options ....................14 5.10.1 Parachute ......................14 5.10.2 Radio KRT 2 + antenna ..................15 5.10.3 Radio Icom A25 + antenna ...................15 5.10.4...
-
Page 4: Amendment Record Sheet
Amendment Record Sheet Table of Amendments Review Date Comment Section 0010 09-2021 Reference document Amendments The information in this manual is based on the data that was available at the time of its publication. The latest amendments to this manual will be issued on the Air Création website (http://www.aircreation.fr) in PDF format. -
Page 5: General
General About this Document This manual is a legal document which is approved for use with Air Creation Pixel 303 trike. It must be used in conjunction with the particular wing’s operating handbook and the Polini THOR 303 Owner’s Manual. -
Page 6: Drawings
Drawings Figure 3-1 : Pixel 303 in 3 Perspectives GDMANPixel303-1F Version 0010... -
Page 7: Technical Specifications - Performance
Technical specifications – Performance Performance Propeller Helix H40F 1,5 m E-Props 1,5 m R-GMZ-08-2 R-1300-PROP-150B 65 kg – 143 lbs 65 kg – 143 lbs Empty weight (standard) Maximum empty weight with iFun 13 140,5 kg – 310 lbs 140,5 kg – 310 lbs wing (SP) Maximum take-off weight with iFun 13 230 kg –... -
Page 8: Instructions For Use
Instructions for use Adapting Wings & Trikes The Pixel trike is designed to be used with the single-seater wing iFun 13 and SP version of our production. To install a wing of another brand, check all parameters (height, displacement of the control bar, propeller clearance with keel end) and make sure that there is at least 10cm clearance between the propeller and the wing structure, in all possible angles of attack and angles of bank with the hang point in its most forward position. -
Page 9: Setting & Function Of Controls
Setting & Function of Controls 5.3.1 Throttle The primary throttle control is a foot throttle which is connected to the right foot pedal. This is activated by pressing the foot pedal. The power of the engine increases when you push the top of the right pedal forward. In the XC version, there is also an additional hand throttle which is located on the right side of the instrument panel. -
Page 10: Baggage Storage
5.4.3 Baggage Storage Luggage can be stored in the following locations: • The bag in front of the pilot, under his legs. Its maximum load is 3 Kg. • The removable bag behind the seat. Its maximum load is 9 Kg. The weight of the baggage shall be taken into account for the calculation of the mass of the aircraft before take-off. -
Page 11: Boarding
Boarding 5.6.1 General A protective helmet must always be worn, fit correctly and secured. Check that you don’t have any objects that can fall out of your pockets during flight. Ensure articles of clothing, such as gloves, scarves, glasses/sun-glasses, as well as cameras, maps, knee boards, portable navigation instruments etc. -
Page 12: Flight
Prior to Take-Off Your ultralight must be in good flight condition, that is to say maintained and used as prescribed by Air Creation. Fasten the belt in the manner of an automobile belt and check for correct engagement. Safety belts should be placed at hip level and tightened correctly. Safety belts fastened at abdominal level may cause internal injury in the event of a violent shock. -
Page 13: Landing
To avoid permanent pressure on the right foot throttle, push the hand lever on the right of the control panel until it resists, then release the pedal. To return to pedal control, press the pedal until it resists, then pull back the lever. Checking the fuel level is done by looking in the rear view mirror located on the left side of the landing gear (right in the US). -
Page 14: Restart The Engine In Flight
5.9.3 Restart the engine in flight Activate the electric starter with the key (if installed) or pull the handle of the manual starter placed on the upper beam. Adjust the throttle. Restarting in flight may be hazardous. Keep enough altitude and stay close to a landing field. -
Page 15: Radio Krt 2 + Antenna
The parachute does not change the flight behavior of the aircraft but its weight reduces the useful load by 4 kg (9 lbs). The maximum weight for which the parachute has been tested is 220 kg (489 lbs) at a speed of 130 km / h. 5.10.2 Radio KRT 2 + antenna This option allows the pilot to communicate with the outside environment. -
Page 16: Maintenance
Maintenance Transport Trikes should preferably be transported on light trailers (please consult us for further details). Storage The trike unit should be thoroughly checked and cleaned prior to storage. After cleaning, wipe all components with a clean lightly oiled cloth, while avoiding joints and rubberized parts. -
Page 17: Trike Maintenance Schedule
6.4.1 Trike Maintenance Schedule Hours of Operation Item Maintenance Requirement 125 150 175 225 250 275 1 yr 2 yrs 3 yrs All structural members and welds for cracks, dents, corrosion or deformation All fasteners for security, condition or fretting All rig/unfix connectors, rings and clips Upper beam hang point area for condition Hang bolt... -
Page 18: Powerplant Maintenance Schedule
6.4.2 Powerplant Maintenance Schedule The following engine maintenance schedules are of a general overview nature. The Polini engine Maintenance Manual should be used for specific maintenance required for the engine. Disconnect spark plug leads prior to all maintenance and inspection. Hours of Operation Item Maintenance Requirement... - Page 19 PERIODICAL OVERHAUL BOARD Serial number : Company which has carried Date Hours flown Interventions out the overhaul address and stamp Coordonnées et cachet GDMANPixel303-1F Version 0010...
- Page 20 PERIODICAL OVERHAUL BOARD Sérial number : Company which has carried Date Hours flown Interventions out the overhaul address and stamp Coordonnées et cachet GDMANPixel303-1F Version 0010...
-
Page 21: Appendix
Appendix Trike – Quality Form Anxious to ensure the perfection of our products, we have set up a sequence of controls covering all steps of production. We are continuously working on their improvement and we are in need of your help. Please return this reply form accurately filled in if you find any issues or problems concerning your trike that could affect its quality or finish, even if it is a minor matter. - Page 22 615 Route de l’Aérodrome, 07200 Lanas, France Téléphone: +33 (0)4 75 93 66 66 • Fax: +33 (0)4 75 35 04 03 • info@aircreation.fr http://www.aircreation.fr GDMANPixel-1G Version 0050...
